HP AF446A Instrucciones de montaje

EL-MF877-00 Page 1

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Product End-of-Life Disassembly Instructions

Product Category: External Options

Marketing Name / Model

[List multiple models if applicable.]

T750 G2 UPS NA / AF446A

T750 G2 UPS INTL / AF447A

T1000 G3 UPS NA / AF448A

T1000 G3 UPS INTL / AF449A

T750J UPS / AF456A

Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions

for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU

directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).

1.0 Items Requiring Selective Treatment

1.1 Items listed below are classified as requiring selective treatment.

1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as

applicable.

Item Description Notes

Quantity

of items

included

in product

Printed Circuit Boards (PCB) or Printed Circuit

Assemblies (PCA) With a surface greater than 10 sq cm

Batteries All types including standard alkaline and lithium coin

or button style batteries 2

Mercury-containing components For example, mercury in lamps, display backlights,

scanner lamps, switches, batteries 0

Liquid Crystal Displays (LCD) with a surface greater

than 100 sq cm Includes background illuminated displays with gas

discharge lamps 0

Cathode Ray Tubes (CRT) 0

Capacitors / condensers (Containing PCB/PCT) X capacitors 2

Electrolytic Capacitors / Condensers measuring

greater than 2.5 cm in diameter or height 1

External electrical cables and cords 1

Gas Discharge Lamps 0

Plastics containing Brominated Flame Retardants

weighing > 25 grams (not including PCBs or PCAs

already listed as a separate item above)

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner Include the cartridges, print heads, tubes, vent

chambers, and service stations. 0

Components and waste containing asbestos 0

EL-MF877-00 Page 2

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Components, parts and materials containing

refractory ceramic fibers 0

Components, parts and materials containing

radioactive substances 0

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components

and materials requiring selective treatment can be removed.

Tool Description Tool Size (if

applicable)

Philips Screw Driver #2

Torx Head Screw Driver Large

Wrench M4

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

1. Bezel-Manual removal

2. Removal the battery fixed plate

3. Battery connector-Manual disconnection

4. Removal of cover with Hex head screw drive on the rear of the unit

5. Pull the battery pack out from the battery room,disconnect the battery pack with PCB

6. Removal the rear panel with Philips Screw Driver, disconnect the wire between the rear panel and PCB

7. Removal the PCB from the main frame with Philips screw driver

8. Remove the AVR from the main frame with a M4 wrench

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items

contained in the product that require selective treatment (with descriptions and arrows identifying locations).

(1) The Component location of T750/T1000 UPS Unit

(2) Capacitor Location(diameter over 2.5cm)

(3) Battery Pack disassembly

EL-MF877-00 Page 3

Template Revision B

PSG instructions for this template are available at EL-MF877-01

(1) The Component location of T750/T1000 UPS Unit

a. front side

b. Top side

EL-MF877-00 Page 4

Template Revision B

PSG instructions for this template are available at EL-MF877-01

(2) Capacitor Location(diameter over 2.5cm)

(3) Battery Pack disassembly

EL-MF877-00 Page 5

Template Revision B

PSG instructions for this template are available at EL-MF877-01

NOTE:The battery should be properly disposed of at a local recycling/reuse or

hazardous waste center.
