IEI Technology KINO-780EB Manual de usuario

Mini-ITX SBC with AMD® ASB1 (BGA) processors, VGA/HDMI/LVDS,

PCIe GbE, USB2.0, SATAII

KINO-780EB

Quick Installation Guide

Version 1.0

Mar. 22, 2010

Package Contents

KINO-780EB package includes the following items:

z1 x KINO-780EB Single Board Computer

z1 x RS-232 cable with bracket

z1 x KB/MS Y cable

z2 x SATA with 5V power cable kits

z1 x Audio cable

z1 x I/O shielding

z1 x Mini Jumper Pack

z1 x Utility CD

z1 x QIG(Quick Installation Guide)

Specifications

zCPU :

AMD® Dual core L325 1.5GHz ASB1 (BGA) processor (for

KINO-780EB-L325-R10)

AMD® Single core 210U 1.5GHz ASB1 (BGA) processor (for

KINO-780EB-210U-R10)

zSystem Chipset : AMD RS780E + SB710

zBIOS : AMI BIOS

zSystem Memory :

Two 200-pin 667MHz Dual Channel DDR2 SDRAM SO-DIMM

supported (system max. 4GB for KINO-780EB-L325-R10)

One 200-pin 667MHz Single Channel DDR2 SDRAM SO-DIMM

supported (system max. 2GB for KINO-780EB-210U-R10)

zEthernet : One Realtek RTL8111CP GbE Controller(PCIe x1 Interface)

zI/O Interface :

1 x RS-232/422/485

1 x RS-232

8 x USB 2.0 (2 on rear side, 6 on board by pin header)

4 x SATA II (with 2 x SATA power connector)

1 x PS/2 for KB/MS

1 x CF type II (Optional)

zDisplay Interface :

ATI Radeon HD3200 Graphic core for DX10 support

VGA integrated in the AMD® RS780E (Max. resolution 2560x1600

@32bpp)

HDMI resolution up to 1080p integrated in the AMD® RS780E

18/24bit dual-channel LVDS

zExpansions :

1 x PCI Slot

1 x PCIe mini card slot (PCIe x1 + USB Signal)

zInfrared Interface: 1x Infrared Interface by super I/O ITE IT8718F

zTPM: 2x10-pin pin-header for TPM Module

zDigital I/O :

8-bit digital I/O, 4-bit input / 4-bit output

zSuper I/O : ITE IT8718F

zAudio: Realtek ALC888 HD Audio codec with S/P DIF

zWatchdog Timer :

Software Programmable support 1~255 sec. System reset by Super

I/O: ITE IT8718F

zPower Supply :

Single voltage 12V input

1 x external 4-pin DIN DC jack

1 x internal 4-pin (2x2) power connector

zPower Consumption :

3.49A@12V (AMD® Dual core L325 1.5GHz ASB1 processors with two

2GB 667MHz DDR2)

zTemperature : Operation: 0°C ~ 60°C (32°F ~ 140°F)

zHumidity : Operation: 5% ~95% non-condensing

zDimensions : 170mm x 170mm

zWeight : GW: 1000g / NW: 370 g

Ordering Information

KINO-780EB-L325-R10 :

Mini-ITX SBC with AMD® Dual core L325 1.5GHz processors,

VGA/HDMI/LVDS, PCIe GbE, USB2.0, SATAII

KINO-780EB-210U-R10:

Mini-ITX SBC with AMD® Single core 210U 1.5GHz processors,

VGA/HDMI/LVDS, PCIe GbE, USB2.0, SATAII

32100-088600-RS/ 32102-000100-RS/ 32102-000100-200-RS :

SATA Power cable

32100-192900-RS: One 4-pin (2 x 2) to one 4-pin (1x4) DC power cable with

terminal block

32200-026500-RS: RS-232/422/485 cable

CB-USB02-RS:Dual ports USB cable with bracket

TPM-IN01-R10:

Infineon 20-pin Trusted Platform Module with SW Management Tool

TPM-WI01-R10:

Winbond 20-pin Trusted Platform Module with SW Management Tool

WMPCIE-V01-R10: 802.11b+g PCIe mini card wireless LAN module with

Atheros

WMUSB-V01-R10: 802.11b+g USB embedded module with VIA

63000-FSP0601AD101C746-RS: 60W/12V Power Adaptor 90VAC~260VAC,

DIN 4 PIN

Jumpers Setting

LABEL FUNCTION

J_CMOS1 Clear CMOS Setup

JP3 AT/ATX Power Mode Setting

JP4 LCD Back Light Voltage Level Selection

JP5 LCD Voltage Selection

UART _SEL1 COM2 RS232 or RS-422 or RS-485 Type Select

JP1 LVDS1 Panel Resolution type select

J_CMOS1: Clear CMOS Setup

CLR_CMOS1 DESCRIPTION

Short 1-2

(default) Keep CMOS Setup

(Normal Operation)

Short 2-3 Clear CMOS Setup

JP4: LCD Back Light Voltage Level Selection

JP4 DESCRIPTION

1-2

(default) +5V LVDS

2-3 +3.3V LVDS

JP3: AT/ATX Power Mode Setting

JP3 DESCRIPTION

Short 1-2

(default) ATX Power Mode

Open AT Power Mode

JP5: LCD Voltage Selection

JP5 DESCRIPTION

1-2

(default) +3.3V

3-4 +5V

5-6 +12V

UART_SEL1: COM1 RS232 or RS-422 or RS-485

Type Select

UART _SEL1 DESCRIPTION

1-2

(default) RS-232

3-4 RS-422

5-6 RS-485

7-8

9-10 RS-485 with RTS Control

JP1: LVDS1 Panel Resolution type

select

Default: Disable LVDS Panel Resolution

7-8 5-6 3-4 1-2

Open Open Open Open 640x480 18-bit

Open Open Open Short 800X600 18-bit

Open Open Short Open 1024X768 18-bit

Open Open Short Short 1024x768 24-bit

Short Open Open Open 1366x768 24-bit

Open Short Open Short 1280x1024 48-bit

Short Open Open Short 1680x1050 48-bit

Open Short Short Open 1920x1080 48-bit

Open Short Short Short 1920x1200 48-bit

Table of Connectors

LABEL FUNCTION

VGA1 VGA 15-pin Female Connector

USB1 External 2 Ports USB Connector

LAN1 RJ-45 LAN Connector

S_ATA1

S_ATA2

S_ATA3

S_ATA4

Serial ATA Connectors

SATA_POWER1

SATA_POWER2 Serial ATA Power Output Connectors

COM1 Internal Serial Port Connector (RS-232/422/485)

COM2 Internal Serial Port Connector (RS-232)

USB2

USB3

USB4 Internal 2 Ports USB Connectors

FRONT-PANEL1 Audio Connector

SPEAKOUT1 External Audio Line-out Connector

SPDIF1 SPDIF Connector

CPU_FAN1 CPU Fan Connector

SYS_FAN1 System Fan Connector

BAT1 +3V Battery Connector

LVDS1 24-bit dual-channel LVDS Panel Connector

INVERTER1 LVDS1 Panel Backlight +12V Main Power Source

connector

PWR1 Adapter DC +12V Main Power Input connector

PWR2 Power Supply DC +12V Main Power Input Connector

JSPI1 Flash BIOS SPI ROM Connector

DIO1 Digital I/O Connector

F_APNEL1 Power button, Rest, HDD & Power LED Indicators

Connector

KB/MS1 PS/2 Keyboard & Mouse Connector

HDMI1 HDMI Connector

MINI-PCIE1 PCIe Mini Card Slot

CF1 CF Card Slot (Optional)

IR1 Infrared Interface connector

PCI1 PCI slot

DIMM1

DIMM2 DDR2 SO-DIMM slot

VGA1: 15-pin Female Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 RED 2 GREEN

3 BLUE 4 NC

5 GND 6 CRT_PLUG#

7 GND 8 GND

9 VCC (+5V) 10 GND

11 NC 12 DDCDAT

13 HSYNC 14 VSYNC

15 DDCCLK

USB1: External 2 ports USB Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 VCC (+5V) 5 VCC (+5V)

2 DATA- 6 DATA-

3 DATA+ 7 DATA+

4 GND 8 GND

LAN1: RJ-45 LAN Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 MDIA3- 5 MDIA1+

2 MDIA3+ 6 MDIA2+-

3. MDIA2- 7 MDIA0-

4. MDIA1- 8 MDIA0+

S_ATA1, S_ATA2, S_ATA3, S_ATA4: Serial ATA Connectors

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 GND 5 RX-

2 TX+ 6 RX+

3. TX- 7 GND

4. GND 8 N/C

SATA_POWER1, SATA_POWER2: Serial ATA Power Output

Connectors

PIN NO. DESCRIPTION

1 +12V

2 GND

3 GND

4 +5V

COM1 : Internal Serial Port Connector (RS-232/422/485)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 DATA CARRIER

DETECT (DCD#) 2 DATA SET READY

(DSR#)

3 RECEIVE DATA

(RXD) 4 REQUEST TO SEND

(RTS#)

5 TRANSMIT DATA

(TXD) 6 CLEAR TO SEND

(CTS#)

7 DATA TERMINAL

READY (DTR#) 8 RING INDICATOR

(RI#)

9 GND 10 GND

11 TXD485+ 12 TXD485#

13 RXD485+ 14 RXD485#

USB2, USB3, USB4: Internal 2 ports USB Connectors

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 VCC (+5V) 2 GND

3 DATA- 4 DATA+

5 DATA+ 6 DATA-

7 GND 8 VCC (+5V)

FRONT-PANEL1 : Audio Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 LINE_OUTR 2 LINEIN_R

3 GND 4 GND

5 LINE_OUTL 6 LINEIN_L

7 GND 8 GND

9 MICIN-R 10 MICIN-L

COM2 : Internal Serial Port Connectors (RS-232)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 DATA CARRIER DETECT

(DCD#) 2 DATA SET READY

(DSR#)

3 RECEIVE DATA (RXD) 4 REQUEST TO SEND

(RTS#)

5 TRANSMIT DATA (TXD) 6 CLEAR TO SEND

(CTS#)

7 DATA TERMINAL READY

(DTR#) 8 RING INDICATOR (RI#)

9 GND 10 GND

BAT1: +3V Battery Connector

PIN NO. DESCRIPTION

1 BAT (+3.3V)

2 GND

SPEAKOUT1 : External Audio Line-out Connector

PIN NO. DESCRIPTION

1 Line-Out

SPDIF1 : SPDIF Connector

PIN NO. DESCRIPTION

1 +5V

2 N/C

3 SPDIF_OUT

4 GND

5 SPDIF_IN

CPU_FAN1, SYS_FAN1 : Fan Connector

PIN NO. DESCRIPTION

1 GND

2 +12V

3 Rotation Signal

TPM1: Trusted Platform Module connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 FWHPCLK 2 GND

3 LFRAME# 4 N/C

5 PCIRST# 6 VCC (+5V)

7 LAD3 8 LAD2

9 VCC (+3.3V) 10 LAD1

11 LAD0 12 GND

13 SMBCLK 14 SMBDATA

15 +3.3VDUAL 16 SERIRQ

17 GND 18 CLKRUN#

19 LPCPD# 20 LDRQ#

LVDS1: 24-bit dual-channel LVDS Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 GND 2 GND

3 A_Y0 4 A_Y0#

5 A_Y1 6 A_Y1#

7 A_Y2 8 A_Y2#

9 A_CK 10 A_CK#

11 A_Y3 12 A_Y3#

13 GND 14 GND

15 B_Y0 16 B_Y0#

17 B_Y1 18 B_Y1#

19 B_Y2 20 B_Y2#

21 B_CK 22 B_CK#

23 B_Y3 24 B_Y3#

25 GND 26 GND

27 VCC_LCD 28 VCC_LCD

29 VCC_LCD 30 VCC_LCD

INVERTER1: LVDS1 Panel Backlight +12V Power Source connector

PIN NO. DESCRIPTION

1 LCD_BKLTCTL

2 GND

3 +12V

4 GND

5 BACKLIGHT ENABLE

PWR1: Adapter DC +12V Main Power Input connector

CN7 DESCRIPTION

1 +12V

2 GND

3 +12V

4 GND

5 GND

PWR2: Power Supply DC +12V Main Power Input Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 GND 2 GND

3 +12V 8 +12V

Tabla de contenidos

Otros manuales de Computadora de placa única de IEI Technology

IEI Technology

IEI Technology KINO-TGL-U Manual de usuario

IEI Technology

IEI Technology HPCIE-Q470 Manual de usuario

IEI Technology

IEI Technology IMBA-H420 Manual de usuario

IEI Technology

IEI Technology HYPER-AL Manual de usuario

IEI Technology

IEI Technology KINO-KX Manual de usuario

IEI Technology

IEI Technology ICE-BDE-T7 Manual de usuario

IEI Technology

IEI Technology WAFER-PV-D4252 Manual de usuario

IEI Technology

IEI Technology WAFER-945GSE3 Manual de usuario

IEI Technology

IEI Technology WAFER-EHL-J6412 Manual de usuario

IEI Technology

IEI Technology PCIE-690AM2 Manual de usuario

IEI Technology

IEI Technology SPCIE-C236 Manual de usuario

IEI Technology

IEI Technology IMBA-8650 Manual de usuario

IEI Technology

IEI Technology gKINO-DMF Series Manual de usuario

IEI Technology

IEI Technology ROCKY-4786 Manual de usuario

IEI Technology

IEI Technology NANO-945GSE Manual de usuario

IEI Technology

IEI Technology Rocky-3702EV Manual de usuario

IEI Technology

IEI Technology KINO-DQM871-i1 Manual de usuario

IEI Technology

IEI Technology ICE-BDE-T7 Manual de usuario

IEI Technology

IEI Technology PCIE-690S1 Manual de usuario

IEI Technology

IEI Technology DRPC-124-EHL Series Manual de usuario

IEI Technology

IEI Technology KINO-QM770 Manual de usuario

IEI Technology

IEI Technology ROCKY-558EV Manual de usuario

IEI Technology

IEI Technology WAFER-JL-N5105 Manual de usuario

IEI Technology

IEI Technology PICOe-6612 Series Manual de usuario

Manuales populares de Computadora de placa única de otras marcas

WIN Enterprises

WIN Enterprises PL-80910 Manual de usuario

AXIOMTEK

AXIOMTEK SBC81206 Series Manual de usuario

Embest

Embest SOM-PH8800 Manual de usuario

SeaLevel

SeaLevel SBC-R9 Manual de usuario

SMART Embedded Computing

SMART Embedded Computing ATCA-8310 Manual de usuario

WinSystems

WinSystems PPM-LX800-G Manual de usuario

GIGAIPC

GIGAIPC QBiX-PPC Series Manual de usuario

OLIMEX

OLIMEX A10S-OLinuXino-MICRO Manual de usuario

Commell

Commell FS-978 Manual de usuario

GIGAIPC

GIGAIPC QBiP-8665A/ Manual de usuario

VersaLogic

VersaLogic Python EBX-11 Manual de usuario

Micro Computer Specialists

Micro Computer Specialists IRV-3702 Manual de usuario

CompuLab

CompuLab SB-A510 Manual de usuario

Boser

Boser HS-7321 Manual de usuario

Premier Farnell

Premier Farnell Embest SBC8530 Manual de usuario

MicroSys Electronics

MicroSys Electronics miriac SBC-LS1043A2 Manual de usuario

Aaeon

Aaeon UP Manual de usuario

Portwell

Portwell WUX Series Manual de usuario
