HP StorageWorks EVA4000 SAN

Starter Kit release notes

Part number: 5697-6628

Third edition: April 2007

Legal and notice information

Description

TheHPEVA4000SANStarterKitprovidesaquickandeasymethodforimplementingastoragearea

network (SAN). It includes the hardware and software components required to create a SAN.

This document contains the most recent product information for the HP EVA4000 SAN Starter Kit. Much

of the information is not documented elsewhere; therefore, HP recommends that you read this document

thoroughly before implementing the HP EVA4000 SAN Starter Kit.

For more information

To find additional information about the HP EVA4000 SAN Starter Kit, see Table 1.

Unless otherwise noted, the documentation is available from the Manuals page of the HP Business

Support Center website:

http://www.hp.com/support/manuals

Table 1 Information sources

Topic Information sources

EVA4000 Select DiskStorageSystemsunder Storage, and then select HP StorageWorks

4000/6000/8000 Enterprise Virtual Arrays under EVA Disk Arrays.

HP StorageWorks

SAN Switch 4/8

base

Select Storage Networking under Storage, and then select HP StorageWorks 4/8

SAN Switch under B-series Switches.

HP FC2142SR HBAs Select Storage Networking under Storage, and then select HP StorageWorks PCI-e

4Gb Host Bus Adapter under Host Bus Adapters.

HP StorageWorks

Command View EVA Select Storage Software under Storage, and then select HP StorageWorks

Command View EVA Software under Storage Device Management Software.

Emulex EZPilot •Select Disk Storage Systems under Storage, and then select HP StorageWorks

4000/6000/8000 Enterprise Virtual Arrays under EVA Disk Arrays.

Scroll down to the Emulex EZPilot User Manual underUserguide.

•The Emulex EZPilot User Manual is also available on the Emulex Windows

Installation CD included with the HP EVA4000 SAN Starter Media kit.

Emulex Linux drivers

and utilities The Emulex Linux Installation CD included with the HP EVA4000 SAN Starter

Media kit.

SAN infrastructure For information about HP SANs, switches, and host bus adapters (HBAs), including

information about available firmware and software driver versions, see the HP

StorageWorks Storage Networking website:

http://www.hp.com/go/san

Click SAN Design Guide under Networking Solutions to download HP

StorageWorks SAN Design Reference Guide, which provides useful information on

designing and implementing your SAN.

High availability (HA) High-availability SAN configurations include redundant hardware components to

ensure uninterrupted service. For more information, see the HA website:

http://www.hp.com/go/ha

EVA4000 management software

TwosoftwaremanagementtoolsarepreinstalledontheEVA4000:

•Emulex EZPilot

•HP Command View EVA

HP StorageWorks EVA4000 SAN Starter Kit release notes 3

Emulex EZPilot

EZPilot is used during installation of the EVA4000 SAN Starter Kit to simplify SAN configuration. EZPilot

can also be used to perform basic storage provisioning tasks, such as creating and deleting virtual disks.

HP Command View EVA

HP Command View EVA is a tool for managing all aspects of storage system operation. In addition

to provisioning, HP Command View EVA enables you to monitor the storage system and troubleshoot

problems.

Table 2 identifies the supported management tasks.

Table 2 Supported management tasks

Task EZPilot HP Command

View EVA

Manage virtual disks Yes Yes

Manage disk groups No Yes

Manage HBAs Yes No

Manage Fibre Channel switch Yes No

View storage system status Yes Yes

Manage replacement of hardware No Yes

Access controller event logs No Yes

Upgrade storage system firmware No Yes

Shut down/restart storage system No Yes

Manage data replication No Yes

Installation instructions

For information about installing the EVA4000 SAN Starter Kit, see the following:

•HP StorageWorks EVA4000 SAN Starter Kit quick installation

•Emulex EZPilot User Manual

CAUTION:

When installing the EVA4000 SAN Starter Kit, be sure to use the EZPilot installation CD, which installs

all of the required components. Do

not

use any of the other installation CDs included with the product;

doing so will disrupt the installation process.

Installed components

Table 3 identifies the components installed on the server for each EZPilot installation configuration.

Table 3 Installed components

Installation configuration Installed components

Windows management server •Emulex Windows Storport driver

•EZPilot Manager

•Sun Java JRE 1.5

•Brocade WebToolsEZ

•HP Command View EVA 6.0.2

•HP EVA VDS provider

•HP MPIO software

Windows non-management server •Emulex Windows Storport driver (Server 2003)

•HBAnyware 3.0

•HP MPIO software

Linux non-management server •MultiPulse 2.1 (which includes Emulex Linux 8.0.16.21

driver), Emulex 2.1.6 MultiPulse driver module, HBAnyware

2.1a35 (multipathing driver for Red Hat Enterprise Linux 4

and SUSE Linux Enterprise Server 9)

•Emulex Linux 8.0.16.21 driver with HBAnyware 2.1a35

(standard driver for Red Hat Enterprise Linux 4 and SUSE

Linux Enterprise Server 9)

EZPilot installation prerequisites

BeforeinstallingtheEZPilotsoftware,besureto:

•Record the switch IP address, gateway, and subnet mask.

You will use this information during installation.

•Uninitialize the storage system.

If it has been initialized, you must uninitialize it before installing EZPilot.

•Verify that the switch configuration (including the default password) has not been changed

from the factory default.

•Remove any Emulex or Brocade software installed on the server.

•Remove any MPIO software installed on the server.

System configuration recommendations

•The HP EVA4000 SAN Starter Kit provides a specific configuration for implementing a SAN

using an EVA4000 storage system. This configuration provides a simple SAN solution for

Windows. The EZPilot management software supports a broader range of configurations. Not

all configuration options discussed in the Emulex EZPilot User Manual apply to the HP EVA4000

SAN Starter Kit.

•If you require uninterrupted access to your data, add a second HP StorageWorks SAN Switch

4/8 base to create a high-availability SAN configuration. This dual fabric ensures that a switch

failure, EVA controller failure, or HBA failure will not interrupt EVA access. Contact HP for

information about ordering a second switch.

•Adding a second disk enclosure helps to create a high-availability SAN by providing protection

against disk enclosure failure. Contact HP for information about ordering additional disk

enclosures.

•To protect against power loss, HP recommends that you use uninterruptible power supplies

(UPS) with the EVA4000. For information about UPS products offered by HP, see the HP

Rack-mountable UPS website:

http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/rackups/

index.html

HP StorageWorks EVA4000 SAN Starter Kit release notes 5

•HP Instant Support Enterprise Edition (ISEE) provides a single remote monitoring and support

solution for your EVA4000. ISEE uses continuous hardware event monitoring and automated

notification to identify and prevent critical problems. ISEE is a no-charge feature of the EVA

Foundation Service Solution warranty. For more information, or to download ISEE, see the HP

Online Support Resources website:

http://www.hp.com/go/instantsupport

Server configuration

•In Windows environments, be sure to install all operating system updates and patches.

•Ensure that only one Windows management server is connected to the EVA4000:

• Select a Windows server with access to the EVA4000 as the management server.

• Ensure that the management server is running Windows Server 2003 R2.

• Before installing EZPilot, enable the Storage Management for SANs component included

in the R2 Windows feature pack.

•In a single-switch configuration, you can connect three non-management servers to the EVA4000.

•In a dual-switch high-availability configuration, you can connect up to five non-management

servers can be connected to the EVA4000.

Compatibility/interoperability

Supported components

Table 4 identifies the hardware and software components supported by the EVA4000 SAN Starter Kit.

Table 4 Supported components

Component Required model/version

HBA HP StorageWorks FC2142SR 4Gb PCI-e HBA (LPe1150)

HBA driver •Windows: appropriate version installed automatically by EZPilot

•Red Hat Enterprise Linux 4 and SUSE Linux Enterprise Server 9:

8.0.16.21

•Red Hat Enterprise Linux 4 and SUSE Linux Enterprise Server 9:

MultiPulse 2.1 (which includes Emulex Linux 8.0.16.21 driver), Emulex

2.1.6 MultiPulse driver module, HBAnyware 2.1a35 (multipathing

driver for Red Hat Enterprise Linux 4 and SUSE Linux Enterprise Server

HBA firmware 2.50a2

Fibre Channel switch HP StorageWorks SAN Switch 4/8 base

EVA4000 controller firmware XCS 6.100

Management server operating

system Windows Server 2003 R2

Non-management server

operating system •Windows Server 2003 R2

•Red Hat Enterprise Linux 4 (latest update)

•SUSE Linux Enterprise Server 9 (latest service pack)

HP Command View EVA 6.0.2

SMI-S EVA16.0.2

EVA VDS Provider14.01.00

1These components are installed automatically by EZPilot.

Downloading the XCS 6.100 software

EVA4000 controller firmware XCS 6.100 is available for download on the HP Software Depot website:

http://h20293.www2.hp.com/

Select Storage and NAS under Product category, and then select HP EVA XCS 6.100 Electronic

Download to receive two .ISO images from which you can create CDs.

HP Command View EVA 6.0.2 is available for download on the HP Business Support Center website:

http://www.hp.com/support/downloads

1. Select Storage Software under Storage.

2. Select HP StorageWorks Command View EVA Software under Storage Device Management

Software.

3. Select HP StorageWorks Command View EVA V6.0 Media Kit.

4. Select your operating system.

5. Select HP StorageWorks Command View EVA 6.0.2,andclickDownload.

iSCSI support

The HP EVA4000 SAN Starter Kit does not support the EVA4000 iSCSI Connectivity Option at this time.

Important notes and workarounds

If you have difficulty with the EZPilot installation, see the Emulex EZPilot User Manual for troubleshooting

information.

For additional notes and workarounds for the EVA4000, see the HP StorageWorks 4000/6000/8000

Enterprise Virtual Array release notes.

HP StorageWorks EVA4000 SAN Starter Kit release notes 7
