Huawei R216 Especificaciones técnicas

Product Description

R216 Mobile WiFi

V200R001

Issue 02

Date 2015-01-30

HUAWEI TECHNOLOGIES CO., LTD.

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 2 of 19

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.

Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://consumer.huawei.com/en/

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 3 of 19

About This Document

Summary

This document provides information about the major functions, supported services

and system architecture.

The following table lists the contents of this document.

Chapter Details

1 Overview The supported network modes, basic services and

functions, and the appearance of the product.

2 Features The supported features and technical

specifications of the product.

3 Services and Applications The services and applications of the product.

4 System Architecture The architecture of the product.

5 Packing List The items contained in the package of the product.

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 4 of 19

History

Issue Details Date

01 First release. 2014-11-15

02 Second release.

Modifying the decription of Battery and Weight in

theTable 2-1 Hardware specifications

Modifying the decription of System requirement in

theTable 2-2 software specifications

2015-01-30

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 5 of 19

Contents

1 Overview..........................................................................................................................6

1.1 Brief Introduction .............................................................................................................................. 6

2 Features...........................................................................................................................8

2.1 Main Features .................................................................................................................................. 8

2.2 Technical Specifications ................................................................................................................... 8

2.2.1 Hardware ................................................................................................................................. 8

2.2.2 Software................................................................................................................................. 10

3 Services and Applications ...........................................................................................13

3.1 Data Service................................................................................................................................... 13

3.1.1 Wireless Modem.................................................................................................................... 13

3.1.2 USB Modem .......................................................................................................................... 13

3.2 SMS................................................................................................................................................ 14

4 System Architecture .....................................................................................................15

4.1 System Architecture ....................................................................................................................... 15

4.2 Functional Modules ........................................................................................................................ 16

5 Packing List...................................................................................................................17

A Acronyms and Abbreviations......................................................................................18

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 6 of 19

1 Overview

1.1 Brief Introduction

R216 Mobile WiFi (hereinafter referred to as the R216) is a high-speed packet access

mobile hotspot. It is a multi-mode wireless terminal for SOHO (Small Office and Home

Office) and business professionals.

The R216 supports the following standards:

Long Term Evolution (LTE) FDD(Frequency Division Duplex)

Dual Carrier High Speed Packet Access Plus (DC-HSPA+)

High Speed Packet Access Plus (HSPA+)

High Speed Uplink Packet Access (HSUPA)

High Speed Downlink Packet Access (HSDPA)

Universal Mobile Telecommunications System (UMTS)

Enhanced Data rates for Global Evolution (EDGE)

General Packet Radio Service (GPRS)

Global System for Mobile communications (GSM)

The R216 provides the following services:

LTE FDD packet data service

DC-HSPA+ packet data service

HSPA+ packet data service

HSPA/UMTS packet data service

EDGE/GPRS packet data service

Short Message Service (SMS)

You can connect the R216 with the USB interface of a computer, or connect the R216

with the Wi-Fi. In the service area of the LTE FDD/DC-HSPA+/HSPA+/HSPA/UMTS or

EDGE/GPRS/GSM network, you can surf the Internet and send/receive

messages/emails cordlessly. The R216 is fast, reliable, and easy to operate. Thus,

mobile users can experience many new features and services with the R216. These

features and services will enable a large number of users to use the R216 and the

average revenue per user (ARPU) of operators will increase substantially.

Figure 1-1 shows the profile of the R216.

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 7 of 19

Figure 1-1 R216 profile

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 8 of 19

2 Features

2.1 Main Features

The R216 mainly supports the following features:

LTE FDD (DL) data service of up to 150 Mbit/s

LTE FDD (UL) data service of up to 50 Mbit/s

DC-HSPA+ (DL) data service of up to 43.2 Mbit/s

HSPA+ (DL) data service of up to 21.6 Mbit/s

HSDPA (DL) data service of up to 14.4 Mbit/s

HSUPA (UL) data service of up to 5.76 Mbit/s

UMTS data service of up to 384 kbit/s

EDGE data service of up to 236.8 kbit/s

GPRS data service of up to 85.6 kbit/s

PS domain data service based on LTE/UMTS/GSM

SMS based on UMTS/GSM

Built-in LTE/UMTS/GSM and WLAN high gain antenna

SIM lock

Wi-Fi(2.4GHz, 5GHz)

Press and Play

IPv6/IPv4 dual stack

Built-in DHCP Server, DNS RELAY and NAT

Traffic statistic

Standard Micro USB interface

Windows Vista, Windows 7, Windows 8 (32 and 64 Bit), MAC OS X 10.7, 10.8 ,

10.9 and 10.10 with latest upgrades

2.2 Technical Specifications

2.2.1 Hardware

Table 2-1 lists the hardware specifications.

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 9 of 19

Table 2-1 Hardware specifications

Item Specifications

Technical

standard

WAN:

LTE FDD/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM

WLAN: IEEE 802.11a/b/g/n

Operating

frequency

LTE: FDD B3(1800 MHz)/ B5(8500 MHz)/ B7(2600 MHz)/

B20(800 MHz)

DC-HSPA+/HSPA+/HSPA/UMTS: B1(2100 MHz)/B5(850 MHz)/

B8(900 MHz)

EDGE/GPRS/GSM: B2(1900)/ B3(1800 MHz)/ B8(900 MHz)/

B5(850 MHz)

WLAN: 2.4 GHz, 5 GHz

Internal memory 256 MB NAND flash and 128 MB DDR SDRAM

Maximum

transmitter

power

LTE: Conform to Power Class 3 Definition

UMTS: Conform to Power Class 3 Definition

WLAN 802.11b：13 dBm

802.11g：11 dBm

802.11n：10 dBm

802.11a/n：10 dBm (5 GHz)

Receiver

sensitivity

LTE: Confirm to 3GPP Requirements

UMTS: Confirm to 3GPP Requirements

WLAN 802.11a: -65 dBm@54 Mbit/s

802.11b: -76 dBm@11 Mbit/s

802.11g: -65 dBm@54 Mbit/s

802.11n: -64 dBm@65 Mbit/s

WLAN speed 802.11a: Up to 54 Mbit/s

802.11b: Up to 11 Mbit/s

802.11g: Up to 54 Mbit/s

802.11n HT20: Support MCS0–MCS7; Up to 72.2 Mbit/s.

Support MCS8–MCS15; Up to 144.4 Mbit/s.

HT40: Support MCS0–MCS7; Up to 150 Mbit/s.

Support MCS8–MCS15; Up to 300 Mbit/s.

Maximum power

consumption

3.5 W

R216 Mobile WiFi V200R001

Product Description

Issue 02 (2015-01-30) Commercial in Confidence Page 10 of 19

Item Specifications

Power supply AC: 100–240 V

DC: 5 V, 1 A

Battery Type: Li (rechargeable)

Capacity: 3.8 V, 1500 mAh

Maximum working time: 6 hours (depending on the network)

Maximum standby time: 300 hours (depending on the network)

External

interfaces

Micro USB interface (supports USB 2.0; to be used with Huawei

USB cables when available)

Standard micro 6-PIN SIM card interface

key-press Power switch,Reset switch

Antenna Built-in LTE/UMTS/GSM main antenna

Built-in LTE/UMTS diversity antenna

Built-in WLAN antenna

Dimensions

(W × D × H)

96.8 mm × 58.0 mm × 12.8 mm

Weight About 75g (including the battery)

Temperature Operating: 0°C to +35°C

Storage: -20°C to +60°C

Humidity 5% to 95% (non-condensing)

2.2.2 Software

Table 2-2 lists the software specifications.

Table 2-2 software specifications

Item Description

SMS Writing/Sending/Receiving

Sending/Receiving extra-long messages

Storage: Up to 500 messages can be saved in the

internal memory of the R216.

New message prompt

Network connection

setup

APN management: create, delete and edit

Set up network connection
