Getting Started Guide

HP Integrity rx2600 server and

HP workstation zx6000

Document Part Number: A9664-90030

July 2004

This guide provides an overview of the system front and rear panel

connectors, instructions on how to set up and configure your system,

and troubleshooting tips. The appendix includes regulatory notices.

ii HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide

Contents

Microsoft®, Windows®, Windows 2000®, and Windows XP®are registered

trademarks of Microsoft Corporation in the U.S. and other countries.

Intel®and Itanium®are registered trademarks of Intel Corporation in the U.S.

and other countries.

All other product names mentioned herein may be trademarks of their respective

companies.

Hewlett-Packard Company shall not be liable for technical or editorial errors or

omissions contained herein or for incidental or consequential damages in

connection with the furnishing, performance, or use of this material. The

information in this document is provided “as is” without warranty of any kind,

including, but not limited to, the implied warranties of merchantability and

fitness for a particular purpose, and is subject to change without notice. The

warranties for HP products are set forth in the express limited warranty

statements accompanying such products. Nothing herein should be construed as

constituting an additional warranty.

This document contains proprietary information that is protected by copyright.

No part of this document may be photocopied, reproduced, or translated to

another language without the prior written consent of Hewlett-Packard

Company.

ÅWARNING: Text set off in this manner indicates that failure to follow

directions could result in bodily harm or loss of life.

ÄCAUTION: Text set off in this manner indicates that failure to follow

directions could result in damage to equipment or loss of information.

Getting Started Guide

HP Integrity rx2600 server and HP workstation zx6000

Second Edition (July 2004)

Document Part Number: A9664-90030

HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide iii

Contents

Important Safety Warnings

ÅWARNING: Avoiding Electrical Shocks. To avoid electrical shock, do not

open the power supplies. There are no user-serviceable parts inside.

To avoid electrical shock and harm to your eyes by laser light, do not

open the DVD laser module. The laser module should be serviced by

service personnel only. Do not attempt to make any adjustment to the laser

unit. Refer to the label on the DVD for power requirements and

wavelength. This product is a class I laser product.

ÅWARNING: Removing and Replacing the Cover. For your safety, never

remove the system side cover without first disconnecting the power cord

from the power outlet and removing any connection to a

telecommunications network. If a Power Protection Device is fitted to your

system, you must shut down your computer using its on/off switch, then

remove the power cord before removing the system’s side cover. Remove

the Power Protection Device cables before any servicing operation. Always

replace the side cover before switching the system on again.

ÅWARNING: Battery Safety Information. There is a danger of explosion if

the battery is incorrectly installed. For your safety, never attempt to

recharge, disassemble, or burn an old battery. Replace the battery with

the same or equivalent type, as recommended by the manufacturer.

The battery in this system is a lithium battery that does not contain any

heavy metals. However, to protect the environment, do not dispose of

batteries in household waste. Return used batteries either to the shop from

which you bought them, to the dealer from whom you purchased your

system, or to HP so that they can either be recycled or disposed of in the

correct way. Returned batteries are accepted free of charge.

ÅWARNING: Avoiding Burn Injuries. Some parts inside the computer will

be hot. Wait approximately three to five minutes for them to cool down

before touching them.

iv HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide

Contents

ÄCAUTION: Avoiding Static Electricity. Static electricity can damage

electronic components. Turn OFF all equipment before installing an

accessory card. Don’t let your clothes touch any accessory card. To

equalize the static electricity when replacing an accessory card, rest the

accessory card bag on top of the system unit while you are removing the

card from the bag. Handle the card as little as possible and with care.

ÄCAUTION: Information on Ergonomic Issues. It is strongly recommended

that you read the ergonomics information, available in the “Working In

Comfort” section of this manual, before using your system. You can access

more extensive ergonomics information at: www.hp.com/ergo.

NOTE: Recycling Your System. HP has a strong commitment toward

the environment. Your HP system has been designed to respect the

environment as much as possible. HP can also take back your old

system for recycling when it reaches the end of its useful life. HP has

a product take-back program in several countries. The collected

equipment is sent to an HP recycling facilities in Europe or the U.S.A.

As many parts as possible are reused. The remainder is recycled.

Special care is taken for batteries and other potential toxic substances,

these are reduced into non-harmful components through special

chemical processes. If you require more details about the HP product

take-back program, contact your local dealer or your nearest HP Sales

Office.

HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide v

Contents

1 Setting Up and Using Your System

System Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2

Rear Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–4

Setting Up Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7

Connecting Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8

Starting and Stopping Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–10

Starting Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–10

turning off Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–11

Installing Hardware Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–12

Firmware and Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–13

Configuring Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–14

Extensible Firmware Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–14

Management Processor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–25

Baseboard Management Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–26

2Troubleshooting

Your System Does Not Start Properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

You Find a Hardware Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3

You Forgot the EFI Password(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5

Troubleshooting with the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–6

Troubleshooting with the e-buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–10

the System Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–12

Software Diagnostics Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–13

HP e-DiagTools Hardware Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–13

Restoring the OS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–18

vi HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide

Contents

Where to Get Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–19

Information to Collect Before You Contact Support . . . . . . . . . . . . . . . . . . . . . . 2–19

Online Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–20

Phone Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–20

Additional Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–21

A Regulatory Information

Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–2

Federal Communications Commission Radio Frequency Interference Statement

(for USA only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3

Notice for Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3

Safety Warning for the USA and Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3

Notice for France. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–4

Notice for the Netherlands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–4

Notice for Germany. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–4

Noise Declaration for Germany . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–5

Notice for Japan (Class A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–5

Notice for Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–5

Notice for Taiwan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–5

Index

HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide 1–1

setting up and using your system

This chapter includes:

■descriptions of the system front and rear panels

■information on how to set up your system

■instructions for starting and stopping your system

■basic system configuration information

system configurations

The HP Integrity rx2600 server and HP workstation zx6000 are

available in tower and rack-mount configurations.

Configuration

Accessory

Slots

Fan Type/

Speed

Management

Processor

Redundant

Hot-swap

Power

Supply

workstation zx6000

tower 3 PCI

1 AGP Quiet/

Low No No

workstation zx6000

rack-mount 3 PCI

1 AGP Hi Capacity/

High Optional Optional

Integrity rx2600 server

tower 4 PCI Hi Capacity/

High Yes Yes

Integrity rx2600 server

rack-mount 4 PCI Hi Capacity/

High Yes Yes

1–2 HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide

Setting Up and Using Your System

front panel

The front panels of the rx2600 and zx6000 have the following

features:

■Power LED is green when the power is on, or the power button is

pushed in. If the power is on and the button is pushed in, the light

stays on even after the system is powered down. When the button

is released, the green light turns off.

■Power Button turns the system power on and off.

■LAN LED indicates the system is communicating over the

Gigabit or System Management LAN.

■System and Diagnostic LEDs identify system errors on

workstation zx6000s with no MP card installed.

■Locator LED and Button (rack-mount configuration only)

identify the rack position of the system.

■Disk Activity LEDs on each hard drive turn green when the disk

is accessed.

■e-buzzer icon indicates the position of the internal speaker.

HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide 1–3

Setting Up and Using Your System

Front Panel, Tower Configuration

Front Panel, Rack-mounted Configuration

1 e-buzzer Icon 5 System LED

2 Locator LED and Button

(rack-mounted system only) 6Power Button

3 Diagnostic LEDs 1-4

(active only on workstation zx6000s

with no MP card installed)

7Power LED

4 LAN LED

1–4 HP Integrity rx2600 server and HP workstation zx6000 Getting Started Guide

Setting Up and Using Your System

rear panel

The rear panel has the following features:

■Connectors are shaped to go in one way only to prevent improper

cable attachment.

■Ports are labeled for easy identification.

■Management Processor (MP) ports are positioned above

(rack-mount) or to the right of (tower) standard connectors

(optional on workstation zx6000).

■LAN LEDs provide additional information:

❏Four Gigabit LAN LEDs

❏Two System Management 10/100 LAN LEDs

❏Four MP LAN LEDs (optional on workstation zx6000)

■Monitor Connector (on graphics card). workstation zx6000s

may include graphics cards with single or multiple monitor

support.

■Locator LED (rack-mount configuration only) identifies the rack

position of the system.

Otros manuales para Integrity rx2600

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Servidor de HP

HP Tc2100 - Server - 128 MB RAM Manual de usuario

HP P5389A - Intel Pentium III-S 1.4 GHz Processor... Manual de funcionamiento

HP ProLiant XL730f Gen9 Server Instrucciones de funcionamiento

HP ProLiant ML310e Gen Manual

HP Apollo 4200 Gen9 Manual

HP Integrity rx2620 Manual de usuario

HP Integrity BL860c Manual de usuario

HP Cloudline CL2100 G3 806R Instrucciones de funcionamiento

HP BL30p - ProLiant - 1 GB RAM Manual de usuario

HP ProLiant DL140 - G2 Server Manual de usuario

HP Compaq t5515 Manual de usuario

HP ProLiant DL560 Manual de usuario

HP ProLiant ML110 Instrucciones de uso

HP DL120 - ProLiant - G5 Instrucciones de uso

HP P5389A - Intel Pentium III-S 1.4 GHz Processor... Manual de usuario

HP ProLiant SL165s G7 Manual

HP DL740 - ProLiant - 4 GB RAM Manual de usuario

HP ProLiant MicroServer Manual de usuario

HP HPE ProLiant DL365 Gen10 Plus Server Manual de usuario

HP ProLiant DL180 G6 Instrucciones de montaje

HP ProLiant DL585 G2 Instrucciones de uso

HP BL465c - ProLiant - 2 GB RAM Manual de usuario

HP PROLIANT BL45P Instrucciones de uso

HP ProLiant 6400R Guía de instalación

Manuales populares de Servidor de otras marcas

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

Milestone

Milestone Husky IVO 350T Manual de usuario

Planet

Planet NAS-7410 Manual de usuario

Lenovo

Lenovo ThinkSystem SR635 V3 Manual de usuario

Dell

Dell PowerEdge HS5610 Manual
