Page 1 of 24 Joe Conforti

– Avid Technology – September 14th, 2012

Rev A - Initial Public Release

Avid Configuration Guidelines

HP Z820 Dual Six-Core / Dual Eight-Core CPU Workstation

Media Composer 6.x Symphony 6.x NewsCutter 10.x and later

Page 2 of 24 Joe Conforti – Avid Technology – September 14th, 2012

Rev A - Initial Public Release

1.) HP Z820 AVID Qualified System Specification:

Z820 / AVID Qualified Operating System:

Microsoft® Windows 7 Professional 64-bit Edition with Service Pack 1

Z820 Hardware Configuration

Supported CPU Choices

1.) Dual Intel® 6-Core Xeon® E5-2640 Processors @ 2.5GHz 15MB cache / 1600MHz memory

(The 6-Core Xeon® E5-2640 Processors will run the 1600MHz memory at 1333MHz speed due to the

speed limitation of the memory controller in the E5-2640 Processor).

2.) Dual Intel® 8-Core Xeon® E5-2665 Processors @ 2.4GHz 20MB cache / 1600MHz memory

Supported Video Card

NVIDIA Quadro 4000 2GB PCI-e video board

System Disk Drive - 1TB (minimum recommended) SATA-II 3Gb/s 7200RPM

Standard AVID memory configuration: 16GB (8 x 2GB) DDR3 1600 ECC memory –

(Requires eight 2GB DIMMs, DIMM sizes cannot be mixed sizes)

2GB memory modules must be installed in the following memory slots:

CPU0-DIMM1, CPU0-DIMM3, CPU0-DIMM6, CPU0-DIMM8

CPU1-DIMM1, CPU1-DIMM3, CPU1-DIMM6, CPU1-DIMM8

Memory configuration constraints

- No other memory configurations are formally supported in AVID environments. Only the 16GB (8 x 2GB),

configuration is supported. Un-balanced memory configurations which mix and match memory module

sizes and locations will result in a poor performing, non-optimal operating environment.

2.) Qualified Operating Systems, Avid Client Editing Applications, Hardware and Shared-Storage

support for the HP Z820:

- Media Composer / Symphony 6.x , NewsCutter 10.x or later

- Supported: Only Microsoft® Windows 7 Professional 64-bit Edition with SP1 (SP1 required)

- Not Supported – Any version of Microsoft® Windows XP or Vista

- Not Supported - Microsoft® Windows 7 – any 32-bit version, or any version of Home, Ultimate or

Enterprise editions.

Note regarding Service packs:

As of this writing Service Pack 1 is the current Service Pack release for Win7. SP1 is required for Media

Composer 6.x, Symphony 6.x and NewsCutter 10.x. As future Service Packs are released Avid will evaluate

and announce formal support when testing is completed.

Page 3 of 24 Joe Conforti – Avid Technology – September 14th, 2012

Rev A - Initial Public Release

3.) Qualified O.S., Hardware and shared storage supported:

Qualified / Supported

Nitris DX / Mojo DX

Yes

3rd Party Qualified Hardware

See release notes and Avid website for

information regarding supported 3rd party

hardware (vendor qualified)

Unity ISIS 1Gb Ethernet Client

ISIS 5000 / 7000 V4.0

Unity ISIS Hi-res (10 Gbit) client

ISIS 5000 / 7000 V4.0

Qualified Operating System

Win 7 Pro 64-bit

Service Pack

SP1 – Required

1394 Adrenaline DNA

N/A Not Supported

1394 Mojo-SDI DNA

N/A Not Supported

1394 Mojo-Analog DNA

N/A Not Supported

Page 4 of 24 Joe Conforti – Avid Technology – September 14th, 2012

Rev A - Initial Public Release

AVID qualified HBA info

AVID qualified HBA

AVID Part Number Slot

Location

Function

Vendor qualified 3rd party

hardware interface requiring:

x4 PCI-E or lesser interface

¾ Length PCI form factor or

smaller

Not stocked by AVID

Vendor qualified 3rd party hardware interface. See

release notes and Avid website for information

regarding supported 3rd party hardware

Vendor qualified 3rd party

hardware interface requiring:

x8 PCI-E or greater interface

Full Length PCI form factor

Not stocked by AVID

Vendor qualified 3rd party hardware interface. See

release notes and Avid website for information

regarding supported 3rd party hardware

Intel PRO 1000 PT

7030-20139-01

Shared Storage: Unity ISIS Copper Gb-Ethernet

Dual Gb ISIS Connectivity

Intel i350-T2 – Dual Gb NIC

Not stocked by AVID

Shared Storage: Unity ISIS Copper Gb-Ethernet

Dual Gb ISIS Connectivity

Intel PRO 1000 PF - ISIS

Not stocked by AVID

Shared Storage: Unity ISIS Optical Gb-Ethernet

Myricom 10G-PCIE-8B-S

7030-30041-01

Shared Storage: Unity ISIS 10Gb-Ethernet for

Hi-Res client (ISIS 5000 / 7000)

Avid HIB, DX Interface HBA**

Active: 7030-30048-01

Active: 7030-20084-01

Passive: 7030-30021-01

Avid DX Hardware Interface HBA

Atto R680

Not stocked by AVID

#1 or #4 Local SAS Storage Support –

Avid VideoRAID ST (5-bay)

Xtore StudioRAID 5Ti (5-bay)

LSI 9200-8e SAS controller

7030-30036-01

#1 or #4 SAS Local Storage:

Xtore StudioRAID 16Re (16-bay) chassis

Xtore StudioRAID 5Te (5-bay) chassis

Pro Tools HD h/w

#3 and / or #4

Pro-Tools h/w for Pro-Tools co-install

Red Rocket Accelerator

Not stocked by AVID

#3, #4 or #6

Accelerator for RED files

** Avid DX Interface HBA Support Note: (See reference pictures on page 7 of this guide).

All 3 versions of the DX interface HBA are supported on the Z820 with Media Composer / Symphony 6.x and

NewsCutter 10.x

1) Active DX interface HBA 7030-30048-01

2) Active DX interface HBA 7030-20084-01

3) Passive DX interface HBA 7030-30021-01

Page 5 of 24 Joe Conforti – Avid Technology – September 14th, 2012

Rev A - Initial Public Release

4.) Slot Configuration:

Slot Configuration Information

Slot #

Electrical

Mechanical

x4 PCI-E Gen 3

Open-

ended

Connector

Vendor Qualified 3rd Party Hardware PCI-e Interface requiring:

x4 PCI-E or lesser interface

¾ Length PCI form factor or smaller

(Secondary slot location) Local SAS Storagec ontrollers:

Atto R680

LSI 9200-8e

x16 PCI-E Gen 3

(225Watts)

x16

Graphics Card:

Nvidia Quadro 4000

x8 PCI-E Gen 3

x16

Shared Storage Controllers ISIS 5000 / 7000:

Intel PRO 1000 PT

Intel PRO 1000 PF

Intel i350-T2

Myricom 10G-PCIE-8B-S

or Pro Tools HD h/w or Red Rocket Accelerator

x16 PCI-E Gen 3

x16

Local SAS Storage Controllers:

Atto R680

LSI 9200-8e

or Pro Tools HD h/w or Red Rocket Accelerator

x4 PCI-E Gen 2

x16

Avid HIB, DX Interface HBA

Active: 7030-30048-01 & 7030-20084-01

Passive: 7030-30021-01

x16 PCI-E Gen 3

x16

Vendor Qualified 3rd Party Hardware PCI-e Interface requiring:

x8 PCI-E or greater interface

Full - Length PCI form factor

or Red Rocket Accelerator

PCI-E 32bit /33MHz

PCI 32/33

Secondary SAS Port Break-out connector (Embedded)

Embedded Intel

82574L Gb NIC

PCI-E x1

Gen 1

Qualified for Avid ISIS 5000 / 7000 connectivity.

This is the NIC port adjacent to the Firewire port

Embedded Intel

82579LM Gb NIC

PCI-E x1

Gen 1

Do not use for ISIS. Not qualified and is not functional with ISIS 5000 / 7000.

This is the NIC port adjacent to the blue and green audio jacks

Page 6 of 24 Joe Conforti

– Avid Technology – September 14th, 2012

Rev A - Initial Public Release

5.) Use of embedded NIC ports for ISIS connectivity Important Information

The Z820 has two embedded NIC ports. One port is the 82574L. The 82574L port is qualified for ISIS and should be used

for single Gb connectivity to ISIS 5000 / 7000. The 82574L port is the port directly above the Firewire port. The other

embedded NIC port is an 82579LM. The 82579LM will not work with ISIS and should never be connected to either ISIS 5000

or 7000. The 82759LM port is marked with the letters AMT and is adjacent to the blue and green audio jacks.

Embedded Intel network interface for ISIS connectivity:

For proper operation and connectivity of the Intel 82574L network interface with ISIS the following settings are required:

1. For the Intel 82574L driver, under the performance settings, change the following parameters:

- Receive Buffers to 1024

- Transmit Buffers to 1024

2. Disable the windows firewall.

6.) Utilization of the Z820 embedded (on-board) 1394 ports for Camera / Deck / Disk Drive support

Media Composer / Symphony 6.0 and NewsCutter 10 do not support Avid 1394 hardware such as Adrenaline and

1394 Mojo-SDI. This simplifies utilization of the Z820 embedded 1394 ports. The embedded 1394 ports can and should be used

for all 1394 Camera / Deck / Disk Drive connectivity for all configurations running Media Composer / Symphony 6.0 and

NewsCutter 10.

Use the embedded Intel 82574L

network interface for single Gb ISIS

5000 / 70000 connectivity.

Do not use the embedded Intel

82579LM network interface for any

ISIS connectivity.

Page 7 of 24 Joe Conforti

– Avid Technology – September 14th, 2012

Rev A - Initial Public Release

7.) Various Configuration Details:

A.) D/X hardware configs –

All 3 versions of the DX interface HBA are supported with the Media Composer / Symphony 6.x and NewsCutter 10.x

1) Active DX interface HBA 7030-30048-01

2) Active DX interface HBA 7030-20084-01

3) Passive DX interface HBA 7030-30021-01

Active DX interface HBA 7030-30048-01 Active DX interface HBA 7030-20084-01

Passive DX interface HBA (7030-30021-01)

Page 8 of 24 Joe Conforti – Avid Technology – September 14th, 2012

Rev A - Initial Public Release

B.) Qualified Avid system BIOS version(s): (As of this writing):

Failure to update the Z820 to an “Avid qualified BIOS” and set the BIOS settings per the instructions below may

result in non-optimal operation of the AVID software and hardware.

- Minimum BIOS ver 1.12

Current Avid qualified Z820 BIOS information is maintained at the following Avid KB link:

http://avid.custkb.com/avid/app/selfservice/search.jsp?DocId=267609&Hilite=hp+bios

C.) Required system BIOS settings for AVID environments:

Hyper-Threading Setting:

Please Note: CPU Hyper-threading should be enabled in all configurations per the chart below. It is

currently enabled by default by HP for shipping Z820’s with BIOS ver 1.12 or earlier

Z820 Required system BIOS changes:

1. Verify CPU Processors are set to Hyper-Threading – Set per chart above. Current version

BIOS v1.12 has Hyper-Threading enabled by default

2. Set Memory NUMA – Disable

3. Set Runtime Power Management - Disable

4. Set Idle Power Savings - Normal

Z820 Optional system BIOS change:

1. Set Intel Turbo Mode**– Disable

** Only required if connecting USB audio I/O devices. This setting will eliminate any audio

“motor-boating” or audio “popping” which may be experienced with USB audio I/O devices.

Hyper-Threading Setting

Software Version Dual 6-core CPU Dual 8-core CPU

Media Composer v6.x

Symphony v6.x

NewsCutter v10.x

Enabled (Mandatory)

Page 9 of 24 Joe Conforti – Avid Technology – September 14th, 2012

Rev A - Initial Public Release

Set Z820 Required system BIOS changes:

- During boot up press F10 at the HP splash screen to invoke Set Up.

- Select the Advanced tab

- Select Device Options <Enter>

- Select Hyper-Threading

- Verify setting is Enable

If Hyper-Threading is set for Disable then it must be changed to Enable

- Hi F10 to save the Hyper-Threading setting

- Select the Power tab

- Select OS Power Management <return>

- Select Runtime Power Management

- Default setting is Enable

Change this setting from Enable to Disable

- Select Idle Power Savings

- Default setting is Extended

Change this setting from Extended to Normal

- Hi F10 to save the Runtime Power Management and Idle Power Savings settings

- Select Advanced Tab

- Select BUS options

- Select NUMA

- Default setting is Enable

Change this setting from Enable to Disable

- Hi F10 to save the NUMA setting

- Press F10 twice to Save

- Save Changes and Exit

- System will Reboot

Set Z820 Optional system BIOS setting: ** Only required if connecting USB audio I/O devices.

- Select the Power tab

- Select Hardware Power Management <Enter>

- Select Intel Turbo Mode

- Default setting is Enable

Change this setting from Enable to Disable

- Press F10 twice to Save

- Save Changes and Exit

Page 10 of 24 Joe Conforti

– Avid Technology – September 14th, 2012

Rev A - Initial Public Release

D.) Nvidia Qualified Driver:

Nvidia qualified drivers

AVID Software Version(s) Nvidia GPU Nvidia Driver Required

Media Composer / Symphony

NewsCutter

6.0 and later

10.0 and later

Quadro 4000

275.89

After installation of the AVID software the supported Nvidia driver can be found in the following directory:

Program Files / Avid / Utilities / Nvidia

Set optimized Nvidia driver settings for Avid editing environments:

1. See picture below

2. Right-Click on the desktop and select Nvidia Control Panel

3. Select the “Desktop” menu selection in the control panel menu bar.

4. Enable “Desktop -> Video Editing Mode

Otros manuales para Z820 Series

Tabla de contenidos

Otros manuales de De oficina de HP

HP Presario SR1200 - Desktop PC Manual de usuario

HP Presario SR5400 - Desktop PC Manual de usuario

HP Vectra VL 5/xxx Manual de usuario

HP XM600 - Kayak - 128 MB RAM Manual de usuario

HP Pavilion 483 Manual de usuario

HP Vectra SERIES Manual de instrucciones

HP 282 Pro G3 Instrucciones de instalación

HP XM600 - Kayak - 128 MB RAM Manual de usuario

HP Presario SR1100 - Desktop PC Manual de usuario

HP A524x - Pavilion - 512 MB RAM Manual de instrucciones

HP Compaq Presario Manual de usuario

HP Pavilion w1100 - Desktop PC Manual de usuario

HP Vectra VT6 Manual de usuario

HP EliteOne 1000 G1 Instrucciones de instalación

HP ThinkPad T43 Manual del propietario

HP d325 Slim Tower Model Manual de operación y mantenimiento

HP Compaq Microtower Business PC dx2300 Instrucciones de uso

HP Pavilion d4000 - Desktop PC Instrucciones de instalación

HP Xw4600 - Workstation - 2 GB RAM Guía de referencia

HP Pavilion Media Center m7300 - Desktop PC Hoja de especificaciones

HP Z210 Series Manual

HP EliteOne 1000 G2 Manual de operación y mantenimiento

HP S5220F - Pavilion Slimline - Desktop PC Manual

HP OMEN Obelisk 875 Instrucciones de instalación

Manuales populares de De oficina de otras marcas

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Dell

Dell Alienware Area-51 R4 Manual de usuario
