Product End-of-Life Disassembly Instructions

Product Category: Monitors and Displays

Marketing Name / Model

[List multiple models if applicable.]

HP EliteDisplay E190i 19-in 5:4 LED Backlit IPS Monitor

Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions

for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU

directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).

1.0 Items Requiring Selective Treatment

1.1 Items listed below are classified as requiring selective treatment.

1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as

applicable.

Item Description Notes

Quantity

of items

included

in product

Printed Circuit Boards (PCB) or Printed Circuit

Assemblies (PCA)

With a surface greater than 10 sq cm

USB BD, IF BD, POWER BD, FK BD

Batteries

All types including standard alkaline and lithium coin

or button style batteries

Mercury-containing components

For example, mercury in lamps, display backlights,

scanner lamps, switches, batteries

Liquid Crystal Displays (LCD) with a surface greater

than 100 sq cm

Includes background illuminated displays with gas

discharge lamps Panel

Cathode Ray Tubes (CRT)

Capacitors / condensers (Containing PCB/PCT)

Electrolytic Capacitors / Condensers measuring

greater than 2.5 cm in diameter or height

Power BD only (C805)

External electrical cables and cords

USB cable, D-sub cable, DVI cable, Power cord

Gas Discharge Lamps

Plastics containing Brominated Flame Retardants

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner

Include the cartridges, print heads, tubes, vent

chambers, and service stations.

Components and waste containing asbestos

Components, parts and materials containing

refractory ceramic fibers

Components, parts and materials containing

radioactive substances

EL-MF877-00 Page 1

Template Revision A

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components

and materials requiring selective treatment can be removed.

Tool Description

Tool Size (if

applicable)

Description #1 SCREW DRIVER(PHILLIPS HEAD)

Description #2

Description #3

Description #4

Description #5

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

1. Take Screw(x4) Off From Stand & Remove Stand

2. Remove Rear Cover From Display Head

3. Remove Front Cover From Display Head

4. Remove Rubber foot From Rear Cover

5. Remove Key Board Off From Chassis

6. Remove Lamp Cable & LVDS Cable Out of Panel

7. Take Screw(x4) Off From Chassis Cover & Remove Panel

8. Take Screw(x6) Off From P.C.B

9. Take Screw(x1) Off From USB

10. Take Screw(x7) Off From P.C.B

11. Remove BKT (Printed Circuit Assemblies>10cm*2

12. Remove Mylar From Chassis Cover & Remove USB BD From Chassis

13. LCD PANEL EXPLODE

14. Take Screw(*4)Off From Quick Release

15. Remove Quick Release off Stand Base

16. Remove the PET(Al Film) cover shield

17. Dismantle the case top ( Down)

18. Dismantle the case top (Right or Left )

19. Separate case top (push the case top because of damages on COF)

20. Dismantle the PCB

21. Remove the Conductive Tape

22. Remove the Board Assay

23. Remove the Guide Panel

24. Remove Optical Sheet

25. Remove Optical LGP

26. Disassembling Complete

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items

contained in the product that require selective treatment (with descriptions and arrows identifying locations).

EL-MF877-00 Page 2

Template Revision A

HP E190i Disassembly Process

Stone Zhang

Mechanical Engineer

Aug-12-2013

External Electric Cables Dissecting Process

1.Remove Cable From Display Head. 2.Dissecting To Complete.

Power Cord

USB Cable

DVI Cable D-SUB

Remove Stand from Display Head

2.Remove Stand from Display Head.

1. Release the four screws for Stand to RC

5.Remove Rear Cover from Display Head.

Remove Rear Cover From Display Head

Remove Front Cover From Display Head

6.Remove Front Cover.

Remove F/K BD by hand

Remove Rubber foot From Rear Cover

Take Screw(*2) Off From Chassis Cover & Remove Panel

1. Remove connector from Panel

2. Remove four screws from Chassis

4.Remove connector off from Panel. 5.Separate the Panel and Metal.

3. Pear off the Aluminum Tape from LVDS connector

Take Screw(x7) Off From P.C.B

1. Take Screw(x7) Off From P.C.B
