Hunter PRO-C Hydrawise Manual de usuario

Table of Contents

Setting up a Controller in Offline Mode

Offline Mode - Advanced Offline Mode

Offline Mode - Run the Setup Wizard

Offline Adjustments - Watering with no Internet

Offline Mode - Sensors

Offline Mode - Turning Off Start Times

Offline Mode - Seasonal Adjust

Setting up a Controller in Offline

Mode

Offline programming will allow your controller to run without any internet access like a

traditional irrigation controller. Hydrawise controllers have two different modes that will run

in offline mode.

Modes Controller Models

Standard Mode HPC, HCC, PRO-HC, and X2

Advanced Mode HPC, HCC, PRO-HC, and HC

Standard offline programming will allow the controller to run like our traditional controllers

the X-core and the Pro-C models. Each of the six programs (a-f) allows you to start each

program up to four times a day, set run lengths and set specific days to water.

Advanced offline programming will allow the controller to run independently for each

zone(station). Each zone (station) can have up to four start times with their individual run

times.

To set your controller in Offline Mode for manual configuration, please follow the steps

below:

1. From the main menu, tap on Settings.

2. Select Config.

3. Select Factory Default.

4. Next , press Erase Config. This will reset the controller back to factory settings. You

will be presented with a warning dialogue.

5. Select Configure Offline and follow the wizard steps.

This wizard will guide you through the steps to set up your controller to run in offline mode

without an internet connection.

If you choose to switch modes when using the compatible model, use the steps below:

1. From the main menu, tap on Settings.

2. Select Offline Programs and Settings.

3. Select Offline Mode.

4. Choose mode and select Confirm.

If you decide to connect the controller via internet at a later date, the online programming

will sync with controller within a few seconds and override the offline programming.

Offline Mode - Advanced Offline

Mode

Offline Mode

If the controller loses its internet connection for more than 24 hours, you’ll receive a

notification email. The controller will then go into offline mode. In offline mode, your

controller won’t be able to access local weather conditions such as rainfall or evaporation.

As a result, it will revert to a predefined program.

For Smart Watering zones, the controller will adjust each zone’s watering length

based on your offline watering budget and will water at each zone’s configured peak

watering frequency.

For Time-Based Watering zones, the controller will adjust each zone’s watering length

based on your offline watering budget and will water at each zone’s configured

watering frequency.

Note that Cycle and Soak is not supported in offline mode and each zone will water

for its full watering length without pausing.

The controller will only water at your configured Program Start Times.

To set your controller to Offline Mode for manual configuration, please follow the steps

below:

1. From the main menu, tap on Settings.

2. Tap on Offline Settings.

3. Tap on Disable Wi-Fi.

4. You will be presented with a warning dialogue. Please make sure you understand the

warning before proceeding. If you're sure that you want to go offline, tap Go Offline.

5. Now that your controller is in Offline Mode, you can configure it manually by tapping

on Program Start Times.

6. From this screen, you can manually configure each zone according to your desired

schedule. Simply tap on Add to add a program start time and follow the steps below.

You can toggle between zones by tapping on Next/Previous or you can leave the start

time to APPLY to ALL ZONES.

Applying the start time to ALL ZONES will run through all zones with a

single start time.

Tap ADD in the start times menu.

Select the green box upper in left to enter PROGRAM START TIME (24 hr format)

Tap the DAYS to be selected after finished with start time entry.

Tap CONFIRM to save the start time entry.

Add a second start time for all zones or single zone if desired.

Tap the HOME icon (upper right) to allow station run times setup.

NOTE: Each zone can have up to four program start times and an additional four start

times under the All Zones section as shown below.

7. From the home screen, you can manually configure each zone run time.

Simply tap on ZONES to add a zone run time and follow the steps below.

You can toggle between zones by tapping on each zone number.

Tap ZONES in the home menu.

Tap the first zone to edit, (For Example: ZONE 1).

Tap on RUN TIME in the center of the screen.

Enter RUN TIME (minutes:seconds format), then press OK to save entry.

Repeat steps 1-4 for station run times.

NOTE: To get your controller back in online mode, follow the above steps, enable Wi-Fi,

reconnect to your SSID (Wi-Fi connection), and let the controller synchronize with your

online Hydrawise account.

Offline Mode - Run the Setup

Wizard

Please follow the steps below to run the setup wizard in offline mode. Refer to Setting

Controller to Offline Mode [1] or How to Factory Reset Controller [2] before running the wizard.

1. From the Connection Wizard screen, tap on Configure Offline. If you select OK, you

will proceed to the online setup wizard.

2. Tap OK to move on to the next step.

3. Enter in today’s date if it hasn’t already been set or if it is incorrect.

4. Enter today’s time if it hasn’t already been set or if it is incorrect.

5. From this screen, tap OK.

6. Please assign your Master Valve if you’re running one as advised on the previous

screen. Otherwise, keep Not Assigned selected and tap Confirm.

7. Tap OK.

8. You can now enter (in minutes) the run length you want for your default zone run

time. Then tap OK.

9. Tap OK to proceed to the next screen.

10. Next, set how often each zone will run. As advised on the previous screen, you can set

individual frequencies for each zone.

11. Tap on OK to proceed.

12. From this screen, you can manually configure each zone according to your desired

schedule. Simply tap on Add to add a program start time and follow the steps below.

You can toggle between zones by tapping on Next/Previous or you can leave the start

time to APPLY to ALL ZONES.

Note: Each zone can have up to four program start times and an additional four start times

under the All Zones section as shown below. Applying the start time to ALL ZONES will run

through all zones with a single start time.

1. Tap ADD in the start times menu.

2. Select the green box upper in left to enter PROGRAM START TIME (24 hr format)

3. Tap the DAYS to be selected after finished with start time entry.

4. Tap CONFIRM to save the start time entry.

5. Add a second start time for all zones or single zone if desired.

6. Tap the HOME icon (upper right) to allow station run times setup.

From the home screen, you can manually configure each zone run time. Simply tap

on ZONES to add a zone run time and follow the steps below. You can toggle between

zones by tapping on each zone number.

Note: The default run time and default watering frequency are applied to all zones during

the setup wizard. Setting individual run times and frequencies is done by going into each

zone afterwards.

1. Tap ZONES in the home menu.

2. Tap the first zone to edit, (For Example: ZONE 1).

3. Tap on RUN TIME in the center of the screen.

4. Enter RUN TIME (minutes format), then press OK to save entry.

5. Repeat steps 1-4 for station run times.

NOTE: To get your controller back in online mode, follow the above steps, enable Wi-Fi,

reconnect to your SSID (Wi-Fi connection), and let the controller synchronize with your

online Hydrawise account.

Offline Adjustments - Watering

with no Internet

If your controller loses internet connectivity for more than one day, we'll send you an email

notification. During this time, your controller will run the last synced schedule in offline

mode.

Offline watering adjustments apply when your controller is not connected to the internet

after 30 minutes.

You can access this setting from the Controller Settings tab on your home dashboard.

In offline mode, the controller will set watering times based on watering adjustments set up

beforehand.

If the next irrigation event for a zone was scheduled for Saturday, offline mode for that zone

would start after the irrigation event on Saturday if the controller didn’t have the internet. If

there are no irrigation events scheduled in the controller when it loses the internet, offline

mode will start 30 minutes after the controller loses internet.

NOTE: Without internet connectivity, your controller won't be able to automatically modify

its watering schedule based on weather forecasts.

Offline Mode - Sensors

Please follow the steps below to add and configure your sensor or flow meter in Offline

Mode. Please use the following link for Installation Instructions [3].

1. From the main menu, select Settings.

2. Next, select Offline Settings.

3. Select Sensors.

4. From this screen, you can now navigate between Sensor 1 and Sensor 2 by using the

Next and Previous options. Just as you configure your sensors online, you can select

the different options to make changes accordingly.

STEP 1

STEP 2

STEP 3

STEP 4
