HP LaserJet 9000 Manual de usuario

I/O Card Installation Guide

D Class and R Class

HP 9000 Enterprise Servers

Part No. A3262-90007

Mfg. Part No. A3262-96127

Edition 4- November 1998

E1198

Printed in: USA

Legal Notices

The information in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this manual,

including, but not limited to, the implied warranties of merchantability and fitness

for a particular purpose. Hewlett-Packard shall not be held liable for errors

contained herein or direct, indirect, special, incidental or consequential damages in

connection with the furnishing, performance, or use of this material.

Restricted Rights Legend. Use, duplication or disclosure by the U.S. Government

is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in

Technical Data and Computer Software clause at DFARS 252.227-7013 for DOD

agencies, and subparagraphs (c) (1) and (c) (2) of the Commercial Computer

Software Restricted Rights clause at FAR 52.227-19 for other agencies.

HEWLETT-PACKARD COMPANY 3000 Hanover Street Palo Alto, California

94304 U.S.A.

reserved.

Reproduction, adaptation, or translation of this document without prior written

permission is prohibited, except as allowed under the copyright laws.

Trademark Notices. UNIX is a registered trademark in the United States and other

countries, licensed exclusively through X/Open Company Limited.

Contents

iii

Who Should Use this Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

1. I/O Card Installation Guide

I/O Card Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

I/O Card Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

I/O Card Installation Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22

I/O Card Installation Verification Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22

2. R Class I/O Card Installation

I/O Card Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

I/O Card Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

I/O Card Installation Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

I/O Card Installation Verification Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

Contents

Printing History

The manual printing date and part number indicate its current edition. The printing

date will change when a new edition is printed. Minor changes may be made at

reprint without changing the printing date. the manual part number will change

when extensive changes are made.

Manual updates may be issued between editions to correct errors or document

product changes. To ensure that you receive the updated or new editions, you should

subscribe to the appropriate product support service. See your HP sales

representative for details.

First Edition: November, 1995

Second Edition: November, 1996

Third Edition: August, 1997

Fourth Edition: November, 1998

NOTE Reader Comments. We welcome your comments about our documentation. If you

have editorial suggestions or recommended improvements for this document, please

write to us. You can reach us through e-mail at: hardwaredoc[email protected]om or by

sending your letter to: Documentation Manager, M/S 5657, Hewlett-Packard

Company, 8000 Foothills Blvd., Roseville, CA 95747-6588 USA. Please include the

following information in your message:

• Title of the manual you are referencing.

• Manual part number (from the title page).

• Edition number or publication date (from the title page).

• Your name.

• Your company’s name.

SERIOUS ERRORS, such as technical inaccuracies that may render a program or a

hardware device inoperative, should be reported to your HP Response Center or

directly to a Support Engineer.

Who Should Use this Guide

The procedures in this guide are intended to be performed by a person who is

qualified in the installation and servicing of computer equipment, and is trained to

recognize the hazards involved. Internal peripherals are installed in an area of the

product where energy levels considered hazardous may be produced.

1 I/O Card Installation Guide

I/O Card Installation Overview

To install I/O cards, you must turn off system power, and disassemble the system to

gain access to the cabinet interior. An overview of the procedure is given below:

A. Turn off power to the system.

B. Remove the front bezel.

C. Remove the side panel.

D. Remove the EMI cover.

E. Remove the I/O card retainer bracket.

F. Remove the I/O slot cover plate from bulkhead.

G. Set I/O card configuration.

H. Install HSC cards.

I. Install EISA cards.

J. Replace the I/O card retainer bracket.

K. Replace the EMI cover.

L. Replace the side panel.

M. Replace the front bezel.

N. Refer to I/O card-specific documents.

After completing all desired procedures, you should proceed to the I/O Card

Installation Verification section later in this chapter for procedures to verify that I/

O cards have been correctly installed.

Required Tools • Small flat-bladed screwdriver

• Torx driver, #15

• Torx driver, #10

• Phillips screwdriver.

I/O Card Installation Guide

I/O Card Installation Overview

Safety

Considerations

WARNING The installation procedures in this guide require opening the system cabinet,

which may expose you to high-energy (high-amperage) circuits, possible

ejection of molten metal, and exposed sharp edges in equipment chassis. Be

sure to remove all rings, watches, and other jewelry from fingers, wrists, and

arms before opening the system cabinet.

Electrostatic

Discharge

Precautions

Electrostatic discharge can damage the integrated circuits on printed-circuit boards.

To prevent such damage from occurring, be sure to observe the following

precautions when handling and installing boards:

1. Use a grounding mat and an anti-static wrist strap, such as those included in the

ESD Field Service Kit (HP P/N A3024-80004).

2. Wear the anti-static wrist strap to ensure that any accumulated electrostatic

charge is discharged from you body to ground.

3. Keep uninstalled printed-circuit boards in their protective anti-static bags until

you are ready to install them.

4. Handle printed-circuit boards by their edges after you have removed them from

their protective anti-static bags.

I/O Card Installation Guide

I/O Card Installation Procedure

A. Turn Off Power

to the System 1. Set the computer front panel Power switch to the OFF position.

2. After the system has properly completed shutdown and internal DC power has

turned off, disconnect the power cord from the server cabinet.

I/O Card Installation Guide

I/O Card Installation Procedure

B. Remove the

Front Bezel 1. Unlock the front peripheral door using the key that was shipped with your

server.

2. Grab the bottom sides of the front bezel, and pull thebottom of the bezel slightly

out from the cabinet.

3. Carefully push the bezel up so that the top of the bezel comes loose from the top

of the cabinet, then pull the bezel away from the cabinet.
