HP Visualize J5600 UNIX®Workstations

PA8600

Upgrade Instructions

Manufacturing Part Number: A5998-90000

Edition E1299

Notice

The information contained in this document is subject to change without

notice.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

Hewlett-Packard Warranty Statement

Refer to Warranty & Support for your HP Workstation for warranty terms

applicable to your Hewlett-Packard product and replacement parts.

Restricted Rights Legend

Use, duplication, or disclosure by the U.S. Government Department of

Defense is subject to restrictions as set forth in paragraph (b)(3)(ii) of the

Rights in Technical Data and Software clause in DFARS 252.227.7013.

This document contains proprietary information that is protected by

photocopied, reproduced or translated to another language without the

prior written consent of Hewlett-Packard Company.

UNIX is a registered trademark in the United States of America and

other countries, licensed exclusively through X/Open Company Limited.

California.

This software and documentation is based in part on the Fourth Berkeley

Software Distribution under license from the Regents of University of

California.

1 Getting Started

The following important information must be adhered to for proper

removal and replacement of all Hewlett-Packard parts.

6Chapter1

Getting Started

Safety Warnings

WARNING Removing the device cover may expose sharp edges in the

equipment chassis. To avoid injury, use care when installing

customer add-on devices.

NOTE Before performing removal/replacement procedures, position the

workstation on a cushioned ﬂat, stable surface, such as a table top or

workbench.

NOTE Installing the recommended HP replacement part in your J5000

workstation does not affect the regulatory and safety classiﬁcations or

approvals listed in the original owner’s guide.

Electrostatic Discharge (ESD) Precautions

To prevent damage to the J5000 workstation, observe all of the following

ESD precautions while performing removal and replacement procedures:

• Remove all ESD-generating materials from the work area in which

you will remove and replace the workstation ﬁeld replaceable unit(s).

• Open the ESD materials provided with the replacement part kit.

Unfold the black conductive sheeting (antistatic mat) and place it

under a corner of the workstation.

• Wear a static strap to ensure that any accumulated electrostatic

charge is discharged from your body to ground. Attach the

static-grounding wrist strap by following the instructions on the

package. Attach the sticky end of the wrist strap to bare metal on the

rear panel of the workstation.

• Connect all equipment together, including the static-free mat, static

strap, clips attached to the wrist strap, nodes, and peripheral units.

Chapter 1 7

Getting Started

Safety Warnings

• Keep uninstalled printed circuit boards in their protective antistatic

bags.

• Once you have removed printed circuit boards from their protective

antistatic bags, handle the printed circuit boards by their edges only.

• Ensure you have a sufﬁcient ESD protected area on which to lay out

the parts you remove from the system.

8Chapter1

Getting Started

Replacement Part Kit Contents

Take a moment to verify that your kit contains the following contents:

• System board upgrade tray assembly

• Electrostatic Discharge (ESD) materials

• Removal/Replacement Instructions

If you are missing any part or any documentation, please call your

designated service representative.

Required Tools

You will need the following tools for removal/replacement procedures:

• T-10 and/or T-15 Torx drivers

• ESD materials

Chapter 1 9

Getting Started

Upgrade Instructions Overview

The steps for performing the upgrade are outlined below and should be

performed in the sequence listed. Refer to individual sections of this

guide for step-by-step procedures for upgrading a J5000 to a J5600.

1. Prepare your workstation

- Verify that you have the correct version of HP-UX.

- Determine and WRITE DOWN the LAN ID of your system. You may

need to re-enter it after installing the new system board.

- Power off the workstation and any peripherals.

- Unplug the power.

2. Remove the front panel.

3. Remove the top panel.

4. Remove the side panels.

5. Disconnect the ﬂex cable.

6. Remove the bus bar shield.

7. Remove the memory card(s) (DIMMs).

8. Disconnect the system board cables.

9. Remove the old system board.

10.Install the new system board.

11.Reconnect the system board cables.

12.Reinstall the memory card(s) (DIMMs).

13.Reinstall the bus bar shield.

14.Reconnect the ﬂex cable.

15.Replace the side panels.

16.Replace the top panel.

17.Replace the front panel.

18.Verify system operations.

10 Chapter1

Getting Started

Preparing Your Workstation

The workstation must be running HP-UX 10.20 with Additional Core

Enhancements (ACE4) 9906 or later to accommodate the PA8600

upgrade. It should report B.10.20. If the workstation is running an older

version of HP-UX, update the operating system software before

continuing. Use the command /usr/sbin/swlist -l bundle | grep ACE to

view what software products are loaded in your system. If the product

list includes B6193DA, you do not need to update HP-UX.

1. Determine the workstation’s LAN ID by entering the following

command: /usr/sbin/lanscan.

The output is similar to the following:

Hardware Station Crd Hardware Net-Interface NM MAC HP DLPI Mjr

Path Address In# State NameUnit State ID Type Support Num

2.0.2 0x08000970ECC0 0 UP lan0 UP 4 ETHER YES 130

Record the LAN ID here. You will need it after installing the new

system board:

Enter LAN ID: ___ ___ ___ ___ ___ ___ -___ ___ ___ ___ ___ ___

You must supply the dash (-) between the ﬁrst six digits and the last

six digits

After you install the new system board and power on the system for

the ﬁrst time, you may be prompted for the LAN ID.

2. Power down the system as described in the next section.
