HP s500 Manual de usuario
s500
Digital Camera
Quick Start Guide
1
For more details about the camera operation and troubleshooting, please read the User Manual located on
the CDROM disc included with your camera or visit http://www.hp.com/support and download it for
the camera support page.
1
Tour of Your HP Camera
Front View
1 2
3
4
Flash1.
Self-timer LED / AF Assist Lamp2.
Lens3.
Microphone4.
Back View
11
10
5
8
7
6
9
LCD Screen5.
Shutter button6.
Menu Button7.
Function / Delete Button8.
LED Indicator9.
OK Button / 4-way Navigation Control10.
Mode Selector Switch11.
Photo Mode
Video Mode
Playback Mode
2 3
Top View
12
13
Power Button12.
Zoom Toggle13.
Bottom View
15 16
14
Battery/Memory card compartment14.
Tripod screw hole15.
Speaker16.
Left/Right View
18
17
USB/TV Out17.
Strap Ring18.
2 3
1. Getting Started
Attach the Camera Strap
To reduce the risk of dropping the camera, it is strongly recommended
to attach and use the provided camera strap
Inserting the Battery
Follow these instructions to insert the battery into the battery/memory card compartment.
If the battery are already installed, make sure to power off1.
the camera before removing and inserting recharged or new
battery.
Open the battery/memory cardcompartment at the bottom of2.
the camera as illustrated.
4 5
Insert the battery into the compartment with correct3.
orientation as illustrated. Be sure to push the battery into
position until the battery is locked into place.
Close and secure the battery/memory card compartment by sliding the locking button towards the4.
edge of the camera (as illustrated).
4 5
Charging the Battery by USB
The battery that comes alone with your package is not fully charged. You need to charge the battery
before using the camera.
Connect the camera with the USB cable as shown.1.
Connect the other end with the USB adapter and plug it into a power outlet or with the USB port of2.
PC directly for charging.
When the battery is charging, the LED indicator lights up.•
When the battery is fully charged, the LED indicator turns off.•
Whenthebatteryisincorrectlycharged,theLEDindicatorashesrapidly.•
When the camera is connected without the battery, the LED indicator will not Light up.•
1
2
The battery charging time is approximately 2 hours.
It’s not recommended to operate the camera when charging.
6 7
Inserting an SD/SDHC/SDXC Memory Card
It is highly recommended that the camera storage is expanded by inserting a SD or SDHC or SDXC
memory card. These memory cards are available at most consumer store and online locations.
Make sure to power off the camera before proceeding. Inserting1.
the memory card while powered on may damage the card and
camera.
Open the battery/memory card compartment at the bottom of the2.
camera.
Insert the SD/SDHC/SDXC card into the memory card slot with3.
the metallic connectors facing the front side of the camera as
illustrated below.
Push the SD/SDHC/SDXC card into the memory slot until it clicks into place. If the card does not4.
click into place, repeat the previous step to ensure proper orientation.
Close the battery/memory card compartment.5.
The 720p video recording capability of this camera requires a class 6 or faster
(High Speed) SD/SDHC/SDXC memory card.
6 7
- To remove the SD/SDHC/SDXC card
Make sure to power off the camera before proceeding.1.
Removing the memory card while powered on may damage
the card and camera.
Open the battery/memory card compartment.2.
Gently push the card until it clicks and pushes out of3.
position.
Carefully pull out the card.4.
8 9
2. Initial Settings
Whenthecameraispoweredupforthersttime,pleasesetthedisplaylanguageanddate&time.
Setting the Language
Use the 4-way navigation control to move through the selections.1.
Highlight the desired language and press the2. OK button to select.
Setting the Date & Time
Use the 4-way navigation control to move through the selections and to change the setting values.1.
Press2. OK button when finished. This will save your date and time settings.
If necessary, press3. Menu button to close the menu.
At this point, the camera settings are set to the default automatic mode and is ready to take photos and
videos.
