Huawei ATN 905 Especificaciones técnicas

ATN 905 Multi-service Access Equipment

V200R002C01

Product Description

Issue 01

Date 2013-05-30

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and the

customer. All or part of the products, services and features described in this document may not be within the

purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,

and recommendations in this document are provided "AS IS" without warranties, guarantees or representations

of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: [email protected]

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

About This Document

Purpose

This document describes the networking application, functions, structure, features of the ATN

905 device.

Note the following precautions

lCurrently, the device supports the AES and SHA256 encryption algorithms. AES is

reversible, while SHA256 is irreversible. A protocol interworking password must be

reversible, and a local administrator password is recommended to be irreversible.

lIf the plain parameter is specified, the password will be saved in plaintext in the

configuration file, which has a high security risk. Therefore, specifying the cipher parameter

is recommended.

Related Version

The following table lists the product version related to this document.

Product Name Version

ATN 905 V200R002C01

Intended Audience

This document is intended for:

lNetwork Planning Engineers

Symbol Conventions

Symbol Description

DANGER

Indicates a hazard with a high level or medium level of risk,

which if not avoided, could result in death or serious injury.

ATN 905 Multi-service Access Equipment

Product Description About This Document

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

Symbol Description

WARNING

Indicates a hazard with a low level of risk, which if not

avoided, could result in minor or moderate injury.

CAUTION

Indicates a potentially hazardous situation, which if not

avoided, could result in equipment damage, data loss,

performance degradation, or unexpected results.

TIP

Indicates a tip that may help you solve a problem or save

time.

NOTE

Provides additional information to emphasize or supplement

important points of the main text.

Command Conventions

Convention Description

Boldface The keywords of a command line are in boldface.

Italic Command arguments are in italics.

[ ] Items (keywords or arguments) in brackets [ ] are optional.

{ x | y | ... } Optional items are grouped in braces and separated by

vertical bars. One item is selected.

[ x | y | ... ] Optional items are grouped in brackets and separated by

vertical bars. One item is selected or no item is selected.

{ x | y | ... }*Optional items are grouped in braces and separated by

vertical bars. A minimum of one item or a maximum of all

items can be selected.

[ x | y | ... ]*Optional items are grouped in brackets and separated by

vertical bars. Several items or no item can be selected.

GUI Conventions

Convention Description

Boldface Buttons, menus, parameters, tabs, window, and dialog titles

are in boldface. For example, click OK.

>Multi-level menus are in boldface and separated by the ">"

signs. For example, choose File > Create > Folder.

ATN 905 Multi-service Access Equipment

Product Description About This Document

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

iii

Change History

Updates between document issues are cumulative. Therefore, the latest document issue contains

all updates made in previous issues.

Changes in Issue 01 (2013-05-30)

This document is the first release of the V200R002C01 version.

ATN 905 Multi-service Access Equipment

Product Description About This Document

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

Contents

About This Document.....................................................................................................................ii

1 Product Positioning and Features...............................................................................................1

1.1 Positioning......................................................................................................................................................................1

1.2 Product Highlights..........................................................................................................................................................6

2 Product Features and Functions..................................................................................................8

3 Product Operation and Maintenance.......................................................................................25

4 Hardware Structure.....................................................................................................................30

4.1 Indoor ATN 905 Devices.............................................................................................................................................30

4.2 Outdoor ATN 905 Devices...........................................................................................................................................34

4.3 Swappable Optical/Electrical Modules........................................................................................................................41

4.3.1 Overview...................................................................................................................................................................41

4.3.2 Technical Specifications............................................................................................................................................43

4.4 Cables...........................................................................................................................................................................49

4.4.1 AC Power Cables and Ground Cables.......................................................................................................................49

4.4.2 Ethernet Cables..........................................................................................................................................................52

4.4.3 Optical Fibers............................................................................................................................................................56

4.5 Equipment Support.......................................................................................................................................................57

4.5.1 Cabinet Support.........................................................................................................................................................58

5 Product Technical Specifications.............................................................................................63

A Acronyms and Abbreviations..................................................................................................66

ATN 905 Multi-service Access Equipment

Product Description Contents

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

1 Product Positioning and Features

1.1 Positioning

ATN 905 is small-sized, light-weighted, and low power-consuming case-shaped equipment used

to carry mobile services from small-cell base stations or enterprise leased line services.

lCarrying mobile services from small-cell base stations: ATN 905 can be installed in various

indoor and outdoor environments and supports plug-and-play, improving the network

deployment efficiency and reducing the operating expense (OPEX).

lCarrying enterprise leased line services: ATN 905 functions as a demarcation points of

enterprise domains and carrier domains and supports abundant operation and maintenance

methods, helping quick and effective fault sectionalization and location.

ATN 905 Multi-service Access Equipment

Product Description 1 Product Positioning and Features

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

Carrying Mobile Services from Small-Cell Base Stations

Because macro base stations provide uneven and inflexible coverage, small-cell base stations

featuring small sizes, light weights, and adaptation to any installation environments are used

together with macro base stations on mobile networks.

However, installation and deployment of small-cell base stations and their bearer equipment on

live networks encounter many difficulties because of their large quantity, wide distribution and

various installation environments. In addition, site selection, maintenance, and power supply

also encounter many difficulties.

In the Huawei mobile bearer solution, ATN 905 functions as bearer equipment for small-cell

base stations and benefits:

lAnywhere: ATN 905 is available in the indoor and outdoor types and can be installed in

various environments where small-cell base stations are installed.

lPlug-and-play: Plug-and-play enables NEs to automatically go online and implements

service provisioning in batches and remote commissioning in a centralized manner, thereby

improving the maintenance efficiency and reducing costs.

lPower over Ethernet (PoE): ATN 905 can supply power to small-cell base stations and

radio equipment over Ethernet electrical ports, requiring less space and contributing to

environmental protection.

Figure 1-1 shows networking of the mobile bearer solution to which ATN 905 belongs. As

bearer NEs for small-cell base stations, ATN 905s using a link topology are connected to access

NEs at the macro base station side and are extension of the ATN+CX IPRAN solution (IPRAN

is the abbreviated form of IP radio access network). This scheme enables E2E clocks and E2E

maintenance for the macro base station bearer solution. It is cost-effective, easy to deploy, and

easy to maintain.

ATN 905 Multi-service Access Equipment

Product Description 1 Product Positioning and Features

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

Figure 1-1 Carrying mobile services from small-cell base stations

MME/SGW

RNC

CSG ASG RSG

Macro Cell

Access

Aggregation Core

BSC

Micro/Pico Access

Native IP/Eth

Micro/Pico Micro/Pico

Micro/Pico

Macro Cell

IPRAN

ATN 905 ATN 905

ATN910/910I/

950/950B

SR/BRAS

NOTE

In the IPRAN macro base station backhaul network solution, ATN 905 is supported in the following modes:

lNative IP mode: If IPRAN uses a Layer 3 solution, such as, the hierarchy VPN (HVPN) solution, it is

recommended that ATN 905 connect to the IPRAN macro base station backhaul network in Native IP

mode, which facilitates deployment of end to end (E2E) Layer 3 IP connectivity and performance check

schemes.

lNative ETH: If IPRAN uses E2E Layer 2 solution or L2+L3 mixed VPN, it is recommended that ATN

905 connect to the IPRAN macro base station backhaul network in Native ETH mode, which facilitates

transparent transmission and processing of E2E Layer 2 VLAN packets.

Carrying Enterprise Leased Line Services

Generally, customer premises equipment (CPE) that bears enterprise leased line services

connects to a provider edge (PE) through optical fibers or a leased third-part network as shown

in Figure 1-2.

Figure 1-2 CPE directly connecting to a carrier network

A CPE is often far away from a PE. If a fault occurs, it is difficult to locate whether the fault

occurs on the optical fiber, leased network, enterprise network, or carrier network.

ATN 905 Multi-service Access Equipment

Product Description 1 Product Positioning and Features

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

ATN 905 can be deployed as an Ethernet demarcation device (EDD) directly connected to CPE

and sharing the same equipment room with the CPE as shown in Figure 1-3. In this way, the

carrier network extends to the client side and the provider can manage the network between the

EDD and the PE.

Figure 1-3 CPE connecting to a carrier network through an EDD

In the Huawei enterprise service bearer solution, ATN 905 functioning as an EDD has the

following advantages:

lSupports IP forward performance monitoring (FPM), tests without requiring meters at sites,

quality of service (QoS), and quick fault sectionalization and location complying with RFC

2544.

–Supports 802.1Q in 802.1Q (QinQ) for separating user VLANs and carrier VLANs,

facilitating fault sectionalization.

–Supports dying gasp so that equipment reports an alarm when experiencing power

outage.

lSupport real-time performance management through periodical tests and statistics on E2E

service performance including the throughput, delay, and packet loss rate, service level

agreement (SLA) compliance reports.

Figure 1-4 and Figure 1-5 show basic networking of the enterprise service bearer solution to

which ATN 905 belongs.

lWith the help of the current IPRAN, ATN 905 can connect to the IPRAN macro base station

backhaul network. On the E2E ATN+CX network, enhanced ATN functions, such as DCN

plug and play and RFC 2544-compliant IP FPM, can be deployed to improve the network

operation and maintenance efficiency.

NOTE

In the IPRAN macro base station backhaul network solution, ATN 905 can also connect to the macro

base station backhaul network in Native IP or Native ETH mode.

ATN 905 Multi-service Access Equipment

Product Description 1 Product Positioning and Features

Issue 01 (2013-05-30) Huawei Proprietary and Confidential

Tabla de contenidos

Otros manuales de Punto de acceso inalámbrico de Huawei

Huawei

Huawei eAN3810A Manual

Huawei

Huawei AP4030DN Manual de funcionamiento

Huawei

Huawei OptiX RTN 310 Manual de usuario

Huawei

Huawei LTE E8372 Especificaciones técnicas

Huawei

Huawei R230D Especificaciones técnicas

Huawei

Huawei PT530 Manual de usuario

Huawei

Huawei EG860 Series Manual de usuario

Huawei

Huawei AP Series Manual de usuario

Huawei

Huawei MA5833 Manual de usuario

Huawei

Huawei AP4050DN-HD Especificaciones técnicas

Huawei

Huawei eA660 Series Manual de usuario

Huawei

Huawei UA5000 Manual de usuario

Huawei

Huawei AP8130DN Especificaciones técnicas

Huawei

Huawei B818-263 Especificaciones técnicas

Huawei

Huawei B2338-168ODU Manual de usuario

Huawei

Huawei AP4130DN Manual de usuario

Huawei

Huawei E5186 Manual de usuario

Huawei

Huawei Quidway WA1003A Manual de usuario

Huawei

Huawei eA660 Series Manual de usuario

Huawei

Huawei SmartAX MA5671 Manual de usuario

Huawei

Huawei AP4050DN-E Especificaciones técnicas

Huawei

Huawei OptiXstar P602E Manual de usuario

Huawei

Huawei Quidway NE40E Guía

Huawei

Huawei eLTE2.2 eA660 Series Especificaciones técnicas

Manuales populares de Punto de acceso inalámbrico de otras marcas

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manual de usuario

Ubiquiti

Ubiquiti NanoStation NSM2 Manual de usuario

Cisco

Cisco Aironet 1550 Series Manual de usuario

Aruba

Aruba IAP-335 Manual de usuario

Advantek Networks

Advantek Networks AWN-AP-54MR Manual de usuario

IP-COM

IP-COM AP355 Manual de usuario

Buffalo

Buffalo AirStation WLA-L11G Manual de usuario

EnGenius

EnGenius EnStationACv2 Manual de usuario

D-Link

D-Link DAP-3662 Manual de usuario

xG Technology

xG Technology xMax CN1300 Manual de usuario

Widelink

Widelink ezWave WAP-1100 Series Manual de usuario

Edimax

Edimax CAP1200 Manual de usuario

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manual de usuario

Aruba

Aruba AP-203R Manual de usuario

LuXout Shades

LuXout Shades LUXSHADE MOTION Manual de usuario

CreatComm

CreatComm TB5F Manual de usuario

SineDigital

SineDigital MW-1500AP(H) Manual de usuario

TP-Link

TP-Link AP9650 V1 Manual de usuario
