I-Tech RKP1015 Manual de usuario

User

Manual

RKP1015 /1017

1U15 /17 TFTLCDMonitor

KeyboardDrawer

RKP1015/ RKP1017 UserManual

Rev. : 1.0

P.1

1.TableofContent P.1

2.Introduction P.2

3.Features P.2

4.PackageContents P.3

5.Optional Accessories P.4

6.PeripheralProducts P.4

7.ImportantSafeguards P.5

8.StructureDiagram P.6

9.DimensionDiagram

RKP1015 P.7

RKP1017 P.8

10.LCD OSDMenuOperation

LCD MembraneDiagramP.9

MainMenu P.9

Sub MenuP.10-11

11.ResolutionSettings

ForWindowsP.12

ForSunServersP.13

12.TechnicalSpecification P.14

1.TableOfContent

Rev. : 1.0

P.2

RKP Seriesisacombination ofkeyboard,mouseand monitorintoadrawer,

withfeaturessuchasflip-updesign, adjustablebrackets,builtinLCD OSDto

provide effectiveassistant foran administratortocontrolPCsystem.

RKP Seriesprovidescosteffectiveforyourlimited ITbudgetoverusingCRT

and rack mounting. Also, it willbe spacesavingforyourcompact environment

rack and effectiveassistant foran administratortocontrolPCsystem.

2.Introduction

3.Features

1Uheight, separatesliding screen andkeyboardusing unique minia-

tureCyberslides

Adjustablemounting bracketsfrom390 to790mm (front torear19

mount)

Lightweight aluminiumconstruction—withblackanodisefinish

SlimSizekeyboardwithGlidePoint

TM touchpad mouse

StandardD-Sub15-pinVGAinput connector

Suppliedwith12V5Aremotepoweradapter(singlepowerresource)

BuiltinOnScreen Displaycontrolledbyintegralmembrane switches.

Uniquemechanicaldesigntomaximizerack mountablespace

Uniquemonitorflip-up design allowsviewing through closed glass door

of cabinet.

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation.

RKP1015/ RKP1017 UserManual

Rev. : 1.0

P.3

4.PackageContents

Before Unpacking

It isvery importanttolocatetheLCD KeyboardDrawerinasuitableenvironment.

The surfaceforplacingand fixing the LCDKeyboardDrawershouldbe stableand levelor

mounted intoasuitablecabinet.

Makesuretheplacehasgood ventilation,isoutofdirectsunlight,awayfromsourcesof

excessivedust, dirt,heat, water,moistureand vibration.

Convenienceforconnecting the LCD KeyboardDrawertothe related facilitiesshouldbe

well considerstoo.

Unpacking

The LCD keyboarddrawercomeswiththe standardpartsshownasabove.Checkand make

suretheyareincluded and ingood condition.Ifanything ismissing,ordamage,contactthe

supplierimmediately.

LCD Monitor1Piece

UserManual1Piece

DCPowerAdapter1Piece

PowerCord1Piece

Mounting Bracket1Pair

Fasteners4Pieces

CD-63-in-1KVMcable1Piece

RKP1015/ RKP1017 UserManual

Rev. : 1.0

P.4

5.OptionalAccessories

SUN-31SUN/ iMacUSBtoPS/2Adapter

12V/ 24V/ 48VDCPower

VideoInput

6.PeripheralProducts

ModelDescription

CV-401 /CV-801 /CV-16014-Port/8-port/16-PortPS/2KVMswitch

CV-160216-Port2-ConsolePS/2KVMswitch

CV-S801 /CV-S16018-Port/16-portUSBKVMswitch

CV-S160216-port2-ConsoleUSBKVMswitch

CV-101CAT.5PS/2KVMextender

RKP1015/ RKP1017 UserManual

Rev. : 1.0

P.5

Pleaseread allof theseinstructionscarefullybeforeyou usethe device.

Savethismanualforfuturereference.

UnplugtheLCD KeyboardDrawerfromthepoweroutletbeforecleaning.

Donotsprayliquidcleanersoraerosoldirectlyonthedevice.Wetaclothwitha

neutraldetergent(e.g.cleanwater) andsqueezeittight,then cleanthe screen

slightlywithit.

Donotexposethe LCDKeyboardDrawerdirectlytorain,water,moistureor

sunlight.

Avoidpressureonthe LCD screentopreventpermanentdamagetothedisplay.

Donotattempttoservicethe deviceyourself.Improperoperationmayvoidyour

warranty. Referall servicingtoqualifiedservicepersonnel.

Safestorage environment oftheLCD KeyboardDrawerisrangingbetween –20oC

and60oC.Permanent damagecouldoccuriftheLCD KeyboardDrawerisstored

outside thesaferange.

UnplugtheLCD KeyboardDrawerimmediatelyand call qualifiedserviceperson-

nelunderthefollowingconditions:

1.The VGAsignalcordisfrayedordamaged.

2.Ifthe monitorhasbeenexposedtorain,liquidorwater.

3. Ifthe monitorhasbeendroppedorthecasinghasbeendamaged.

Whatthewarrantydoes notcover

1.Anyproduct,onwhichtheserialnumberhasbeendefaced,modifiedor

removed.

2.Damage,deteriorationormalfunction resulting from:

a)Accident,misuse,neglect,fire,water,lightning,orotheractsofnature,

unauthorized productmodification,orfailuretofollowinstructionssupplied

withthe product.

b)Repairorattemptedrepairbyanyonenotauthorized byus.

c)Anydamageof theproductduetoshipment.

d)Removalorinstallationof the product.

e)Causesexternaltotheproduct, suchaselectricpowerfluctuation orfailure.

f)Useof suppliesorpartsnot meetingourspecifications.

g)Normalwearand tear.

h)Anyothercauseswhichdoesnotrelatetoaproduct defect.

3. Removal, installation, andset-upservicecharges.

7.Important Safeguards

RKP1015/ RKP1017 UserManual

Rev. : 1.0

P.6

8. StructureDiagram

1.PS/2keyboard

2.Aluminiumfrontpanel

3.Class AactivematrixTFT LCD panel

4.Rearmetalcase

5.Analogtodigitalsignalconverter board

6.LCD inverter

7.LCD membrane

8.Ball bearing telescopicslides

9.Adjustablemountingbracket

10.OptionalKVMmembrane&KVMswitchboard

RKP1015/ RKP1017 UserManual

•‚ƒ„…

Š ‡ˆ

†

‰

Rev. : 1.0

P.7

RKP10151U15 LCD Keyboard Drawer

9.Dimension Diagram

RKP1015/ RKP1017 UserManual

15 LCD

Rev. : 1.0

P.8

RKP10171U17 LCD KeyboardDrawer

9.Dimension Diagram

RKP1015/ RKP1017 UserManual

17 LCD

Rev. : 1.0

P.9

10.LCD OSDMenuOperation

LCD MembraneDiagram

Left Right Exit

Menu/SelectionPower

MAINMENU

BRIGHT/CONTRAST

AUTOADJUST

PHASE/CLOCK

H/VPOSITION

MISC

RESET

MainMenu

Bright/ Contrast

Toenterintothe Bright, Blacklevel&Contrast sub-menu

AutoAdjust

Toperformautomaticoptimisationsof allfunctions

An “Adjusting message isdisplayed duringthe process

Phase / Clock

Toenterintothe phase&clock sub menu

H/VPosition

Toenterintothe H/VPosition sub-menu

MISC

Toenterintothe MISCsub-menu

Reset

Reset tothedefaultfactorysettings

RKP1015/ RKP1017 UserManual
