Operating Manual
A1230-02
4-Quadrant Voltage Amplifier (2-Channel)
DC – 7 MHz 450 V/µs 2x 185 W (Source) 2x 68 W (Sink)
Revision 3.0
MA-12300100-03
Contents
1 Introduction.....................................................................................................................3
2 For Your Safety...............................................................................................................5
3 Operating Elements.........................................................................................................9
4 1230-MultiChannel-Control Software..........................................................................13
5 Notes on Operation.......................................................................................................18
6 Integration into utomated Test Systems......................................................................22
7 Maintenance and Service..............................................................................................25
8 Decommissioning and Disposal....................................................................................26
9 Warranty.......................................................................................................................26
10 Contact Information....................................................................................................27
11 Guidelines...................................................................................................................27
12 Document History.......................................................................................................28
1230-02
1 Introduction
1.1 Device Description
The 1230-02 is a linear, extremely wideband precision power amplifier. It is ideal for all
applications that require fast changing signals at any purely resistive and complex loads.
The 1230-02 has two summable inputs per channel with 50 Ω and 100 kΩ input resistance; the
50 Ω input makes it the ideal downstream equipment for conventional function generators.
Two optional operating voltages are available for high-voltage/low-current or low-voltage/high-
current applications. Especially in case of very low-impedance loads, choosing the low operating
voltage leads to a considerable reduction of the power loss and a higher output current.
If higher output voltages are required, the preamplifier output ( Bridge Out ) allows a simple set-up
of a bridge circuit with the second channel of the 1230-02 for doubling the output voltage.
Use the plug-on adapter box to easily connect both channels in parallel if more current is required.
Operation with equal output signals is strictly required in this setup.
The device is equipped with a temperature-controlled, low noise fan. It also features an over-
temperature protection. power-loss calculation and an absolute-current monitoring guarantee
perfect short-circuit and overload protection. The operation is implemented over the operating
elements on the front panel. In addition, the amplifier is fully remote controllable via the USB port
using a simple byte protocol.
If even higher output voltages or higher output currents are required, configurations with series or
parallel connections of several 1230-02 are possible.
Always read the enclosed data sheet
The separate data sheet is part of these operating instructions and must also be read and
understood. Device-speci c modi cations on customer request can only be found in the data sheet!
The data sheet is part of the scope of delivery of the device and can be downloaded from our
website www.drhubert.com.
A1230-02 Introduction Page 3
1.2 Scope of Delivery
•USB thumb-drive including
◦These operating instructions
◦Datasheet
◦pplication software 1230-Multichannel-Control
•Power cable
•USB cable
•BNC wire (ca. 8 cm) for bridge operation
•4 mm connector for bridge operation
•dapter box for parallel operation
•BNC wire (ca. 18 cm) for parallel operation
•BNC T-piece adapter for parallel operation
A1230-02 Introduction Page 4
2 For Your Safety
2.1 Used Symbols and Notations
2.1.1 Warning Level
Type and source of danger
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
Type and source of danger
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
Type and source of danger
Indicates a potentially hazardous situation which, if not avoided, could result in minor or moderate
injury or property damage.
Type and source of danger
Indicates important information about the product or procedures that should be considered for the
correct functioning of the device.
2.1.2 Used Warning Symbols
Warning about a dangerous voltage
Warning about general danger
Description of what should be done or what to pay attention to
A1230-02 For Your Safety Page 5
2.2 General Safety Advice
The following general safety instructions must be observed during the use of this device.
Disregarding this advice or specific warnings in this manual will violate safety standards in the
intended uses of this equipment.
The manufacturer is not responsible for consequences resulting from disregarding the advice and
warnings.
Electrical voltage – Danger of electric shock
Parts under voltage:
Always cover all parts under voltage that inevitably arise during operation.
Touching of cables, sockets and plugs:
Never touch the contacts of cables, sockets or plugs directly after disconnecting them, as there is a
risk of electric shock.
Contact between amplifier outputs and PE:
Touching an ampli er output and PE at the same time can result in a life threatening electric shock.
Earth the device:
The device ful lls the requirements for protection class I. To avoid the risk of electric shock, the
device housing must be earthed and therefore always operate the device via the supplied three-
core power cable with protective conductor. The mains cable may only be plugged into a grounded
socket with a protective earth contact. An interruption of the protective earth conductor inside or
outside the device reduces the safety of the device and is prohibited.
Safety Regulations for the work with electrical equipment:
- Disconnect mains!
- Prevent reconnection!
- Test for absence of harmful voltages!
- Ground and short circuits!
- Cover or close of nearby live parts!
Devices with a heavy current connection:
Devices with a heavy current connection may only be operated via a 4-pole RCD with ≤40 ms at 5 x
IΔn. If it is not possible to install the RCD in the building installation, then our device must be
connected to the mains supply via a mobile distributor with the appropriate RCD.
Do not open the housing:
Covers must not be removed by the operating personnel. Maintenance and repair work is reserved
exclusively for quali ed service personnel.
A1230-02 For Your Safety Page 6
Important notes
The device must be used exclusively for its intended purpose.
The device is only approved for operation within the connected loads speci ed on the type label.
Do not insert any mechanical parts, especially metal parts, into the device through the ventilation
slots.
Protect the unit from moisture, humidity and condensation. Avoid using liquids near the device.
Never connect loads while the ampli er outputs are switched on.
Operate the device exclusively on the public power supply system (no generators/UPS).
To avoid personal injury and property damage, make sure that the equipment and components
used in the test are not overloaded. Read all operating instructions for the devices used thoroughly
and ensure that all defined device limits are adhered to. If there are doubts about the suitability of
the devices for the test to be performed, contact the manufacturer of the device.
2.3 Intended Use
2.3.1 Hardware
The device is intended exclusively for use as an LF power amplifier. Typical applications are the
operation as voltage amplifier on passive loads. ctive loads are only permitted under certain
conditions in agreement with the manufacturer.
Operation on active loads
Active loads are only permitted under certain conditions in agreement with the manufacturer.
The device may only be operated within the technical data and under the ambient conditions
specified in this manual.
Changes to the device are not permitted without the consent and release of the manufacturer.
Proper and safe operation of the device requires correct installation and careful operation. This
manual is part of the device and must always be accessible to the user. Observe all safety
regulations listed in this manual.
The improper use leads to the exclusion of any liability claims.
The operator alone is liable for all damage caused by improper use.
A1230-02 For Your Safety Page 7
2.3.2 Software
‘ 1230 Control’ is software developed to control and configure HUBERT power amplifier. Take into
account technical data and applications described in this manual. Changes to the software are not
permitted without the consent and release of the manufacturer. Proper and safe operation of the
software requires correct installation and careful operation. This manual is part of the software and
must always be accessible to the user. Observe all safety regulations listed in this manual.
2.4 User
Operation may only be performed by qualified persons.
Reading and understanding the operating instructions
Never use the device without having read and understood the operating instructions. Always contact
the manufacturer if you have any questions.
Qualified persons within the meaning of the safety instructions in this manual are authorized
persons for commissioning and operating systems in accordance with the standards of safety
technology.
Risk of injury in case of insufficient qualification
Improper work can lead to personal injury and damage to property. Any work may only be carried
out by persons who have the necessary training, knowledge and experience.
A1230-02 For Your Safety Page 8
3 Operating Elements
3.1 Front Panel Elements
Each of the two amplifier channels has its own front panel elements (3, 4, 5, 7, 8, 9, 10).
[1] POWER BUTTON
On / Off switch.
(Here is implemented the switchover ready to operate / standby. The standby mode is
signaled by the weakly-lit, blue LED. The power supply disconnection is implemented with
the switch on the rear side.)
[2] S FETY SHUTDOWN 1 / 2
2 mm jacks to connect the safety shutdowns of both channels. If connected, a safety
shutdown on one channel triggers the safety shutdown on the other channel. This
shutdown is indispensable and is provided automatically if the adapter box for parallel
operation is used. Using the safety shutdown is recommended in series operation as well.
[3] OUT+ / OUT-
4 mm safety sockets, amplifier output
Reference potential (negative-socket) is connected to protective earth via 1 MΩ.
A1230-02 Operating Elements Page 9
[4] MP IN 50 Ω BUTTON
OFF: 50 Ω input is switched off
ON: 50 Ω input is switched on
[5] MP IN 100 KΩ BUTTON
OFF: 100 kΩ input is switched off
ON: 100 kΩ input is switched on
[6] GROUND SOCKET
Connection to the protective conductor potential.
[7] POWER SUPPLY HIGH / LOW BUTTON
Changing of the operating voltage
HIGH (LED on): High operating voltage (ca. ± 90 V)
LOW (LED off): Low operating voltage (ca. ± 45 V)
recommended for low-impedance loads
[8] IN 100 KΩ
100 kΩ Signal input; isolated BNC socket
Reference potential is connected to protective earth via 1 MΩ.
[9] IN 50 KΩ
50 Ω Signal input; isolated BNC socket
Reference potential is connected to protective earth via 1 MΩ.
[10] RE DY/PROTECTION LED
Green: Lights up when the amplifier is ready for operation.
(RE DY)
Red: Signals the intervention of a protection mechanism.
Red LED lights up constantly: Over-temperature protection; the device switches on
automatically after the drop of the temperature.
Red LED flashes slowly (≈1/s): Disconnection because of exceeding the permissible
power loss or output current.
Red LED flashes rapidly (≈3/s): Hardware fault. The device must be sent to the
manufacturer
A1230-02 Operating Elements Page 10
