I3 International Ax47DC Manual de usuario

User Manual

Please read this guide carefully before you install your Ax47DC.

Keep this guide for future reference.

Rev. 170322

Ax47DC

i3 INTERNATIONAL INC.

1.866.840.0004

www.i3international.com

Canada 780 Birchmount Road,

Unit 16, Scarborough,

ON, M1K 5H4

U.S.A. i3 America Inc.

4450 Witmer Industrial Estates Unit 4

Niagara Falls, NY 14305

i3-TRNG-CAMS-Ax47DC-UM.indd Rev. 170322

Default IP: 192.0.0.16

Default Subnet Mask : 255.255.255.0.

Default User Name: i3admin

Default Password: i3admin

Ax47DC User Manual

No part of this manual may be reproduced or transmitted in any form or by any means,

electronic or mechanical, including but not limited to, photocopying, recording, or by

any information storage or retrieval system, without the prior written permission of the

Annexxus is a registered trademark of i3 International Inc.

Disclaimer

This manual is provided as is, without warranty of any kind, expressed or implied,

including but not limited to performance, merchantability, or fitness for any particular

purpose. Neither i3 International Inc. nor its dealers or distributors shall be liable to any

person or entity with respect to any liability, loss, or damage, caused or alleged to have

been caused directly or indirectly by this information.

Furthermore, i3 International Inc. reserves the right to revise this publication, and to

make changes to the content at any time, without notice.

FCC

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

Scan this QR code or visit www.i3international.com > Media

Library to view and download available user documentation for

this product. Please contact our Technical Support team if you

have any technical questions or require services or support.

Technical Support can be reached by email at:

[email protected] or

by phone Toll Free 1.877.877.7241.QR Code for User

Documentation / ACT

3Rev. 170322i3-TRNG-CAMS-Ax47DC-UM.indd

Table of Contents

Introduction 5

Warnings and operation notes 6

Precautions 6

Power 7

Cleaning 7

Servicing 7

Routine Maintenance 7

Unpacking 8

Accessories 8

Dimensions & Parts Identification 9

Installation 10

Optional Mounting Accessories 10

Door Count Installation Requirements 11

Disassembling the Camera 11

Mounting 12

Camera Wiring Options 12

Axis lens position adjustment 13

Surface Mounting 14

Mounting w/ Ax61BB Back Box (optional) 15

Connect Camera to SRX-Pro Server 16

Hardware/Software Requirements 17

Configuring IE for Video Display 17

RTSP Stream Information 18

Changing Camera’s Default IP 18

Viewing Camera in IE browser 19

Adding Annexxus Camera to SRX-Pro Server. 20

Configuring Door Count in SRX-Pro 22

Advanced Camera Setup via IE 23

Basic Setup 24

Camera Settings (Primary Streaming only) 24

Network settings 25

Video Setup 25

Camera Settings 25

Triple Video Streaming 26

Stream 1 (Primary Streaming) 26

Stream 2 (Secondary Streaming) / Stream 3 (Third Streaming) 27

Advance Settings 27

Video Adjustment 28

Motion Detection (edge) 28

Motion Setting 28

Motion Zone Area Setting 29

Store to SD Card 29

On Screen Display 30

Sending E-mail by MOTION 30

Privacy Zone (edge) 31

Privacy Zone Setting 31

Privacy Zone List 31

Exposure 32

Exposure Mode > Auto Exposure 32

Exposure Mode > Manual Exposure 33

Day Night Setting 33

SD Card (edge recording) 34

SD Card Setting 34

SD Card Status 35

SD Card LifeSpan Notification Setting 36

Recording/Schedule (edge) 37

SMTP Server 37

Email Address List 38

Arming Schedule Setting > SCHEDULE 38

Arming Schedule Setting > DEFOCUS 39

Arming Schedule Setting > TAMPER 40

Communication Setup 41

Network Settings 41

RTSP Settings 41

UPnP Settings 41

OSD Settings 41

User Management 42

Adding a User 43

Deleting a User 43

Changing Username, Password or Permission 43

System Setup 44

Date & Time 44

Restart/Reset 45

Export Configuration 45

Logs 46

Searching by Event Type 46

5Rev. 170322i3-TRNG-CAMS-Ax47DC-UM.indd

1. Introduction

Thank you for purchasing an i3 Ax47DC Door Count Dome Camera.

i3’s Annexxus Ax47DC megapixel IP camera features 1.3MP video resolution. This dome

camera comes with a fixed 2.1mm lens, providing the widest camera view to maximize

the accuracy of traffic count. For best results, the camera must be mounted 8 to 12 feet

(3.65 meters) above the floor and 4 feet (1.22m) back from the center of the door.

For traffic count, SRX-Pro Server VC (VisionCount) license must be purchased (sold

separately).

This camera delivers triple streaming performance and supports H.264 and Motion

JPEG video compression. H.264 codec allows for faster and more efficient video

transmission over the network.

This moisture-, dust- and vandal-resistant dome camera is IP67-certified and IK10-

compliant and comes in an aluminum casing. Annexxus 47DC model requires PoE

power.

The Ax47DC camera is designed specifically for indoor Door Counting applications in

combination with i3’s SRX-Pro and CMS.

The Ax47DC camera is backed by i3’s superior 3-year parts and 1-year labor warranty

policy as well as 2-for-1 policy. Please read i3’s Limited Warranty for more information:

http://i3international.com/tools/media/medialibrary/PDF/Polices/limited_product_warranty.pdf

i3-TRNG-CAMS-Ax47DC-UM.indd Rev. 170322

2. Warnings and operation notes

Please read this guide carefully before you install the camera.

Keep this guide for future reference.

If the camera needs to be modified or repaired, contact a certified i3 International

Dealer/Installer. When serviced by unauthorized technician, the camera warranty will

be voided. Should you have any problems or questions regarding our products, contact

your local i3 International Dealer/Installer.

WARNING! To reduce the risk of fire or electric shock, do not

expose the product to rain or moisture.

Camera’s default IP address is 192.0.0.16

Camera’s default Subnet mask address is 255.255.255.0.

Default camera User Name: i3admin and default Password: i3admin

2.1 Precautions

Installation and servicing should be performed only by qualified and

experienced technicians to conform to all local codes and to maintain your

warranty.

When installing your Ax47DC camera, be sure to avoid:

• excessive heat, such as direct sunlight or heating appliances

• contaminants such as dust and smoke

• strong magnetic fields

• sources of powerful electromagnetic radiation such as radios or TV transmitters

• moisture and humidity

• areas with mechanical vibrations

• fluorescent lamps or objects that reflect light

• unstable light sources as this may cause flickering

• temperatures below -20°C (-4°F) and above 50°C (122°F)

7Rev. 170322i3-TRNG-CAMS-Ax47DC-UM.indd

2.2 Power

This camera supports PoE power only. IEEE 802.3af Class 3, max load of 8.5W.

Incorrect voltage may cause irreparable damage to the video camera and will

effectively void the camera warranty. For PoE power, insert the RJ45 cable into the

RJ45 jack on the camera’s cable. Connect the other end of the RJ45 cable to a

compatible PoE switch/hub/router.

2.3 Cleaning

• For maximum optical clarity, the camera or lens must remain clean. Use a soft, dry

cloth to remove finger prints and dust from the dome cover.

• Use a blower to remove dust from the lens.

• Clean the body with a soft, dry cloth. If it is very dirty, use a cloth dampened with a

small quantity of neutral detergent, then wipe dry.

• Do not use volatile solvents such as alcohol, benzene, or thinners, as they may

damage the surface finish.

2.4 Servicing

To avoid electrical shock and to preserve the product warranty, DO NOT disassemble

the camera. Refer servicing to qualified personnel only.

2.5 Routine Maintenance

• The dome bubble is an optical part. Use a soft and dry cloth to remove any

fingerprints and dust.

• Clean the camera housing with a soft and dry cloth. For more stubborn marks, use

a cloth dampened with a small quantity of neutral detergent, then wipe dry.

• CAUTION: Do not use volatile solvents such as alcohol, benzene or

thinners, as they may damage the surface finish.

i3-TRNG-CAMS-Ax47DC-UM.indd Rev. 170322

3. Unpacking

Ensure that the items received match those listed on the order form and the packing

slip. In addition to this manual and a fully assembled camera, the dome camera

packing box includes:

1. Drill Template sticker x1

2. Torx key x1

3. Plastic Anchor x3

4. Round Head Screw (Tapping type) x3

5. Desiccant (attach to the inside of the Inner Liner) x1

6. 3-ft network cable x1

If any parts are missing or damaged, contact the dealer you purchased the camera

from.

*Note: Based on installation location and surface type, supplied screws and anchors

may not be adequate. Mounting hardware is site-specific and may need to be supplied

by the installer.

3.1 Accessories

3-Ø4.5 holes

( for plastic anchor )

Cable hole

Logo Direction

1 2 3 4

5 6

(not to scale)

9Rev. 170322i3-TRNG-CAMS-Ax47DC-UM.indd

4. Dimensions & Parts Identification

Ax47DC dome camera is designed for indoor installation in commercial environment

specifically for Door Counting installations. The camera installation must comply with

installation requirements (see Installation section for more information).

50.5 mm

110.97 mm

82 mm

i3-TRNG-CAMS-Ax47DC-UM.indd Rev. 170322

1. Mounting holes (x3)

2. Dome bubble housing / Dome cover

3. Screws securing the dome bubble housing to camera module (x3, silver)

4. Lexan bubble

5. Screws attaching camera module to the camera base (x4, black)

6. Lens base. Rotate to adjust lens.

7. Camera Lens Assembly. Pan to adjust lens.

8. Tilt Bracket with two locking screws. Loosen the screws and tilt to adjust lens angle.

9. Inner Liner / Shroud. Attach the desiccant tot he inside of the inner Liner, without

obstruction the lens movement.

10. Camera lens.

11. RJ45 Ethernet PoE Port with waterproof RJ45 connector assembly.

Insert an Ethernet cable into the port for network connection as well as PoE (Power

over Ethernet) capability. To maintain water-resistant rating in outdoor installations,

make sure to use the included waterproof RJ45 Connector assembly.

12. Reset/Default button. Press for 1 second to reboot the camera. Press for 6 seconds

to restore camera settings to factory defaults.

13. Micro SD Card slot for on-camera video storage. (Micro SD card sold separately).

5. Installation

Optional Mounting Accessories

• Ax61BB (Back Box 3/4” & 1/2” NPT). Use for pendant mount, or pole mount.

• DB60 (Goose Neck Bracket 3/4” NTP). Together with the optional DB60CPM

bracket, DB60 goose neck bracket has the capability of being pole-mounted.

• DB60CPM (Pole Mount bracket for DB60)

Important. Please Read:

• It is the installer’s responsibility to ensure that the mounting surface is suitable

for the chosen installation method.

• Based on installation location and surface type, supplied screws and anchors

may not be adequate.

• Mounting hardware is site-specific and may need to be supplied by the

installer.

Tabla de contenidos

Otros manuales de Cámara de seguridad de i3 International

i3 International

i3 International Ax52 Series Manual de usuario

i3 International

i3 International C-AX401C1MN Manual de usuario

i3 International

i3 International Ax32V Series Manual de usuario

i3 International

i3 International Di721 Manual de usuario

i3 International

i3 International Ax46 Series Manual de usuario

i3 International

i3 International i3F417U Manual de usuario

i3 International

i3 International Ax41C1M Manual de usuario

i3 International

i3 International M71 Manual de usuario

i3 International

i3 International Ax52D2MV Manual de usuario

i3 International

i3 International Ax68R Manual de usuario

i3 International

i3 International Ax49D Manual de usuario

i3 International

i3 International C-AX401D1M Manual de usuario

i3 International

i3 International ANNEXXUS Ax41V1MVR Manual de usuario

i3 International

i3 International H59B2 Manual de usuario

i3 International

i3 International Annexxus 52C Manual de usuario

i3 International

i3 International Ax47R series Manual de usuario

i3 International

i3 International M75 Manual de usuario

i3 International

i3 International M77R2 Manual de usuario

i3 International

i3 International i3R363 Manual de usuario

i3 International

i3 International Ax63Z Series Manual de usuario

i3 International

i3 International Ax61 series Instrucciones de funcionamiento y mantenimiento

i3 International

i3 International Ax73RM-series Manual de usuario

i3 International

i3 International Ax63C Instrucciones de funcionamiento y mantenimiento

i3 International

i3 International Am52R Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario

i3 International Ax47DC Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas
