IBM ThinkPad 560X Manual de usuario

Note

Before using this information and the product it supports, be sure to read the general information under “Notices”

on page 231.

First Edition (May 1996)

The following paragraph does not apply to the United Kingdom or any country where such provisions are

inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT ANY

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE LIMITED

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow

disclaimers or express or implied warranties in certain transactions; therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the

information herein; these changes will be incorporated in new editions of the publication. IBM may make

improvements or changes in the products or the programs described in this publication at any time.

Requests for technical information about IBM products should be made to your IBM Authorized Dealer or your IBM

Marketing Representative.

Users – Documentation related to restricted rights – Use, duplication or disclosure is subject to restrictions set forth in

GSA ADP Schedule Contract with IBM Corp.

Thank You for Selecting

an IBM ThinkPad 560 Computer

The thin and light IBM ThinkPad 560 computer

is designed to be convenient

for your mobile computing needs.

We hope you enjoy its fast processing power,

brilliant and colorful DSTN or TFT LCD display,

audio capabilities, and infrared communication.

iii

Distinctive System Features

The following are the distinctive system features of the IBM ThinkPad 560 computer:

ConfigConfig

RestartRestart

Pentium Processor

Lithium-Ion Battery Pack

SVGA Color LCD

Security Features

ThinkPad Features

ESS AudioDrive

Sound Support Features

PCMCIA Support

Fn Key Function

TrackPoint III

Power Management

Infrared Communication

Note: This figure shows a 560 computer with a thin film transistor (TFT) display. However, the

preceding information applies to any type of 560 computer.

iv IBM ThinkPad 560 User's Guide

1Lithium-Ion Battery Pack: Page 55.

The operating time of the computer is extended with the lithium-ion battery pack.

2SVGA Color LCD: Page 45.

The DSTN (dual-scan super-twisted nematic) display models offer 256 colors at 800-by-600

resolution.

The TFT (thin-film transistor) display models offer 65,536 colors at 800-by-600 resolution.

3Infrared Communication: Page 52.

An infrared port for wireless serial communication is supplied with your computer.

4ThinkPad Features Program: Page 29.

The ThinkPad Features program allows you to set various parameters by using a graphical user

interface or commands.

5Power Management: Page 66.

The computer comes with software that allows you to extend battery life by reducing power

usage throughout the computer system. It also provides a resume function, which quickly returns

you to where you left off.

6Security Features: Page 77.

There is a security password for your computer. Lock security also is provided for your

computer, and the Personalization Utilities can help you identify your computer.

7Pentium Processor: Page 219.

The fast Intel Pentium processor gives your computer optimal speed and performance.

8PCMCIA Support: Page 47.

The computer provides two Personal Computer Memory Card International Association

(PCMCIA**) slots that accept a 16-bit PC Card.

9TrackPoint III: Page 18.

Pointing, selecting, and dragging all become part of a single process without your needing to lift

your hands from the keyboard.

1Fn Key Function: Page 20.

The combination of the Fn key with a function key is used to control display output type or

battery power-saving modes.

11 ESS** AudioDrive** Sound Support Features: Page 54.

The ESS AudioDrive sound support features provide various audio features for your

entertainment.

About This Book

Note:

The illustrations in this book might be

slightly different from your computer.

This book contains information that will help you operate the IBM

ThinkPad 560 computer (hereafter called the

560

computer

). Be

sure to read Chapter 1 and Chapter 2 before using the computer.

Read from Chapter 3 on whenever you need to.

Chapter 1, “Getting Started,” provides information about how

to set up your computer.

Chapter 2, “Getting Familiar with Your Computer,” acquaints

you with the basic features of your computer.

Chapter 3, “Operating Your Computer,” provides information

on using your computer's different features.

Chapter 4, “Using Battery Power,” provides power

management information and describes how to operate your

computer with the battery pack.

Chapter 5, “Protecting Your Computer,” provides information

for protecting your computer.

Chapter 6, “Installing and Removing Options,” describes how

to install or remove IBM options.

Chapter 7, “Installing Software,” provides procedures for

installing operating systems and device drivers in your computer.

Chapter 8, “Solving Computer Problems,” describes what to

do when you have a computer problem.

Appendix A, “Avoiding Hardware Conflicts,” lists some steps

you can take to avoid problems when you add or remove

options.

Appendix B, “Advanced Information for PC Cards,” provides

additional information when using PC Cards.

Appendix C, “Using PS2 Commands,” provides the PS2

commands for the ThinkPad Features program.

Appendix D, “Features and Specifications,” describes the

features and specifications associated with your computer.

Appendix E, “Product Warranties and Notices,” contains the

warranty statements for your computer and notices for this book.

The glossary defines terms appearing in this book.

vi IBM ThinkPad 560 User's Guide

Viewing the Online Book

You can view this book online to easily retrieve information about the

computer when you are traveling.

To start the online book, click on the Online Book icon in

OS/2 Warp, Microsoft** Windows** Version 3.11, or Microsoft

Windows 95.

IBM ThinkPad 301 User’s Guide

Starting Easy-Setup

Note: The online book is not available in all countries.

vii

Information Notices This book contains notices that relate to specific information or text.

Note

Attention

Caution

Danger

Usild Lke Sejk

109Chapter2. YoekfBlksd Lekjf

Provides important hints, tips,

guidance, or advice.

Indicates possible damage to

programs, devices, system, or

data. It appears next to the

related instruction or situation

in which possible damage could

occur.

Indicates situations that are

potentially hazardous to you.

It appears in text before the

instruction or situation that

could be hazardous.

Indicates situations that are

potentially lethal or extremely

hazardous to you. It is indicated

by the symbol and appears

in text before the instruction or

situation that could be dangerous.

Using Easy-Setup

Note:

LKjef osijdf lke.

LIej tlkje sfoi efp sl

lkjdf toie sfekjt.

Warning:

LKj tlke fsoiej glkje f

lskjdf oiret e. SKjt

slkfj eoit sf.

Ltke fsoie ltij erlkjs efoitj sdf. The skfeoig

lksjdf otie sfldkj tekjs fdi zdif lkt elskfd.

Pdfk setk sdfk shtke fdij thesdfkl sekj soit

oit skdf 3 lskdti shd gkejt wse. Tkj eoisdjf

tlkjsd.

Caution:

Ljsdkf thkejr fosidj tlkje afshei ldfkue.

Toisdjf sldj ohd flskajt shdf, foiasj.

Danger:

Lskjdt oidsfa thie rsldkj etskdjf xo.

Oijds kj dtah fia glisdjf klasdjt sadf.

LKdkfsa oif lkaj oisdt lskef.

Attention

Treatment of Icons This book contains the following icons (symbols):

For procedures or information unique to the operating system

installed in your computer:

For information referred to:

OS/2

Information for IBM

Operating System/2

(OS/2) users.

DOS

Information for IBM DOS

users.

WIN

Information for Microsoft

Windows Version 3.11

users.

WIN Information for Microsoft

Windows 95 users.

Where to go for more

information.

viii IBM ThinkPad 560 User's Guide

Safety Notice

DANGER

Do not disassemble, incinerate, or short-circuit the

rechargeable battery pack. Do not put it in trash that is

disposed of in landfills. Dispose of it as required by

local ordinances or regulations. In the United States,

call IBM at 1-800-IBM-4333 for information on disposal.

CAUTION:

The lithium battery (IBM P/N 40H6424, UL-recognized

component—File No. MH12560), can be replaced only by your

dealer or an IBM service representative. It contains lithium and

can explode if not properly used, handled, or disposed of. Do

not: (1) throw or immerse into water, (2) heat to more than

100°C (212°F), or (3) repair or disassemble. Dispose of it as

required by local ordinances or regulations.

CAUTION:

The fluorescent lamp in the liquid crystal display (LCD) contains

mercury. Do not put it in trash that is disposed of in landfills.

Dispose of it as required by local ordinances or regulations.

The LCD is made of glass, and rough handling or dropping the

computer can cause the LCD to break. If the LCD breaks and

the internal fluid gets into your eyes or on your hands,

immediately wash the affected areas with water for at least 15

minutes; then get medical care if any symptoms are present

after washing.

Ergonomics Information

This is important information to read before using your ThinkPad

computer in the virtual office.

Working in the virtual office may mean adapting to frequent changes

in your environment. Following some simple “rules of the road” will

make things easier and bring you the maximum benefits of your

ThinkPad computer. Keeping in mind such basics as good lighting

and proper seating, for example, can go a long way in helping you

enhance your performance and achieve greater comfort wherever

you are.

Chair

Head

Display

Thighs

View

Arms

Note: The example shown here of someone in a traditional setting. Even

when not in such a setting, you can follow many of these tips. Develop

good habits, and they will serve you well.

xIBM ThinkPad 560 User's Guide
