HTC Breeze Manual de usuario

HTC confidential

Service Manual

for

Breeze

HTC Proprietary

Confidential Treatment Requested

Rev. A02

Aug. 24, 2006

HTC Corp.

Engineering Mobility

HTC confidential

TITLE: Service Manual for Breeze

REV.

NO. DATE CONTENTS DEP. REVISED APP

D STGE.PER.

A01 07/05/2006 First release TSE Tracy

A02 08/24/2006 Revised page 32. test item TSE Tracy

HTC confidential

Table of contents

Chapter 1 - Introduction 5

1.1History

Chapter 2 - Product Specifications 6

Chapter 3 - Servicing Tools 9

Chapter 4 - Assembling and Disassembling 10

4.1Disassembling

4.2Assembling

4.3MBPre-Assembling

4.4LCDPre-Assembling

Chapter 5 - Diagnostic Programs 32

5.1ListofTestItems(DiagnosticsinSDcard)

5.2 Test Procedure

5.3 Test Procedure and Description

Chapter 6 - Leakage current Measurement on MB 36

6.1 Leakage current measurement with Fixture

6.2BatteryCapacityTest

Chapter 7 - Software Upgrade procedure 40

7.1 Software upgrade

7.2 Smartphone Reset

7.4SoftwareBackuptoSDcard

Chapter 8 - RF Antenna test spec and criteria 47

8.1 Antenna Test Specification

8.2 Antenna Test Criteria

HTC confidential

Chapter 9 - Inspection Criteria 49

9.1Definition

9.2InspectionArea

9.3Criteria

Chapter 10 - Trouble Shooting 51

Chapter 11 - Labeling Plan 58

Chapter 12 - Spare parts list 66

12.1Sparepartslistforrepair

12.2AccessorySparepartslist

12.3Boardlevelpartslist

Chapter 13 - Board Level Repair 71

13.1 Problem Identification &Troubleshooting

13.2 Components to be Replaced

Chapter 14 – Return to Vendor(RTV) 75

Chapter 15 – Repair report format and definition 76

Chapter 16 – HTC service document on line (SDO) 79

HTC confidential

Chapter 1 – Introduction

This manual provides the technical information to support the service activities of Breeze.

It contains highly confidential information, so any or all of this document should not be

revealed to any third party.

1.1 History

Reversion Update item Pages effected

A01 First release N/A

HTC confidential

Chapter 2 - Product Specifications

Function Specification

Platform zBar type form factor with Tri-mode HSDPA/

zUMTS and Tri-band GSM/ GPRS/ EDGE,

zBluetooth, and mega-pixel camera

zMicrosoft Windows Mobile Version 5.0 -Smartphone

Dimensions z112.4mm(L) x 49mm(W) x 14.8mm(T)

Weight z120g (with battery pack)

Processor zQualcomm MSM6275

zSamsung 2442M stacked CPU with 300MHz

Memory zFlash ROM: 128MB

zRAM: 64MB SDRAM

HSDPA/UMTS/GP

RS/ EDGE/GSM

Functional block

zHSDPA/UMTS/GPRS/ EDGE/GSM Functional

zInternal antenna

zTri-Mode (HSDPA/UMTS, EDGE, GSM/GPRS)

zUMTS/HSDPA(TBD)

z2100: 1920-1980, 2110-2170MHz

zEDGE/GSM/GPRS

z900: 880-915, 925-960MHz

z1800: 1710-1785, 1805-1880MHz

1900: 1850-1910, 1930-1990MHz

Display z2.2" 64K colors TFT LCD

zLED backlight

Keyboard/Button zPower Button/Quick List (Wake up key)

zTwo Soft-key Buttons (Wake up key)

z5 ways navigation pad

zSend Button (Wake up key)

zQuick Press: Start a phone call

zLong Press: Switch On/Off loud speaker

zEnd button (Wake up key)

zQuick Press: End a phone call

zLong Press: Switch On Key Lock

zVideo Telephony Button (Wake up key)

zHome (Wake up key)

HTC confidential

zQuick Press: Home

zLong Press (Press and Hold): BT/PDP Quick list

zBack/Clear Button (Wake up key)

zText Editing mode: Clear one character (Long press to delete

whole text field)

zNon-Text mode: Back key

zOperator Portal Button (Wake up key)

zNumerical dialing keypad (12 buttons / Wake up key)

zKeypad is labeled as GSM 02.30

zCamera Button (Right Lower Side / Wake up Key)

z3-Way Jog Wheel (Left Upper Side/ Wake up Key)

zNormal function: up/down/action key

zVoice volume control function: voice volume up/down in voice call

or in video call.

zVoice Dial/ Voice Record Button (Right Upper Side / Wake up

Key)

Interface z1.8V/3V of UICC

zUSIM Application at least according to 3GPP TS 31.102

zOne Infrared IrDA SIR

z11-pin mini-USB (USB1.1 full speed) / audio jack in one

zMicro SD card slot

zExternal RF connector with cover

Power zBattery

Rechargeable battery, Li-Ion 1190 mAh

RTC backup battery - golden capacitor for min.20minutes

Battery Meter Showing available battery

Low Battery Warning

zAC Adapter:

AC input rating: 100 ~ 240 VAC, 50/60Hz

DC output: 5VDC, 1A

zAmbient light sensor for Keypad LED power consumption

Sensor

zSupport Mi-ni-USB charging

HTC confidential

Device to device

connectivity zBluetooth

Compliant with v2.0 without EDR

ÖClass 2 transmit power

ÖSerial Port Profile

ÖActiveSync

zInfrared IrDA SIR

zUSB 1.1 with mini-USB plug and receptacle

Digital Camera

zMain Camera: 1.3 Mega Pixels CMOS

zSecond Camera: CIF CMOS for Video Telephony

zSupport Landscape mode

zLighting: Min. 5 Lux

Notification zNotification

zOne bi-color LED (Green, Red and Amber) for UMTS/GSM

standby, UMTS/GSM network status, Event Notification, Power

Charging status, PDANotification

zOne Blue LED for Bluetooth connectivity status

zVibration for notification and incoming call

zNotification by LED, Sound, Message, Vibration Motor

Accessories zAC adapter (Mini-USB Plug)

zUSB Sync. Cable

zStereo wired headset with microphone

zStandard Battery

zUser Manual, Quick Start Guide, Sync.

zSoftware CD

zOption : Car adapter ,Carrying Case, Bluetooth Headset

HTC confidential

Chapter 3 - Servicing Tools

This chapter provides information for the servicing tools for Riemann.

List of Servicing Tools

No. Item Use Remark

1 Disassembly tools Plastic stick for dismantle the unit

Cleaning wipers

Philips Screw driver

Protective Film

Tweezers

Air Gun

Clean Bench (Mandatory)

2 Mini USB cable For Synchronization Test

3 Mini SD Memory Card For SD card test

4 Headset For Hand free / Recording test

5 AC Adapter Power supply to this model

6 Diagnostic Test Program Test Program for Functional Test

7 Software Upgrade tools For software version upgrade or re-flash

8 Label Printer & Scanner For Printing & Scanning regulation label when

housing or M/B is changed.

9 Battery Test Jig For Main Battery judgment.

10 Mini SD card for OS reflash Optional method besides of using RUU via PC

How to purchase repair tool:

Please place your order for item you need to correspond BSO window; normally it will need 2 ~4

weeks for purchasing lead time.

Note: Not suitable for (** IN REMARK)

HTC confidential

Chapter 4 - Assembling and Disassembling

4.1 Disassembling Tools needed for Assembling and

Disassembling the Smart Phone

1. Glove & Lens Cleaning Tissue.

2. Plastic type tweezers.

3. Philip Screw Driver #0.

4. Philip Screw Driver type T6

5. Special Made Plastic Stick

6. Precision flat driver type 0.9mm (Θ)

Front side

Remove antenna rubber, battery cover, battery

from unit
