Huawei FusionModule800 Manual de usuario

HUAWEI TECHNOLOGIES CO., LTD.

FusionModule800 Smart Small Data

Center

Quick Guide

Issue: 02

Date: 2021-02-05

Item Specifications

Cabinet dimensions

(H x W x

D)/Reference net

weight

•IT cabinet: 2000 mm x 600 mm x 1350 mm/160 kg

•Converged Cabinet: 2000 mm x 600 mm x 1350 mm/410 kg

•Battery cabinet (deployed inside the aisle containment): 2000 mm x

600 mm x 1350 mm/160 kg

•Battery cabinet (deployed outside the aisle containment): 2000 mm

x 600 mm x 1100 mm/1200 mm/140 kg

•Network cabinet: 2000 mm x 800 mm x 1350 mm/160 kg

Indoor unit (with a

control unit)

dimensions (H x W x

D)/Net & gross

weight

•With water pump, heater, and humidifier: NetCol5000-A013: 486

mm x 442 mm x 800 mm/52.6 kg & 70 kg

•With water pump, but without heater and humidifier: NetCol5000-

A013: 486 mm x 442 mm x 800 mm/49.4 kg & 66.8 kg

Outdoor unit

dimensions (H x W x

D)/Net & gross

weight

•NetCol500-A018: 966 mm x 1057 mm x 339 mm/83 kg & 99 kg

•NetCol500-A020: 1327 mm x 966 mm x 320 mm/101 kg & 114 kg

•NetCol500-A021: 1350 mm x 1270 mm x 730 mm/205 kg & 235 kg

Bearing capacity

•Standard live load of the main equipment room: 8-12 kN/m²(If the

battery cabinet is placed inside the smart module, use the standard

live load of the main equipment room as a reference.)

•Suspended load of the main equipment room: 1.2 kN/m²

•Standard live load of the battery room: 16 kN/m²

Levelness Allowed deviation: 3/2000 mm

Equipment room

height ≥ 2.6 m

Equipment room area 8–30 m²

Door size Height > 2.2 m; width > 0.9 m

Elevator

Elevator bearing capacity > 1.5 t

Elevator internal size: height > 2.4 m, depth > 1.4 m

Elevator door size: height > 2.2 m; width > 0.9 m

Power supply 380 V AC/400 V AC/415 V AC, 3 Ph, 50 Hz/60 Hz

Floor drain DN50 or larger, made of cast iron or stainless steel

Grounding

A general ground bar is configured in the Converged Cabinet. The

general ground point in each cabinet connects to the general ground

bar in the Converged Cabinet. The general ground bar in the

Converged Cabinet connects to the floor ground bar or collective

ground bar.

Water port

Condensate drain outlet: for draining condensate from the smart

cooling product.

Humidifier water pipe port: Connects to external water pipes to supply

water to the humidifier.

Overview

IT cabinet

Camera mounting kit on

the enclosed framework

Side sealing

plate

Gas

spring

Battery

cabinet

cabinet electronic

clasp lock

Converged cabinet

The component layout illustrates only the positions of components. The actual component

installation positions prevail.

Space requirements for the cold and hot aisle containment

Installation Scenarios

1Smart Module Installation Scenario

•The cabinet layout shown in the figure is for ease of description and does not provide

reference for engineering layout.

•If the site conditions do not meet the space requirements, contact Huawei technical support.

•If the outdoor unit is placed higher than the indoor unit, the maximum height deviation

between them should be less than or equal to 30 meters. Install an oil trap every 5–6 meters

in the vertical direction along the gas pipe.

•If the indoor unit is placed higher than the outdoor unit, the maximum height deviation

between them should be less than or equal to 8 meters.

2Outdoor Unit Installation Scenario

(1) Oil trap

(2) Tilted gas pipe

(3) Indoor unit

(4) Tilted liquid pipe

Layout of upward piping Layout of downward piping

Hardware Installation

1(Optional) Removing Aisle Containments

1. Remove the PAD cable.

2. Remove the gas springs.

3. Remove the cabinet doors.

4. Remove the top plate.

5. Remove the air director.

6. Remove an aisle containment.

7. Reinstall all components.

2Adjusting the Positions of Aisle Side Sealing Plates

1. Remove the aisle side sealing plates

from the Converged Cabinet.

2. Install sealing plate fasteners for an end

cabinet.

3. Install floating nuts for the end cabinet.

4. Install aisle side sealing plates for the end cabinet.

3Installing a Cabinet

•Use a measuring tape to check that the

vertical distance between the top of the 2000

mm high cabinet and the floor is 2000 mm

(+3 mm). Then use a level to check that the

cabinet is level.

•Do not remove the anchor bolts. Otherwise,

rework is required if the cabinet height does

not meet requirements.

1. Determine the cabinet position based

on the engineering layout diagram.

2. Place the end cabinet at the correct

installation position.

3. Level the cabinet using a wrench.

4. Combine cabinets.

5. Install other cabinets in the same way.

4(Optional) Install the eLight

1. Install the strip light. 2. Interconnect the terminals.

3. Install the eLight actuator and power

module.

eLight actuator

eLight power module

(1)Strip light extension

cable

(2) ETH converter

4. Connect cables to the eLight system.

a. Open the rear door of the end cabinet.

b. Align one end of the support with the notch

on the rear door side of the top panel, and

hook the other end of the support to the

long strip hole on the top panel, as shown

by (1) in figure.

c. Secure the support using two screws at the

notch on the rear door side of the top panel,

as shown by (2) in figure.

1. (Optional) Remove the guide rails.

Moving the Mounting Bar

5.1

3. Remove an air baffle from the top of the front door of the cabinet shown in Figure (1),

rotate the air baffle by 180 degrees, and secure it to the top. Obtain the other four air baffles

from the fittings bag and secure them to the post on the front door.

2. Remove screws from the mounting bar.

5(Optional) Install an Indoor Unit

•This section applies to the scenario with three or four smart cooling products. The figures in

this document use the third cooling product as an example. If the fourth cooling product is

configured, refer to the installation method of the third cooling product. When the fourth

cooling product is installed, the layout of the control units are different. If there are only two

smart cooling products, skip this section.

•Install the rPDU before installing the third and fourth smart cooling products.

5. Move the two front mounting bars on the front door side 75 mm towards the cabinet rear,

and secure them to the transfer brackets. Then move the two rear mounting bars on the

middle side 50 mm towards the cabinet rear directly.

4. Obtain transfer brackets from the fitting bag of the cabinet, and install them at the six

positions shown in Figure (2).

Installing Guide Rails at the

Bottom of the IT Cabinet

5.2 Floating Nut Installation Positions

(for the Third Indoor Unit)

5.3
