HP ProLiant DL980 Manual de usuario

HP ProLiant DL980 G7 with HP PREMA Architecture is an eight socket server built to handle the largest x86 enterprise environments with

confidence. The DL980 G7 blends industry standard economies with advanced mission critical capabilities to deliver balanced scaling,

self healing resiliency and breakthrough efficiencies needed in essential enterprise compute environments. Whether housing a single

very large data intensive workload, or many consolidated or virtualized workloads to improve resource utilization, the DL980 G7

featuring HP PREMA Architecture with Smart CPU caching and a resilient system fabric, is designed to reduce bottlenecks, improve

throughput and performance, as well as deliver enhanced reliability not previously available in an x86 environment.

Front View:

Rear View:

Quick removal access panel

Integrated Lights-Out 3 port

8 hot plug redundant fans standard on all models, upper four

fan positions shown, lower four not shown

Mouse port

DVD drive bay

Serial port

Front panel LED display and Power button

Gigabit NIC port

Slide-out System Insight Display

Gigabit NIC port

Two front accessible USB 2.0 ports

Gigabit NIC port

One front video port

Gigabit NIC port

Quick release lever for fast server access

Video port

Upper and lower front accessible processor and memory

drawer

Keyboard port

10.

Support for up to eight 10-core Intel Xeon processors (4

processors in upper and 4 processors in the lower drawer)

10.

Two USB ports

11.

Support for up to 8 small form factor (SFF) SAS drives

11.

Upper XNC ports

12.

Universal tool-less "Snap In" Sliding Rail Solution

12.

Up to 5 low profile slots supported

13.

Server lifting handles

13.

Lower XNC ports

14.

8U rack form factor

14.

XNC module

15.

Up to 11 full height/full length slots supported

15.

Service tool

16.

Hot Plug Redundant Power Supplies (4 or 8 depending on the

model)

16.

Power supplies (4 or 8 depending on the model)

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Overview

DA - 13708 North America — Version 38 — September 23, 2013

Page 1

What's New

Support for HP StoreFabric SN1000 16Gb Host Bus Adapters

Support for HP Smart Array P421 Controller

Support for HP Ethernet 10Gb 2-port 530T Adapter

Support for HP 3TB G2 Multi Level Cell PCIe ioDrive2 IO Accelerator

Support for HP ProLiant DL980 331i SPI Board based on integrated 331i quad port 1GbE networking controller

Support for HP ProLiant NC375i SPI Board based on integrated NC375i quad-port 1GbE networking controller

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Overview

DA - 13708 North America — Version 38 — September 23, 2013

Page 2

NOTE:

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory

Integrated Models" section.

Processor

Four or Eight of the

following processors

depending on model

Ten-Core Processors

Intel® Xeon® E7-2850 (2.00GHz/10-core/24MB/130W) Processor

Intel® Xeon® E7-2860 (2.26GHz/10-core/24MB/130W) Processor

Intel® Xeon® E7-4870 (2.4GHz/10-core/30MB/130W) Processor

Eight-Core Processors

Intel® Xeon® E7-2830 (2.13GHz/8-core/24MB/105W) Processor

Six-Core Processors

Intel® Xeon® E7-4807 (1.86GHz/6-core/18MB/95W) Processor

Cache Memory

One of the following

depending on Model

30MB (1x30MB) Level 3 cache

NOTE:

For E7-4870 Processor only.

24MB (1 x 24MB) Level 3 cache

NOTE:

For E7-2830, E7-2850 and E7-2860.

18MB (1 x 18MB) Level 3 cache

NOTE:

For E7-4807 Processor only.

Chipset

Industry Standard Intel® 7500 Chipset

Hewlett-Packard DL980 G7 Node Controller

NOTE:

Up to three Industry Standard Intel® 7500 Chipsets with six high-speed interconnects up to 6.4GT/s.

NOTE:

For more information regarding Intel chipsets, please see the following URL:

http://www.intel.com/products/server/chipsets/

Upgradeability

Upgradeable to eight processors

Memory Protection

Advanced ECC

Mirrored Memory

Online Spare Memory Rank

Dynamic Device Data Correction (Intel Xeon E7 Family)

Memory

Type

PC3-10600R Registered Low Voltage (1.35V) DIMMs (DDR3)

Maximum

4TB (128 x 32GB)

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 3

Network Controller

Choose one of the

following

HP ProLiant DL980 NC375i SPI Board

NOTE:

Optional Dual Port 10GbE upgrade (replaces two 1G ports).

HP ProLiant DL980 331i SPI Board

NOTE:

Does not support 10GbE upgrade

Expansion Slots

NOTE:

Up to 16 slots supported: 11 full length/full height and 5 low profile slots. Base I/O backplane configuration: 2 PCI-E 2.0 x8, 3

PCI-E x4. Optional full height/full length I/O backplanes - (choose only one): 2 PCI-E 2.0 x16, 1 PCI-E 2.0 x4, 2 PCI-X OR 4 PCI-E 2.0 x8, 1

PCI-E 2.0 x4, 1 PCI-E 1.1 x4. Optional low profile I/O backplane: 4 PCI-E 2.0 x8, 1 PCI-E 2.0 x4

Expansion

Slots with

No Option Card

Expansion Slot

Technology

Width

Connector

Width

Bus

Number(

)(

)

Form Factor

Notes

N/A N/A N/A N/A N/A N/A

PCI Express

Gen2

x4 x8

0x05

FH/FL

PCI Express

Gen2

x4 x8

0x08

FH/FL

PCI Express

Gen2

x16

0x0B

FH/FL

PCI Express

Gen2

x4 x8

0x0E

FH/FL

PCI Express

Gen2

x16

0x11

FH/FL

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.

** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest

bus).

FL= Full length; FH = Full height; LP = low-profile.

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 4

Expansion

Slots with

Combination

PCI-X, PCI-e

and 300W GPU

I/O Expander

Expansion Slot

Technology

Width

Connector

Width

Bus

Number(

)(

)

Form Factor

Notes

PCI-X

64-bit

N/A

0x72 (Device 1)

FH/FL

100MHz

PCI-X

64-bit

N/A

0x72 (Device 2)

FH/FL

100MHz

PCI Express

Gen2

x16 x16

0x76

FH/FL

PCI Express

Gen2

x4 x8

0x79

FH/FL

N/A N/A N/A N/A N/A N/A

PCI Express

Gen2

x16 x16

0x84

FH/FL

PCI Express

Gen2

x4 x8

0x05

FH/FL

PCI Express

Gen2

x4 x8

0x08

FH/FL

PCI Express

Gen2

x16

0x0B

FH/FL

PCI Express

Gen2

x4 x8

0x0E

FH/FL

PCI Express

Gen2

x16

0x11

FH/FL

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.

** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest

bus).

FL= Full length; FH = Full height; LP = low-profile.

Expansion

Slots with

Standard PCI-e

option I/O

Expander

Expansion Slot

Technology

Width

Connector

Width

Bus

Number(

)(

)

Form Factor

Notes

PCI Express

Gen1

x4 x8

0x71

FH/FL

PCI Express

Gen2

x16

0x74

FH/FL

PCI Express

Gen2

x16

0x77

FH/FL

PCI Express

Gen2

x4 x8

0x7A

FH/FL

PCI Express

Gen2

x16

0x84

FH/FL

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 5

PCI Express

Gen2

x16

0x87

FH/FL

PCI Express

Gen2

x4 x8

0x05

FH/FL

PCI Express

Gen2

x4 x8

0x08

FH/FL

PCI Express

Gen2

x16

0x0B

FH/FL

PCI Express

Gen2

x4 x8

0x0E

FH/FL

PCI Express

Gen2

x16

0x11

FH/FL

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.

** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest

bus).

FL= Full length; FH = Full height; LP = low-profile.

Expansion

Slots with Low

Profile I/O

expander (PCI-

e option)

Expansion Slot

Technology

Width

Connector

Width

Bus

Number(

)(

)

Form Factor

Notes

PCI Express

Gen2

x4 x8

0x05

FH/FL

PCI Express

Gen2

x4 x8

0x08

FH/FL

PCI Express

Gen2

x16

0x0B

FH/FL

PCI Express

Gen2

x4 x8

0x0E

FH/FL

PCI Express

Gen2

x16

0x11

FH/FL

PCI Express

Gen2

x16

0x71

PCI Express

Gen2

x16

0x74

PCI Express

Gen2

x4 x8

0x77

PCI Express

Gen2

x16

0x7A

PCI Express

Gen2

x16

0x84

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 6

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.

** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest

bus).

FL= Full length; FH = Full height; LP = low-profile.

Expansion

Slots with

Combination

PCI-X, PCI-e

and 300W GPU

and Low Profile

PCI-e I/O

Expanders

Expansion Slot

Technology

Width

Connector

Width

Bus

Number(

)(

)

Form Factor

Notes

PCI-X

64-bit

N/A

0x52 (Device 1)

FH/FL

100MHz

PCI-X

64-bit

N/A

0x52 (Device 2)

FH/FL

100MHz

PCI Express

Gen2

x16 x16

0x56

FH/FL

PCI Express

Gen2

x4 x8

0x59

FH/FL

N/A N/A N/A N/A N/A N/A

PCI Express

Gen2

x16 x16

0x5C

FH/FL

PCI Express

Gen2

x4 x8

0x05

FH/FL

PCI Express

Gen2

x4 x8

0x08

FH/FL

PCI Express

Gen2

x16

0x0B

FH/FL

PCI Express

Gen2

x4 x8

0x0E

FH/FL

PCI Express

Gen2

x16

0x11

FH/FL

PCI Express

Gen2

x16

0xA1

PCI Express

Gen2

x16

0xA4

PCI Express

Gen2

x4 x8

0xA7

PCI Express

Gen2

x16

0xAA

PCI Express

Gen2

x16

0xAD

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 7

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.

** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest

bus).

FL= Full length; FH = Full height; LP = low-profile.

Expansion Slots

with Standard

PCI-e and Low

Profile PCI-e

option I/O

Expanders

Expansion Slot #

Technology

Width

Connector Width

Bus

Number(

)(

)

Form Factor

PCI Express

Gen1

x4 x8

0x51

FH/FL

PCI Express

Gen2

x16

0x54

FH/FL

PCI Express

Gen2

x16

0x57

FH/FL

PCI Express

Gen2

x4 x8

0x5A

FH/FL

PCI Express

Gen2

x16

0x5D

FH/FL

PCI Express

Gen2

x16

0x60

FH/FL

PCI Express

Gen2

x4 x8

0x05

FH/FL

PCI Express

Gen2

x4 x8

0x08

FH/FL

PCI Express

Gen2

x16

0x0B

FH/FL

PCI Express

Gen2

x4 x8

0x0E

FH/FL

PCI Express

Gen2

x16

0x11

FH/FL

PCI Express

Gen2

x16

0xA1

PCI Express

Gen2

x16

0xA4

PCI Express

Gen2

x4 x8

0xA7

PCI Express

Gen2

x16

0xAA

PCI Express

Gen2

x16

0xAD

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 8

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.

** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest

bus).

FL= Full length; FH = Full height; LP = low-profile.

Expansion Slot Restrictions

Up to 16 I/O cards are supported within the DL980 server, however due to I/O port space limitations,

no more than 11 of any combination of the following I/O cards may be installed in the DL980 server

at one time:

HP SC08e 2-ports Ext PCIe x8 SAS Host Bus Adapter (PN 614988-B21)

Storage Controller

HP Smart Array P410i controller with optional FBWC

The Flash Backed Write Cache (FBWC) increases cache data retention capabilities from two days of existing

battery backed write cache (BBWC) to infinite data retention.

Standard on 4P Models, optional on factory integrated models

Transportable data protection

Increases overall controller performance

Internal Storage Devices

Diskette Drive

None

Optical Drive

Slimline DVD-RW Drive standard

Hard Drives

None ship standard

Hard Disk Drive

Backplane

Internal SAS backplane supports up to eight SFF hard disk drives

Maximum Internal

Storage

Hot Plug SFF SAS

7.2TB

8 x 900GB

Hot Plug SFF SAS SSD

3.2TB

8 x 400GB

Interfaces

Serial

Video

1 front; 1 rear

SD slot

Network RJ-45

iLO 3 Remote Management

Keyboard

Pointing Device (Mouse)

USB 2.0 Ports

6 total: 2 front (video); 2 rear (video, NIC); 2 internal

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 9

Industry Standard

Compliance

ACPI 2.0. Compliant

PCIE 2.0 Compliant

PXE Support

WOL Support

Physical Address Extension (PAE) Support

Microsoft® Logo certifications

USB 2.0 Support

Server Power Cords

One 6' highline (IEC-IEC) power cord per power supply is shipped standard with each system.

NOTE:

If customers require a local power cord, they can check the power cord matrix for the appropriate

country specific sku. Please see the following power cord matrix for details:

http://www.hp.com/go/powercordmatrix

Power Supply

NOTE:

Rear accessible Hot Plug Power Supplies with option for redundancy (Redundant power supplies are

standard on some models).

E7-2800 4P Model:

(4) 1200W Common Slot Platinum Power Supplies (220VAC only)

E7-4800 4P Model:

(8) 1200W Common Slot Platinum Power Supplies (220VAC only)

NOTE:

The HP ProLiant DL980 G7 requires four power supplies to operate. With four power supplies there

is no power redundancy. Eight power supplies are required for power redundancy. The level of redundancy

will be reported during the system power on.

System Fans

8 Hot plug, redundant fans ship standard

Required Cabling

For required cabling information, refer to the HP Web site at:

www.hp.com/servers/dl980

Operating Systems and

Virtualization Software

Support for ProLiant

Servers

Microsoft Windows Server

Microsoft Windows Server Hyper V

Red Hat Enterprise Linux (RHEL)

SUSE Linux Enterprise Server (SLES)

Oracle Solaris

Oracle Linux

VMware

NOTE:

For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization

Software and latest listing of software drivers available for your server, please visit our Support Matrix at:

http://www.hp.com/go/ossupport

and our driver download page

www.hp.com/support/DL980G7

Graphics

Integrated ATI ES1000 with 32MB embedded video SDRAM

Max Resolution 1280 x 1024 x 16M color

QuickSpecs

HP ProLiant DL980 Generation 7 (G7)

Standard Features

DA - 13708 North America — Version 38 — September 23, 2013

Page 10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Servidor de HP

HP ProLiant ML310e Generation 8 (Gen8) Instrucciones de uso

HP D7171A - NetServer - LPr Manual de usuario

HP StorageWorks P4000 Series Cómo utilizar

HP ProLiant M800 Instrucciones de funcionamiento

HP ProLiant DL360p Gen8 Manual de usuario

HP ProLiant ML310e Manual de usuario

HP T5720 - Compaq Thin Client Hoja de especificaciones

HP DL360 - ProLiant - Photon Manual de usuario

HP ProLiant DL380 G5 DPSS Instrucciones de montaje

HP ProLiant PC2-6400 Instrucciones de uso

HP 124708-001 - ProLiant Cluster - 1850 Manual de usuario

HP ProLiant DL560 Manual de usuario

HP Integrity rx7620 Manual de usuario

HP P4535A - Web Cache Server Appliance Manual de usuario

HP ProLiant SL250s Gen8 Manual de usuario

HP ProLiant DL585 Manual de usuario

HP D7171A - NetServer - LPr Manual de servicio

HP Apollo 4200 Gen9 Manual de usuario

HP DL360 - ProLiant - Photon Instrucciones de uso

HP Cluster Platform Introduction v2010 Manual de referencia

HP Proliant DL580 Instrucciones de uso

HP ML530 - ProLiant - 128 MB RAM Manual de usuario

HP Integrity rx5670 Instrucciones de funcionamiento

HP ProLiant ML10 Manual de usuario

Manuales populares de Servidor de otras marcas

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

Milestone

Milestone Husky IVO 350T Manual de usuario

Planet

Planet NAS-7410 Manual de usuario

Lenovo

Lenovo ThinkSystem SR635 V3 Manual de usuario

Dell

Dell PowerEdge HS5610 Manual
