ESBDVS

Technical Data Sheet

P/N 0474007_B

NSF®Certified

December 2006

Item Part # Description Wiring Item #

FAN ASSEMBLIES AND THERMOSTATS

A. 0392457 Fan Motor, Evaporator (120V) (1)

(MO.4410101)

0409511 Fan Blade (120V) (FB.0409511)

embossing toward motor

0436517 Fan Motor, Evaporator (230V)

(MO.4410105)

0409512 Fan Blade (230V) (FB.0409512)

embossing toward motor

B. 0404551 Fan Motor, Ambient (120V) (2)

(MO.0404551)

0404552 Fan Motor, Ambient (230V)

(MO.4410590)

C. 0382028 Standard Non-adjustable (3)

Defrost Thermostat

(CT.0382028)

D. Optional Adjustable Refrigeration Thermostat(4)

0353949 (CT.4481087)

Item Part # Description Wiring Item #

HEATERS

E. 0460453 Heater, Ambient (120V) (5)

(HE.4850579)

E. 0461866 Heater, Ambient (230V) (6)

(HE.4850646)

LAMPS AND BALLASTS

F. 0355716 Ballast, Electronic, 2 lamps

(120V) (BA.0355716) (7)

F. 0355398 Ballast, Electronic, 3 lamps

(120V) (BA.4480118) (8)

F. 0440215 Ballast, Electronic, 2 lamps

(230V 50-60 Hz) (BA.4481267) (7)

F. 0428652 Ballast, Electronic, 3 lamps

(230V 50-60 Hz) (BA.4480897) (8)

0385104 Ballast Transformer

(230V 50-60 Hz, per ballast)

(TR.4481191)

G. Fluorescent Lamp (9)

Replace with like fixtures

We reserve the right to change or revise specifications

and product design in connection with any feature of

our products. Such changes do not entitle the buyer to

corresponding changes, improvements, additions or

replacements for equipment previously sold or shipped.

U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM

HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. ESBDVS Technical Data Sheet2 of 6

26 1/4

(667)

(1168)

29 3/8

(746)

35/8 (92)

33 1/4

(845)

Legs

Water Seal

Front

Refrigeration

Outlet

Electrical

Waste Outlet

Elite Meat & Delicatessen

Straight Hinged Glass Models

Engineering

Plan Views

4 ft 6 ft 8 ft 12 ft

General

(A) Case Length (without ends or partitions) 48 1/4(1226) 72 3/8(1838) 96 3/8 (2448) 144 1/2(3670)

Maximum O/S dimension back to front (with bumper) 46 (1168) 46 (1168) 46 (1168) 46 (1168)

Back of case to front of front panel 33 1/4 (845) 33 1/4 (845) 33 1/4 (845) 33 1/4 (845)

RH end of case to outside edge of external support 1 5/8(41) 1 5/8(41) 1 5/8(41) 1 5/8(41)

Distance between edges of

external support and center support NA 28 1/2(724) 40 5/8 (1032) 40 5/8 (1032)

Distance between edges of center supports NA NA NA 44 (1118)

Distance between edges of external supports 37 (940) NA NA NA

Electrical Service (Electrical Field Wiring connection point)

RH End of case to center of farthest knockout 10 3/8 (264) 10 (254) 10 1/4 (260) 10 1/4 (260)

Back of case to center of end knockout 3 5/8 (92) 3 5/8 (92) 3 5/8 (92) 3 5/8 (92)

(B) RH End of case to RH end of raceway 5 (127) 5 (127) 5 (127) 5 (127)

Waste Outlet

(D) RH End of case to the center of waste outlet 24 (610) 24 1/8 (613) 24 1/8 (613) 72 1/4 (1835)

LH End of case to the center of waste outlet 24 1/4 (616) 48 1/4 (1226) 72 1/4 (1835) 72 1/4 (1835)

Back O/S of case to center of waste outlet 26 1/4 (667) 26 1/4 (667) 26 1/4 (667) 26 1/4 (667)

Water Seal

Edge of water seal to center of waste outlet 4 (102) 4 (102) 4 (102) 4 (102)

Outside diameter of the drip pipe 1 1/2 (38) 1 1/2 (38) 1 1/2 (38) 1 1/2 (38)

(Field installed water seal outlets, tees, and connectors

are shipped with the merchandiser.)

Refrigeration Outlet

Back of case to center of refrigeration outlet 29 3/8 (746) 29 3/8 (746) 29 3/8 (746) 29 3/8 (746)

(E) RH end of case to center of refrigeration outlet 8 1/4 (210) 8 1/4 (210) 8 1/4 (210) 8 1/4 (210)

Dimensions shown as in. and (mm).

REFRIGERATION DATA

Note: This data is based on store temperature

and humidity that does not exceed 75°F and

55% R.H.

ESBDVS

Discharge Air (°F) 25

Evaporator (°F) 20

Unit Sizing (°F) 18

Btu/hr/ft ESBDVS

Parallel 315

Conventional 380

DEFROST DATA

ESBDVS

Frequency (hr) 12

Defrost Water (lb/ft/day) 0.5

(± 15% based on case configuration and

product loading).

OFFTIME ESBDVS

Temp Term (°F) 43

Failsafe (minutes) 90

ELECTRIC OR GAS Not Recommended

Standard Defrost Thermostat

Close on rise: close 43°F — open 33°F

CONVENTIONAL CONTROLS

Low Pressure Backup Control

ESBDVS

CI/CO (Temp °F)*13

Indoor Unit Only, Pressure Defrost

Termination (Temp °F)*

Not Recommended

*Use a Temperature Pressure Chart to

determine PSIG conversions.

PHYSICAL DATA

Merchandiser Drip Pipe (in.) 1 1/2

Merchandiser Liquid Line (in.) 3/8

Merchandiser Suction Line (in.) 5/8

Estimated Charge (lb)**

4 ft 0.8

6 ft 1.2

8 ft 1.5

12 ft 2.0

**This is an average for all refrigerant types.

Actual refrigerant charge may vary by

approximately half a pound.

Length Added to Lineup by Each End

and Partition 1 in.

3 of 6P/N 0474007_B HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

(457)

52 7/8

(1343)

(1168)

25 1/2

(648)

17 3/8

(441)

4(102)

27 1/4

(692)

33 1/4

(845)

26 1/4

(667)

29 3/8

(746)

13 1/4

(337)

(508)

(584)

30 7/8

(784)

19 3/4

(502)

12 3/4

(324)

ESBDVS

Refrigeration

Outlet

Electrical

COIL

FA N

Dimensions shown as in. and (mm).

Impact Elite ESBDVS

Meat & Delicatessen

Elite Straight Hinged Glass, Blower, 3 Display Level

NSF Certification

These merchandisers are manufactured to meet ANSI /National Sanitation

Foundation (NSF ®) Standard #7 requirements.

HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. ESBDVS Technical Data Sheet4 of 6

Impact Elite ESBDVS

Meat & Delicatessen

Electrical Data

Number of Fans 4 ft 6 ft 8 ft 12 ft

Refrigeration (120V 60hz) – 4W 1 2 2 3

Ambient Air Wipe – 15W 2 4 4 6

Export Refrigeration (230V 50 hz ) – 4W 1 2 2 3

Export Ambient Air Wipe – 15W 2 4 4 6

Amperes Watts

Merchandiser 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft

Refrigeration Fans

Standard (120V 60hz) 0.31 0.62 0.62 0.93 24 48 48 72

Energy Efficient (120V 60hz) 0.14 0.28 0.28 .42 10 20 20 30

Export (230V 50 hz) 0.18 0.36 0.36 0.56 27 54 54 81

Ambient Air Wipe Fans

Standard (120V 60hz) 0.52 1.04 1.04 1.56 45 90 90 135

Export (230V 50 hz) 0.30 0.60 0.60 0.90 50 100 100 150

Constant-on Anti-Sweat Heaters (On/Off Switch Optional)

Standard (120V 60hz) 3.34 6.68 6.68 10.02 400 800 800 1200

Export (230V 50 hz) 1.74 3.48 3.48 5.22 400 800 800 1200

Minimum Circuit Ampacity

With Standard Fans (120V 60hz) 3.95 7.69 7.69 11.44

With Energy Efficient Fans (120V 60hz) 3.78 7.35 7.35 10.93

With Export Fans (230V 50 hz ) 2.20 4.20 4.20 6.21

Maximum Over Circuit Protection 120V 20

Maximum Over Circuit Protection 230V 15

Standard Lighting* (120V 60hz) 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft

2 Row Canopy 0.49 0.98 0.98 1.42 59 118 118 171

Optional Lighting

1 Row Rail 0.49 0.49 0.49 0.71 59 59 59 86

1 Row Ledge 0.49 0.49 0.49 0.71 59 59 59 86

1 Row Shelves 0.49 0.49 0.49 0.71 59 59 59 86

2 Row Shelves 0.49 0.98 0.98 1.42 59 118 118 171

*230V lighting values are under review.

5 of 6P/N 0474007_B HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

Defrost

Termination

Thermostat

Refrigeration Thermostat

Condensing

Unit

}

(Field Installed)

R = Red G = Green BL = Blue LB = Light Blue DB = Dark Blue B = Black W = White

= 120V POWER = 120V NEUTRAL = Field GROUND = Case GROUND

Fan Wiring

Offtime Defrost

Fans

Electric Service Receptacle Receptacles

120V N

EUTRAL

MAROON

BAND

120V P

OWER

N.E.C.

TAGS

MAROON

BAND

BROWN BAND

Fans

BROWN BAND

120V POWER

120V NEUTRAL

WARNING

All components must have mechanical ground, and the merchandiser must be grounded.

Circled Numbers = Parts List Item Numbers

Grayed components in 12 foot models only.

BROWN BAND

Fans

BROWN BAND

120V POWER

120V NEUTRAL

Ambient Fan

Wiring

Glass Air Wipe

Fans

Purple BAND

Heaters

Purple BAND

120V POWER

120V NEUTRAL

Ambient Heater

Wiring

Heaters

4 ft case has 2 Heaters

6 ft case has 4 Heaters

8 ft case has 4 Heaters

12 ft case has 6 Heaters

4 ft case has 2 Fans

6 ft case has 4 Fans

8 ft case has 4 Fans

12 ft case has 6 Fans

4 ft case has 1 Fan

6 ft case has 2 Fans

8 ft case has 2 Fans

12 ft case has 3 Fans

Heater

Switch

ESBDVS Technical Data Sheet6 of 6 HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.

Optional Rail

Light Circuit

connectors

Optional

Shelf Harness

and

Light Circuits

Standard Lighting 2 Row Canopy

Light Circuits

R = Red G = Green BL = Blue B = Black W = White

= 120V POWER = 120V NEUTRAL = Field GROUND = Case GROUND

WARNING

All components must have mechanical ground, and the merchandiser must be grounded.

Circled Numbers = Parts List Item Numbers

Grayed components in 12 foot models only.

120V NEUTRAL

RANGE

AND

Light

Switch

120V POWER

RANGE

AND

GGG

99 9

GGG

99 9

Optional Ledge

Light Circuit

connectors

GGG

99 9
