WS250/WS400/WS500
INSTRUCTION MANUAL
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 2of 28 ISSUE 3: 11/6/19
© Copyright
CONTENTS
CONTENTS...........................................................................................................................................................2
INTRODUCTION..................................................................................................................................................3
OPERATION .........................................................................................................................................................4
Initial set up:.......................................................................................................................................................4
MAINTENANCE...................................................................................................................................................7
SPECIFICATIONS ................................................................................................................................................8
FAULT FINDING..................................................................................................................................................9
Mechanical .........................................................................................................................................................9
Electrical.............................................................................................................................................................9
FITTING AMERGRAPH CABLE TO SLIPRING................................................................................................11
FITTING C1 CONNECTOR TO AMERGRAPH CABLE....................................................................................14
FITTING ANGLE PLUG TO AMERGRAPH CABLE.........................................................................................15
FITTING TEE PLUGTO AMERGRAPH CABLE ...............................................................................................17
PART LIST ..........................................................................................................................................................18
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 3of 28
© Copyright
INTRODUCTION
The HyQuest Solutions Models WS250, WS400 and WS500 Gauging Winches are our latest
generation of portable type single drum winches. The WS250/400/500 is used in conjunction with a
current meter and a gauging weight for the measurement of water flow in streams where wading is a
difficult task, hence measurement is performed from a boat or a bridge.
All models are fitted with an automatic “Weston” brake assembly that will hold the load in position
once the crank handle is stopped. Hence, to operate the winch and lower the suspended current
meter/gauging weight, it is necessary to rotate the handle in a counter-clockwise position.
They are also fitted with amergraph cable and a C1 connector ready for operation with a current
meter. As an option our SAN22SS stainless steel winch board and outrigger can be provided (see
page 4 of this manual.)
ISSUE 3:11/6/19
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 4of 28
© Copyright
OPERATION
The current meter can be fitted with a stabiliser tail fin which is attached to a hanger bar and
Colombus gauging weight in sizes of 7, 15, 23, 34, 45 and 68 Kg. This assembly is suspended from
the WS250/400/500 gauging winch with armoured signal cable.
HyQuest Solutions provides a range of counters to operate with the WS250/400/500 winch. The
models available are CMC20A, CMCsp, PVD100, PVD200 and the HydroTab/CMCbt android
device.
Initialsetup:
Remove the winch from the carry case.
Fit handle, washer and M10 retaining screw onto the shaft of the winch. Use the supplied
“Allen Key” to tightly lock the retaining screw.
For light gauging
weights use this
position on the handle
For heavy gauging weights,
use this position on the handle
to gain more torque
ISSUE 3:11/6/19
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 5of 28
© Copyright
Fit the winch to the required location such as the winch board or the A Reel trolley using the
supplied bolts and washers.
Wind off sufficient cable to attach gauging weight and current meter.
Connect pulse counter and check operation by spinning the Fan/cup wheel on the current
meter.
Using the Winch Board
All models can be used with the HyQuest Solutions Winch board model SAN22SS. Due to the wide
drum width on the Model WS500 it is not suitable for the 3WBC or 4WBC Bridge Crane products.
Note:
The Winch Board is light weight and is easily handled for performing boat or
bridge gauging. The WS250/400/500 is mounted to the winch board using the 4
mounting holes on the bottom of the frame and the 4 bolts supplied with the
winch.
SAN22SS Winch Board used for gauging a
stream from a bridge or from a boat
ISSUE 3:11/6/19
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 6of 28
© Copyright
Using the A Reel Trolley
Note:
The WS250/400 is mounted to the 3WBC Bridge Crane using the 4 mounting
holes on the bottom of the frame and the 4 bolts supplied with the winch.
A Reel Trolley used to perform gauging
from a bridge.
ISSUE 3:11/6/19
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 7of 28
© Copyright
During Operation
Rotate the handle in a counter-clockwise direction until the “underside” of the gauging weight
touches the surface of the water.
At this instance, you need to reset the mechanical counter on the winch. Please note do not
reset the counter while rotating as it may cause the number reels to momentarily jam. If this
happens, stop rotating the handle and then press the reset button again.
•Lower the current meter and weight to 0.2m, 0.6m or0.8m of the water level and measure
the velocity
MAINTENANCE
TheonlymaintenancerequiredistolightlyoilorgreasetheLayerwindingscrew
periodically.Thisusuallyisrequirediftheleadscrewappearstobe“dry”orifthe
sheaveisemitting“squealing”noisewhenrotating.
Mechanical Counter
Layer Winding Screw
ISSUE 3:11/6/19
HyQuest Solutions Pty Ltd
Page 8of 28
SPECIFICATIONS
70kg (154 lbs) maximum when used with the 4WBC bridge crane (Models
WS250 and 400 only).
45Kg ( 99lbs) when used stand alone on a SAN22SS winch frame or with
the 3WBC bridge crane. (all Models)
Cast Aluminium, 320mm (12.6”) Circumference.
Robust Stainless Steel Grade 304, Powder Coated.
Six digit resettable, registering depth in centimeters, 1cm resolution
(Imperial 1/10 of a foot)
Carry handle and light weight
Positive Weston Brake will hold the load in any position
Winch Model Capacity Using 2.5mm
(1/10”) Dia. Cable
(Supplied Standard)
Capacity Using 3.2 mm
(1/8”) Dia. Cable
(available on request)
WS250 25m (84ft) 20m (65ft)
WS400 40m (131ft) 30m (99ft)
WS500 50m (164ft) 40m (131ft)
4 x M10 mounting holes for winch board with outrigger model SAN22SS
4 x M10 mounting holes for A reel trolley
Manual
Winch
Model Length
(mm)& (inch) Width
(mm)& (inch) Height
(mm)& (inch) Weight
(Kg) & (lb)
WS250 341mm (13.4”) 210mm (8.3”) 230mm (9”) 15Kg (30 lb)
WS400 460mm (18”) 210mm (8.3”) 230mm (9”) 17Kg (38 lb)
WS500 540mm (21”) 210mm (8.3”) 230mm (9”) 23Kg (50 lb)
Load Capacity:
Sounding Drum:
Frame:
Counter:
Portable:
Brake:
Drum Capacity:
Mounting:
Operation:
Dimensions:
Packing Details:
WS200/WS300/WS500
© Copyright
Supplied in aluminum carry case
Winch
Model Length
(mm)&
(inch)
Width
(mm)&
(inch)
Height
(mm)&
(inch)
Weight
(Kg) &
(lb)
Volume
M3
WS250 461mm
(13.4”) 280mm
(11”) 270mm
(10.6”) 25Kg
(30 lb) 0.04
WS400 580mm
(23”) 280mm
(11”) 270mm
(10.6”) 27Kg
(38 lb) 0.044
WS500 660mm
(26”) 280mm
(11”) 270mm
(10.6”) 33Kg
(50 lb) 0.05
ISSUE 3:11/6/19
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 9of 28
© Copyright
FAU LT FINDING
Mechanical
Fault Symptom Possible Cause Action
Counter not registering -Counter was reset while rotating
handle -Reset counter in a stop
position
-Counter gear loose on shaft - Tighten Grub Screw
Weston brake will not
disengage -Seizure due to prolonged period
without use-Attach heavy load to
cable and pull or hit the
handle sharply in the
lower direction (Anti-
Clockwise). Repeat
several time and if
unsuccessful; remove
brake assembly for
inspection.
Weston brake slips in “raise”
mode -Ratchet wheel, friction disc and
drum end surfaces not “bedded-
in”
-Attach light load to
cable and wind up and
down several times with
Weston brake engaged.
If no improvement,
dismantle and check for
grease on friction
surfaces.
Layer winding sheave not
freely running, emitting
“squealing” noise or lead
screw dry
-Shaft dirty - Remove from winch
and clean sheave and
shaft separately. Lightly
oil or grease after re-
installing
-Thread damaged -Repair damaged thread
with file. Lightly oil or
grease after re-installing
-ThreadDry -Lightly oil or grease
Electrical
Fault Symptom Possible Cause Action
Current meter counter not
registering -Counter faulty -Bridge positive and
negative terminals on
counter. If no signal,
repair counter
-Lead damaged - Connect lead to counter
and bridge other end. If
no signal, lead faulty.
Replace or repair ends.
-Earth (Black) terminal is faulty -With lead connected to
winch, bridge red
terminal to frame. If no
signal terminal loose or
corroded.
ISSUE 3:11/6/19
HyQuest Solutions Pty Ltd
WS200/WS300/WS500 Page 10 of 28
© Copyright
-Damaged brush or terminal wire
-Wiring to slipring break
-Bridge slipring towinch
frame. If signal emits
that means proper circuit
between brush and red
terminal. If no signal,
loose red terminal
connection, broken, or
brush sticking. To check
condition of brush
remove signal adaptor
by unscrewing the black
terminal and the
mounting screw. Ensure
that brush and spring
move freely insignal
adaptor housing or
repair with file and
extend the spring.
-Check the wire on the
slipring if loose or
broken. If broken see
section fitting
amergraph cable to
slipring.
Fault Symptom Possible Cause Action
Current meter counter
registering continuously -Faulty lead -Fit lead to counter only.
Signal shows internal
short circuit in lead.
Inspect for break or
damage.
-Current meter or angle plug are
faulty -Disconnect meter. If
signal still emitting
continuously. Check the
earth inside angle plug
or damage to cable
between meter and
gauging weight. If
signal stops emitting
continuously repair the
current meter.
-Meter suspension cable is
damaged, or slipring wires
earthing to drum end
-With lead connected to
winch, bridge red
terminal to frame. If no
signal terminal loose or
corroded.
ISSUE 3:11/6/19
