IBT Technologies IB500 Manual de usuario
IB500
Half-Size Socket 7 CPU Card
With Optional VGA/LAN/SCSI
USER’S MANUAL
Version 1.0A
ii IB500 User’s Manual
Acknowledgments
Award is a registered trademark of Award Software International,
Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Pentium are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of their
respective owners.
IB500 User’s Manual iii
Table of Contents
Introduction...............................................................1
Product Description..........................................................1
Checklist...........................................................................2
Specifications....................................................................3
Board Dimensions.............................................................4
Installations ..............................................................5
Installing the CPU.............................................................6
MicroPCI Daughter Card Installation................................6
Installing the Memory (DIMM) .........................................7
Setting the Jumpers...........................................................8
Connectors on IB500 ......................................................17
Watchdog Timer Configuration.......................................30
BIOS Setup..............................................................31
VGA Drivers Installation ........................................55
LAN Drivers Installation.........................................58
SCSI Drivers Installation .......................................62
Appendix.................................................................68
A. POST Codes......................................................................69
B. I/O Port Address Map.......................................................73
C. Interrupt Request Lines (IRQ) .........................................74
iv IB500 User’s Manual
A Picture of the IB500 CPU Card
INTRODUCTION
IB500 User’s Manual 1
Introduction
Product Description
IB500 is a high-performance PISA-compliant CPU card that comes with
a MicroPCI Socket that supports MicroPCI daughter cards with VGA,
VGA/LAN, LAN, and SCSI functions. It is based on the Intel 430TX
PCIset and features a Socket 7 architecture that supports Socket 7 level
processors with frequencies up to 400MHz using a front side bus of
60MHz or 66MHz.
System memory is provided by one 168-pin DIMM socket that
accommodates up to 256MB SDRAM. The on board Award BIOS
facilitates easy system configuration and peripheral setup. Other
advanced features include DiskOnChip flash disk support, watchdog
timer, USB and IrDA interface.
DiskOnChip flash disks are storage devices that has no moving parts and
emulates FDD/HDD with Flash/RAM/ROM offering reliable
data/program storage and long life span. They are reliable and suitable for
industrial or other harsh environments characterized by motion, shock,
vibration, adverse temperature, dust and humidity. Other features include
faster data access, longer MTBF, lower power consumption, cost
effective for small capacity and small form factor.
INTRODUCTION
2IB500 User’s Manual
Checklist
Your IB500 package should include the items listed below.
•The IB500 CPU Card
•This User’s Manual
•1 IDE Ribbon Cable
•1 Floppy Ribbon Connector
•2 Serial Port Ribbon Cables and 1 Parallel Port attached to a
Mounting Bracket
•1 CD containing the following:
•Intel PCI IDE Driver and Flash Memory Utility
•VGA Drivers
•Ethernet Drivers
•Initio INIC1060 SCSI Drivers
INTRODUCTION
IB500 User’s Manual 3
Specifications
Processor
Supported Socket 7 processors with CPU frequency up to 400MHz
60MHz/66MHz Front Side Bus
Chipset Intel 430TX PCIset
BIOS Award BIOS
Supports DMI, PnP
System Memory 1x DIMM socket support up to 256MB capacity
Multi I/O Chipset
Winbond W83977EF (keyboard controller is built-in)
I/O Features 1x FDD (up to 2.88MB, 3 Mode, LS120)
1x Parallel Port (EPP, ECP Port)
2x Serial Ports (1x RS232 and 1x RS232/422/485)
1x IrDA TX/RX Headers
Bus Master IDE 2x IDE interfaces for up to 4 devices; supports PIO Mode
3/4 or Ultra DMA/33 IDE HDD, and ATAPI CD-ROM
VGA (option) Using IBD69 MicroPCI VGA card or IBD99 MicroPCI
VGA/LAN Combo card that features:
CHIPS 69000 PCI VGA accelerator
CRT & LCD panel support
2MB integrated memory
Ethernet (option)
Using IBD59 MicroPCI LAN card or IBD99 MicroPCI
VGA/LAN Combo card that features:
Intel 82559 Fast Ethernet controller
10/100Mbps data transfer speeds, WakeOnLAN support
Using IBL39 MicroPCI LAN card that features:
Realtek RTL8139 Fast Ethernet controller
10/100Mbps data transfer speeds, WakeOnLAN support
SCSI (option) Using IBD60 MicroPCI LAN SCSI card featuring:
Initio INIC1060 Ultra 2 SCSI controller
Built-in Ultra2 SCSI connector
Hardware
Monitoring Winbond W83781D IC
Monitors CPU/system temperature and voltages
SSD Interface Supports M-Systems 2MB~144MB DiskOnChip flash disk
Other Features Watchdog timer
Power
Consumption +5V 8A (max)
+/-12V 200mA (max)
Form Factor Half Size, PISA compliant
Dimensions 186mm x 129mm (7.32” x 5.0”)
INTRODUCTION
4IB500 User’s Manual
Board Dimensions
INSTALLATIONS
IB500 User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the IB500 in order to set up a workable system. The topics
covered are:
Installing the CPU.............................................................6
MicroPCI Daughter Card Installation................................6
Installing the Memory (DIMM) .........................................7
Setting the Jumpers...........................................................8
Connectors on IB500 ......................................................17
Watchdog Timer Configuration.......................................30
INSTALLATIONS
6IB500 User’s Manual
Installing the CPU
The IB500 CPU Card supports a Socket 7 processor socket that comes
with a lever to secure the processor. Raise this lever to approximately 90°
to allow the insertion of the processor. Place the processor into the socket
by making sure the notch on the corner of the CPU corresponds with that
of the socket. Once the processor has slid into the socket, return the lever
to the lock position.
After you have installed the processor into the socket, check if the
jumpers for the CPU type and speed are correct. Refer to the section on
Setting the Jumpers.
?
Ensure that the CPU heat sink and the CPU’s top surface are
in total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.
MicroPCI Daughter Card Installation
The IB500 CPU card is integrated with one MicroPCI socketthat uses a
144-pin connector. The socket can accommodate the VGA, Ethernet or
SCSI MicroPCI daughter cards.
To insert the MicroPCI daughter cards, position it at 30°to the PCB and
gently push it into the MicroPCI connector. The card will not fit when
inserted at an angle of 45°or 15°. Once inserted, slowly press the card
towards the PCB until it locks on both sides to the clips of the connector.
Screw the card to the PCB to secure the installation.
