IK115 User Manual V1.0
1
IK115 GPS Tracker
User Manual V1.0
Preface
Congratulations on choosing the icar GPS IK115 Card GPS tracker. This manual shows
how to easily program and setup the tracker for best results. Make sure to read this manual
carefully before using this product, so as to avoid delays or confusion with it’s operation.
Please note that specifications and instructions are subject to change without notice to
facilitate product improvement. Updates and changes will be integrated into the latest release.
The manufacturer assumes no responsibility for any errors or omissions in outdated
documents.
IK115 User Manual V1.0
2
1. Overview
IK115 is a GPS tracker designed for wallet tracking.
2. Features
Real-timing tracking
GPS+WiFi Positioning
History record check
Geo-Fence alarm
Low battery alarm
Power saving mode
PC & Mobile App tracking
Mini Hidden
IP65 Water resistant
One way communication
SOS
3. Applications
Elderly tracking
Alone worker tracking
Kids tracking
Wallet tracking
4. Specifications
Item
Specifications
Dimension
64*43*7 mm
Weight
25.7g
Charger
DC 5V/1A
Backup battery
3.7 V 500mAh
Power consumption
40mA standby current
Working temperature
-20°C to 65°C
Item
Specifications
Cellular Bands
GSM: 850/900/1800/1900Mhz
Positioning
GPS, AGPS, LBS
Tracking Sensitivity
-162 dBm
IK115 User Manual V1.0
3
Sensor
Accelerometer
LED
RED/GREEN/BLUE
SIM Card interface
Nano SIM
Waterproof
IP65
5. IK115 interface
6. In the box
1* IK115 GPS Tracker
1* Quick Start Guide
1* Charge Cable
IK115 User Manual V1.0
4
7. Installation
7.1 SIM Card installation
Get ready a Nano Sim Card that support GSM&GPRS with 30MB data per month
Open the top housing
Insert Sim card to sim card slot correctly
Devices would turn on autoly (blue led will blinking).
After that the device will be ready.
If you want to turn off the tracker,you could press the SOS button 5 times quickly.
7.2 LED Indications
Flash
Fix
Off
Blue Light
GSM/GPRS conversation start
No GPRS signal
Power off or in sleep mode
Green Light
GPS location successful
No GPRS signal
Power off or in sleep mode
Red Light
charging
Full battery or charged full
8. SMS Commands List
Function
Command Format
Reply
for example
APN
SL APNapn content
apn set ok
SL APNcmnet
SL APNapn content,apn user
Apn set ok
SL APNapn content,apn user,apn user pas
sword
Apn set ok
admin
number
SL CP186*********
SL CP186********
Domain&IP P
ort
SL DPa.icargps.net 7700
SL DPa.icargps.net 7700
upload
frequency(ti
me)
SL SC0,50
50=50 seconds
upload
frequency(dis
tance)
SL SC1,500
500=500 meters
IK115 User Manual V1.0
5
Position
SL LC
Google map Link
SL LC
Restart Devic
e
SL RT
Device would restart i
mmediately
SL RT
Check
SL CX
SN:47120100939 SE
R:a.icargps.net 7700
APN:internet GSM:24
GPS:8 BAT:31
SL CX
Back to facto
ry
SL FT
OK
SL FT
9. App & PC Tracking platform
9.1 App install & Login
Search “ICAR GPS” in Google Play or iOS store(or scan the following QR code) to
download the Mobile APP;
Choose the” Login by Device No.,
Input your device’s ID number and password(default is 123456) to login.
IK115 User Manual V1.0
6
Choose the” Login by User name.,
Input your user name and password(default is 123456) to login
9.2 PC login
Web: www.icargps.net, Choose “ID No.”
Input your device’s ID number and password(default is 123456) to log in
Web: www.icargps.net, Choose “Account”
Input user name and password(default is 123456) to log in
10. FAQ
Q：Start up Fail?
A：Check the device power on or not.
Q：The device can not obtain location information?
A：Place the unit at the open area to test.
IK115 User Manual V1.0
7
Q：How to choose SIM card?
A: the SIM card must support GSM&GPRS，and ensure t
hat the card has enough currency and credit.
Q: How to use in the foreign countries?
A：please set the APN before use，please edit the text “SL
APNapn content,apn user,apn user password “ and send it
to the SIM card of the device，CMNET is Chinese operat
or’s APN, Replace the corresponding APN when use in oth
er countries, APN details, please consult your local SIM ca
rd carrier.
