IBM 8250 Manual de usuario

8250 Management Modules SA33-0233-04

Command Quick Reference Guide

This guide provides a quick reference to commands and options when you

are operating the following 8250 Management Modules:

●Ethernet Management Module (EMM)

●Token Ring Management Module (TRMM)

●FDDI Management Module (FMM)

This guide includes the following information:

●Terminal Keystroke Functions

●IBM®8250 Management Module Commands

Refer to the 8250 Management Commands Guide

(Document Number SA33-0302) for more information on command use.

sa233.fr5 Page 1 Monday, April 1, 1996 2:31 PM

2 8250 Command Quick Reference Guide

Terminal Keystroke Functions

Table 1 is a quick reference for terminal keystrokes and their functions.

Table 1. Terminal Keystroke Functions

The command table that follows uses the following notations:

1 Command is only available through Maintenance Mode.

2 Command is only available using Advanced EMM software (that is, not

available using Basic EMM, or other 8250 management modules).

3 Command is only available using Advanced TRMM software (that is, not

available using Basic TRMM, or other 8250 management modules).

4 Command is only available using FMM software.

Keystroke Function

Backspace Moves the cursor back one character and deletes that

character.

Ctrl-C Terminates the current command and returns to a blank

command line at any time.

Ctrl-D Closes a TELNET session.

Ctrl-R Retypes the previous command string on the command

line.

Delete Same as Backspace.

Enter Enters the command.

Space Bar Completes a command through command completion.

?Displays the available command options.

sa233.fr5 Page 2 Monday, April 1, 1996 2:31 PM

Management Commands 3

8250 Management Module Commands

In the command table:

●Select commands from the left column, then select parameters from

the right columns.

●User-selectable command variables appear in italic.

Command Parameters

BOOT1

BOOTP

(Not available

for EMM)

CLEAR arp_table

bootp resultTRMM only

community 1 to 10

all

counter all

device

module

network

port

station

slot

slot.port, slot.all

mac address, all

event_log 4

group3all

group1 to group8 slot.port, all,

non_existing

host 1 to 20

all

log 3 system_event2

event_log

trap_log

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 3 Monday, April 1, 1996 2:31 PM

4 8250 Command Quick Reference Guide

CLEAR

(continued) login 1 to 10

all

rmon4alarm

event

host

matrix

ringstation

statistics mac_layer

statistics promiscuous

statistics sourcerouting

topN_hosts

all

index

schedule 31 to 20

all

script 31 to 8

all

security 2, 3

autolearn slot.all

slot.port mac_address address

security 2, 3 intruder_list

security port 2, 3 slot.all

slot.port mac_addressaddress

tftp result2

threshold3all

1 to 10

COPY script 1 to 8

DOWNLOAD inband2

out_of_band2

all_fddi_port_module4

device4

boot 3, 4

flash 3, 4

media 4

LOGOUT

MAINTAIN

Command Parameters

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 4 Monday, April 1, 1996 2:31 PM

Management Commands 5

MONITOR

(EMM and

FMM)

0:05 seconds to

30 minutes module slot

network

port slot.port

MONITOR

(TRMM)

0:05 seconds

to 30 minutes

device

network

port slot.port

station all

station mac_address

top_errors2

top_receivers2

top_senders2

errors, traffic2

1 to 18, all, last value

by_frames,

by_mac_address,

by_octets

PING ip_address

name

ip_address

host name (EMM only)

# of packets, 1

packet

# of packets, 1

packet

REMOTE_

LOGIN2ip_address

mac_address

name

ip address

mac address

name

RESET concentrator

device

mastership

module

power_supply slot

RUN SCRIPT 1 to 8

Command Parameters

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 5 Monday, April 1, 1996 2:31 PM

6 8250 Command Quick Reference Guide

REVERT or

SAVE alert

all

bootp

community

concentrator

device

group3

host

module_port

schedule

scripts

security 2

terminal

threshhold3

tftp 2

SET ALERT authentication

change

console_display 4

filter

hello

port_filter 4

port_up_down filter 2, 3

screen

script

disable, enable

port_up_down disable, enable, filter

SET BOOTP 3 power_up_mode disable, enable

server_ip_address ip address

SET CLOCK time (hh:mm) date (yy/mm/dd) day (day of week)

SET

COMMUNITY all

name ip address, all all, oldall, oldtrap,

read_oldtrap,

read_only,

read_trap,

read_write, trap

SET CONCENTRATOR platform 8250-006, 8250-006_FT,

8250-017

Command Parameters

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 6 Monday, April 1, 1996 2:31 PM

Management Commands 7

SET

COUNTER port_statistics disable, enable

SET DEVICE beacon_recovery disable, enable

beacon_timeout time (0 to 100 seconds)

beacon_trunk_retry value (0 to 255)

contact contact name

default_gateway

ip_address

subnet_mask

ip_address

hex_mask

all (EMM and TRMM)

isolated (EMM)

network_1 (EMM)

network_2 EMM)

network_3 (EMM)

token_ring_1 (TRMM)

token_ring_2 (TRMM)

token_ring_3 (TRMM)

token_ring_4 (TRMM)

token_ring_5 (TRMM)

token_ring_6 (TRMM)

token_ring_7 (TRMM)

diagnostics disable, enable

dip_configuration disable, enable

location location name

monitor_contention disable, enable

name device name

password

(EMM) administrator

user password

password

reset_mastership disable, enable

trap_receive 2 disable, enable

SET DOWNLOAD 2 network 1, 2, 3

Command Parameters

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 7 Monday, April 1, 1996 2:31 PM

8 8250 Command Quick Reference Guide

SET GROUP 3group1 to group8 mode disable, enable

name name

network token_ring_1 (TRMM)

token_ring_2 (TRMM)

token_ring_3 (TRMM)

token_ring_4 (TRMM)

token_ring_5 (TRMM)

token_ring_6 (TRMM)

token_ring_7 (TRMM)

port slot.port

SET HOST host name ip address

SET LOGIN 4administrator

password

super_user

user

access super_user

SET

MODULE slot autopartition_threshold 31_collisions

63_collisions

127_collisions

255_collisions

slot cable_impedance 100ohm, 150ohm

slot connector 1

slot connector 2 network ethernet_1

ethernet_2

ethernet_3

isolated_1

isolated_2

slot crossover disable

enable

slot

(EMM) fifo_fill_level 7

slot

(TRMM) locally_administered_address mac address

slot low_light_warning disable, enable

Command Parameters

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 8 Monday, April 1, 1996 2:31 PM

Management Commands 9

SET MODULE

(continued) slot mac_address_type burned_in

locally_administered

slot mac_path primary, secondary

slot master_network 3 isolated

token_ring_1

token_ring_2

token_ring_3

token_ring_4

token_ring_5

token_ring_6

token_ring_7

no_change

slot mastership_priority 1 to 10

slot module_bypass bypass, insert

slot network ethernet_1

ethernet_2

ethernet_3

fddi_1

fddi_2

fddi_3

fddi_4

isolated

token_ring_1

token_ring_2

token_ring_3

token_ring_4

token_ring_5

token_ring_6

token_ring_7

slot per_port_counters_connector 1, 2

slot probe_mode disable, enable

slot ring_speed 4mbps, 16mbps

Command Parameters

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 9 Monday, April 1, 1996 2:31 PM

10 8250 Command Quick Reference Guide

SET PORT slot.2active_connector db9, rj45

slot.all

slot.port alert disable, enable

slot.port

slot.all alert_filter disable, enable

slot.port

slot.all collision normal, alternate

slot.port

slot.all half_step disable, enable

slot.port

slot.all high_power disable, enable

slot.port

slot.all link_integrity disable, enable

slot.port

slot.all low_light_warning disable, enable

slot.port mode

slot.all mode disable, enable

disable, enable

slot.port mode

slot.all mode local, remote

local, remote

slot.port mode

slot.all mode redundant

non_redundant slot.port

slot.port

slot.port mode

slot.all mode remote_diagnostics

non_remote_diagnostics

slot.port mode remote_failure_signaling

Command Parameters

1 = Maintenance Mode , 2 = Advanced EMM, 3 = Advanced TRMM, 4 = FMM

sa233.fr5 Page 10 Monday, April 1, 1996 2:31 PM
