Idis DC-S3283EX Manual de usuario

Explosion-proof

Speed Dome camera

InstructionManual

DC-S3283EX

DC-S3283EX Explosion-proof Speed Dome Camera

Copyright Statement.....................................................................................................I

Quality Guarantee ........................................................................................................I

Security Assurance ......................................................................................................I

Notice ..........................................................................................................................II

Safety Requirements..................................................................................................III

How to move this product........................................................................................ VIII

Thank you for choosing IDIS Ex products！

Please read this Instruction Manual carefully before installation and operation of this product,

following the instructions and keep this instruction manual properly.

Documents version

Document

Product name

DC-S3283EX explosion-proof speed dome camera

Document name

Instruction manual

Version

Date

Remarks

V1.0

2020.12.22

1st version

DC-S3283EX Explosion-proof Speed Dome camera

IDIS Co., Ltd. (hereinafter referenced as IDIS). Claims copyright ownership of the

contents (including text and images) of this Instruction Manual. Any content may not

be copied, transferred, modified or reproduced by any person or organization

without expressed permission of IDIS.

IDIS remains the right to modify the content and technical specifications of the

product in this Instruction Manual without any form of notification, to provide the

newest and most advanced product. The end users can get the latest product

information on our website: http://www.idisglobal.com.

Quality Guarantee

For DC-S3283EX Explosion-proof Speed Dome Camera, we provide free maintain

service in the guarantee period but we will ask the user to pay for the cost of labor

and component in the follow conditions:

Damage caused by improper operation that against the Instruction Manual.

Damage caused by unauthorized disassembly.

Thunder or other force majeure natural disasters.

If any other contracts between clients and us exist,

we will follow the promise or regulation strictly.

Security Assurance

Operation of this product complies with the following requirements:

No adverse interference in operation;

The operation of this product cannot be interfered by external factors even

adverse interference in a certain degree.

DC-S3283EX Explosion-proof Speed Dome camera

Notice

The user shall not disassemble this product optionally, such as removal of top

cover or bolts may cause leakage of water or creepage. Please operate the

product according to the requirements in this Instruction Manual;

Ensure this product is always used in environment with atmosphere pressure,

ambient temperature and relative humidity specified in Chapter 1.6;

To be sure the power supply complies with the requirement indicated in the

nameplate;

The internal and external grounding shall be reliable;

Ensure the installation is firm and reliable, to avoid

unexpected damage of the camera;

It’s not allowed to do any modification on qualified products, otherwise

Explosion-proof performance may be affected

DC-S3283EX Explosion-proof Speed Dome camera

III

Please read this Instruction Manual carefully before installation and operation of this product.

The safe service period is 1 years after date of manufacture, see nameplate of the date of

manufacture.

Please read and understand associate knowledge, safety notices and cautions before put into

service.

1. Safety cautions in installation

Cut off the power supply before any maintenance or repair of the product. DO

NOT OPEN WHEN ENERGIZED!

Avoid opening of this product in environment where oil smoke, heavy dust,

high temperature or dewing may exist. These will cause the decrease of the

image definition.

Connect the cables according to the requirement indicated in the Instruction

Manual, otherwise fault may happen.

Protect the flame proof joint in maintenance; avoid any metal fragment or other

substances get access in the internal chamber.

No disassembly or modification allowed.

2. Construction Safety

The protective regulations on construction spot shall be followed strictly.

Measurement shall be carried out immediately when any security risks found to

eliminate the risks, stop construction if necessary.

All kinds of safety facilities shall be inspected, calibrated or repaired in the

event of severe weather.

The ice, fog, rain and snow shall be removed clearly.

Alert area shall be set and a person shall be specified to protect the area when

protective casing and other safety facilities are constructed or dismantled.

Work high above the ground may require in installation of this product, the

operating personnel shall be qualified.

DC-S3283EX Explosion-proof Speed Dome camera

3. Power supply requirements

Local electrical safety standard shall be followed in installation and service of

this product.

Convenient de-energizing device shall be adopted for emergency cutting off.

Check if the power supply is suitable for operation before start.

Protect the power cable from trample or compressing, especially for the plug,

socket and joint out from devices.

Service condition requirements

Please do not focus the camera to hard light (such as lamp or sunlight), which

will cause too bright of the image, it’s not malfunction but it does will affect the

duration of the CCD (or CMOS).

Transport, operate and store this product in applicable temperature and

humidity range. Do not locate it in wet, overheated (over +60ºC), extreme cold

(less than -40ºC) environment or area with strong electromagnetic radiation or

unstable lighting conditions.

The product shall be protected from any entry of water or other conductive fluid,

which may damage the internal electrical element.

Avoid overheated, the product shall be well ventilated.

Avoid damage caused by compressing or violent vibration in transmission,

storage or operation.

The product shall be well packaged as new product or equivalent in

transmission.

We suggest using this product with Lightning Protection Devices.

Internal and external grounding shall be reliable and the cross-sectional area

shall be no less than 4mm2.

DC-S3283EX Explosion-proof Speed Dome camera

4. Operation & maintenance requirements

Do not dismantle this product; there is no user serviceable part inside.

Do not touch the CCD (or COMS) directly; a proper way is to blow away the

dust with a blower on the lens. If it is necessary to clean it, use soft cloth with a

little alcohol to wipe the lens gently. Replace the cover when not use to protect

the CCD (or COMS).

Soft, dry cloth can be used for camera body cleaning. For dirt not easy to clean,

some neutral detergent can be used, clear the dirt away then dry the camera

body. Corrosive agent, abrasive cleaner cannot be used for camera cleaning,

they may damage the surface or even decrease the service performance.

This product shall be installed and repaired by authorized personnel, please do

not dismantle or repair it by yourself. Only manufacturer indicated components

/ accessories can be used when replacement is necessary.

The CCD (or COMS) may be damaged by laser beam, it’s better to avoid the

camera suffering radiation of laser beam.

6. Environmental protection

For components of the products made by our company may pollute the

environment, such as PCB, electrical elements, plastic and lubricant, collection

and control measurement shall be taken in maintenance and scrapping of the

products. These pollution sources shall be delivered to the government for

further treatment, no casually discard allowed, avoid any adversative effect to

the environment.

DC-S3283EX Explosion-proof Speed Dome camera

7. Special announcement

Pictures in this manual is a diagram for reference only.

We remain the right to modify the content and technical specifications of the

product in this Instruction Manual without any form of notification when the

product updates, there may exist

little differences after updating.

You can get the latest software and description document by consulting the

customer service department.

Any problem in operation of this product, please contact the distributor or

customer service department.

We always tried to make this instruction manual as perfect as we can, but there

still may be some de-tolerance between the real data and the data we provide, if

you have any questions or disputes, please refer to our company for finally

explanation.

The operator or user shall be responsible for damages or losses caused by

misuse or operations do not comply with this manual.

DC-S3283EX Explosion-proof Speed Dome camera

VII

Ex structure instruction

We have made adequate consideration in flameproof enclosure design of the

explosion-proof camera to prevent explosive gases getting into the inner

volume, the explosion inside the enclosure cannot cause the explosion of the

external explosive gases. We ensure the explosion-proof performance by

strengthen enclosure the strength, adjust the length and gap of the joint of

associate components and limit the maximum surface temperature.

The enclosure is able to subject to static pressure test (1.5 times for at least

10s) specified in EN60079-1/IEC60079-1, no leakage or deformation allowed

after test.

The maximum surface temperature will no more than 80ºC in normal operation.

Tempering glass is adopted in observation port, the tempering glass shall pass

the impact and thermal shock test.

Ingress protection level: IP66, IP68(2m/2h).

Protection the flameproof surface in maintaining of this product, otherwise the

damaged flameproof surface will affect the Explosion-proof performance.

When the product needs anti-corrosion treatment (especially carbon steel), the

surface of the product will be sprayed. In this case, please wipe the

non-metallic layer with a damp cotton cloth during maintenance. Pay attention

to the protective coating. Do not use liquids with strong corrosion.

The light-transmitting parts of this product have static electricity risk. When

wiping lens parts of this product, it is necessary to ensure that it is carried out in

a safe environment. Do not wipe with dry cloth.

DC-S3283EX Explosion-proof Speed Dome camera

VIII

De-energize the product, holding the upper cover to move it; no dragging or

knocking allowed.

Sun shade

Light transmitting

When the product is energized: it’s NOT allowed to open, move, knock or drag this

product.
