hp StorageWorks

edge switch release notes

Part Number: AA-RTDZA-TE/958-000284-001

First Edition (January 2003)

These release notes contain late-breaking and supplemental information for the

HP StorageWorks Edge Switch 2/24 and Edge Switch 2/32.

For the latest version of these Release Notes and other Edge Switch documentation,

visit the HP storage website at: http://www.hp.com/country/us/eng/prodserv/storage.html.

Hewlett-Packard Company makes no warranty of any kind with regard to this material, including,

but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential

damages in connection with the furnishing, performance, or use of this material.

This document contains proprietary information, which is protected by copyright. No part of this

document may be photocopied, reproduced, or translated into another language without the

prior written consent of Hewlett-Packard. The information contained in this document is subject to

change without notice.

Microsoft, MS-DOS, Windows, and Windows NT are trademarks of Microsoft Corporation in the

U.S. and/or other countries.

All other product names mentioned herein may be trademarks of their respective companies.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions

contained herein. The information is provided “as is” without warranty of any kind and is subject

to change without notice. The warranties for Hewlett-Packard Company products are set forth in

the express limited warranty statements accompanying such products. Nothing herein should be

construed as constituting an additional warranty.

Printed in the U.S.A.

edge switch release notes

First Edition (January 2003)

Part Number: AA-RTDZA-TE/958-000284-001

edge switch release notes

edge switch release notes 3

These Release Notes contain late breaking and supplemental information for the

HP StorageWorks Edge Switch 2/24 and Edge Switch 2/32.

Be sure to read these Release Notes before installing an edge switch. This information

is periodically updated and available on the World Wide Web at:

http://www.hp.com/country/us/eng/prodserv/storage.html.

Contents

These Release Notes cover the following topics:

•Firmware Version 04.01.02, Build 04

•Related Documentation

•CD-ROM Directory Structure

•Supported Configurations

•Cable Requirements

•Known Issues

Firmware Version 04.01.02, Build 04

Firmware Version 04.01.00, Build 12 is the initial firmware released with the edge

switches. A copy of the latest version of the firmware, 04.01.02, Build 04 (as of this

date) is contained on the hp StorageWorks edge switch documentation and firmware

CD (Part Number 524-000001-001).The latest firmware is also available on the

HP website at:

http://www.hp.com/country/us/eng/prodserv/storage.html.

You need to upgrade Version 04.01.00, Build 12 to Version 04.01.02, Build 4. For

more information on upgrading firmware versions, refer to the appropriate

hp StorageWorks edge switch service manual. The features of this firmware version

are detailed in the accompanying manuals.

edge switch release notes

4edge switch release notes

Related Documentation

In addition to these release notes, HP provides corresponding information:

• hp StorageWorks edge switch 2/24 rack mount kit installation instructions,

AA-RTDGB-TE/958-000285-001

• hp StorageWorks edge switch 2/24 flexport upgrade instruction,

AA-RTDHA-TE/958-000286-000

• hp StorageWorks edge switch 2/24 installation guide,

AA-RTDWA-TE/958-000283-000

• hp StorageWorks edge switch 2/24 service manual, AA-RTDXA-TE

• hp StorageWorks edge switch 2/24 product manager user guide, AA-RTDYA-TE

• hp StorageWorks edge switch rack mount kit installation instructions,

AA-RT4MB-TE/958-000293-000

• hp StorageWorks edge switch 2/32 flexport upgrade instruction,

AA-RS33B-TE/958-000291-000

•hp StorageWorks edge switch 2/32 installation guide,

AA-RSTZB-TE/958-000290-000

•hp StorageWorks edge switch 2/32 service manual, AA-RS2GB-TE

• hp StorageWorks edge switch 2/32 product manager user guide, AA-RS2HB-TE

• hp StorageWorks CLI reference guide for directors and edge switches,

AA-RQ7AC-TE

• hp StorageWorks SNMP reference guide for directors and edge switches,

AA-RQ7BC-TE

• hp StorageWorks SAN high availability planning guide, AA-RS2DB-TE

• hp StorageWorks embedded web server user guide, AA-RTDRA-TE

• hp StorageWorks ha-fabric manager user guide, AA-RS2CB-TE

• hp StorageWorks HAFM server installation guide, AA-RT4KB-TE

•hp StorageWorks ha-fabric manager release notes, AV-RSNXC-TE

edge switch release notes

edge switch release notes 5

CD-ROM Directory Structure

The hp StorageWorks edge switch documentation and firmware CD contains the

following items:

CD-ROM Directory Structure for Edge Switch 2/24 and Edge Switch 2/32

Documentation

• Manuals.pdf – (HP StorageWorks Edge Switch and Edge Switch 2/32

Documentation; links to all documents below and search function)

•Docs

— README.TXT – (HP Doc Structure; late breaking doc changes)

— AA-RTDWA-TE/958-000283-000 – (hp StorageWorks edge switch 2/24

installation guide)

— AA-RTDXA-TE – (hp StorageWorks edge switch 2/24 service manual)

— AA-RTDYA-TE – (hp StorageWorks edge switch 2/24 product manager user

guide)

— AA-RSTZB-TE/958-000290-000 – (hp StorageWorks edge switch 2/32

installation guide)

— AA-RS2GB-TE – (hp StorageWorks edge switch 2/32 service manual)

— AA-RS2HB-TE – (hp StorageWorks edge switch 2/32 product manager user

guide)

— AA-RQ7AC-TE – (hp StorageWorks CLI reference guide for directors and

edge switches)

— AA-RQ7BC-TE – (hp StorageWorks SNMP reference guide for directors and

edge switches)

— AA-RS2DB-TE – (hp StorageWorks SAN high availability planning guide)

— AA-RS2CB-TE – (hp StorageWorks ha-fabric manager user guide)

— AA-RTDRA-TE – (hp StorageWorks embedded web server user guide)

— AA-RT4KB-TE – (hp StorageWorks HAFM server installation guide)

•Firmware

— HPQ_HAF_v04.01.00-12.bin – (HP StorageWorks edge switch preloaded

Firmware)

— HPQ_HAF_v04.01.02-04.bin – (HP StorageWorks edge switch Firmware)

edge switch release notes

6edge switch release notes

— firmwareupdate.txt – (Instructions for updating Firmware)

•Acrobat

— RP505ENU.EXE – (Windows installation file for Acrobat Reader 5.0 with

Search)

Supported Configurations

Operation of multiple switches in a fabric topology is subject to the following

topology limits. Consider the impact of these limits when planning the fabric.

NOTE: For more information about planning the fabric, refer to hp StorageWorks SAN high

availability planning guide.

• Fabric Elements—Each fabric element is defined by a unique domain ID that

ranges between 1 and 31; therefore, the theoretical limit of interconnected

directors in a single fabric is 31. The supported limit of interconnected switches in

a single fabric is 24. Because this number is subject to change, contact your

HP authorized service representative for the current number of interconnected

switches supported in a single fabric.

• Inhomogeneous fabric—To determine if interoperability is supported for a

product, or if restrictions apply, refer to the product publications, or contact your

HP authorized service representative.

• Number of Interswitch Links (ISLs)—The ISL limit per Edge Switch 2/24 is 24

and per Edge Switch 2/32 is 32. For redundancy, at least two ISLs should connect

any two switch-class fabric elements. Because this number is subject to change,

contact your HP authorized service representative for the current number of ISLs

supported per switch.

• Hop Count—The fibre channel theoretical limit of ISL connections traversed (hop

count) in a single path through a fabric is 7. The maximum supported hop count in

a single path through a fabric is 3. Because this number is subject to change,

contact your HP authorized service representative for the current hop count

supported by a single fabric path.

NOTE: The hop count is equal to the number of ISL connections traversed in a single path,

not the total number of ISL connections between devices.

edge switch release notes

edge switch release notes 7

Cable Requirements

IMPORTANT: Please note that optical cables for the edge switch must be ordered separately.

For cables measuring up to 500 meters (1 Gbps) or 300 meters (2 Gbps), use

multi-mode Fibre Channel cables. For longer cables, use single-mode Fibre Channel

cables.

Multi-mode optical cables are connected to short-wave optical transceiver modules in

a switch. Single-mode optical cables are connected to long-wave optical transceiver

modules in a switch. Multi-mode cables should use 50/125 optical fibers, and

single-mode cables typically use 9/125 optical fibers for distances up to 10 km.

Verify that connectors interfacing with the edge switch use LC Duplex connectors

with a PC finish. In addition, the connector at the opposite end of the cable must use

either LC or SC type, depending on the requirements of the connected device.

Known Issues

This section describes the known issues related to the HP StorageWorks Edge

Switch 2/24 and Edge Switch 2/32.

HSG80 Transparent Mode Not Supported with IBM AIX

Use of an HSG80 with IBM AIX is restricted to operating the HSG80 in Multibus

mode with the edge switch. Transparent mode is not supported at this time.

Workaround

None.

edge switch release notes

8edge switch release notes

HSG80 Transparent Mode Not Recommended with Controller

in SCSI-3 Mode with HP-UX Operating Systems

Due to an issue with non-existent duplicate LUNs being displayed with the HP-UX

operating systems, the HSG80 controller is restricted to SCSI-2 mode of operation

when set to Transparent failover mode.

SCSI-3 mode of operation in Multibus failover mode is fully supported with the use of

Secure Path software, Version 3.0.

Workaround

None.

ISL Disconnect Causes NOS Error with the OpenVMS

Operating Systems

When an ISL connection is physically removed between directors or switches, the

Fibre Channel Adapter model FCA2354 transmits a Not Operational Sequence (NOS)

error. This is observed as an entry in the HAFM server Link incident log for the port in

which the FCA2354 is attached. The director’s Hardware View also displays a yellow

triangle icon over the port that detected this incident. The fabric operation or data

movement is not disrupted by these incidents, which can be cleared using the

following procedure.

Workaround

Use these steps to clear the incident alerts.

1. At the HAFM Hardware View, click the port module to open the Port Card

View.

2. Right click on the port with the yellow triangle icon, and choose Clear Link

Incident Alert(s).

Disconnecting the Null Modem Cable

Always log-out and disconnect the Null Modem cable from the serial maintenance

port when not in use or when the switch is reset.

edge switch release notes

edge switch release notes 9

Updating an Earlier Version of Firmware

FW that predates the 1.3/1.4 FW release must first be updated to a 1.3 FW version or

higher before the final update to 2.00.00_33 or 2.00.02_1 can be completed.

Using the Same Firmware

All switches and directors managed by HAFM should have the same FW level

installed—whether 1 Gbps or 2 Gbps capable.

Reinstalling Feature Licenses

Feature Licenses (or keys) must be reinstalled after performing a factory reset on a

switch to regain use of the licensed features (e.g., SANtegrity or additional flexports).

Multiple FC HBA Ports in Separate Zones

Multiple FC HBA ports in the same host should be placed in separate zones or they

might be perceived as potential targets (some HBA's log-in as both host and target).

CTP Controls Port Lights

Port lights on the edge switch and director products are controlled by the CTP

functionality. Certain activities, such as FW updates, IPLing the CTP, or switching

over to the backup CTP (Director) can cause these port lights to extinguish

momentarily until control is reasserted by the CTP. The actual FC traffic is not

affected during these times.

Support for Speed Auto-Negotiate

Currently, Speed Auto-Negotiate is not supported for HA and Failover SAN

configurations and is not recommended in general at this time. The speed should be

hard set to match the attached host or target port capability whenever possible.

Hot Insertion of an Optical Transceiver May Produce Port

Failure Event

There should be no impact to the switching and throughput capabilities of the switch

and the error event can be cleared.

edge switch release notes

10 edge switch release notes

Ports May Accumulate Spurious Events

A port may accumulate “Invalid transmission word” and “Bit-Error Threshold Link

Incident” events when a transceiver is poorly seated resulting in a poor ground

connection.

Workaround

Reseating the optical transceiver will correct the problem.

Otros manuales para 316095-B21 - StorageWorks Edge Switch 2/24

Tabla de contenidos

Otros manuales de Cambiar de HP

HP StoreFabric SN4000B Manual de programación

HP GbE2c - Blc Layer 2/3 Fiber SFP Option Manual de instrucciones

HP OfficeConnect 1405 Series Manual de usuario

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de usuario

HP 336045-B21 Manual de usuario

HP 3600 v2 Series Manual de instalación

HP aruba 9300-32D Series Manual de usuario

HP 336044-B21 Manual de usuario

HP A5120 Series Manual de instrucciones

HP PROCURVE 2910AL Manual de usuario

HP 5130 EI Switch Series Manual de usuario

HP ProCurve 6600-48G Instrucciones de montaje

HP HP 2530 Manual de usuario

HP ProLiant BL p-Class GbE2 Manual de usuario

HP PS1810 SERIES Manual de usuario

HP ProCurve 1600M Manual

HP 6125XLG Manual de instalación

HP 1920 Gigabit Ethernet Switch Series Manual de usuario

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de usuario

HP J3128A AdvanceStack 10Base-T Hub-8E Manual de instalación y funcionamiento

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de usuario

HP OfficeConnect 1850 6XGT 2XGT/SFP Manual de usuario

HP HPE FlexFabric 5901 Series Manual de usuario

HP ProCurve 1810G-8 Manual del propietario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
