ICRealtime ICIP-D2000-IR-B Manual de usuario

HD IR Waterproof Network Dome Camera User’s Manual

Version 3.5.1

Welcome

Thank you for purchasing our Network camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conform to your local electrical safety codes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC in the IEC60950-1.This series product supports PoE too. Please note:

Do not connect these two power supplying sources to the device at the same time; it may result

in device damage!

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series network camera should be installed in a cool, dry place away from direct sunlight,

inflammable, explosive substances and etc.

Please keep it away from the electromagnetic radiation object and environment.

Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.

Otherwise it may result in CCD (CMOS) optical component damage.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

Thunder-proof device is recommended to be adopted to better prevent thunder.

The grounding studs of the product are recommended to be grounded to further enhance the reliability

of the camera.

6. Daily Maintenance

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

iii

Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens

surface.

Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to

dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the

device.

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

7. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

Accessory Name

Amount

Network Camera Unit

Quick Start Guide

Installation Accessories Bag

Table of Contents

1General Introduction..............................................................................................................1

1.1 Overview ...................................................................................................................1

1.2 Features....................................................................................................................1

1.3 Specifications ...........................................................................................................2

1.4 Factory Default Setup ..............................................................................................3

2Structure .................................................................................................................................8

2.1 Components .............................................................................................................8

2.2 Framework and Dimension .....................................................................................8

3Device Installation ...............................................................................................................10

3.1 Installation Steps....................................................................................................10

3.2 Restore Factory Default Setup Introduction ........................................................12

4Quick Configuration Tool ....................................................................................................13

4.1 Overview .................................................................................................................13

4.2 Operation ................................................................................................................13

5Web Operation.....................................................................................................................15

5.1 Network Connection...............................................................................................15

5.2 Login and Logout ...................................................................................................15

6FAQ.......................................................................................................................................17

Appendix Toxic or Hazardous Materials or Elements.............................................................18

1General Introduction

1.1 Overview

This series network camera integrates the traditional camera and network video technology. It adopts

video data collection, transmission together. It can connect to the network directly without any auxiliary

device.

This series network camera uses standard H.264 video compression technology, which maximally

guarantees the video quality.

It supports the IR night vision function. In the night environments, the device can use the IR light to

highlight the object which is suitable for the surveillance function in the low illumination environments.

The waterproof design conforms to the IP 66 level. It has the sound waterproof function suitable for

use in the outdoor environments.

It can be used alone or used in a network area. When it is used lonely, you can connect it to the

network and then use a network client-end. Due to its multiple functions and various uses, this series

network camera is widely used in many environments such office, bank, road monitor and etc.

1.2 Features

User

Management

Different user rights for each group, one user belongs to one group.

The user right shall not exceed the group right.

Storage

Function

Support central server backup function in accordance with your configuration

and setup in alarm or schedule setting

Support record via Web and the recorded file are storage in the client-end

PC.

Support network storage function such as FTP.

Network

Monitor

Network camera supports one-channel video data transmit to network

terminal and then decode. Delaying time is within 270ms (network bandwidth

support needed)

Max supports 20 connections.

Adopt the following video transmission protocol: HTTP, TCP, UDP,

MULTICAST, RTP/RTCP, RTSP and etc.

Support web access.

Network

Management

Realize network camera configuration and management via Ethernet.

Support device management via web or client-end.

Power

External power adapter DC 12V.

Support PoE.

Warning！

Do not connect these two power supplying sources to the device at the

same time; it may result in device damage!

Assistant

Function

Log function

Support system resource information and running status real-time display.

Day/Night mode auto switch.

Support picture parameter setup such as electronic shutter and gain setup.

Support motion detect.

Backlight compensation: screen auto split to realize backlight compensation

to adjust the bright.

Support video watermark function to avoid vicious video modification.

Built-in IR light. Support IR night vision.

The enclosure conforms to the IP 66 protection. Has the waterproof function.

1.3 Specifications

Please refer to the following sheet for network camera performance specification.

Model

Parameter

ICIP D2000IR

System

Main Processor

TI Davinci high performance DSP

Embedded LINUX

System

Resources

Support real-time network, local record, and remote operation at the

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/2.8-inch CMOS

Pixel

1920(H)*1080(V)

Day/night

Support IR-CUT switch

Gain Control

Fixed/Auto

White Balance

Manual/Auto

Exposure Mode

Manual/Auto

PAL: It ranges from 1/3 to 1/10000

NTSC: It ranges from 1/4 to 1/10000

Video

Compression

Standard

H.264/JPEG/MJPEG

Video Frame

Rate

PAL:

Main stream(1920*1080@25fps)，extra stream(704*576@25fps)

NTSC:

Main stream(1920*1080@30fps),

extra stream,(704*480@30fps)

Video Bit Rate

48k~8192kbps

Bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, camera masking.

Lens

3.6mm, 6mm, 8mm. Fixed focus.

Lens Interface

M12. Lens is the default accessories

Video

Motion Detect

396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The

6th level has the highest sensitivity)

Activation event: video storage, image snapshot, log, email function

and etc.

Record

and

Backup

Record Priority

Manual>External alarm >Video detect>Schedule

Storage

Management

Support FTP storage.

Wire Network

1-ch 10/100 M Ethernet , RJ45 port

Network Protocol

HTTP, TCP/IP, ARP, RTSP, RTP,UDP, RTCP, SMTP, FTP, DHCP,

DNS, DDNS, PPPOE, IPv4/6, SNMP, UPNP, NTP

Remote

Operation

Monitor, system setup, file download, log information, maintenance ,

upgrade and etc

Restore Default

Setup

Built-in Reset button

IR light

IR light 25M.

General Parameter

Power

DC12V power and PoE.

Warning！

Do not connect these two power supplying sources to the device

at the same time; it may result in device damage!

Power

Consumption

4.5W MAX

Working

Temperature

-10℃~+60℃

Working

Humidify

10%~90%

Dimensions(mm)

Φ113×86

Weight

280g(Excluding box)

Installation

Fixed on the wall, ceiling and etc.

1.4 Factory Default Setup

Please refer to the following sheet for factory default setup information.

Setup

Item

Default Setup

ICIP D2000IR

Camera

Conditions

Brightness

Contrast

Sharpness

Saturation

Anti-flicker

Outdoor

Gain Mode

Auto

Gain Limit

0~50

Scene Mode

Auto

Day/night Mode

Auto

BLC

Off

Mirror

Off

Flip

Off

Video

Video bit stream

Main

Stream

Bit stream

type

General

Encode mode

H.264

Resolution

1080P(1920*1080)

Frame

Rate(FPS)

PAL: 25

NTSC:30

Bit Rate Type

CBR

Recommende

d Bit

3584-8192 Kb/S

Setup

Item

Default Setup

ICIP D2000IR

Bit Rate

8192

I Frame

interval

Watermark

Enable

Watermark

character

DigitalCCTV

Sub

Stream

Enable

Bit stream

type

General

Encode

mode

H.264B

Resolution

CIF(352*288)

Frame

Rate(FPS)

PAL: 25

NTSC:30

Bit Rate Type

CBR

Recommend

ed Bit

192-1024Kb/S

Bit Rate

1024

I Frame

interval

Snapshot

Type

General

Image Size

1080P（1920*1080）

Quality

Better

Interval

Video Overlay

Privacy Mask

Disable

Channel Title

Enable

Time Title

Enable

Path

Snapshot

Path

C:\PictureDownload

Record Path

C:\RecordDownload

Network

TCP/IP

Host Name

IPC

Ethernet Card

Wire(Default)

Mode

Static

Mac Address

Device MAC address when it is shipped out of the

factory

IP Version

IPV4

IP Address

192.168.1.108

Subnet Mask

255.255.255.0

Default

Gateway

192.168.1.1

Setup

Item

Default Setup

ICIP D2000IR

Preferred

DNS

8.8.8.8

Alternate

DNS

8.8.8.8

Enable

ARP/Ping set

device IP

address

service

Enable

Connection

Max

Connection

TCP Port

37777

UDP Port

37778

HTTP Port

RTSP Port

554

Enable HTTP

Disable

HTTPs Port

443

PPPoE

Enable

Disable

Username

none

Password

N/A

DDNS

Server Type

Disable，CN99 DDNS

Server IP

none

Server Port

Domain

Name

none

User

none

Password

****

Update

Period

10 minutes

IP Filter

Trusted sites

Disable

SMTP(Email)

SMTP Server

none

Port

Anonymity

Disable

User Name

anonymity

Password

****

Sender

none

Authenticatio

n (Encryption

mode)

N/A

Title (Subject)

IPC Message

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de ICRealtime

ICRealtime

ICRealtime THIP-P2078FM-IR Manual de usuario

ICRealtime

ICRealtime HD-PTZ-12X-W Manual de usuario

ICRealtime

ICRealtime ICIP D3000AVIR-M Manual de usuario

ICRealtime

ICRealtime PTZN23X4D Manual de usuario

ICRealtime

ICRealtime ClearView WiFi-2MP-BL100 Manual de usuario

ICRealtime

ICRealtime ICR300H3B Manual de usuario

ICRealtime

ICRealtime AVSD2218Z Manual de usuario

ICRealtime

ICRealtime ICR-100X Manual de usuario

ICRealtime

ICRealtime ICR2200 Manual de usuario

ICRealtime

ICRealtime ICIP D2010IR Manual de usuario

ICRealtime

ICRealtime PTZ-3660SIR Manual de usuario

ICRealtime

ICRealtime IPEL-MB80F-IRW1 Manual de usuario

ICRealtime

ICRealtime EL-3000N Manual de usuario

ICRealtime

ICRealtime Pixim I-Sniper EL-720 Manual de usuario

ICRealtime

ICRealtime Elite Manual de usuario

ICRealtime

ICRealtime ICIP-D3077P Manual de usuario

ICRealtime

ICRealtime AVS-B2712SL Manual de usuario

ICRealtime

ICRealtime F Series Manual de usuario

ICRealtime

ICRealtime AVS-B2218Z Manual de usuario

ICRealtime

ICRealtime Full HD(HD-SDI) CCTV Box Camera Manual de usuario

ICRealtime

ICRealtime IPMX Series Manual de usuario

ICRealtime

ICRealtime ICIP-B1300 Manual de usuario

ICRealtime

ICRealtime ICR300H3W Manual de usuario

ICRealtime

ICRealtime ICIP2040IR Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
