HPE LSWM1FANSC Manual de usuario

HPE LSWM1FANSC & LSWM1FANSCB

Fan Assemblies Installation

Part number: 5998-1615R

Document version: 6W101-20160115

The information contained herein is subject to change without notice. The only warranties for Hewlett Packard

Enterprise products and services are set forth in the express warranty statements accompanying such

products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett

Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or

copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software

Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s

standard commercial license.

Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard

Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise

website.

Acknowledgments

Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the

United States and other countries.

Microsoft® and Windows® are trademarks of the Microsoft group of companies.

Adobe® andAcrobat® are trademarks ofAdobe Systems Incorporated.

Java and Oracle are registered trademarks of Oracle and/or its affiliates.

UNIX® is a registered trademark of The Open Group.

Contents

Fan trays overview··························································································1

LSWM1FANSC fan tray·····································································································································1

Overview····················································································································································1

Specifications·············································································································································1

LSWM1FANSCB fan tray···································································································································2

Installing and removing a fan tray···································································4

Safety guidelines················································································································································4

Tools required····················································································································································4

Installing a fan tray·············································································································································4

Removing a fan tray···········································································································································5

Document conventions and icons···································································7

Conventions·······················································································································································7

Network topology icons······································································································································8

Support and other resources ··········································································9

Accessing Hewlett Packard Enterprise Support ································································································9

Accessing updates·············································································································································9

Websites ··················································································································································10

Customer self repair·································································································································10

Remote support········································································································································10

Documentation feedback ·························································································································10

Fan trays overview

LSWM1FANSC fan tray

Overview

The LSWM1FANSC (JC682A) fan tray blows cool air from the back (power side) to the front (port

side). It comprises two separate fans. The LSWM1FANSC features small size, fast heat dissipation,

and hot swapping. It can automatically adjust the fan speed, providing powerful heat dissipation for

the device.

Figure 1 LSWM1FANSC fan tray

(1) Captive screw (2) Airflow direction label

(3) Fan tray handle

Specifications

Table 1 LSWM1FANSC specifications

Item Specifications

Fans Two 40 × 40 × 28 mm (1.57 × 1.57 × 1.10 in) fans

Airflow direction Fans blow air from the power module side to the

network port side

Max fan speed 18500 R.P.M

Max airflow 45 CFM

Max power consumption 19.5 W

Voltage 12 V

Item Specifications

Operating temperature –10°C to 70°C (14°F to 158°F)

Relative humidity 5% to 95% (non condensing)

Storage temperature –40°C to 75°C (–40°F to 167°F)

Relative humidity 5% to 95% (non condensing)

LSWM1FANSCB fan tray

Overview

The LSWM1FANSCB (JC683A) fan tray draws in hot air from the front (port side) to the back (power

side). It comprises two separate fans. The LSWM1FANSCB features small size, fast heat dissipation,

and hot swapping. It can automatically adjust the fan speed, providing powerful heat dissipation for

the device.

Figure 2 LSWM1FANSCB fan tray

(1) Captive screw (2) Airflow direction label

(3) Fan tray handle

Specifications

Table 2 LSWM1FANSCB specifications

Item Specifications

Fans Two 40 × 40 × 28 mm (1.57 × 1.57 × 1.10 in) fans

Airflow direction Fans draw in air from the network port side to the

power module side

Max fan speed 18500 R.P.M

Item Specifications

Max airflow 45 CFM

Max power consumption 19.5 W

Voltage 12 V

Operating temperature –10°C to 70°C (14°F to 158°F)

Relative humidity 5% to 95% (non condensing)

Storage temperature –40°C to 75°C (–40°F to 167°F)

Relative humidity 5% to 95% (non condensing)

Installing and removing a fan tray

The installation and removal procedures for the LSWM1FANSC and LSWM1FANSCB are similar.

For more information, see “Installing a fan tray” and “Removing a fan tray.”

Safety guidelines

To avoid fan tray and device damage, and bodily injury, note the following guidelines when installing

or removing a fan tray:

•Wear an ESD-preventive wrist strap, and make sure the wrist strap makes good skin contact.

•Do not touch any wire or connector on a fan tray.

•Do not place a fan tray on a moist area, and avoid liquid flowing into the fan tray.

•Do not remove any component on a fan tray. If a failure occurs on the internal wires or units,

contact the technical stuff to troubleshoot the problem.

Tools required

Prepare the following tools when installing and removing a fan tray:

•Phillips screwdriver

•ESD-preventive wrist strap

Installing a fan tray

TIP:

Before installing a fan tray, make sure the air flow of the fan tray is as required.

1. Wear an ESD-preventive wrist strap and make sure it makes good skin contact and is well

grounded.

2. Take the fan tray from the package and check that the fan tray model is as required.

3. Face the slot into which the fan tray is to be installed. Grasp the handle of the fan tray with one

hand and support the fan tray bottom with the other, and then slide the fan tray along the guide

rails into the slot until the fan tray seats into the slot and has a firm contact with the connector on

the backplane (see callout 1 in Figure 3).

4. Fasten the captive screws on the fan tray with a Philips screwdriveruntil the fan tray is fixed into

the chassis (see callout 2 in Figure 3).

Figure 3 Install a fan tray

(1) Slide the fan tray into the slot (2) Fasten the captive screws

CAUTION:

•To prevent damage to the fan tray or the connector on the backplane, insert the fan tray gently. I

you encounter a hard resistance while inserting the fan tray, pull out the fan tray and then insert it

again.

•If the captive screws cannot be tightly fixed, check the installation of the fan tray.

Removing a fan tray

CAUTION:

•When replacing a fan tray with the device running, note safety with electricity.

•Do not touch rotating fans when replacing a fan tray with the device running.

1. Wear an ESD-preventive wrist strap and make sure it makes good skin contact and is well

grounded.

2. Face the fan tray to be removed from the device. Loosen the captive screws on the fan traywith

a Philips screwdriver until the captive screws fall off the device, as shown in callout 1 in Figure

3. Grasping the handle of the fan tray with one hand, pull the fan tray part way out the slot.

Supporting the fan tray bottom with the other hand, pull the fan tray slowly along the guide rails

out of the slot, as shown in callout 2 in Figure 4.

4. Put the removed fan tray on an anti-static mat or in its original package.

Figure 4 Remove a fan tray

(1) Loosen the captive screws on the fan tray (2) Pull the fan tray out of the slot

CAUTION:

•When removing a fan tray, take out the fan tray after the fans stop rotating.

•Do not touch the fans even if the fans stop rotating to avoid affecting the fan balance, which can

cause greater fan operation noise.

•To ensure normal operation of the device, install a new fan tray within two minutes after the fan

tray is removed if you replace a fan tray with the device running.

Document conventions and icons

Conventions

This section describes the conventions used in the documentation.

Port numbering in examples

The port numbers in this document are for illustration only and might be unavailable on your device.

Command conventions

Convention Description

Boldface Bold text represents commands and keywords that you enter literally as shown.

Italic Italic text represents arguments that you replace with actual values.

[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.

{ x | y | ... } Braces enclose a set of required syntax choices separated by vertical bars, from which

you select one.

[ x | y | ... ] Square brackets enclose a set of optional syntax choices separated by vertical bars,

from which you select one or none.

{ x | y | ... } * Asterisk marked braces enclose a set of required syntax choices separated by vertical

bars, from which you select at least one.

[ x | y | ... ] * Asterisk marked square brackets enclose optional syntax choices separated by vertical

bars, from which you select one choice, multiple choices, or none.

&<1-n> The argument or keyword and argument combination before the ampersand (&) sign

can be entered 1 to n times.

# A line that starts with a pound (#) sign is comments.

GUI conventions

Convention Description

Boldface Window names, button names, field names, and menu items are in Boldface. For

example, the New User window appears; click OK.

> Multi-level menus are separated by angle brackets. For example, File > Create >

Folder.

Symbols

Convention Description

WARNING! An alert that calls attention to important information that if not understood or followed

can result in personal injury.

CAUTION: An alert that calls attention to important information that if not understood or followed

can result in data loss, data corruption, or damage to hardware or software.

IMPORTANT: An alert that calls attention to essential information.

NOTE: An alert that contains additional or supplementary information.

TIP: An alert that provides helpful information.
