ST-1600

OWNER’S MANUAL

ST-1600

Long-Range Synthetic Turf Rotor

Installation

• With a maximum radius of 165',

the ST-1600 Rotor is designed for

placement outside the eld for safety

and serviceability.

• Pair the rotor with the ST-1600-KIT

vault system to bring all irrigation

components together inside one

strong enclosure for simple access

to the complete system.

ST-1600-HS-B: Pop-Up Gear Drive

The best-in-class gear-driven ST-1600-HS-B Synthetic Turf Rotor oers a premium solution for

synthetic turf irrigation. The rotor cools, cleans, and ushes synthetic sports elds to enhance eld

safety and playability. With a throwing radius up to 165', the powerful and reliable ST-1600-HS-B

Rotor oers years of solid performance in a range of applications.

ST-1600-HS-BR: Riser-Mounted Gear Drive

The riser-mounted ST-1600-HS-BR conguration is an ideal retrot option for synthetic turf

irrigation. It is also an eective dust-control solution for horse arenas, corrals, and pastures.

Key Benets

• Heavy-duty internal gear drive and

stainless steel pop-up riser provide

years of reliable operation

• Long-range performance exibility up

to 165' with six nozzle choices

• Full-circle and adjustable arc in one

model from 40° to 360°

• Adjustable speed of rotation using the

adjustment knob to set the speed to

your requirements

Factory Settings

• Preinstalled #20 nozzle; other nozzles

are included in the packaging

• Speed control pre-set for maximum

speed of rotation

• 40° arc setting

Table of Contents

2Overview

3Product Details

4ST-1600-HS-B Replacement Parts

5Servicing and Maintenance

6ST-600-KIT System Components

7Riser-MountedSystem Components

8Field Layouts

11 Troubleshooting

Overview

hunterindustries.com

Lower Flange

O-Ring

Stainless

Steel Piston

Product Dimensions:

• Overall height: 22⁄"

• Pop-up height: 5"

• Exposed diameter: 14"

• Inlet size: 2" BSP*

Operating Specications:

• Radius: 107' to 165'

• Flow: 96.2 to 326.8 GPM

• Operating pressure range: 60 to 120 PSI

• Speed of rotation: 80 seconds at 90 PSI in a single 180° sweep

Gearbox

Reversing

Mechanism Boot

Piston Flange

Speed

Control Knob

Turbine Housing

2" BSP Inlet

Secondary Brass

Nozzle

Primary

Nozzle

Arc Adjustment

Rings

14"

12"

14"

2" BSP

22⁄"

*Use P/N 241400SP adapter for 2" PVC pipe if needed.

Product Details

ITEM DESCRIPTION CATALOG NO.

1 Primary Nozzle Retainer 502402SP

2 Primary Nozzle

#16 784800SP

#18 784801SP

#20 784802SP

#22 784803SP

#24 784804SP

#26 784805SP

3 Secondary Nozzle Kit Female-threaded

nozzle with elbow 10005900SP

Male-threaded

nozzle 10006100SP

4 Speed Control Knob 510101SP

5 Gearbox Cover 502455

6 Turbine Assembly Kit 10006200SP

7 Reversing Kit 510164SP

8 Turret inlet Kit 510167SP

9Threaded rotor

inlet 893600SP

10 Arc Rings (2) 205617SP

11 Gear-Drive Assembly 881900SP

12 Rotor Cover Kit 204205SP

13 Upper Body Kit 502432SP

14 Riser Assembly 502432SP

15 Rubber boot 502423

16 Lower Body Kit 502442SP

17 Gear-Drive Insertion/Removal Tool 517600SP



































ST-1600-HS-B: Replacement Parts

hunterindustries.com

➊

➌

A. Replacing the cover and rotor

1. Remove center plug with a at-

blade screwdriver and unscrew the

nut underneath using a ⁄" (13 mm)

socket.

B. Replacing the propeller and

checking for debris

1. Remove the eight screws on the

turbine housing (six large, two

small).

C. Speed control adjustment

1. Turn the brass knob clockwise to

slow down rotation.

D. Servicing secondary nozzle

1. Unthread the secondary nozzle.

E. Arc adjustment

1. For part-circle operation, reach

inside the rotor to set the arc

adjustment rings to the desired arc

setting.

2. Use the Gear-Drive Insertion/

Removal Tool to unscrew the rotor

from the piston. The tool will grab

onto the screws below the rotor.

3. Turn the wrench counterclockwise

until the unit is free from the

threads.

4. Li the unit out of the body.

2. Pull to remove the propeller cover

and expose the propeller.

3. Remove the propeller from the

housing to clear any debris that

may be trapped inside.

2. For 360° operation, remove both

adjustment rings.

2. Clear any debris that may be

trapped inside.

Servicing and Maintenance

ITEM DESCRIPTION

1ST-1600-HS-B Synthetic Turf Rotor

2ST-IBS-1600 Rubber Cover Kit with inll

barrier system

3ST-243636-B Vault

4ST-BKT-1600 Bracket for rotor

ST-BVF30-K Manifold, including

3" (80 mm) Victaulic ttings, isolation

valve, drain valve

6ST-V30-KV 3" (80 mm) grooved

Victaulic type low-pressure-loss valve

7ST-SPT-K Adjustable manifold supports

(2 required)

ST-H30-K Flexible stainless steel hose,

Victaulic connection to 3" (80 mm)

female NPT

9HQ-5-RC Quick coupler 1" (25 mm) inlet

with 1¼" (30 mm) outlet

10 ST-BKT-QCV Hanger bracket for

quick coupler

11 On-o-auto selector (included with

ST-V30-KV)

12 Compacted ground base

Note: All components above make up the ST-1600-KIT.

The ST-1600-HS-B Rotor paired with the ST-1600-KIT vault system is the superior solution for

all synthetic turf irrigation needs. The ST-1600-KIT brings ST irrigation components together

inside one strong underground enclosure that oers simple access from the top for quick

servicing and maintenance.













 











Victaulic is a trademark of Victaulic Company.



ST-1600-KIT System Components

hunterindustries.com

The riser-mounted ST-1600-HS-BR Rotor cools and cleans synthetic elds from above. If

riser-mounted irrigation is your choice, protect the riser with padding for safety. This

option is also a great dust-control solution for horse arenas, corrals, and pastures.























ITEM DESCRIPTION

1ST-1600-HS-BR Synthetic Turf Rotor,

riser-mounted

2ST-173026-C Vault

3ST-V30-KV 3" (80 mm) grooved

Victaulic type low-pressure-loss valve

4On-o-auto selector (included with

ST-V30-KV)

5 Isolation valve

6 3" (80 mm) PVC pipe

7 3" (80 mm) elbow

83" to 2" (80 mm to 50 mm)

reducer bushing

9 3" (80 mm) schedule 40 steel pipe

10 Protective padding

11 Compacted ground base

Riser-Mounted System Components

American football eld, with a #20 nozzle installed, operating at 100 PSI

Field Layouts

hunterindustries.com

International soccer pitch, with a #24 nozzle installed, operating at 90 PSI

Field Layouts

ST1600 PERFORMANCE DATA IMPERIAL

Nozzle Pressure Radius Flow Precipitation in/hr*

PSI . GPM

16 60 107 96.2 1.63 1.88

70 115 107. 3 1.57 1.81

90 121 1 17. 8 1.54 1.78

100 128 127.3 1.50 1.73

115 135 137. 4 1.46 1.69

18 60 112 1 07.0 1.66 1.91

70 121 119.4 1.56 1.80

90 128 131.0 1.54 1.78

100 133 141.3 1.54 1.78

115 141 153.2 1.48 1.71

(Factory installed)

60 115 144.0 2.10 2.43

70 128 160.9 1.89 2.18

90 141 176.5 1.71 1.97

100 144 190.5 1.76 2.03

115 148 204.2 1.80 2.08

22 60 118 171.5 2.37 2.73

70 130 191.8 2.20 2.54

90 144 210.0 1.94 2.24

100 151 226.9 1.84 2.12

115 157 243.1 1.89 2.18

24 60 121 202.1 2.64 3.05

70 133 225.9 2.46 2.84

90 148 247.6 2.19 2.52

100 156 2 6 7.4 2.12 2.45

115 160 286.4 2.16 2.49

26 60 126 233.2 2.83 3.27

70 136 260.4 2.71 3.13

90 151 284.5 2.40 2.77

100 160 3 07.0 2.31 2.67

115 165 326.8 2.32 2.68

* All precipitation rates are calculated for 180° operation. For the precipitation rate of a 360° sprinkler, divide by 2.

25°

26'

135'

141'

148'

157'

160'

165'

107'

112'

115'

118'

121'

126'

Nozzle #16

Nozzle #18

Nozzle #20

Nozzle #22

Nozzle #24

Nozzle #26
