getting started

hp iPAQ Navigation System

Loading the application:

1Load Disc 1 of 2 into the CD drive on your computer to activate the

Install Shield Wizard and follow the on-screen prompts to install the application.

When the installation is complete click Finish to initiate the Map Loader.

Checklist before you begin:

1My iPAQ Pocket PC is connected to

my computer via the iPAQ Pocket PC

cradle or synchronization cable.

2My iPAQ Pocket PC is synchronized with

my computer using ActiveSync. (See your

iPAQ Pocket PC User’s Guide for help

on synchronizing your iPAQ Pocket PC.)

3I have the two Navigation System

installation discs.

4I have closed all applications on my

desktop and my iPAQ Pocket PC.

get ready

application & map installation

This CD includes:

• Navigation Software

• Western U.S. and

Canada Map Data

• User’s Guide

hp iPAQ Navigation System

First Edition September 2003

348771-001

Loading maps to your iPAQ Pocket PC:

2From the Map Loader screen, click either the tab By State or By City.

3For By State, select state or states to download by placing a checkmark

in the box to left of the state.

In the box labeled Location, click the drop down arrow to select location where

maps reside, Pocket PC Storage Card or Pocket PC Main Memory. If you

have a storage card, it is recommended that you select the Storage Card option.

(NOTE: Selected size of map(s) should not exceed available memory space.

You can track this by referring to the Available Memory and Selected Size

boxes.)

For By City, select a state from the drop down box. Select a city from the City

drop down box. Select the radius around the city to be downloaded by moving

the map radius cursor (between 25-125 miles).

In the box labeled Location: click the drop down arrow to select Pocket PC

Main Memory or Pocket PC Storage Card.

(NOTE: You can adjust the radius around the selected city by moving the Map

Radius indicator to the right. The selected map size appears in the box labeled

Selected Size. You will be alerted if the selected map size exceeds the available

memory in the iPAQ Pocket PC Main Memory or Pocket PC Storage Card.)

4Click Generate Map to transfer the map to your iPAQ Pocket PC.

When prompted, insert Disc 2 into your CD drive and click OK.

Partnering the GPS to the iPAQ Pocket PC:

1From the Today screen, tap Start. From the

Start Menu, select Programs.

2Tap iPAQ Navigation System to launch the

application and tap OK to acknowledge your

agreement not to enter data or manipulate the

software controls while operating a vehicle.

3The iPAQ Navigation System automatically partners

with the GPS receiver after launch on most iPAQ

devices. To check if your device has partnered,

tap the Windows icon on the top left hand of the

screen, and open the Bluetooth Manager.

4Tap the My Shortcuts tab on the Bluetooth screen.

Two green arrows on the BT-GPS Receiver icon

indicate a connection is active. If the connection is

active, go to the “Go” section of this guide.

(NOTE: For certain devices it is necessary to

manually create a partnership. Please see the

steps on the next page for manually creating a

partnership.)

Checklist before you begin:

1My iPAQ Pocket PC has the hp Navigation

application loaded and the power is on.

2My Bluetooth GPS receiver is charged

and the power is on.

3The Bluetooth radio on my iPAQ Pocket

PC is turned on.

get set

Bluetooth®connection

Manually creating a partnership:

1From the Today screen tap Start. Tap Settings

on the drop down menu.

2From the Settings Menu, tap System. From the

System Menu, tap Bluetooth. Tap Turn On under

Bluetooth status to display the message Bluetooth

is On. Tap Bluetooth Manager to set connections.

3Tap New at the bottom of the screen and tap

Connect! to display the Connection Wizard.

From the Connection Wizard, select Explore

a Bluetooth Device and tap Next.

4Tap inside the Device box to display a list of

available Bluetooth devices.

5Tap the icon labeled BT-GPS-xxxxxx to display

the Service Selection screen. Tap Serial xxxxxx

in the Service Selection box and tap Next.

Tap Finish.

6Double tap the icon labeled BT-GPS-xxxxxx

to confirm connection between the iPAQ

Pocket PC and GPS receiver.

Acquiring a satellite fix:

1Position the hp Bluetooth GPS receiver in the vehicle

window so that the receiver has an unobstructed view

of the sky. When the green LED flashes, the satellites

have located the receiver.

(NOTE: The Bluetooth GPS receiver may take 5-10 minutes to

acquire a fix on the three satellites needed to accurately position the

vehicle. In the event that the GPS receiver does not acquire a fix

within 5-10 minutes, reposition the GPS receiver and try again.)

2From the iPAQ Navigation System,tap View at

the bottom of the screen and tap Map. A map

display will appear centered on your current

location. Your current location is depicted as a

green arrow in a blue circle

(NOTE: A yellow arrow indicates low GPS signal; a red arrow

indicates no GPS signal. Reposition the GPS receiver and try again.)

Checklist before you begin:

1My iPAQ Pocket PC is on.

2My Bluetooth®GPS receiver is charged

and the power is on. The blue LED is

flashing and the green LED is solid.

3The iPAQ Navigation System application

is running.

navigating to a destination

3Tap Menu and tap Destination to display the

Set Destination screen. Select type of destination

(e.g., Address, Points of Interest, Recent,

Intersection, Favorites). This Getting Started

guide covers only how to enter your destination

by address. For instructions on using other

options, please refer to the User’s Guide.

4Tap Address to display the Select Input

Method screen.

5Tap Street First to display the navigation key-

board on the Enter Street Name screen and tap

the letters needed to spell out the street name of

your destination and tap OK.

6From the Enter House Number screen, use the

navigation keyboard to enter the house number

of your destination and then tap OK to display

an alphabetical list of addresses in cities that

match the street address of your destination.

7Tap the Arrow Up or Down buttons to highlight

the address that matches your destination and

tap NAV.

8Follow the voice prompts and map display to

your destination.

For troubleshooting and further information:

www.hp.com/go/ipaqnavigation

1.866.4HP.NAV1

(1-866-447-6281)

348773-001

www.hp.com/go/ipaqnavigation

All product names mentioned herein may be trademarks of their respective companies. First Edition (September 2003)
