iCheckTPMS IC005 Manual de usuario
Instruction Manual
Model IC005 / IC008 / IC010
PROTECT MORE THAN JUST
YOUR TYRES.
WITH AUSTRALIA’S BEST.
CONTENTS
3
1. Product Information ............................................................................................................... 4
1-1. Product Feature ....................................................................................................... 4
1-2. iCheckTPMS IntelliData™ .................................................................................... 4
1-3. Intelligent O Road Mode.................................................................................... 4
1-4. iCheckTPMS InstaData™ ...................................................................................... 5
2. Product Accessories ............................................................................................................... 6
3. Sensor Installation ................................................................................................................... 8
4. Product Settings ....................................................................................................................... 9
4-1. Change Unit ............................................................................................................. 9
4-2. Switch Display to View Vehicle Spare Tyre / Trailer Spare Tyre ............. 9
4-3. Benchmark Pressure Set Automatically.......................................................... 9
4-4. Wheel Bearing Sensor High Temperature Alert Setting........................... 9
4-5. Caravan Disconnect Feature .............................................................................. 9
4-6. Caravan Connect Feature.................................................................................... 10
4-7. Restore Factory Settings ....................................................................................... 10
5. Installation Tips ........................................................................................................................ 10
6. Special Features ........................................................................................................................ 11
6-1. Monitor Battery Saving Mode ............................................................................. 11
6-2. Automatic Backlight............................................................................................... 11
6-3. Manually Turn On/Off Backlight ....................................................................... 11
6-4. Solar Powered Charging ...................................................................................... 11
6-5. Alarm Mute ................................................................................................................ 11
7. Monitor Features ...................................................................................................................... 12
7-1. Monitor Tyre Display .............................................................................................. 12
7-2. Signal Booster Icon ............................................................................................... 12
8. Alarm Status ............................................................................................................................... 13
9. Sensor Pairing ........................................................................................................................... 14
9-1. TPMS Sensor Pairing............................................................................................... 14
9-2. Wheel Bearing Sensor Activation and Pairing.............................................. 14
10. Wheel Bearing Sensor Installation ................................................................................. 15
11. Monitoring Your Hub / Bearing Temperatures........................................................... 16
12. Technical Specifications ..................................................................................................... 16
12-1. Display Parameters................................................................................................ 16
12-2. TPMS Sensor Parameters................................................................................... 17
12-3. Wheel Bearing Sensor Parameters................................................................. 17
13. Sensor Battery Replacement ............................................................................................. 18
14. FAQ’s / Special Notes ........................................................................................................... 19
1. PRODUCT INFORMATION
1-1. Product Feature
Thank you for choosing iCheckTPMS. Our tyre pressure monitoring system
allows you to monitor not only your tyre pressure and temperatures but also your
caravan wheel bearing and hub temperatures. A world first.
Please read the manual in full to familiarise yourself with all its features and
benefits before installing the system.
1-2. iCheckTPMS IntelliData™
What is IntelliData™?
Unlike iCheckTPMS, other tyre pressure monitoring systems can be dicult to set
up, especially when setting your high and low alarm pressures for each wheel, for
car and then caravan, which generally run dierent pressures.
With our exclusive IntelliData™, it’s much easier and quicker. Here’s how.
On cold tyres, simply screw the wheel sensors onto your tyre valves. This sets the
benchmark alarm pressure alerts. If a tyre pressure increases by 25% (from the cold
benchmark pressure), it will give a visual and audible alarm. If a tyre pressure drops
by 15% (from the cold benchmark pressure), it will give a visual and audible alarm.
With this feature, you do not have to set dierent high and low pressures for your
tow vehicle or caravan; simply screw them on and you’re done.
1-3. Intelligent O Road Mode
When the need arises to reduce the air pressure of your tyres, simply unscrew
the wheel sensors, air them down, and reinstall the sensors. This then sets a new
benchmark with pressure alerts if the tyre’s pressure rises by 25% or drops by 15%.
Every time your sensors are removed and reinstalled, they reset to the current
pressure so there’s no need to keep readjusting your high and low pressure alarms.
Clever huh?
4
1-4. iCheckTPMS InstaData™
What is lnstaData™?
Currently other TPMS systems have wheel sensors that go into sleep mode after
a short period of time and no movement, and are only activated by motion,
generally at speeds over 25km/h.
Here lies the problem... if your caravan has been sitting for some weeks or months
and has a slow leak you won’t know until your halfway down the road. Having
hooked up ready for your trip then only to be made aware that you have low
pressures in one or more tyres.
This then is a pain having to pull over and put air in your tyres on the side of the
road. Keep in mind too that there is visually no dierence between a tyre with
40PSI and 20PSI and there is no way of telling whether you have low pressures
in your car and or caravan before you leave, (unless checked manually with a tyre
pressure gauge).
The iCheckTPMS wheel sensors send data every five minutes to the monitor
whether in motion or not via our exclusive InstaData™.
This means as soon as you hop in your car with your caravan on tow you will have
the latest PSI data before you even drive out the driveway.
5
Power On/Off
Press and hold the
+ and - buttons
for 3 seconds.
Solar Panel Power Socket
2. PRODUCT ACCESSORIES
Monitor Components and Icons
- SET +
6
Car Caravan
/ Trailer
Icon Indication
Tyre Position
Sensor Low Battery
Monitor Power Level
Tyre Alarm Status
Solar Power Indicator
Booster Indicator
7
Lock Nut
Spanner
Lock NutSensor
Opening Tool
Caravan Wheel Bearing
Sensor (Optional)
Rubber O Ring
Non Slip Pad
LCD Monitor
Wheel SensorUSB Power
Cable
Signal Booster
(Optional)
Rubber Dust
Cover
8
Each sensor has been marked with a position number and has been paired to the
monitor from factory. Please install the sensors according to the below diagram.
Wheel
Sensor
Location
3. SENSOR INSTALLATION
1Unscrew the valve cap 3Screw on the nut
5Tighten up the nut to the
sensor with the spanner
2Insert dust proof cover onto
the valve stem
4Screw on the sensor 6Check air leakage by
spraying soapy water
2
4
6
5
8
1
3
7
IC008
2
4
7
9
10
1
3
6
8
IC010
5
IC005
2
4
5
1
3
5
Please Note: Use of the lock nuts and rubber dust covers is optional. Non use will
not aect performance or warranty of your product.
9
4-1. Change Unit
In standby mode, press and hold the ‘+’ button for 3 seconds to switch between
PSI / BAR pressure units.
In standby mode, press and hold the ‘-’ button for 3 seconds to switch between
°F / °C temperature units.
4-2. Switch Display to View Vehicle Spare Tyre / Trailer Spare Tyre
Press the ‘+’ or ‘-‘ buttons in standby mode to scroll through to spare tyre status.
4-3. Benchmark Pressure Set Automatically
Turn on the monitor and install the wheel sensors onto cold tyres. This will
become the benchmark pressure. When a tyre pressure increases by 25%, or drops
by 15% from the benchmark pressure, the monitor will alert you by a visual and
audible alarm.
4-4. Wheel Bearing Sensor High Temperature Alert Setting
The factory default alarm is set to 70 degrees Celsius. To adjust higher or lower,
press and hold the ‘set’ button for 3 seconds and release after the beep, the tyre
icons and temperature value will flash at the same time. Press the ‘+’ or ‘-‘ buttons
to select your preferred alarming status. After the new setting is complete,
press the ‘set’ button for 3 seconds to save the data and return to the normal
display interface.
4-5. Caravan Disconnect Feature
Press and hold the ‘-‘ button for 6 seconds and release after the second beep.
4. PRODUCT SETTINGS
Factory Default Setting
Pressure Unit PSI
Temperature Unit °C
High Temperature Alert 70°C
10
4-6. Caravan Connect Feature
Press and hold the ‘+’ button for 6 seconds and release after the second beep.
4-7. Restore Factory Settings
Turn o the monitor. Then turn the monitor back on and ‘within’ 3 seconds,
press and hold the ‘set’ button and release after the beep.
1. Please fully charge the unit before first time use.
2. Before installing the wheel sensors turn on the monitor and make sure you
have cold tyre pressures before installation of the wheel sensors.
3. Due to air expansion and contraction, tyre pressures and temperatures will
change whilst driving.
4. All sensors in this unit have been pre-set individually for each tyre in the
factory. Whenever the location of a tyre is changed it is necessary to put the
numbered sensor back to its original position as per the factory default wheel
sensor location.
5. When installing the monitor on the dash, ensure it is placed securely and does
not obstruct the driver’s view of the road.
5. INSTALLATION TIPS
