Product Description

HUAWEI E5783-330 Mobile WiFi

V100R001

Version 01

Date 2020-12-28

UAWEI

DEVICE

., L

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 2 of 21

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees

or representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Device Co., Ltd.

Address: No.2 of Xincheng Road

Songshan Lake Zone

Dongguan, Guangdong 523808

People's Republic of China

Website: http://consumer.huawei.com/en/

Email: mobile@huawei.com

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 3 of 21

About This Document

Summary

This document introduces the major functions, supported services, and system architecture of

the HUAWEI E5783-330 Mobile WiFi.

The following table lists the contents of this document.

Chapter Details

1 Overview Supported network modes, basic services and functions, and the

appearance of the product

2 Features Major features and technical specifications

3 Services and

Applications

Supported services

4 System

Architecture

System architecture

5 Packaging Box

Items

Items contained in the packaging box

6 Appendix Supported LTE bandwidths

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 4 of 21

History

Version Details Date

01 First release 2020-12-28

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 5 of 21

Contents

1 Overview ............................................................................................................................. 6

1.1 Introduction ......................................................................................................................................... 6

1.2 Optional Features ................................................................................................................................. 6

2 Features .............................................................................................................................. 7

2.1 Main Features ...................................................................................................................................... 7

2.2 Technical Specifications ........................................................................................................................ 8

2.2.1 Hardware .................................................................................................................................... 8

2.2.2 Software .................................................................................................................................... 11

3 Services and Applications ..................................................................................................... 13

3.1 Data Service ....................................................................................................................................... 13

3.1.1 Wireless Modem ......................................................................................................................... 13

3.1.2 USB Modem .............................................................................................................................. 13

3.1.3 LTE/3G/Wi-Fi Auto Offload ........................................................................................................... 14

3.2 SMS .................................................................................................................................................. 14

4 System Architecture ............................................................................................................ 15

4.1 System Architecture ........................................................................................................................... 15

4.2 Functional Modules ............................................................................................................................ 16

5 Packaging Box Items ............................................................................................................ 17

6 Appendix ........................................................................................................................... 18

7 Acronyms and Abbreviations ................................................................................................. 19

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 6 of 21

1 Overview

1.1 Introduction

HUAWEI E5783-330 Mobile WiFi (hereinafter referred to as the E5783-330) is a high-speed

packet access mobile hotspot. It is a multi-mode wireless terminal for SOHO (Small Office and

Home Office) and business professionals.

It provides users with packet data services and SMS through multiple network modes. You can

connect the micro USB port on the E5783-330 to a computer using a micro USB data cable, or

connect multiple devices to the E5783-330 over Wi-Fi. In the service area of the network, the

E5783-330 allows you to surf the Internet and send/receive messages/emails, providing you with

a fast, reliable, and convenient user experience. It also helps carriers improve their average

revenue per user (ARPU).

1.2 Optional Features

Optional features refer to features that are not supported on the standard version. These

features can be customized according to carrier or customer requirements. The E5783-330's

optional features include the following:

 SIM lock

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 7 of 21

2 Features

2.1 Main Features

The E5783-330 features:

 LTE Category 7

 LTE FDD CA (DL) packet data service of up to 300 Mbps

 LTE FDD (DL) packet data service of up to 150 Mbps

 LTE FDD CA (UL) packet data service of up to 100 Mbps

 LTE FDD (UL) packet data service of up to 50 Mbps

 LTE TDD CA (DL) packet data service of up to 224 Mbps

 LTE TDD (DL) packet data service of up to 112 Mbps

 LTE TDD CA(UL) packet data service of up to 20 Mbps

 LTE TDD (UL) packet data service of up to 10 Mbps

 DC-HSPA+ (DL) packet data service of up to 42 Mbps

 HSUPA packet data service of up to 5.76 Mbps

 HSPA+ (DL) packet data service of up to 21 Mbps

 HSDPA (DL) packet data service of up to 14.4 Mbps

 UMTS (UL/DL) packet data service of up to 384 Kbps

 SMS based on LTE/UMTS

 Built-in LTE/UMTS and Wi-Fi antenna

 2.4 GHz and 5 GHz Wi-Fi

 LTE/3G/Wi-Fi auto offload

 Compatible with HUAWEI AI Life app

 Plug and Play

 IPv4v6 dual stack

 Built-in DHCP Server, DNS RELAY, and NAT

 Online software upgrade

 Traffic statistics

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 8 of 21

 WPS

 Standard Micro USB port

 Compatible with Windows 7, Windows 8, Windows 8.1, Windows 10 (excluding Windows RT),

MAC OS X 10.12, 10.13, 10.14 and 10.15

2.2 Technical Specifications

Hardware

Table 2-1 lists the hardware specifications.

Table 2-1 Hardware specifications

Item Specifications

Technical

standard

WAN:

LTE/DC-HSPA+/HSPA+/HSUPA/HSDPA/UMTS

Wi-Fi/WLAN: IEEE 802.11a/b/g/n/ac

Operating

frequency

LTE : B1/B3/B5/B7/B8/B18/B19/B20/B28/B32/B38/B40/B41/B42

UMTS: B1/B5/B8

LTE UL CA:

Intra-Band continuous CA:

3C, 7C, 38C, 40C, 41C

LTE DL CA:

1A-3A, 1A-7A, 1A-8A, 1A-20A, 1A-28A, 3A-5A, 3A-7A, 3A-8A,

3A-20A, 3A-28A, 3A-42A, 7A-8A, 7A-20A, 7A-28A, 20A-32A,

1C, 3C, 7C, 38C, 40C, 41C, 42C, 3A-3A, 41A-41A

See Appendix for supported LTE channel bandwidths

Wi-Fi/WLAN: 2.4 GHz

AP 5-12

STA 5-13

Wi-Fi/WLAN: 5 GHz

AP: W52, W56, W58

STA: W52, W53, W56, W58

Memory RAM: 256 MB

ROM: 512 MB TBD

Transmit power

TBD

LTE: Conforms to Power Class 3 Definition

WCDMA/HSPA/HSPA+: Conforms to Power Class 3 Definition

Wi-Fi/WLAN 802.11b: 14 dBm

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 9 of 21

Item Specifications

2.4 GHz 802.11g: 13 dBm

802.11n: 12.5 (20 MHz)/12 (40 MHz) dBm

Wi-Fi/WLAN 5

GHz

802.11a: 13 dBm

802.11n: 13 dBm

802.11ac: 12 (20 MHz)/11(40 MHz)/11(80 MHz) dBm

Note: The value above represents a typical transmit power in Wi-

Fi/WLAN mode, and may vary slightly by device.

Receiver

sensitivity

TBD

LTE: Conforms to 3GPP

WCDMA/HSPA/HSPA+: Conforms to 3GPP

Wi-Fi/WLAN

2.4 GHz

802.11b: -76 dBm@11 Mbps

802.11g: -65 dBm@54 Mbps

802.11n: -64 dBm@65 Mbps

Wi-Fi/WLAN

5 GHz

802.11a: -65 dBm@54 Mbps

802.11n: -64 dBm@65 Mbps

802.11ac: -64 dBm@65 Mbps

WLAN MIMO 2*2 MIMO

Wi-Fi/WLAN

speed

802.11a: Up to 54 Mbps

802.11b: Up to 11 Mbps

802.11g: Up to 54 Mbps

802.11n: HT20: Supports MCS0–MCS7; Up to 72.2 Mbps.

Supports MCS8–MCS15; Up to 144.4 Mbps.

HT40: Supports MCS0–MCS7; Up to 150 Mbps.

Supports MCS8–MCS15; Up to 300 Mbps.

802.11ac: Up to 867 Mbps

Power

consumption

<3.5 W

Charger

(Optional)

AC: 100–240 V

DC: 5 V, 1 A

Battery Type: Rechargeable lithium battery (removable)

Capacity: 3.8 V, 2400 mAh

HUAWEI E5783-330 Mobile WiFi V100R001

Product Description

Version 01 (2020-12-28) Secret and confidential Page 10 of 21

Item Specifications

Maximum working hours: 9 (depending on the network)

Maximum standby hours: 550 (depending on the network)

External ports Micro USB port

Micro-SIM card slot (3FF)

Buttons Power button, RESET button

Antenna Built-in LTE/UMTS main antenna

Built-in LTE/UMTS diversity antenna

Built-in WLAN antenna

Dimensions

(W × D × H)

108 mm x 62 mm x 17.45 mm

Weight Approximately 100 g (including the battery) TBD

Temperature Operating temperature: 0°C to 35°C

Storage temperature: –20°C to +60°C

Humidity 5% to 95% (non-condensing)
