VP3300 OEM User Manual

80149509-002 Rev. G

3 November 2020

ID TECH VP3300 OEM User Manual

Page | 2

ID TECH

10721 Walker Street

Cypress, CA 90630 USA

This document,as well as the software and hardware described init, is furnished under license and

maybe used or copied online in accordance with the terms of such license. The content of this

document is furnished for information use only, is subject to change without notice, and should not

be construedasa commitmentbyIDTECH. While everyeffort hasbeen made to ensure the accuracy

of the information provided,ID TECH assumes no responsibility or liability for any unintentionalerrors

or inaccuraciesthat may appear in this document. Except as permitted by such license, no part of this

publication may be reproduced or transmitted by electronic,mechanical, recording, or otherwise, or

translated into any language form without the express written consent of ID TECH.

ID TECH and ViVOpayare trademarks or registered trademarks of ID TECH.

Warranty Disclaimer

The servicesandhardware are provided "asis" and"as-available" and the use of the services and

hardware are at its own risk. ID TECH does not make,and herebydisclaims,anyand all otherexpress

or implied warranties, including, but not limited to, warranties of merchantability, fitness for a

particularpurpose,title, and anywarrantiesarising from a course of dealing,usage,or trade practice.

ID TECH does not warrant that the services or hardware will be uninterrupted, error-free, or

completelysecure.

ID TECH VP3300 OEM User Manual

Page | 3

FCC Regulatory Compliance

This device complies withPart 15 of the FCC Rules:

•This device may not cause harmfulinterference,and

•This device mustacceptanyinterferencereceived,including interferencethatmaycause

undesiredoperationof the device.

Notices: Class B Equipment

This equipment has been tested and found to comply with the limits for a Class B digital device

pursuant to Part15 of the FCC Rules.These limits are designedto provide reasonable protection

against harmfulinterference in a residentialinstallation. This equipment generates, uses,and can

radiate radio frequencyenergyand, if not installed and used in accordance with the instructions, may

cause harmfulinterferenceto radiocommunications.However,there is no guarantee that

interference will not occur in a particular installation.

This device complies withpart 15 of the FCC rules. Operationissubjectto two conditions:

This device maynotcause harmfulinterference,and(2) this device mustacceptanyinterference

received,including interference that maycause undesiredoperation.

If this equipment does cause harmfulinterference to radio or television reception, which can be

determinedbyturning the equipmentoffand on, the useris encouraged totryto correctthe

interference byone or more ofthe following measures:

•Reorientor relocate the receivingantenna.

•Increase the separationbetween the equipmentand the receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to the VP3300 OEM not expresslyapproved byID TECHcould void the

user's authority to operate the device.

Cautions and Warnings

Warning: Avoid close proximity to radio transmitters, which may reduce the capabilities of

the reader.

ID TECH VP3300 OEM User Manual

Page | 4

Table of Contents

1. INT ROD UCTION ..........................................................................................................................................................................5

1.1. Major VP3300 OEM Features......................................................................................................................................5

1.2. Magnetic Stripe Features..............................................................................................................................................5

1.3. ICC Contact Card Features............................................................................................................................................6

1.4. Contactless (NFC) Features ..........................................................................................................................................6

1.5. Other Agency Approvals and Compliances ...............................................................................................................6

2. PHYS ICAL SP EC IFICAT IONS .....................................................................................................................................................7

2.1. Electrical Power...............................................................................................................................................................7

2.2. Available Interfaces........................................................................................................................................................7

3. DESIGN GUIDELINES .................................................................................................................................................................8

4. INSTALLATION AND USE GUIDE FOR MAGNETIC HEADS................................................................................................9

4.1. Track Locations................................................................................................................................................................9

4.2. Reference Surface/Wear-Plate .................................................................................................................................10

4.3. Card Reader Rails/Slot and Magnetic Head Protrusion.......................................................................................11

5. BEFORE USING THE VP3300 OEM ......................................................................................................................................13

6. LED STATUS AND AUDIBLE BEEPER INDICATORS ..........................................................................................................13

7. WHAT KIND OF USB CABLE TO USE WITH A VP3300 ....................................................................................................13

8. FOR SOFTWARE DEVELOPERS: SOFTWARE DEVELOPMENT SUPPORT ..................................................................14

8.1. Best Practices for VP3300 OEM Developers .........................................................................................................14

9. USDK DEMO APP......................................................................................................................................................................15

10. FOR MORE INFORMATION..................................................................................................................................................16

ID TECH VP3300 OEM User Manual

Page | 5

1. Introduction

VP3300 OEM is ID TECH's ultra-compact,EMV L1/L2-certified 3-way(MSR,contactEMV,and

contactless)card reader, based on the VP3300-series design, butwith card-reader componentry

externalized to allow custom placement of the chip card slot andthe magnetic stripe readhead

within a customer-designed chassis.

The VP3300 OEM is built to optimize cost, high reliability, and maximum compatibility with existing

contactless paymenttechnologies (including Apple Pay,Android Pay, and Samsung Pay).

The VP3300 OEM incorporates the proven ID TECH Common Contact EMV L2 kernelthat is also

found in ID TECH's popularUniPayIII card reader. Developers can integrate VP3300OEM into

terminalsystems with minimaleffort using ID TECH's UniversalSDK,available for Windows, Android,

or iOS.

1.1. Major VP3300 OEM Features

•Micro-USB port for communications and power

•Magnetic stripe support: ISO 7810/ISO 7811, Hi-Co+Lo-Co Magnetic, JIS1/JIS2

•MSR is bidirectional,reading up to 3 tracksof data atonce

•ICC support: EMV Level 1 and EMV L2 approvals. All L1 & L2 on the device

•Contactless transaction support via Near Field Communication (NFC)

•LED status indicator

•Audio feedback

•Field upgradable firmware

•Standbymode for low power consumption

•Compactand ergonomic design to integrate with a variety of devices

•Available with a sturdy stand, for tabletop use

•TDES and AES 128 encryption support

•DUKPTkeymanagement

•Software DevelopmentKits for Windows, Android, and iOS

•One-year manufacturer's warranty

•Supports 16 contact and 16 contactless AIDs, for a total of 32 AIDs

1.2. Magnetic Stripe Features

•ISO 7810 / ISO 7811

•AAMVA format

•JIS I / II

•Single / Dual / Triple Track Support

•Bi-directional reading

•Samsung Pay MST

ID TECH VP3300 OEM User Manual

Page | 6

1.3. ICC Contact Card Features

•EMVCo ContactLevel1 & 2 compliant

1.4. Contactless (NFC) Features

•ISO 14443 Type A&B

•ISO 18092 (P2P)

•MasterCard® MCL (Formerly PayPass)

•Visa payWave/VCPS

•Visa IRWIN

•Discover® DPAS

•American Express® ExpressPay

•MIFARE

•Apple Pay

•Apple VAS Loyalty

•Samsung Pay NFC and MST

•Android Pay

•Google Pay Smart Tap Loyalty

1.5. Other Agency Approvals and Compliances

•CE (EN55022/EN55024, Class- B)

•FCC (Part 15, Class-B)

•RoHS (DIRECTIVE 2011/65/EU)

•REACH

•EMV Contact L1&L2

•EMV Contactless L1

•TQM

ID TECH VP3300 OEM User Manual

Page | 7

2. Physical Specifications

Item

Specification

Physical Dimensions

64mm x 49mm x 15mm (LxWxH)

Structure Material

Plastic, PC UL 94V-0

Texture

MT11010

Weight

50g

Operation and Storage Environment

Operating Temperature

0° C to 55° C Non-condensing

Storage Temperature

-20° C to 60° C Non-condensing

Operating Humidity

5% to 95% Non-condensing

Storage Humidity

5% to 95% Non-condensing

2.1. Electrical Power

State

Current Draw

Idle

230 mA

Contact EMV

230 mA

MSR swipe

280 mA

Contactless EMV

530 mA

Transactions per battery charge:

250 MSR + 125 EMV + 125 EMV CTLS transactions (Total 500 transactions) per charge.1

2.2. Available Interfaces

Although ID TECH recommends using a USB connection to communicate with the VP3300 OEM, a

VP3300 OEM Bluetooth version is also available.

1Transactions per battery charge only applicable to OEM Bluetooth.

ID TECH VP3300 OEM User Manual

Page | 8

3. Design Guidelines

When integrating the VP3300 OEM into a project,make sure to follow the guidelinesbelow.

•MSR Head: VP3300 OEM device supports multiple MSR head types including:

oWing Spring

oLeaf Spring

oFrame Spring

oCantilever

•MSR Connection: The MSRconnectionmustbe flexible printed circuit.

•MSR ConnectorLength:The recommendedFPCmaximum length is 30cm.

•Contactless Mounting: Note that the antenna’s RF field antenna is sensitive to the proximity

of metal. There are three options for mounting the VP3300 OEM components in a metal

surface:

oMount with the RF emitting surface of the antenna at least 1cm forward ofanymetal.

oMount with the RF emitting surface of the antenna at least 1cm behind any metal.

This will reduce the effective range of the antenna.

oMount flush with the metal but allow a minimum of1cm distance from the metal.

•EMV Mounting:The EMV cable comeswith a ferrite shield2to protect from EMF interference;

see mounting guidelinesbelow:

2Contact your ID TECH representative for a CAD model for design purposes.

ID TECH VP3300 OEM User Manual

Page | 9

4. Installation and Use Guide for Magnetic Heads

This section definesthe designspecifications ID TECH customers require to install magnetic readers

and heads to the correct dimensions and other specific requirementsthatensure maximum life and

reading reliability. ID TECH has spentyears testing magnetic heads with our electronics to determine

the best dimensions and characteristics.These factors,combined with the specified reference

surface,provide forID TECH’s industry-leading reading reliability. It is extremely important to follow

these instructions to achieve the bestperformance for ID TECH magnetic reading components that

are designed into your product(s).

4.1. Track Locations

ISO 7810 and ISO 7811 standards define the specification forall “standard” magnetic stripe cards.

The location of each magnetic head’s track’s centerline is shown below in Figure 13. ID TECH’s heads

are installed in spring mounts that have mounting holes locatedon the centerline ofTrack 2; refer to

Figure 2 for the 3-trackstandard magnetic head and(wing) spring mount.The pivot pins must be

preciselylocated to the dimensions shown below in Figure 1 for the Track 2 centerline, ensuring the

read head will be to the proper dimensions for all tracks.

Figure 1: Location of Magnetic Track Centerlines

3Note: Magnetic heads can contain one, two, or three tracks, but a three-track head is the most common.

ID TECH VP3300 OEM User Manual

Page | 10

Figure 2: Standard Magnetic head assembly showingtolerances of Azimuth

4.2. Reference Surface/Wear-Plate

The reference surfaceis an important elementforthe properdesignofall credit card readers because

all dimensions for installing magnetic heads are measuredfrom that surface. There are important

considerations to understandwhendesigning the reference surface/wear-plate:

1. ID TECH uses stainless steel for the reference surface/wear-plate in most of our credit

readers to preventany measurable wearfrom the pressure exerted bycard edges,

assuring negligible wear. Integrators should remember thatthe magnetic head’s

installation dimensionsare takenfrom the reference surface andthat anyvariationfrom

those dimensions could have a negative effectonreadingreliability.

Note that electrostatic discharge can be an issue for MagStripe readers.Whenusing metal

for the reference surface/wear-plate,integrators shouldeither ground the plate or use

conductive plastic to help minimize ESD.

2. ID TECH uses wear-resistant 30% glass-filled plastics in applications where stainless steel

is impractical, such as insert readers. Inthis type ofreader,the force from the card’s edges

is small while inserting and withdrawing cardscompared to the force exerted on the wear

plate in a conventionalswipe reader.ID TECH’s insert readers use a 30% glass-filled

polycarbonate plastic in the insert reader’s rails.

3. It is extremely important that the reference surface not have any bumps or abrupt changes

on the surface for one card length (3 and 3/8 inches) from the centerline of the readhead’s

gap; any irregularities will cause reading failures.The critical design requirementisthat the

reference surface/wear-plate mustbe atminimum flush toabove anysurface within a

card length of the read head’s center line. Any surface that is in-line with the card swipe, if

Otros manuales para VP3300 OEM

Tabla de contenidos

Otros manuales de Lector de tarjetas de IDTECH

IDTECH

IDTECH Spectrum IIa Manual de usuario

IDTECH

IDTECH ViVOpay VP3320 Manual de usuario

IDTECH

IDTECH ViVOpay KioskII Manual de usuario

IDTECH

IDTECH PiP Manual de usuario

IDTECH

IDTECH MiniSmart II Manual de instalación

IDTECH

IDTECH MINIMAG Manual de instrucciones

IDTECH

IDTECH VP3300 Manual de usuario

IDTECH

IDTECH SecureHead Manual de usuario

IDTECH

IDTECH clearent ID TECH VP8300 Manual de usuario

IDTECH

IDTECH MINIMAG Manual de usuario

IDTECH

IDTECH Kiosk III Manual de usuario

IDTECH

IDTECH SecureMag Manual de usuario

IDTECH

IDTECH ViVOpay VP3600 Manual de usuario

IDTECH

IDTECH BT Mag Manual de usuario

IDTECH

IDTECH SmartPIN L80 Manual de usuario

IDTECH

IDTECH Kiosk V Manual de usuario

IDTECH

IDTECH Xpress CM100 Manual de instrucciones

IDTECH

IDTECH IDWA-332312 Manual de instrucciones

IDTECH

IDTECH ViVOpay VP3300 Series Manual de usuario

IDTECH

IDTECH OMNI Manual de instrucciones

IDTECH

IDTECH SREDKey Manual de instrucciones

IDTECH

IDTECH MINIMAG Manual de usuario

IDTECH

IDTECH EasyMag Manual de usuario

IDTECH

IDTECH VP3300 OEM Manual de usuario

Manuales populares de Lector de tarjetas de otras marcas

Lindy

Lindy 43185 Manual de usuario

Lindy

Lindy 43185 Manual de usuario

ViziT

ViziT RD-4F Manual de usuario

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Manual de usuario

AVID ID

AVID ID AVID1043 Manual de usuario

Conrad

Conrad PCMCIA Manual de usuario

Rosslare

Rosslare DR-6255 Manual de usuario

Lindy

Lindy 51541 Manual de usuario

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Manual de usuario

Johnson Controls

Johnson Controls Kantech tyco ioSmart Manual de usuario

ACS

ACS ACR122L Manual de usuario

Secukey

Secukey S2-MF Manual de usuario

Elecom

Elecom MR-SMC07 series Manual de usuario

Alien

Alien ALR-9800 Manual de usuario

ACS

ACS ACR310 Manual de usuario

Datamars

Datamars R-IN1300 MID Manual de usuario

Alarm Lock

Alarm Lock AL-PRE2 Manual de usuario

xpr

xpr B100PROX-AH Guía del usuario
