IBM 10G Network Active Bypass Manual de usuario

IBM Security 10G Network Active Bypass

User Guide

Ve r s i o n 3 .4



U.S. Government Users Restricted Rights — Use, duplication or disclosure restricted by GSA ADP Schedule Contract with

IBM Corp.

Publication Date: April 2014

Contents

Homologation statement - regulation

notice................v

Safety, environmental, and electronic

emissions notices ..........vii

About this publication .......xvii

Contacting IBM Support .........xviii

Chapter 1. About the 10G Network

Active Bypass unit ..........1

About the 10G Network Active Bypass unit ....1

Front panel ...............3

Switching modes .............5

Heartbeat settings ............6

Operation modes .............7

TAP ports ...............9

Power failure protection ..........9

SFP and SFP+ transceiver support .......10

Chapter 2. Setting up the 10G Network

Active Bypass unit .........11

Connecting the 10G Network Active Bypass unit on

your network ..............11

Logging in to the management interface .....12

Bypass settings .............13

HA Service ..............16

Bond service ..............16

Link SFP ...............17

Management port settings .........17

System logging .............18

Email notification settings .........19

SNMP settings .............20

NTP and Time Zone settings ........21

Chapter 3. Monitoring the 10G Network

Active Bypass unit from the

management interface ........23

System status..............23

Backup or restore settings .........24

Firmware updates ............25

Port statistics ..............25

User account settings ...........25

Remote authentication: TACACS+ .......26

Alerting capabilities ...........27

Chapter 4. Using the command-line

interface ..............29

Accessing the command-line interface .....29

Command-line parameters .........30

Notices ..............33

Trademarks ..............34

Index ...............35

iv 10G Network Active Bypass V3.4: User Guide

Homologation statement - regulation notice

This product is not intended to be connected directly or indirectly by any means whatsoever to interfaces

of public telecommunications networks.

vi 10G Network Active Bypass V3.4: User Guide

Safety, environmental, and electronic emissions notices

Safety notices may be printed throughout this guide. DANGER notices warn you of conditions or

procedures that can result in death or severe personal injury. CAUTION notices warn you of conditions

or procedures that can cause personal injury that is neither lethal nor extremely hazardous. Attention

notices warn you of conditions or procedures that can cause damage to machines, equipment, or

programs.

DANGER notices

DANGER

To prevent a possible shock from touching two surfaces with different protective ground (earth),

use one hand, when possible, to connect or disconnect signal cables. (D001)

DANGER

Overloading a branch circuit is potentially a fire hazard and a shock hazard under certain

conditions. To avoid these hazards, ensure that your system electrical requirements do not exceed

branch circuit protection requirements. Refer to the information that is provided with your device

or the power rating label for electrical specifications. (D002)

DANGER

If the receptacle has a metal shell, do not touch the shell until you have completed the voltage and

grounding checks. Improper wiring or grounding could place dangerous voltage on the metal shell.

If any of the conditions are not as described, STOP. Ensure the improper voltage or impedance

conditions are corrected before proceeding. (D003)

DANGER

An electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of

the system or the devices that attach to the system. It is the responsibility of the customer to ensure

that the outlet is correctly wired and grounded to prevent an electrical shock. (D004)

DANGER

When working on or around the system, observe the following precautions:

Electrical voltage and current from power, telephone, and communication cables are hazardous. To

avoid a shock hazard:

vConnect power to this unit only with the IBM®ISS provided power cord. Do not use the IBM

ISS provided power cord for any other product.

vDo not open or service any power supply assembly.

vDo not connect or disconnect any cables or perform installation, maintenance, or reconfiguration

of this product during an electrical storm.

vThe product might be equipped with multiple power cords. To remove all hazardous voltages,

disconnect all power cords.

vConnect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet

supplies proper voltage and phase rotation according to the system rating plate.

vConnect any equipment that will be attached to this product to properly wired outlets.

vWhen possible, use one hand only to connect or disconnect signal cables.

vNever turn on any equipment when there is evidence of fire, water, or structural damage.

vDisconnect the attached power cords, telecommunications systems, networks, and modems before

you open the device covers, unless instructed otherwise in the installation and configuration

procedures.

vConnect and disconnect cables as described in the following procedures when installing, moving,

or opening covers on this product or attached devices.

To disconnect:

1. Turn off everything (unless instructed otherwise).

2. Remove the power cords from the outlets.

3. Remove the signal cables from the connectors.

4. Remove all cables from the devices.

To connect:

1. Turn off everything (unless instructed otherwise).

2. Attach all cables to the devices.

3. Attach the signal cables to the connectors.

4. Attach the power cords to the outlets.

5. Turn on the devices.

(D005)

CAUTION notices

CAUTION:

Data processing environments can contain equipment transmitting on system links with laser modules

that operate at great than Class 1 power levels. For this reason, never look into the end of an optical

fiber cable or open receptacle. (C027)

viii 10G Network Active Bypass V3.4: User Guide

CAUTION:

The battery contains lithium. To avoid possible explosion, do not burn or charge the battery.

Do not:

vThrow or immerse into water

vHeat to more than 100°C (212°F)

vRepair or disassemble

Exchange only with the IBM ISS-approved part. Recycle or discard the battery as instructed by local

regulations. In the United States, IBM ISS has a process for the collection of this battery. For

information, call 1-800-426-4333. Have the IBM ISS part number for the battery unit available when

you call. (C003)

CAUTION:

For 19” rack mount products:

vDo not install a unit in a rack where the internal rack ambient temperatures will exceed the

manufacturer's recommended ambient temperature for all your rack-mounted devices.

vDo not install a unit in a rack where the air flow is compromised. Ensure that air flow is not

blocked or reduced on any side, front, or back of a unit used for air flow through the unit.

vConsideration should be given to the connection of the equipment to the supply circuit so that

overloading the circuits does not compromise the supply wiring or overcurrent protection. To

provide the correct power connection to a rack, refer to the rating labels located on the equipment

in the rack to determine the total power requirement of the supply circuit.

v(For sliding drawers) Do not pull or install any drawer or feature if the rack stabilizer brackets are not

attached to the rack. Do not pull out more than one drawer at a time. The rack might become

unstable if you pull out more than one drawer at a time.

v(For fixed drawers) This drawer is a fixed drawer and must not be moved for servicing unless

specified by the manufacturer. Attempting to move the drawer partially or completely out of the

rack might cause the rack to become unstable or cause the drawer to fall out of the rack.

(R001 Part 2 of 2)

Product handling information

One of the following two safety notices may apply to this product. Please refer to the specific product

specifications to determine the weight of the product to see which applies.

CAUTION:

This part or unit is heavy but has a weight smaller than 18 kg (39.7 lb). Use care when lifting,

removing, or installing this part or unit. (C008)

CAUTION:

The weight of this part or unit is between 18 and 32 kg (39.7 and 70.5 lb). It takes two persons to

safely lift this part or unit. (C009)

Safety, environmental, and electronic emissions notices ix

Product safety labels

One or more of the following safety labels may apply to this product.

DANGER

Hazardous voltage, current, or energy levels are present inside any component that has this label

attached. Do not open any cover or barrier that contains this label. (L001)

DANGER

Multiple power cords. The product might be equipped with multiple power cords. To remove all

hazardous voltages, disconnect all power cords. (L003)

World trade safety information

Several countries require the safety information contained in product publications to be presented in their

national languages. If this requirement applies to your country, a safety information booklet is included

in the publications package shipped with the product. The booklet contains the safety information in

your national language with references to the US English source. Before using a US English publication to

install, operate, or service this IBM ISS product, you must first become familiar with the related safety

information in the booklet. You should also refer to the booklet any time you do not clearly understand

any safety information in the US English publications.

Laser safety information

The following laser safety notices apply to this product:

CAUTION:

This product may contain one or more of the following devices: CD-ROM drive, DVD-ROM drive,

DVD-RAM drive, or laser module, which are Class 1 laser products. Note the following information:

vDo not remove the covers. Removing the covers of the laser product could result in exposure to

hazardous laser radiation. There are no serviceable parts inside the device.

vUse of the controls or adjustments or performance of procedures other than those specified herein

might result in hazardous radiation exposure. (C026)

CAUTION:

Data processing environments can contain equipment transmitting on system links with laser modules

that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical

fiber cable or open receptacle. (C027)

x10G Network Active Bypass V3.4: User Guide
