HP L1815 Manual de usuario

hp L1815

P4830A

18.1-inch LCD monitor

(18.1-inch viewable image)

user’s guide

www.hp.com/go/monitorsupport

l1815.book Page i Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

Notice

The information contained in the documents accompanying this

product is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to

this material, including, but not limited to, the implied warranties

of merchantability and fitness for a particular purpose.

HP shall not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing,

performance, or use of this material.

HP assumes no responsibility for the use or reliability of its software

on equipment that is not furnished by HP.

These documents contain proprietary information that is protected

by copyright. All rights are reserved. No part of these documents

may be photocopied, reproduced, or translated to another language

without the prior written consent of HP.

Hewlett-Packard France

Business Desktops Division

Grenoble

Cedex 9

France

Hewlett-Packard is a registered trademark of Hewlett-Packard

Company in the United States of America and other countries. Other

brand or product names are trademarks of their respective holders.

l1815.book Page 1 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

Important Safety Instructions

WARNING: The lightning flash with arrowhead symbol inside an

equilateral triangle is intended to alert the user to the

presence of uninsulated, dangerous voltage which

may be of sufficient magnitude to constitute a risk of

electric shock.

WARNING: The exclamation point within an equilateral triangle

is intended to alert the user to the presence of

important operating and servicing instructions in the

literature accompanying the appliance.

WARNING: If you are unsure that you can lift the equipment

safely, do not try to move it without help.

Before you connect any cables or install the HP

monitor, refer to the above safety instructions. Also,

refer to the set up poster and the documentation

included with the PC and the video adapter to ensure

this equipment is correctly installed.

For your safety, always connect equipment to a

grounded wall outlet. Always use a power cord with

a properly grounded plug, such as the one provided

with the equipment, or one in compliance with your

national safety standards. This equipment can be

disconnected from the power by removing the power

cord from the power outlet. This means the

equipment must be located close to an easily

accessible power outlet.

WARNING: To avoid electrical shock, do not open the monitor

cover. There are no user-serviceable parts inside.

Only qualified service personnel should service these

parts.

Make sure the computer is turned off before

connecting or disconnecting a display peripheral.

l1815.book Page 3 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

Important Safety Instructions

Working in Comfort

To optimize your comfort and productivity, it’s important that you set

up your work area correctly and use your HP equipment properly.

With that in mind, we have developed some setup and use

recommendations based on established ergonomic principles for you

to follow.

These recommendations can be found in the online version of the

Working in Comfort guide, which is preloaded on the hard disk of

your HP computer. They can also be found on the HP Working in

Comfort Web site at www.hp.com/ergo along with other

information.

Before contacting customer services, please refer to the following HP

web sites:

www.hp.com/go/monitorsupport

www.hp.com/go/pcaccessories

l1815.book Page 4 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

What the hp L1815 Monitor Offers

The HP L1815 monitor is a liquid crystal display (LCD) 18.1-inch,

high resolution, multi-synchronous color monitor. Multi-synchronous

means that the monitor can be used with a range of video modes. It

is optimized for use with all HP computers.

The HP L1815 monitor has the following features:

• A 18.1-inch LCD; thin film transistor (TFT) with an anti-glare, hard

coated surface

• Support of video modes up to 1280 x 1024 at a 75 Hz refresh

rate

• Analog/Digital interface: a VGA (analog) and a DVI-I (digital or

analog) connector enables connection to up to two computers at

the same time.

• True color (16.7 million colors)

• Auto-adjustment of image position, clock, and phase for the VGA

interface

Full scan TFT screen that

gives edge-to-edge image

Input selection/Adjustment

Auto/Select

Anti-glare surface

On/Off

Status LED indicator

Brightness/Select

l1815.book Page 5 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

What the hp L1815 Monitor Offers

• An onscreen display (OSD) manager that allows you to adjust all

settings through onscreen menus.

• The monitor has VESA compliant mounting to allow for simple wall

or arm mounting (refer to “Removing your monitor’s pedestal” on

page 12).

• Power-management system (VESA1standard) controlled from

suitably equipped HP computers to automatically reduce the

power consumption of the monitor

NOTE: As an ENERGY STAR partner, HP has determined that this

product meets ENERGY STAR guidelines for energy

efficiency.

• Compliance with stringent Swedish Low Emissions guidelines

TCO '99 on certain models

• Plug and Play capability (compliant with VESA DDC standard,

version 3, revision 1 at level, DDC/2B, version 1) that enables the

monitor to identify itself to suitably equipped HP computers

• Slot for security lock

1.VESA is the Video Electronics Standards Association.

l1815.book Page 6 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

Unpacking the Monitor

Check for the following items. If they are missing or damaged,

consult your retailer immediately.

• 1 liquid crystal display (LCD)

• 1 power cord

• 1 video cable (VGA to DVI-I)

• 1 video cable (VGA)

• 1 Quick User’s Guide

• 1 warranty booklet

• 1 CD-ROM

• 1 Declaration of Conformity flyer

• 1 TCO95/99 flyer

• 1 Customer welcome flyer.

l1815.book Page 7 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

Setting Up the Monitor

Where to place the monitor

Place the monitor on a flat, sturdy surface. Ensure that the operating

site is free from excessive heat and moisture. For best performance,

make sure nothing is resting on the monitor.

WARNING: Before you connect any cables or install the HP

monitor, refer to the safety instructions at the

beginning of this manual. Refer also to the

documentation that came with the computer to

ensure this equipment is correctly installed.

Connecting two computers to the monitor

The LCD monitor has two video signal connectors on the rear panel:

one D-SUB analog (VGA) and one digital (DVI-I). This allows you to

connect the monitor to up to two computers at the same time.

Connecting the cables to the monitor

Look at the following diagram and follow the steps listed below to

connect the cables to the LCD monitor.

CAUTION: This monitor is equipped with an auto-sensing power

supply for voltage ranges 100—240 V AC, 50/60

Hz. Use the monitor with the supplied DC adapter

only.

D-SUB (VGA)

DVI-I

Note: this image shows connection to

the VGA connector only

l1815.book Page 8 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

Setting Up the Monitor

The back of your monitor will look like picture below:

To connect the cables to the monitor:

1 Make sure the computer is turned off.

2 Plug the video cable into the correct video connector (VGA or

DVI-I) on the back of the monitor. Secure the cable by tightening

the thumbscrews.

NOTE: All monitors are equipped with both a VGA and a DVI-I

connector and come with a VGA cable. By using both video

connectors, you can connect this monitor to up to two

computers at the same time.

Monitor-Mains connection Monitor-PC connection

D-SUB (VGA)

DVI-I

VGA cable →D-SUB connector

DVI-I cable →DVI-I connector

l1815.book Page 9 Tuesday, April 9, 2002 3:47 PM

hp L1815 LCD Monitor

Setting Up the Monitor

3 Plug the power cord into the connector at the rear of the monitor.

4 Turn on the main power source (for example, a surge protector),

and then turn on the power switch for both the computer and the

monitor.

To disconnect the cables from the monitor:

1 Turn off the power switch for the monitor and the computer, and

then turn off the main power source.

2 Disconnect the power cord from the main power source and the

monitor AC connector.

3 Unscrew the thumbscrews on the video cable(s) and disconnect the

video cable(s).

Securing your monitor

Your monitor can be secured to a desk or to any other fixed object,

using a security lock cable. The cable can be attached a slot located

on the rear of the monitor.

NOTE: The security lock is not an HP accessory. It cannot be

ordered from HP. Contact your retailer for more

information.

Slot for lock

Left-hand rear view

l1815.book Page 10 Tuesday, April 9, 2002 3:47 PM
