Huawei B882-66 Manual del operador

B882-66 LTE Wireless Gateway

Quick Start

96722859_01

1Getting to know your B882-66

Power indicator

On: the B882-66 is powered on.

Off: the B882-66 is powered off.

Network mode

indicator

Blinking red: no USIM card is found, the PIN is not

verified, or the USIM card is not working properly.

Steady cyan: registered with an LTE network.

Steady blue: registered with a 3G network.

Off: no signal.

Wi-Fi/WPS

indicator

Steady on: Wi-Fi turned on or data transfer in

progress.

Blinking: a WPS connection is being set up.

Off: Wi-Fi turned off.

SMS indicator

Steady on: inbox is full.

Blinking: new messages.

Call status

indicator

Steady on: call in progress.

Blinking: incoming call.

Wireless

connection

indicator

Steady on: connected to a LTE/3G network.

Blinking: connecting to a LTE/3G network.

/ /

LAN indicator

Steady on: LAN port is connected to a client.

Blinking: data is being transmitted through LAN

port.

Off: no client is connected to LAN port.

Wired

connection

indicator

Steady on: connected to an Ethernet network.

Blinking: connecting to an Ethernet network.

USIM card slot

Install a USIM card to access to the Internet via a

LTE/3G data connection.

Dial-up button

The B882-66 can access the Internet in Auto, Manual,

or On Demand mode.

In Manual mode, press it to manually connect to or

disconnect from the Internet.

Wi-Fi/WPS

button

Press and hold for about 3 seconds to turn on or off

Wi-Fi.

Press and hold for 6 or more seconds to active

WPS connection when Wi-Fi is turned on.

Reset button

Restoring the default settings of the B882-66 will

erase all previous settings.

When the B882-66 is powered on, use a sharply

pointed object to press and hold for about 3 seconds

until all indicators are blinking to restore the B882-66

to its factory settings. After the factory defaults are

restored, the B882-66 will restart automatically.

WAN port

Connect to an Ethernet port on the wall through a

network cable if you want to access to the Internet via

wired way.

/ /

LAN port

Connect to computer, switch, or other LAN device.

Telephone port

Connect to telephone.

Power port

Connect to compatible power adapter.

Power button

Press and hold for about 3 seconds to power the

B882-66 on or off.

2Installation

Installing the USIM card

If you want to use LTE/3G wireless data service and voice service, please install the

USIM card.

1. Pull out the card slot cover and rotate it to reveal the USIM card slot.

2. Partially insert the USIM card into the card slot. Ensure that the beveled edge of the

USIM card aligns with that of the card slot. Gently push the card until it clicks into

place.

3. Close the card slot cover.

Before installing or removing the USIM card, ensure that the B882-66 is powered off

and disconnected from the power outlet.

Connecting cables

Once connected to a power outlet, the B882-66 automatically powers on.

Ethernet port

on the wall

Computer

Telephone

Power adapter

Laptop, tablet, or

smart phone

To prevent interference caused by radio signals, place the B882-66 at least 1 meter (3.28

feet) away from telephone and other electrical devices.

Do not connect the B882-66 to the telephone wall outlet (or any Public Switched

Telephone Network), because doing so could damage the B882-66 due to excessive

heat.

3Setting up a Wi-Fi connection

Turning on Wi-Fi on the B882-66

When the indicator is steady on, the Wi-Fi of the B882-66 is turned on.

To manually turn Wi-Fi on, press and hold the button for about 3 seconds.

Recording the SSID and Wi-Fi key

The default SSID and Wi-Fi key are printed on the B882-66's rear label.

Make sure your client (computer, tablet, or smart phone) also supports Wi-Fi.

To prevent unauthorized parties from accessing your wireless network, it is

recommended that you change the SSID and Wi-Fi key from time to time. For details,

see the help information on the web management page.

Setting up a Wi-Fi connection from a client

On Windows 7

1. Click on the status bar on the PC desktop.

2. A dialog box is displayed, and the computer scans for available wireless networks

within range. From the search results, select the wireless network with the same

SSID as the B882-66, and click Connect.

3. In the Connect to a Network dialog box, enter the B882-66's Wi-Fi key, and click OK.

Note that the Wi-Fi key is case sensitive.

4. When Connected is displayed next to the B882-66's SSID, the PC is connected to the

wireless network.

On Mac OS

1. Click on the status bar on the Mac desktop. Choose Turn AirPort On from the

displayed menu.

2. The Mac then scans for available wireless networks within range. From the search

results, select the wireless network with the same SSID as the B882-66.

3. In the displayed dialog box, enter the B882-66's Wi-Fi key, and click Join. Note that

the Wi-Fi key is case sensitive.

4. When a check mark appears next to the B882-66's SSID, the Mac is connected to the

wireless network.
