HP EliteDesk 705 G3 Manual de operación y mantenimiento

Hardware Reference Guide

HP EliteDesk 705 G3 Desktop Mini

L.P.

Windows is either a registered trademark or

trademark of Microsoft Corporation in the

United States and/or other countries.

The information contained herein is subject to

change without notice. The only warranties for

HP products and services are set forth in the

express warranty statements accompanying

such products and services. Nothing herein

should be construed as constituting an

additional warranty. HP shall not be liable for

technical or editorial errors or omissions

contained herein.

First Edition: July 2016

Document part number: 865597-001

Product Notice

This guide describes features that are common

to most models. Some features may not be

available on your computer.

Not all features are available in all editions or

versions of Windows. Systems may require

upgraded and/or separately purchased

hardware, drivers, software or BIOS update to

take full advantage of Windows functionality.

For details on Windows® 8 functionality, go to

http://www.microsoft.com for details.

For details on Windows 7 functionality. Go to

http://windows.microsoft.com/en-us/

windows7/get-know-windows-7 for details.

To access the latest user guides or manuals for

your product, go to http://www.hp.com/

support, and select your country. Select Find

your product, and then follow the on-screen

instructions.

Software terms

By installing, copying, downloading, or

otherwise using any software product

preinstalled on this computer, you agree to be

bound by the terms of the HP End User License

Agreement (EULA). If you do not accept these

license terms, your sole remedy is to return the

entire unused product (hardware and software)

within 14 days for a refund subject to the

refund policy of your place of purchase.

For any further information or to request a full

refund of the computer, please contact your

local point of sale (the seller).

About This Book

This guide provides basic information for upgrading the HP Desktop Mini Business PC.

WARNING! Text set o in this manner indicates that failure to follow directions could result in bodily harm or

loss of life.

CAUTION: Text set o in this manner indicates that failure to follow directions could result in damage to

equipment or loss of information.

NOTE: Text set o in this manner provides important supplemental information.

iii

iv About This Book

Table of contents

1 Product features ........................................................................................................................................... 1

Standard conguration features ........................................................................................................................... 1

Front components ................................................................................................................................................. 2

Rear components ................................................................................................................................................... 3

Serial number location .......................................................................................................................................... 4

2 Setup ............................................................................................................................................................ 5

Changing from desktop to tower conguration .................................................................................................... 5

Attaching the computer to a mounting xture ..................................................................................................... 6

Installing a security cable ...................................................................................................................................... 7

Connecting the power cord .................................................................................................................................... 7

3 Hardware upgrades ....................................................................................................................................... 8

Serviceability features ........................................................................................................................................... 8

Warnings and cautions .......................................................................................................................................... 8

Removing the computer access panel ................................................................................................................... 9

Replacing the computer access panel ................................................................................................................. 10

Installing memory modules ................................................................................................................................ 11

Memory modules ............................................................................................................................... 11

Memory module specications ......................................................................................................... 11

Populating memory module slots .................................................................................................... 12

Installing memory modules .............................................................................................................. 13

Removing a hard drive ......................................................................................................................................... 17

Installing a hard drive .......................................................................................................................................... 18

Replacing an M.2 PCIe solid state drive (SSD) ..................................................................................................... 19

Replacing the WLAN module ............................................................................................................................... 23

Installing an external antenna ............................................................................................................................ 27

Replacing the battery .......................................................................................................................................... 31

Synchronizing the optional wireless keyboard and mouse ................................................................................ 35

Appendix A Electrostatic discharge .................................................................................................................. 37

Preventing electrostatic damage ........................................................................................................................ 37

Grounding methods ............................................................................................................................................. 37

Appendix B Computer operating guidelines, routine care and shipping preparation ............................................. 38

Computer operating guidelines and routine care ............................................................................................... 38

Shipping preparation ........................................................................................................................................... 39

Index ............................................................................................................................................................. 40

1 Product features

Standard conguration features

Features may vary depending on the model. For a complete listing of the hardware and software installed in

the computer, run the diagnostic utility (included on some computer models only).

NOTE: This computer model can be used in a tower orientation or a desktop orientation. The stand is sold

separately.

Standard conguration features 1

Front components

NOTE: Your computer model may look slightly dierent from the illustration in this section.

Ite

Icon Component Ite

Icon Component

1 Audio-out (headphone) jack 4 USB port

2 Audio-out (headphone)/Audio-in (microphone)

combo jack

5 Hard drive light

3 USB 3.0 (charging) port 6 Power button

NOTE: The USB 3.0 (charging) port also provides current to charge a device such as a Smart Phone. The charging current is available

whenever the power cord is connected to the system, even when the system is o.

2 Chapter 1 Product features

Rear components

NOTE: Your computer model may look slightly dierent from the illustration in this section.

Ite

Icon Component Ite

Icon Component

Ite

Component Ite

Component

1 External antenna 8 Power cord retention hook

2 Dual-Mode DisplayPort (D++) 9 USB ports (2)

3 VGA monitor port 10 Padlock loop

4 External antenna connectors (2) 11 RJ-45 (network) jack

5 DisplayPort, HDMI (shown), VGA, or Serial

connector*

12 Security cable slot

6 Thumbscrew 13 Power connector

7 USB 3.0 ports (2) (blue)

* Optional

Rear components 3

Serial number location

Each computer has a unique serial number and a product ID number that are located on the exterior of the

computer. Keep these numbers available for use when contacting customer service for assistance.

4 Chapter 1 Product features
