Huawei EchoLife HG8040H Especificaciones técnicas
EchoLife HG8040H/HG8012H/HG8010H GPON
Terminal
V300R013C00
Product Description
Issue 01
Date 2013-08-08
HUAWEI TECHNOLOGIES CO., LTD.
Copyright © Huawei Technologies Co., Ltd. 2013. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or representations
of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [email protected]
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i
About This Document
Product Version
The following table lists the product versions related to this document.
Product Name Product Version
EchoLife HG8040H/HG8012H/HG8010H V300R013C00
Overview
GPON terminal EchoLife ONT is an indoor optical network terminal (ONT) designed for home
users. This document provides the appearance, key features, and technical specifications of the
ONT, which helps you know the ONT quickly.
NOTE
Each ONT supports different types and counts of ports. Contents in this document may not be supported by all
ONTs. For differenes between ONTs, see 1.3 Specifications Differences Between Different Product
Models.
Symbol Conventions
The following symbols may be found in this document. They are defined as follows:
Symbol Description
DANGER indicates a hazard with a high level or medium
level of risk which, if not avoided, could result in death or
serious injury.
WARNING indicates a hazard with a low level of risk
which, if not avoided, could result in minor or moderate
injury.
CAUTION indicates a potentially hazardous situation
that, if not avoided, could result equipment damage, data
loss, performance degradation, or unexpected results.
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description About This Document
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
Symbol Description
Indicates a tip that may help you solve a problem or save
your time.
Provides additional information to emphasize or
supplement important points of the main text.
Change History
Changes between document issues are cumulative. Therefore, the latest document issue contains
all changes made in previous issues.
Issue 01 (2013-08-08)
This is the first official release for the V300R013C00 version.
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description About This Document
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Contents
About This Document.....................................................................................................................ii
1 Introduction....................................................................................................................................1
1.1 Product Positioning.........................................................................................................................................................2
1.2 Network Applications.....................................................................................................................................................2
1.3 Specifications Differences Between Different Product Models.....................................................................................3
1.4 Product Overview...........................................................................................................................................................3
1.4.1 HG8040H.....................................................................................................................................................................3
1.4.2 HG8012H.....................................................................................................................................................................8
1.4.3 HG8010H...................................................................................................................................................................12
2 Product Functions and Features................................................................................................18
3 Product Highlights......................................................................................................................19
3.1 Comprehensive Triple Play Service.............................................................................................................................20
3.2 Quality CATV Service Transmission...........................................................................................................................20
3.3 Convenient Automatic Provisioning, Maintenance, and Management of the Remote Service....................................20
4 Port Specifications.......................................................................................................................21
4.1 GPON Port Specifications............................................................................................................................................22
4.2 GE Port Specifications..................................................................................................................................................22
4.3 CATV Port Specifications............................................................................................................................................23
5 Acronyms and Abbreviations...................................................................................................24
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description Contents
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv
1 Introduction
1.1 Product Positioning
1.2 Network Applications
1.3 Specifications Differences Between Different Product Models
This topic introduces the specification differences between ONTs in V300R013C00,
specifically, features supported by different ONTs.
1.4 Product Overview
This topic introduces the appearances, ports, and LEDs of ONTs in V300R013C00.
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1.1 Product Positioning
EchoLife GPON terminal V300R013C00 is an indoor optical network terminal (ONT) designed
for home users. Its upper shell adopts the natural heat dissipation material, and its optical port
adopts the dust-proof design with a rubber plug. The ONT is eye-pleasing and energy-efficient.
It can be deployed on a workbench or mounted on a wall, meeting users' deployment
requirements in different scenarios.
The ONT provides the more convenient and efficient remote management function. It supports
the ONT Management and Control Interface (OMCI) protocols and manages all home terminals
in a unified manner, implementing remote fault diagnosis, service provisioning, and performance
statistics.
By using the Gigabit-capable Passive Optical Network (GPON) technology, the ONT provides
a high-speed data channel through a single optical fiber with an upstream rate of 1.244 Gbit/s
and a downstream rate of 2.488 Gbit/s. In this way, you can enjoy the high-speed data service,
quality voice service, and superior video service.
1.2 Network Applications
As a network terminal, the ONT is deployed at the GPON access layer and connects the home
user to the Internet through the optical upstream port.
Figure 1-1 shows the position of the ONT on a network.
Figure 1-1 Network topology of the ONT
lIn the upstream direction, the ONT is connected to the optical splitter and the networkside
OLT through the passive optical network (PON) port, namely the OPTICAL port, to
provide the integrated access service.
lIn the downstream direction, the ONT is connected to the HG through the LAN port so as
to provide various interfaces to connect different terminals, implementing the triple play
service.
Ethernet port, which can be connected to terminals such as the PC, STB, and video phone
to provide the high-speed data and video services.
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
NOTE
Each Ethernet port allows only 1 user access.
1.3 Specifications Differences Between Different Product
Models
This topic introduces the specification differences between ONTs in V300R013C00,
specifically, features supported by different ONTs.
ONT
Type
Ethernet
Access
CATV 3.2 Quality
CATV
Service
Transmissio
n
4.2 GE Port
Specificatio
ns
4.3 CATV
Port
Specificatio
ns
HG8040H 4xGE No No Yes No
HG8012H 1xGE 1xCATV Yes Yes Yes
HG8010H 1xGE No No Yes No
NOTE
lIn the preceding table, Yes indicates that the feature is supported while No indicates not supported.
lThe preceding table lists only differences supported by products.
1.4 Product Overview
This topic introduces the appearances, ports, and LEDs of ONTs in V300R013C00.
1.4.1 HG8040H
Introduced the appearance, interfaces, LEDs and device parameters of the HG8040H.
Appearance
Figure 1-2 Appearance of the HG8040H
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
Port/Button
Figure 1-3 and Figure 1-4 show the ports on the rear panel and side panel of the HG8040H
respectively.
Figure 1-3 Ports and buttons on the rear panel of the HG8040H
Table 1-1 Description of ports and buttons on the rear panel of the HG8040H
Port/Button Function
ON/OFF Indicates the power button. It is used to power on or power off
the device.
POWER Indicates the power port, used to connect to the power adapter
or backup battery unit.
LAN1–LAN4 Indicates auto-sensing 10/100/1000M Base-T Ethernet ports
(RJ-45), used to connect to PCs or IP set-top boxes (STBs).
Figure 1-4 Ports and buttons on the side cover of the HG8040H
Table 1-2 Description of ports and buttons on the side cover of the HG8040H
Port/Button Function
Reset
Indicates the reset button. Press the button for a short time to
reset the device; press the button for a long time (longer than
10s) to restore the device to the default settings and reset the
device.
Figure 1-5 shows optical ports on the HG8040H.
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
Figure 1-5 Optical ports on the HG8040H
Table 1-3 Optical ports on the HG8040H
Port/Button Function
OPTICAL
Indicates an optical port. The optical port is equipped with a
rubber plug and is connected to an optical fiber for upstream
transmission.
The type of the optical connector connected to the OPTICAL
port is SC/APC.
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
