icetro ID-150AN Manual de usuario
Dispenser Ice Maker
Manual
MODEL : ID-150AN, ID-0300-AN
※ Please check the voltage specification.
If the voltage specification is different, it can not be used.
※ This product is designed for indoor installation.
Please be sure to install it indoors.
※ The external appearance, design, color, and/or components
of this machine may be changed without prior notice for the sake
of the Company's product manufacture.
※ Please read the preparations for safety.
※ For maximum hygiene, be sure to clean and sterilize the product
on a daily basis.
2
We Think of Customer Satisfaction
INDEX
1. Safety Precautions 3~8
9
10~11
12~16
12~13
14
15
16
17~20
18
19
20
20
21
21
22~25
22
23
24~25
26
27
28
29
30~31
4. How to install
- The installation place
- Panel disassembly method
- Connection method for water supply and drainage
- About grounding
2. Product Specification
3. Appearance and Size
5. How to start the product
- Button operation
- Function button description (FND display window)
- Three drainage functions
(forced drainage, automatic draining, water drainage)
- Stop switch
7. Maintenance, repair and disinfection
- Maintenance schedule
- Cautions for cleaning the external panel(stainless steel)
- How to clean and disinfect
6. Required precautions to prevent frost
- Water removal in water tank and evaporator
9. Error type
8. Circuit diagram
10. Before Requesting Service
11. Product Warranty
12. Part List
- Always keep the instruction manual in an accessible and visible place. -
3
Warning
1. Safety Precautions
When there is a risk of causing physical problems such as death or serious injury
in the event of improper use.
When injury or damage to property such as house or furniture may occur
in the event of improper use.
Please check the voltage specification.
If the voltage specification is different,
it may cause malfunction or accident.
Warning
Caution
SHOULD BE DONE PROHIBITION GROUNDEDDO NOT
DISASSEMBLE
DO NOT
TOUCH
DISCONNECT
POWER PLUG
◆ An electrical fire may be caused by a receptacle holding
more than one item.
◆ Do not use an adapter or an extension cord.
Use a single receptacle for the ice machine.
◆ A fire may occur if plug is not cleaned.
Clean the plug if covered in foreign material or dust etc.
with a clean, dry towel.
Clean the plug
4
We Think of Customer Satisfaction
Warning
◆ The objects or containers may fall and cause water to leak
and the insulation may be weakened, resulting in a fire
due to a short circuit.
◆ Insulation may be weakened, resulting in short circuit,
electric shock, or fire.
◆ If you continue operating in abnormal conditions,
there is a risk of fire or electric shock.
◆ There is a risk of fire due to electric shock or short circuit.
◆ Risk of explosion or fire.
Do not place heavy objects or containers containing
water on the ice maker.
Do not install the product in a humid place or
where there is a risk of water splashing.
Do not use
If the product malfunctions, such as smoke or burning
smell, unplug the power cord to stop operation.
Do not use
Do not use if the outlet is loose or has a problem.
Do not use
Do not use flammable spray around the ice maker.
5
Warning
◆ It may cause damage to the product.
◆ It may cause a failure or electric shock.
◆ It may cause a failure or electric shock.
◆ It may cause a failure or electric shock.
◆ It may cause an electric shock or fire.
Do not forcibly apply force or shock to the product.
◆ There is a danger of a current leak, electric shock and/or fire.
◆ Be sure to contact the customer service center if the power cord or plug get peeled or damaged.
Prohibition
Do not bend the power cord severely, or allow it to be pressed by a heavy matter.
which can cause damage to the cord.
Do not move the product by pulling the power plug.
Be sure to use the grounded consent.
Do not pull off the power plug.
When the power plug is damaged, do not replace it
arbitrarily and contact the service agency.
6
We Think of Customer Satisfaction
Warning
◆ Ignition or abnormal operation is dangerous and may cause more trouble.
◆ There is a danger of the ice maker twitching or falling, resulting in injury.
◆ In particular, please do not let children hang on the reservoir not fixed
to the product
◆ There is a danger of electric shock.
◆ The ice reservoir may break or become damaged.
◆ The cord or plug may be peeled and there is a risk of fire
or electric shock.
◆ If the cord or plug is peeled or damaged, be sure to ask the service
to replace it.
Disassembly forbidden
Do not modify or repair the product yourself.
Prohibition
Do not let children hang on the product.
Do not touch
Do not touch or pull on the power plug with wet hands.
Do not touch
Do not damage the inside of the ice maker with a sharp tool.
Prohibition
Do not allow electrical cords or plugs to be pinched or twisted.
7
Warning
Do not connect multiple
Products to a single outlet.
◆ It may cause electric shock or fire.
◆ It may cause fire or spark when unplugged by plug wire or driver.
◆ There is a risk of machine failure or electric shock due to short circuit.
◆ Do not plug in multiple plugs at the same time. Connecting multiple plugs
to a power strip will cause a fire.
Disconnect power plug
When not in use for a long time, remove ice and water
(to prevent winter frost), and unplug the power cord
from the outlet.
Disconnect power plug
When cleaning dust or replacing parts,
unplug the power plug first.
Disconnect power plug
When unplugging, grasp the plug body and remove it
Grounded
Please be sure to ground.
8
We Think of Customer Satisfaction
Caution
◆ New users need a manual for safe use.
◆ There is a risk of injury if you slip on the ice maker or get hands
or feet in the bottom of the side.
◆ The bottom of the ice maker have iron plates and
various parts which may cause injury.
◆ If it is plugged in immediately, it may cause a trouble in operation
of the freezer and it may cause malfunction of the ice maker.
Caution
If there is a risk of slippery water or oil on the floor near
the ice maker, please wipe it.
Hand over
When transferring this ice maker to another person,
please hand it along with the instruction manual
Do not put your hands or feet on the bottom of the ice maker.
If you unplug the power plug from the wall outlet and plug
it back in again, wait at least 5 minutes before reinserting.
For areas where water contains much calcareous sediments, be sure to install
a calcium filter at the water inlet port (calcium may reduce the lifecycle
of the product).
9
2. Product Specification
Category Specification
Model
ID-150AN, ID-0300-AN
Ice shape
Nugget
※ Maximum capacity (lb / day)
Ambient temperature 70 ℉,
Water temperature 50 ℉
297 (135 kg)
Storage capacity (lb)
11
※ Size (W X D X H inch)
- Foot excluded
16.6 X 25 X 28
Power Supply
AC 115 V 60 ㎐, 1PH
Current consumption
5.8 A
Weight Before packaging
145.5 lb ± 1 lb (66 kg)
After packaging
178.5 lb ± 1 lb (81 kg)
Compressor
3/8 HP
Condensation method
Air-cooled
Refrigerant
R-404A 11.29 oz
Deceleration
motor
Power Supply
AC 115 V 60 ㎐, 1PH
Rated output
80 W
Discharging method
Solenoid
Installation
environment
standard
Specification
50 ~ 100 ℉ (10~38 ℃)
Water temperature
50 ~ 89.6 ℉ (10~32 ℃)
Supply water
pressure
0.1 ~ 0.5 Mpa
※ Maximum production is based on ambient temperature 70 ℉(21 ℃)
and water temperature 50 ℉(10 ℃).
However, the deviation may occur depending on the conditions of the installation
environment, and the deviation may increase at high temperature conditions such as
the summer season.
※※ Depending on the specifications of the reservoir, the size may be different,
please check before purchase.
10
We Think of Customer Satisfaction
3. Appearance and Size
Front
Top Bottom
Rear
16.6
Unit : inch
31.3 ~ 31.9
Drain box
Height-adjustable feet
Display panel
Ice discharge lever
Filter
Water
connection
NPT 3/8"
NPTF 3/4"
Ice exit
Upper vent
