UPS2000-G-(1 kVA-3 kVA)

Quick Guide

Issue: 05

Date: 2017-07-21

UPS Model Represented By Weight Dimensions (H x W x D)

UPS2000-G-1KRTS

1 K

-standard model-rack

mounted

-IEC 10.7 kg 88 mm x 438 mm x 310 mm

UPS2000-G-1KRTL

1 K

-long backup time

model

-rack mounted-IEC 5.9 kg 88 mm x 438 mm x 310 mm

UPS2000-G-2KRTS

2 K

-standard model-rack

mounted

-IEC 18.5 kg 88 mm x 438 mm x 410 mm

UPS2000-G-2KRTL

2 K

-long backup time

model

-rack mounted-IEC 8.6 kg 88 mm x 438 mm x 410 mm

UPS2000-G-3KRTS

3 K

-standard model-rack

mounted

-IEC 27. 9 kg 88 mm x 438 mm x 630 mm

UPS2000-G-3KRTL

3 K

-long backup time

model

-rack mounted-IEC 9.2 kg 88 mm x 438 mm x 410 mm

1Introduction

UPS2000-G-1KRTS

UPS2000-G-1KRTL

UPS2000-G-2KRTS

UPS2000-G-2KRTL

(1) Mains input socket

(C14)

(2) Input circuit breaker

(3) Universal serial bus

(USB) port (security

protection mechanism

supported)

(4) RS232 port

(5)

Optional card slot

(6) Output socket (C13)

(7) External battery

connector (only for

long backup time

models)

(1) Mains input socket

(C14)

(2) Input circuit breaker

(3)

USB port (security

protection mechanism

supported)

(4) RS232 port

(5)

Optional card slot

(6) Output socket (C13)

(7) External battery

connector (only for

long backup time

models)

UPS2000-G-3KRTS

UPS2000-G-3KRTL

(1) Mains input socket

(C20)

(2) Input circuit breaker

(3)

USB port (security

protection

mechanism

supported)

(4) RS232 port

(5)

Optional card slot

(6) Output socket (C13)

) Output socket (C19)

(8) External battery

connector (only for

long backup time

models)

UPS2000-G Rack-mounting Installation

Scenario 1

1. Before installation, read the UPS2000-G-(1 kVA-3 kVA) User Manual to get familiar with UPS

information and safety precautions. UPS is short for uninterruptible power system.

2. Use fully insulated tools during installation and operations.

3. Only engineers certified by the manufacturer or its agents are allowed to perform UPS

installation, commissioning and maintenance. Otherwise, personal injury or equipment damage

may occur, and the resulting UPS faults are beyond warranty scope.

1. Install mounting brackets on UPS.

2. Install guide on the Cabinet. Then place the UPS on the guide rails. For details about how to

install guide and UPS on the cabinet, see the UPS2000-G-(1 kVA-3 kVA) Rail Assembly Quick

Installation Guide.

NOTICE

2Installing a Single UPS

UPS2000-G Tower-mounting Installation

Scenario 2

To tower-mount a UPS, perform the following steps:

1. Remove the UPS front panel.

2. Rotate the control panel 90 degrees clockwise.

3. Rotate the logo 90 degrees clockwise on the front panel. Reinstall the front panel.

4. Assemble support bases. The minimum distance between two support bases should be 150 mm.

5. Place UPS on the support bases in sequence.

6. Adjust the UPS and the support bases to be horizontally.

UPS load

UPS2000-G-1KRTS

UPS load

UPS2000-G-1KRTL

UPS load

UPS2000-G-2KRTS

3Installing Cables

For socket-type output, connect loads to the UPS output sockets

Installing the UPS Output Power Cables

3.1

Connect the battery cable delivered with the long backup time model to an external battery pack.

(This step is optional for the long backup time model. The standard model contains batteries and

provides no battery port.)

The installation method for 1 kVA UPS, 2 kVA UPS, and 3 kVA UPS is the same. The figures

below are based on the 3 kVA UPS.

For details, see the UPS2000-G-(1 kVA-3 kVA) Battery Pack Quick Installation Guide.

Installing the UPS Battery Cable (Only for UPS with Long Backup Time)

3.2

UPS load

UPS2000-G-3KRTS

UPS2000-G-3KRTL

UPS load

UPS2000-G-2KRTL

UPS load

1. If the 1 kVA UPS with long backup time needs to connect to external battery strings, each

battery string must consist of three 12 V batteries connected in series. If the 2 kVA UPS with

long backup time needs to connect to external battery strings, each battery string must consist

of six 12 V batteries connected in series. If the 3 kVA UPS with long backup time needs to

connect to external battery strings, each battery string must consist of eight 12 V batteries

connected in series.

2. The UPS with long backup time provides a charge current of 4 A and the current is not

configurable. If the UPS needs to connect to battery packs or battery strings, the total battery

capacity must exceed 18 Ah. Otherwise, batteries may be damaged. If the capacity of external

battery packs or battery strings to be connected exceeds 40 Ah, it is recommended that an

external charger be purchased to increase the charge current. If an external chargers is not

purchased, the charge time will be long.

3. The battery pack (ESS-36V12-9*2AHBPVBB01) for 1 kVA UPS with long backup time contain

two group battery strings. The battery pack (ESS-72V12-9AHBPVBB01) for 2 kVA UPS with

long backup time only contain one group battery strings. The battery pack (ESS-96V12-

9AHBPVBB02) for 3 kVA UPS with long backup time only contain one group battery strings.

4. The 1 kVA UPS with long backup time is allowed a maximum of two battery packs (ESS-36V12-

9*2AHBPVBB01) in parallel. The 2 kVA UPS with long backup time is allowed a maximum of

four battery packs (ESS-72V12-9AHBPVBB01) in parallel. The 3 kVA UPS with long backup

time is allowed a maximum of four battery packs (ESS-96V12-9AHBPVBB02) in parallel.

Connect the UPS to the RS232 or USB port on a PC. Then you can monitor the UPS status using

the PC as long as you have installed the monitoring software. The installation method for 1 kVA

UPS, 2 kVA UPS, and 3 kVA UPS is the same. The figures below based on the 3 kVA UPS.

Installing the UPS Communication Cable

3.3

1. The USB channel supports a serial data communications protocol between the UPS and the PC.

2. If you connect a DB9 connector to the RS232 port, the UPS can communicate with the PC over

serial data.

3. The UPS support either USB or RS232.

4. To monitor the UPS over a PC, also need to install the monitoring software iManager NetEco

1000U. For details about how to install and use the iManager NetEco 1000U, see the iManager

NetEco 1000U User Manual. The software and the user manual are available at

http://support.huawei.com or http://support.huawei.com/enterprise.

UPS2000-G-3KRTS

PC PC

UPS2000-G-3KRTL

Battery pack

UPS2000-G-3KRTL

Installing the UPS Input Cable

3.4

Mains input

UPS2000-G-1KRTS

Take out input power cable from the fitting bag, and connect mains input power cable to the UPS.

UPS2000-G-1KRTL

Mains input

UPS2000-G-3KRTS

Mains input

For the installation procedure, see the RMS-SNMP01B SNMP Card User Manual, RMS-RELAY01B

User Manual, RMS-MODBUS01B User Manual. The installation method for 1 kVA, 2 kVA UPS, and

3 kVA UPS is the same. The figures below are based on the 3 kVA UPS.

4Installing the Optional Card to the UPS

No. Item Acceptance Criterion

1 Cable routing Cable routing meets engineering requirements.

2 Cable connections Power cables and battery cables are tightened to

specified torques using a torque wrench,

connected correctly, and free of damage.

3 Cable connections for USB ports and

network ports Cables to USB ports and network ports are

connected correctly and securely.

4 Labels Labels are neatly attached to both ends of each

cable, and the information on the labels is concise

and understandable.

5 Ground cable connection and

upstream circuit breaker for the UPS The ground cable is securely connected to the

ground bar in the equipment room. An upstream

circuit breaker of proper specifications is installed

on the UPS input end.

6 Distances between cable ties Distances between cable ties are the same, and

no burr exists.

7 Operating environment Clean the conductive air and other sundries.

Verifying the Installation

5Optional Card

UPS2000-G-3KRTS UPS2000-G-3KRTL

Optional Card

UPS2000-G-3KRTL

Mains input

UPS2000-G-2KRTS UPS2000-G-2KRTL

Mains input

Operations

ON/MUTE SELECT OFF/ENTER

Setting Key UPS Parameters

6.1

1. The 1 kVA UPS with standard backup time have two built-in batteries, the 2 kVA UPS with

standard backup time have four built-in batteries, the 3 kVA UPS with standard backup time

have six built-in batteries.

2. If the 1 kVA UPS with long backup time needs to connect to external battery strings, each

battery string must consist of three 12 V batteries connected in series. If the 2 kVA UPS with

long backup time needs to connect to external battery strings, each battery string must consist

of six 12 V batteries connected in series. If the 3 kVA UPS with long backup time needs to

connect to external battery strings, each battery string must consist of eight 12 V batteries

connected in series.

3. The UPS with long backup time provides a charge current of 4 A and the current is not

configurable. If the UPS needs to connect to battery packs or battery strings, the total battery

capacity must exceed 18 Ah. Otherwise, batteries may be damaged. If the capacity of external

battery packs or battery strings to be connected exceeds 40 Ah, it is recommended that an

external charger be purchased to increase the charge current. If an external charger is not

purchased, the charge time will be long.

4. For the UPS with standard backup time, the battery capacity has a fixed value of 9 Ah and the

charge current has a fixed value of 1 A. Set the battery capacity to the total capacity of all

batteries actually connected. Set the battery capacity for the long backup time model based

on site requirements. The default value is 7 Ah. For example, if eight batteries (9 Ah, 12 V) are

connected in series to form a battery string, and two of such battery strings are connected in

parallel and then to the UPS, set battery capacity to 18 Ah (9 Ah + 9 Ah). This parameter

affects the backup time calculation. Incorrect setting will cause incorrect display of the backup

time on the LCD.

5. When the battery pack/batteries connect to the Long back-up UPS for the first time, you must

do a battery self-check manually, in order to confirm the battery connection is normal. The

method is: hold down ON/MUTE on the front panel for 5 seconds, then the UPS transfer to

battery mode to do a shallow discharge test, after 10 seconds it automatically back to line

mode.

6. Charge the batteries used for the first time for 5 hours. Otherwise, the battery discharge time

will decrease.

NOTICE

If this is the initial startup, set system parameters such as output voltage, output frequency, and

battery parameters as required.

1. After power on the UPS, hold down SELECT for 5 seconds. The UPS enters the preset mode.

2. In the preset mode, press SELECT for more than 3 seconds is used to select the next option,

press ON/MUTE for more than 3 seconds is used to select a previous option, and press

OFF/ENTER for more than 3 seconds is used to confirm your selection. The meaning of LCD

display character see the 7.1 Character Display Description in page 9. Set voltage level to 200

V, 208 V, 220 V, 230 V (default), or 240 V. Set output frequency level to 50 Hz, 60 Hz, and AUT

(default). The battery capacity for the UPS with standard backup time cannot be changed. The

default value of battery capacity is 7 Ah for the UPS with long backup time, and the value can

range from 0 Ah to 999 Ah.

For more parameters setting information, see the UPS2000-G-(1 kVA-3 kVA) User Manual.

1. In the preset mode, LCD will return to the main page with 10 seconds of no operation.

2. If the long backup time model is not connected to an external battery pack, the buzzer keeps

buzzing.

3. The UPS performs a battery self-check automatically once a week. If batteries are faulty, an

alarm is generated.

Starting the UPS to Inverter Mode

6.2

When the UPS is connected to the Mains Input, it is no output. Hold down ON/MUTE on the front

panel for over 5 seconds to make it transfer to inverter mode output. The default output of inverter

mode is 230 V.

Shutting down the UPS

6.3

•Normal Mode: If the UPS is originally in normal mode, hold down OFF/ENTER for over 2

seconds will enable the UPS to enter the standby mode or bypass mode (if set or enabled

before).

•Battery mode: Hold down OFF/ENTER for over 2 seconds to turn off the UPS in battery mode.

Acronym

Display

Description

Acronym

Display

Description

ENA

Enable

FRE

Frequency

DIS

Disable

BVU

Bypass overvoltage

ESC

Escape

BVL

Bypass

undervoltage

Frequency

conversion

CAP

Capacity

Temperature

Discharge time

Charging

ECO

ECO mode

Bypass frequency

unstable

High voltage

EEPROM error

Low voltage

VOT

Voltage

AUT

Constant

frequency

mode

BUZ

Buzzer off

AST

Automatic startup

Alarm

type

Buzzer alarm tone

Battery mode

Beeps once every 4 seconds.

Minor alarm

Beeps once every second.

Overload

Beeps twice every second.

Critical alarm

Buzzes continuously.

Bypass mode

Beeps once every 10 seconds.

7FAQ

Character Display Description

7.1

Buzzer Alarm Tone Description

7.2

Otros manuales para UPS2000-G Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unión Postal Universal de Huawei

Huawei

Huawei UPS2000-H Manual de usuario

Huawei

Huawei UPS5000-H-1200 Series Manual de usuario

Huawei

Huawei UPS5000-S Series Manual de usuario

Huawei

Huawei Telecom Power TP48200A-DX12A1 Manual de usuario

Huawei

Huawei UPS5000-E-80K-LABBS Manual de usuario

Huawei

Huawei SUN2000-4.95KTL-JPL0 Manual de usuario

Huawei

Huawei UPS2000-G-1KRTS Manual de usuario

Huawei

Huawei UPS5000-E Series Manual de usuario

Huawei

Huawei UPS5000 Manual de usuario

Huawei

Huawei UPS2000-G-6KRTS Manual de usuario

Huawei

Huawei UPS5000-E-30 kVA Manual de usuario

Huawei

Huawei UPS2000-G-6KRTS Manual de usuario

Huawei

Huawei UPS5000-A-30KTTL Manual de usuario

Huawei

Huawei UPS5000-E-25 kVA-BF Manual de usuario

Huawei

Huawei UPS5000-E Series Manual de usuario

Huawei

Huawei PowerCube 500 Manual de usuario

Huawei

Huawei UPS5000-H-600 kVA-FTN Manual de usuario

Huawei

Huawei PDU8000 Series Manual de usuario

Huawei

Huawei UPS5000-H-600 kVA Manual de usuario

Huawei

Huawei UPS5000-H-1200 kVA Manual de usuario

Huawei

Huawei SmartLi Series Manual de usuario

Huawei

Huawei UPS5000-H Series Manual de usuario

Huawei

Huawei PDU8000 Series Manual de usuario

Huawei

Huawei UPS2000-G-2KRTL Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario
