IBM Advanced SerialRAID/X Manual de usuario

To add extra function to your Advanced SerialRAID/X Adapter, you

must first download the required firmware and software from the SSA

World Wide Web page at:

http://www.hursley.ibm.com/ssa/pcserver

This Installation Guide asks you to install firmware and software from

CD-ROMs and also from diskettes. However, because the code is

only available from the SSA World Wide Web, you must first visit

the above web page, and select ‘Download Latest Code Levels’.

After agreeing to the license, select the correct operating system

and adapter (the Advanced SerialRAID/X Adapter is identified as

‘LL05’).

For Windows NT, download the ‘All in one (ll05)’ package. This

self-extracting package will load the necessary code into the correct

directories as follows:

1. c:\issa\update\driver

which will contain the device-driver software. If asked to load

device-driver software from the CD-ROM, you must instead

load the software from this directory.

2. c:\issa\update\rsm

which will contain the event logger and Remote System

Management (RSM) software. If asked to load the event

logger from the CD-ROM, you must instead load the code from

this directory.

3. c:\issa\update\ssaflash

which will contain the SSA-adapter microcode.

Refer to Chapter 5 of this manual for details about downloading

the SSA-disk-drive microcode.

For NetWare, download the Host Software, Adapter Microcode and

RSM for NetWare packages. These self-extracting packages allow

you to create the required diskettes or data directories.

Advanced SerialRAID/X Adapter: Installation Guide

READ ME FIRST

IBM Advanced SerialRAID/X Adapter

Installation Guide

SA33-3290-02

IBM Advanced SerialRAID/X Adapter

Installation Guide

SA33-3290-02

Note

Before using this information and the product it supports, be sure to read the general information under “Product

Warranties and Notices” included with your system unit.

Third Edition (October 1999)

This major revision supersedes SA33–3290–01. Technical changes are shown by a vertical line to the left of each

change.

The following paragraph does not apply to any country where such provisions are inconsistent with local law:

THIS PUBLICATION IS PRINTED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions;

therefore, this statement may not apply to you.

This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the

information herein; these changes will be incorporated in new editions of the publication. The manufacturer may make

improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time, without

notice.

It is possible that this publication may contain reference to, or information about, products (machines and programs),

programming, or services that are not announced in your country. Such references or information must not be

construed to mean that such products, programming, or services will be offered in your country. Any reference to a

licensed program in this publication is not intended to state or imply that you can use only the licensed program

indicated. You can use any functionally equivalent program instead.

Requests for technical information about products should be made to your authorized reseller or marketing

Government Users — Documentation related to restricted rights — Use, duplication, or disclosure is subject to

restrictions set forth in the GSA ADP Schedule Contract with IBM Corp.

Contents

Safety Information.......................v

About This Book.......................vii

Related Publications ......................vii

ISO 9000..........................vii

Trademarks .........................vii

Chapter 1. Overview ......................1

Handling the Adapter ......................1

Electrostatic Discharge Protection .................1

SSA Connectors........................2

Adapter Card Lights ......................2

Summary of Installation Procedures .................3

Chapter 2. Preparing for Installation ................5

Inventory ..........................5

Determining Your Cable Requirements ................5

Chapter 3. Installing Hardware ..................7

Installing the Adapter ......................7

Connecting SSA Disk Drives....................8

Problem Determination .....................9

Configuring Your System .....................9

Chapter 4. Installing the Device Driver Software and Microcode ......11

Microsoft Windows NT 4.0 ....................11

Installation on an existing server .................11

Installing NT onto an SSA Resource in a New Server ..........13

Verifying the Installation ....................16

Novell NetWare 4.2 ......................18

Installing on an existing server .................18

Installing NW onto an SSA Resource in a new server ..........19

Verifying the Installation ....................21

Novell NetWare 5 .......................21

Installation on an existing server .................21

Installing NW onto an SSA Resource in a new server ..........23

Verifying the Installation ....................24

Chapter 5. Downloading the Latest Microcode ............27

Downloading the Microcode ...................27

Downloading Adapter Microcode ..................27

Downloading Disk Microcode ...................28

Enclosure Controller Microcode (7133 Models D40 and T40) ........29

Checking the Existing Levels of Microcode and Host Software ........30

Appendix A. Connecting SSA Devices to the Adapter ..........31

SSA Loops and Links .....................31

iii

||||

||||||||

Loops and Data Paths ....................31

Rules for SSA Loops ......................34

Subsystem Performance Recommendations ..............35

Appendix B. Communications Statements ..............37

Federal Communications Commission (FCC) Statement ..........37

VCCI Statement .......................37

Electromagnetic Interference (EMI) Statement - Taiwan ..........38

International Electrotechnical Commission (IEC) Statement .........38

Avis de conformitéaux normes de l’Industrie Canada ...........38

Industry Canada Compliance Statement ...............38

United Kingdom Telecommunications Requirements ...........38

European Union (EU) Statement ..................38

Radio Protection for Germany ...................39

iv IBM Advanced SerialRAID/X Adapter: Installation Guide

Safety Information

DANGER

An electrical outlet that is not correctly wired could place a hazardous voltage

on metal parts of the system or the devices that attach to the system. It is the

responsibility of the customer to ensure that the outlet is correctly wired and

grounded to prevent an electrical shock.

Use one hand, when possible, to connect or disconnect signal cables to

prevent a possible shock from touching two surfaces with different electrical

potentials.

During an electrical storm, do not connect cables for display stations, printers,

telephones, or station protectors for communication lines.

CAUTION:

A lithium battery can cause fire, explosion, or a severe burn. Do not recharge,

disassemble, heat above 100°C (212°F), solder directly to the cell, incinerate, or

expose cell to water. Keep away from children. Replace only with the part number

specified for your system. Use of another battery might present a risk of fire or

explosion.

The battery connector is polarized; do not try to reverse the polarity.

Dispose of the battery according to local regulations.

A module on the IBM Advanced SerialRAID/X Adapter contains a lithium battery.

CAUTION:

The Fast Write Cache Option Card contains a nickel-cadmium (NiCad) battery. To

avoid possible explosion, do not incinerate the battery. Exchange only with a

manufacturer approved part. Recycle or discard the battery as instructed by local

regulations and where recycling facilities exist.

vi IBM Advanced SerialRAID/X Adapter: Installation Guide
