ICP DAS USA A-8111 Series Manual de usuario

- 1 -

Language

English

Version V1.0

Update Oct.2008

………………………………………………

What’s on your package?

 One A-8111 series card

 One companion ISA CD (V2.1 or later



One Quick Start Guide(This document

………………………………………………

Installing Windows Driver

Follow those steps:

1. Setup the Windows driver.

You can get the driver from:

CD:\NAPDOS\ISA\A8111\DLL_OCX\Driver\

http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/a8111/dll_ocx/driver/

8111

Windows driver only support windows 98/NT/2000 and

XP/2003 versions.

- 2 -

2. Click button to start installation.

3. Click button to install driver into the default

folder.

4. Click button to continue installation.

5. Select NO, I will restart my computer later” and

then click button.

………………………………………………

I/O Base Address Setting

 The base address is set from SW1 DIP switch on

board:

1 2

A9 A8 A7 A6 A5 A4`

SW1 : BASE ADDRESS

BASE ADDR

A9 A8 A7 A6 A5 A4

200-20F OFF

ON ON ON ON ON

210-21F OFF ON ON ON ON OFF

220-22F(

OFF ON ON ON OFF ON

230-23F OFF ON ON ON OFF OFF

: : : : : : :

300-30F OFF OFF ON ON ON ON

: : : : : : :

3F0-3FF OFF OFF OFF OFF OFF OFF

(



) : Default base address is 0x220

- 3 -

………………………………………………

Installing Hardware on PC

Follow those steps:

1. Shut down and power off your computer

2. Remove all covers from the computer

3. Select an empty ISA slot

4. Carefully insert your I/O card into the ISA slot

5. Replace the PC covers

6. Power on the computer

After powering-on the computer, continue next process.

………………………………………………

Adding Hardware

7. Add Hardware

7-1

Open the Control Panel” by click the item Start / Settings /

Control Panel”.

7-2 Double-click the item Add/Remove Hardware” and Click

the Next >” button.

7-3 Select the item Add/Troubleshoot a device” and click the

“

““

“Next >” button.

Adding hardware is used on Windows 2000/XP/2003 only.

Windows 9X/Me/NT users can skip it.

- 4 -

7-4 Select the item Add a new device” and click the Next >”

button.

7-5 Select the item No, I want to select the hardware from a

list” and click the Next >” button.

7-6 Select the item Other device” and click the Next >” button.

7-7 Click the Have Disk…” button.

7-8 Click the Browse…” button to select the Inf file default path

is C:\DAQPro\A-8111_Win2K\driver and click the OK”

button.

7-9 Select the correct device from the Models:” listbox and Click

the Next >” button.

7-10

The windows show to dialog box and Click the OK” button to

enter the device’s properties settings.

8. Modify the device properties

9. Reboot the PC

The detail “add hardware” information.

Please refer to

CD:\NAPDOS\ISA\Manual\PCI_ISA_PnP_Driver_Installation_in_Win9x_2K_XP.pdf

Select Input/Output Range

Click “Change Setting” to

change I/O Range (Depend on

I/O Base Address

No devices are conflicting

- 5 -

………………………………………………

Pin Assignments



CN1: Analog input/Analog output connector.

 CN2, CN3: Digital input/output connector.

Desc

ription

Description

1 A/D Analog Input Channel 0

Analog GND

2 A/D Analog Input Channel 1 21 Analog GND

3 A/D Analog Input Channel 2 22 Analog GND

4 A/D Analog Input Channel 3 23 Analog GND

5 A/D Analog Input Channel 4 24 Analog GND

6 A/D Analog Input Channel 5 25 Analog GND

7 A/D Analog Input Channel 6 26 Analog GND

8 A/D Analog Input Channel 7 27 Analog GND

9 Not Used 28 Not Used

10 Not Used 29 Not Used

11 Not Used 30 D/A Analog Voltage output

12 Not Used 31 Not Used

13 Not Used 32 Not Used

14 Analog GND 33 Not Used

15 Analog GND 34 Not Used

16 Not Used 35 Not Used

17 Not Used 36 Not Used

18 Not Used 37 Not Used

19 PCB’s + 5V output

Description Pin

Description

Digital Input 0/TTL 2

Digital Input 1/TTL

Digital Input 2/TTL 4

Digital Input 3/TTL

Digital Input 4/TTL 6

Digital Input 5/TTL

Digital Input 6/TTL 8

Digital Input 7/TTL

Digital Input 8/TTL 10

Digital Input 9/TTL

Digital Input 10/TTL 12

Digital Input 11/TTL

Digital Input 12/TTL 14

Digital Input 13/TTL

Digital Input 14/TTL 16

Digital Input 15/TTL

PCB’s GND output

PCB’s + 5V output

STROBE

Description Pin

Description

Digital output 0/TTL 2 Digital output 1/TTL

Digital output 2/TTL 4 Digital output 3/TTL

Digital output 4/TTL 6 Digital output 5/TTL

Digital output 6/TTL 8 Digital output 7/TTL

Digital output 8/TTL 10

Digital output 9/TTL

Digital output 10/TTL

Digital output 11/TTL

Digital output 12/TTL

Digital output 13/TTL

Digital output 14/TTL

Digital output 15/TTL

PCB’s GND output

PCB’s + 5V output

PCB’s +12V output

- 6 -

………………………………………………

Self-Test

1. Use CA-2002(Optional to connect the CN2 with

CN3.

2. Run the A-8111 sample program.

Get the file from:

C:\NAPDOS\ISA\A8111\DLL_OCX\DEMO\

http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/a8111/dll_ocx/d

emo/

CN1

CN2

CN3

- 7 -

3. Check number of the A-8111 and test DIO function.

4. Get DIO function test result.

Click this

button to do

DIO test.

Click this I/O

Base value

(Depend on I/O

Base Address

3. Click the channel

0 、2、4、6 in the DO.

4. DI show to channel

0、2、4、6 for high state.

(Red light

Complete

- 8 -

………………………………………………

Additional Information

 A-8111 Series Card Product page:

http://www.icpdas.com/products/DAQ/pc_based/a-8111.htm

 CA-2002(Optional) page:

http://www.icpdas.com/products/Accessories/cable/cable_selection.htm

 Documents:

CD:\NAPDOS\ISA\A8111\manual

http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/a8111/manual/

 Software:

CD:\NAPDOS\ISA\A8111

http://www.icpdas.com/download/isa/a8111/index.htm

The ICP DAS Web Site

http://www.icpdas.com

[email protected]

 Technical support

 Supplies and ordering information

 Ways to enhance your device

 FAQ

 Application story
