MPX200 Multifunction Router Release Notes

HP Part Number: 5697-0950

Published: May 2011

Edition: Tenth

Version: 8.0

Description

The HP StorageWorks Enterprise Virtual Array (EVA) and XP families of Fibre Channel (FC) storage

systems are supported for integrated iSCSI connectivity using the MPX200 Multifunction Router.

The MPX200 hardware is integrated with up to four EVA or XP24000/20000 storage systems

and HP StorageWorks Command View EVA (EVA only) to deliver multiprotocol capabilities. This

provides iSCSI and FC-attached servers access to block storage through an FC and Ethernet/IP

network simultaneously.

The MPX200 supports multiple functions including iSCSI, FCoE (10 GbE models), FCIP, and online

or offline block-based data migration. FCIP and data migration are license-enabled features (see

Product models). The MPX200 functions are supported separately or simultaneously as follows:

•iSCSI and/or FCoE only

•FCIP only (license required)

•Data migration only (license required)

•iSCSI/FCoE and FCIP (license required)

•iSCSI/FCoE and data migration (license required)

For more information about MPX200 simultaneous operation, see the MPX200 Multifunction Router

User Guide. For more information on data migration, see the HP StorageWorks MPX200

Multifunction Router Data Migration Solution Guide.

Product models

The following models and licensed features of the MPX200 Multifunction Router are available:

•HP StorageWorks MPX200 Multifunction Router 1 GbE base chassis (AP771A)—Order with

an EVA storage system or to upgrade existing EVA storage systems. This option includes one

MPX200 chassis, one 1-GbE blade, and the components required for installation in an EVA

cabinet.

•HP StorageWorks MPX200 Multifunction Router 1 GbE upgrade blade (AP772A)—Order with

an AP771A connectivity option and an EVA storage system with iSCSI connectivity to provide

high-availability multipath connectivity or to upgrade existing EVA storage systems for

multipathing. This option includes a redundant 1 GbE blade for customers who require high

availability.

•HP StorageWorks MPX200 Multifunction Router 10–1 GbE base chassis (AP773A)—Order

with an EVA storage system or to upgrade existing EVA storage systems. This option includes

one MPX200 chassis, a single 10 – 1 GbE blade, and the components required for installation

in an EVA cabinet.

•HP StorageWorks MPX200 Multifunction Router 10–1 GbE upgrade blade (AP774A)—Order

with the AP773A connectivity option and an EVA storage system with iSCSI connectivity to

provide high-availability multipath connectivity or to upgrade existing EVA storage systems

for multipathing. This option includes a redundant 10–1 GbE blade for customers who require

high availability.

•HP Storage Works MPX200 Half Chassis FCIP License (TA766A)—Includes the license to enable

FCIP functionality in one out of two bays (slots) in an MPX200 Chassis

•HP Storage Works MPX200 Full Chassis FCIP License (TA767A)—Includes the license to enable

FCIP functionality for both bays (slots) in an MPX200 Chassis

Description 3

NOTE: For multi-path (redundant blade for high availability), order the full chassis license

TA767A.

•HP Storage Works MPX200 1TB Full Chassis Data Migration License (TA762A)—Includes the

license to migrate 1 TB of data using a MPX200 Chassis

•HP Storage Works MPX200 5TB Full Chassis Data Migration License (TA763A)—Includes the

license to migrate 5 TB of data using a MPX200 Chassis

•HP Storage Works MPX200 Full Chassis 1 Array Data Migration License (TA764A)—Includes

the license to migrate data from or to a single array using a MPX200 Chassis

NOTE: The MPX200 data migration has a unique fan-in/fan-out licensing model. Using this

particular license, data can be migrated from multiple arrays to a single array or from a single

array to multiple arrays.

•HP Storage Works MPX200 Full Chassis 3 Array Data Migration License (TA765A)—Includes

the license to migrate data from or to a single array, on three unique migration jobs using a

MPX200 Chassis

NOTE: The MPX200 data migration has a unique fan-in/fan-out licensing model. Using this

license, data can be migrated from multiple arrays to a single array or from a single array to

multiple arrays, three times; that is, this license can enable three different migration jobs using

the same MPX200 Chassis at different times.

The following equipment is required to configure the MPX200 Multifunction Router:

•B-series or C-series FC switch (fabric-attached only)

•Optical small form-factor pluggable (SFP) transceivers:

FC ports, 8 Gb/s short range SFP (AJ718A)◦

◦FC ports, 4 Gb/s short range SFP (A7446B)

◦10 GbE ports, short range SFP+ (455883-B21)

•Optical FC cables (fabric-attach or direct-connect)

•Copper FC cables (direct-connect only)

•Cat5e or Cat6 GbE Ethernet network cables

Purpose of the update

The MPX200 firmware version for this release is 3.3.0.2. This release includes the following

updates:

•Fixes for the iSCSI, FCIP, FCoE, and data migration functions. See “Fixes” (page 5).

Product support

For the latest product support information, see the Single Point of Connectivity Knowledge (SPOCK)

on the HP website: http://www.hp.com/storage/spock

You must sign up for an HP Passport to access this website.

Operating systems for iSCSI

The MPX200 Multifunction Router supports the following operating systems:

•Apple Mac OS X (Power PC and Intel Power Mac G5, Xserve, Mac Pro)

•Linux–Red Hat, Linux–SUSE (x86, 32/64-bit, IA64)

•Microsoft Windows, Hyper-V

•Sun Solaris (SPARC and x86)

•VMware ESX

NOTE: Not all operating systems listed are supported with all functions or all storage systems.

For the latest product support information, see the Single Point of Connectivity Knowledge (SPOCK)

on the HP website: http://www.hp.com/storage/spock

You must sign up for an HP Passport to access this website.

Fixes

The following fixes have been implemented in firmware version 3.3.0.2:

•iSCSI fixes: LUN presentation failed with the error message “Virtual disk operation has failed.

Ensure that the FC target connections are online.”

LUN information is now refreshed prior to presentation.

•FCIP fix: IP address validation did not occur. Proper address validation is now performed on

IP addresses and Gateway address, taking subnet mask into account.

•FCoE fix: FCoE initiators were presented as Fibre Channel initiators, preventing Command

View EVA from presenting LUNs to FCoE hosts.

•Data Migration fix: Previously when the SPC-2 option was not set on an EMC DMX array FA

port and a WWLUNID size greater than 64 bytes was reported, the rpcserver would crash.

The LUN WWLUNID now truncates to 64 bytes.

Prerequisites

HP Command View EVA—The MPX200 requires HP Command View EVA version 9.2 or later.

FCoE requires Command View EVA 9.3 or later.

Installation instructions

For information about installing the MPX200 Multifunction Router, see the HP StorageWorks

MPX200 Multifunction Router EVA iSCSI Quick Start Instructions for Microsoft Windows, the HP

StorageWorks Multifunction Router FCIP Quick Start Instructions, and the HP StorageWorks MPX200

Multifunction Router User Guide, available on the HP Manuals website:

http://www.hp.com/support/manuals

Under Storage, click Storage Networking, and then under Routers/Gateways/Multiplexers, select

HP StorageWorks MPX200 Multifunction Router.

Important notes

FCoE notes

Command View EVA auto-presented offline targets

In a configuration with multiple MPX200 Multifunction Routers (different chassis enclosures) within

the same FC zone, auto-presented offline targets for the FCoE ports will display under the Command

View EVA iSCSI controller FC Ports tab.

LUN 0 presentation for MPX200 FCoE/iSCSI target

When managing an EVA using an FCoE/iSCSI CNA-based server with MPX200 FCoE/iSCSI

target connectivity, un-presenting the last FCoE/iSCSI LUN from the MPX200 FCoE/iSCSI Controller

may cause Command View to lose communication with the array. To resolve this problem, use the

Fixes 5

MPX200 CLI to present LUN 0 from each EVA Fibre Channel target WWN to each of the MPX200

FCoE/iSCSI ports, and to each of the management server's FCoE/iSCSI CNA ports. If you use a

dual-blade MPX200 chassis, you must execute this presentation process for both MPX200 Blades.

Data migration notes

Data migration documentation

For information about configuring online and offline data migration, see the MPX200 Multifunction

Router Data Migration Solution Guide. This document is available at: http://hp.com/go/mpx200.

mpx Manager for Data Migration Services

The HP StorageWorks mpx Manager for Data Migration Services GUI application is used to

manage the MPX200 Data Migration Services. The HP StorageWorks mpx Manager for Data

Migration Services for Windows, Linux, and Apple OS X is available at:

http://hp.com/go/mpx200

See Table 1 (page 6) for the mpx Manager for Data Migration Services hardware and software

requirements.

Table 1 mpx Manager for Data Migration Services requirements

HeadingHeading

Windows:

•Windows 2003

•Windows 2008

•Windows XP

•Windows Vista

Linux:

•Red Hat v4.x and v5.2 Enterprise

•SuSe v9.x and v10.x Enterprise

Apple:

•Mac OS X v10.4

Operating system

256 MB minimumMemory

150 MBDisk space

500 mHz or fasterProcessor

CD-ROM drive, RJ-45 Ethernet port, RS232 serial port (optional)Hardware

Microsoft Internet Explorer 5.0 and later

Netscape Navigator 4.72 and later

Mozilla 1.02 and later

Safari Java 2 Runtime Environment to support web applet

Internet browser

iSCSI notes

Management of the MPX200 iSCSI configuration with XP24000/20000 storage systems is provided

through the mpx Manager software or the MPX200 CLI. The mpx Manager software is available

at: http://hp.com/go/mpx200.

Mac server sleep mode

The ATTO Mac iSCSI Initiator does not support Mac server sleep mode. If sleep mode is enabled,

and the Mac server goes to sleep, the initiator can lose iSCSI connectivity to the logical unit numbers

(LUNs).

If the ATTO Mac iSCSI Initiator is installed, disable Mac server sleep mode.

Windows drops the IP connection

Certain I/O workloads can cause Windows to drop the IP connection, resulting in removal of a

LUN.

To restore the IP connection, reboot the system. To avoid dropped connections:

•Reduce the I/O workload.

•Reduce the application transfer size.

Windows registry modifications

CAUTION: Use the Registry Editor at your own risk. Using it incorrectly can cause serious problems

that require reinstallation of the operating system. Be sure to back up the registry before making

any changes.

If you use a method other than the HP StorageWorks MPX200 Multifunction Router Windows

software kit to update, you add the Tcp1323Opts and Disk TimeOutValue to the registry.

Timestamps enable TCP to accurately measure round-trip time (RTT) to adjust retransmission timeouts.

The timestamps option provides two 4-byte timestamp fields in the TCP header. One field records

the time of the initial transmission; the other field records the time on the remote host.

There are two methods to add Tcp1323Opts to the registry. HP recommends that you use the first

method.

IMPORTANT: When you install the Windows iSCSI initiator from the HP StorageWorks MPX200

Multifunction Router Windows software kit, Tcp1323Opts is added to the registry automatically.

Method 1

To enable timestamps, under:

HKLM\SYSTEM\CurrentControlSet\Services\Tcpip\Parameters, set the Tcp1323Opts

entry to REG_DWORD = 2.

To extend the timeout period, under: HKLM\System\CurrentControlSet\services\Disk,

set the TimeOutValue entry to REG_DWORD = 120.

Method 2

Make the change to the registry, or cut and paste the following lines to a text file named:

tcp1323opts.reg:

tcp1323opts.reg.

REGEDIT4

[HKEY_LOCAL_MACHINE\SYSTEM\Current-

ControlSet\Services\Tcpip\Parameters]

"Tcp1323Opts"=dword:00000002

Double-click the tcp1323opts.reg file to add the changes to the registry for the iSCSI initiator.

Important notes 7

Effective date

May 2011

Otros manuales para StorageWorks MPX200

Tabla de contenidos

Otros manuales de Enrutador de red de HP

HP MSR SERIES Manual de usuario

HP J4897A Manual de usuario

HP 5920 Manual de usuario

HP J8726A Manual de usuario

HP StorageWorks MPX200 Manual de usuario

HP ProCurve Networking J8453A Manual de usuario

HP FlexNetwork HSR6600 Manual de instalación

HP VSR1000 Manual de instalación

HP MSR SERIES Manual de usuario

HP HP ProCurve Series 6600 Manual de usuario

HP R100-Series Manual de instrucciones

HP MSR20-10 Manual de usuario

HP MSR930 Series Instrucciones de montaje

HP HPE FlexNetwork MSR Router Series Manual de usuario

HP N1200 - StorageWorks Network Storage Router Manual de usuario

HP ProCurve 1410-24G Manual de usuario

HP Wireless TV Connect Hoja de especificaciones

HP A8800 Series Manual de usuario

HP ProCurve 7102 Manual de usuario

HP 5800 Instrucciones de uso

HP Pavilion a6600 Manual de usuario

HP FlexFabric 12900 series Manual de usuario

HP 6125XLG Manual de usuario

HP N1200 - StorageWorks Network Storage Router Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
