HP Compaq Pro 4300 Manual de usuario

Rear I/O includes (4) USB 2.0 ports, serial port, PS/2 mouse and keyboard ports, RJ-45 network interface, VGA and DVI-D

video interfaces, and audio in/out jacks

Low profile expansion slots include (2) PCI slots, (1) PCI Express x1 slot, and (1) PCI Express x16 graphics slot

Front I/O includes (4) USB 2.0 ports, dedicated headphone output, and a microphone jack

HP Optical Mouse

HP Keyboard

3.5" external drive bay supporting a media card reader

5.25" external drive bay supporting an optical disk drive

3.5" internal drive bay supporting a hard disk drive

240W standard efficiency or 85% high efficiency Power Supply

HP Monitor (sold separately)

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Overview

DA - 14288 North America — Version 22 — December 16, 2013

Page 1

At A Glance

Intel® H61 Express chipset

Intel 2nd & 3rd generation Core™ processors

Integrated Intel HD Graphics

Broadcom BCM 57788 Gigabit Ethernet LAN with Lightning protection

DDR3 Synchronous Dynamic Random Access Memory (SDRAM)

Integrated dual independent monitor support via a VGA and DVI-D video interface

Standard efficiency, high voltage protection or 85% high efficiency energy saving power supplies available (offering will vary by

geographic region)

ENERGY STAR® qualified. EPEAT® registered where applicable/supported. See www.epeat.net for registration status by country.

Created using industry leading Design for Environment standards

Tailored HP Factory Express deployment and lifecycle services available

(

http://h71028.www7.hp.com/enterprise/cache/97688-0-0-225-121.aspx

)

Protected by HP Services, including standard warranties up to 5-5-5 (terms and conditions vary by country; certain restrictions

and exclusions apply)

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Overview

DA - 14288 North America — Version 22 — December 16, 2013

Page 2

OPERATING SYSTEMS

Preinstalled

Windows 8 Pro (64-bit)*

Windows 8 (64-bit)*

Windows® 7 Professional (32-bit)**

Windows® 7 Professional (64-bit)**

Windows® 7 Professional (32-bit) (available through downgrade rights from Windows 8 Pro)***

Windows® 7 Professional (64-bit) (available through downgrade rights from Windows 8 Pro)***

Windows® 7 Home Premium (32-bit)**

Windows® 7 Home Premium (64-bit)**

Windows® 7 Home Basic (32-bit)**

FreeDOS 2.0

Novell SUSE Linux Enterprise Desktop 11

*Not all features are available in all editions of Windows 8. Systems may require upgraded and/or

separately purchased hardware, drivers and/or software to take full advantage of Windows 8

functionality. See

http://www.microsoft.com

**Not all features are available in all editions of Windows 7. This system may require upgraded and/or

separately purchased hardware to take full advantage of Windows 7 functionality. See

http://windows.microsoft.com/en-us/windows7/products/home

for details.

***This system is preinstalled with Windows® 7 Pro software and also comes with a license and media

for Windows 8 Pro software. You may only use one version of the Windows software at a time.

Switching between versions will require you to uninstall one version and install the other version. You

must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid

loss of your data.

Certified

Novell SUSE Linux Enterprise Desktop 11

Supported

Windows® 7 Enterprise Edition (32-bit or 64-bit)

Windows 8 Enterprise (32-bit or 64-bit)

Windows 8 Pro (32-bit)

Windows 8 (32-bit)

PROCESSOR

Intel® 3rd Generation Core™ i7 Processors

Intel® Core™ i7-3770S with Intel HD Graphics 4000 (3.10 GHz, 8 MB cache, 4 cores)

8 threads, 65 W

Intel Stable Image Platform Program (SIPP)

Intel® 3rd Generation Core™ i5 Processors

Intel® Core™ i5-3570S with Intel HD Graphics 2500 (3.10 GHz, 6 MB cache, 4 cores)

4 threads, 65 W

Intel Stable Image Platform Program (SIPP)

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 3

Intel® Core™ i5-3475S with Intel HD Graphics 4000 (2.90 GHz, 6 MB cache, 4 cores)

4 threads, 65 W

Intel Stable Image Platform Program (SIPP)

Intel® Core™ i5-3470S with Intel HD Graphics 2500 (2.90 GHz, 6 MB cache, 4 cores)

4 threads, 65 W

Intel Stable Image Platform Program (SIPP)

Intel® Core™ i5-3470T with Intel HD Graphics 2500 (2.90 GHz, 3 MB cache, 2 cores)

4 threads, 35 W

Intel Stable Image Platform Program (SIPP)

Intel® 3rd Generation Core™ i3 Processors

Intel® Core™ i3-3250 with Intel HD Graphics 2500 (3.50 GHz, 3 MB cache, 2 cores)

4 threads, 55W

Intel® Core™ i3-3245 with Intel HD Graphics 2500 (3.40 GHz, 3 MB cache, 2 cores)

4 threads, 55W

Intel® Core™ i3-3240T with Intel HD Graphics 2500 (2.90 GHz, 3 MB cache, 2 cores)

4 threads, 35W

Intel® Core™ i3-3240 with Intel HD Graphics 2500 (3.40 GHz, 3 MB cache, 2 cores)

4 threads, 55W

Intel® Core™ i3-3225 with Intel HD Graphics 4000 (3.30 GHz, 3 MB cache, 2 cores)

4 threads, 55W

Intel® Core™ i3-3220 with Intel HD Graphics 2500 (3.30 GHz, 3 MB cache, 2 cores)

4 threads, 55W

Intel® Core™ i3-3210 with Intel HD Graphics 2500 (3.20 GHz, 3 MB cache, 2 cores)

4 threads, 55W

Intel® 2nd Generation Core™ i3 Processors

Intel® Core™ i3-2130 with Intel HD Graphics 2000 (3.40 GHz, 3 MB cache, 2 cores)

4 threads, 65W

Intel® Core™ i3-2120 with Intel HD Graphics 2000 (3.30 GHz, 3 MB cache, 2 cores)

4 threads, 65W

Intel® Pentium® Processors

Intel® Pentium® G870 with Intel HD Graphics (3.10 GHz, 3 MB cache, 2 cores)

2 threads, 65 W

Intel® Pentium® G860 with Intel HD Graphics (3.00 GHz, 3 MB cache, 2 cores)

2 threads, 65 W

Intel® Pentium® G645 with Intel HD Graphics (2.90 GHz, 3 MB cache, 2 cores)

2 threads, 65 W

Intel® Pentium® G640 with Intel HD Graphics (2.80 GHz, 3 MB cache, 2 cores)

2 threads, 65 W

Intel® Pentium® G2140 with Intel HD Graphics (3.3 GHz, 3 MB cache, 2 cores)

2 threads, 55 W

Intel® Pentium® G2130 with Intel HD Graphics (3.2 GHz, 3 MB cache, 2 cores)

2 threads, 55 W

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 4

Intel® Pentium® G2120 with Intel HD Graphics (3.1 GHz, 3 MB cache, 2 cores)

2 threads, 55 W

Intel® Pentium® G2030 with Intel HD Graphics (3.0 GHz, 3 MB cache, 2 cores)

2 threads, 55 W

Intel® Pentium® G2020 with Intel HD Graphics (2.90 GHz, 3 MB cache, 2 cores)

2 threads, 55 W

Intel® Pentium® G2010 with Intel HD Graphics (2.80 GHz, 3 MB cache, 2 cores)

2 threads, 55 W

Intel® Celeron® Processors

Intel® Celeron® G1620 with Intel HD Graphics (2.70 GHz, 2 MB cache, 2 cores)

2 threads, 55 W

Intel® Celeron® G1610 with Intel HD Graphics (2.60 GHz, 2 MB cache, 2 cores)

2 threads, 55 W

Intel® Celeron® G555 with Intel HD Graphics (2.70 GHz, 2 MB cache, 2 cores)

2 threads, 65 W

Intel® Celeron® G550 with Intel HD Graphics (2.60 GHz, 2 MB cache, 2 cores)

2 threads, 65 W

Intel® Celeron® G540 with Intel HD Graphics (2.50 GHz, 2 MB cache, 2 cores)

2 threads, 65 W

Intel® Celeron® G470 with Intel HD Graphics (2.0 GHz, 1.5 Mb cache, 1 core)

2 threads, 35 W

Intel® Celeron® G465 with Intel HD Graphics (1.90 GHz, 1.5 Mb cache, 1 core)

2 threads, 35 W

Intel® Celeron® G460 with Intel HD Graphics (1.80 GHz, 1.5 Mb cache, 1 core)

2 threads, 65 W

CHIPSET

Intel® H61 Express

SMBIOS

System Management BIOS, previously known as DMI BIOS, is used to store system management information.

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 5

GRAPHICS

Integrated on all models (depends on processor)

Intel HD Graphics: Basic, 2000, 2500, 4000

NOTE:

Models with Intel Core i3/i5/i7 processors include HD 2000, 2500or 4000 graphics. Models with Pentium or Celeron

processors include HD graphics. Please see specific processors for graphics configuration.

Discrete

AMD Radeon HD 6350 (512 MB) PCIe x16

AMD Radeon HD 7450 (1 GB) PCIe x16

NVIDIA NVS 300 (512 MB) PCIe x16

NVIDIA NVS 310 (512 MB) PCIe x16

NVIDIA NVS 315 1GB PCIe x16 GFX

Adapters and Cables

HP DisplayPort to DVI-D Adapter

HP DisplayPort to HDMI Adapter

HP DisplayPort to VGA Adapter

HP DisplayPort Cable

FireWire / IEEE 1394a PCIe x1 Card

HP Front Dual USB3 Port Device

STORAGE

SATA Hard Drive

250 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV

500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV

1 TB, 7200 rpm, SATA 6.0 Gb/s, SMART IV

SATA Solid State Drive

120 GB, SATA, Solid State Drive

128 GB, SATA, Solid State Drive

160GB SATA 2.5 with caddy Solid State Drive

256GB SATA 2.5 with caddy SED Solid State Drive

256GB SATA 2.5 with caddy Solid State Drive

500GB 7200 RPM SATA 2.5 SED HDD

Optical Disc Drive

HP SATA DVD-ROM

HP SATA SuperMulti DVD Writer

HP SATA Blu-ray Writer

No included ODD

Media Card Reader

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 6

14-in-1 USB 2/3 3.5 (optional)

MEMORY

Type

Non-ECC, DDR3 SDRAM, 1600 MHz, DIMM(runs at 1333 MHz due to chipset)

Maximum

16 GB

# of Slots

NOTE:

Full availability of 4 GB or more of memory requires a 64-bit operating system. With Windows 32-bit operating systems,

the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to

system resource requirements.

NETWORKING/COMMUNICATIONS

Ethernet (RJ-45)

Integrated Broadcom BCM 57788 Gigabit Ethernet LAN with Lightning protection

Intel Pro 1000 CT2 Gigabit Ethernet Network Card (optional)

NOTE:

The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and

does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and

network infrastructure is required.

Wireless

HP 802.11 b/g/n Wireless Network Card PCIe x1 (optional)

Intel 6205 802.11 a/b/g/n PCIe x1 NIC (optional)

Intel 7260 802.11 a/b/g/n PCIe x1 NIC (optional)

AUDIO/MULTIMEDIA

High Definition Audio with Realtek ALC221 codec (all ports are stereo)

Microphone/Headphone front ports (standard)

Line-out and Line-In rear ports (standard)

Multi-streaming capable (standard)

Internal Speaker (standard)

HP Thin USB Powered Speakers (optional)

NOTE:

The audio ports/jacks provided by all HP desktop systems are 3.5mm in diameter. This would include both the front jacks

and rear jacks, for audio in/out, mic in and headphone out.

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 7

KEYBOARDS AND POINTING DEVICES

Keyboard

HP USB Standard

HP PS/2 Standard

HP USB CCID SmartCard Keyboard

HP USB PS/2 Washable Keyboard

HP Wireless Keyboard and Mouse

(Keyboard contains 25% post-consumer recycled plastic content)

HP Wireless Keyboard & Dongle (Brazil)

Mice

HP USB Optical Mouse

HP PS/2 Optical Mouse

HP USB Laser Mouse

HP USB PS/2 Washable Scroll Mouse

HP Wireless Laser Mouse (Brazil)

STAND

HP Small Form Factor tower stand

SECURITY

SATA Port Disablement (via BIOS)

Serial, Parallel, USB enable/disable (via BIOS)

Optional USB Port Disable at factory (user configurable via BIOS)

Removable Media Write/Boot Control

Power-On Password (via BIOS)

Setup Password (via BIOS)

HP Chassis Security Kit

Support for chassis padlocks and cable lock devices

Face Recognition for HP ProtectTools

POWER

240W, 85% efficient, active PFC

240W, standard efficiency, active PFC

SOFTWARE

Included

Windows 8 Windows 7

Security

HP Client Security

Credential Manager

Password Manager

One Step Logon

Face Recognition (with optional webcam)

SpareKey

HP Client Security

Credential Manager

Password Manager

One Step Logon

Face Recognition (with optional webcam)

SpareKey

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 8

Device Access Manager w/JITA

Drive Encryption*

Computrace (user optional)**

Windows Defender

DigitalPass

Device Access Manager w/ JITA

Drive Encryption (McAfee)

File Sanitizer

Privacy Manager

Computrace (user optional)**

Microsoft Security Essentials

Windows

Applications

Internet Explorer

Store

Desktop

Photos

Mail

Games

Calendar

People (contacts)

Messaging

SkyDrive

Music

Video

Camera

News

Sports

Weather

Maps

Finance

Bing (Search)

Productivity

Buy Office Buy Office

HP Additions

HP Registration

HP Getting Started with Windows 8

HP ePrint***

HP Support Assistant

CyberLink Media Suite Windows 8

CyberLink Media Suite

CyberLink YouCam****

CyberLink YouCam Windows 8****

CyberLink Webcam Sharing Manager****

CyberLink PowerDVD SD, BD

CyberLink Power2Go

CyberLink Photo Director

CyberLink Power Director

HP Mobile Connect

Evernote

Skype

Corel WinDVD 10.0 SD (DVD) Player*****

Corel WinDVD 10.0 BD (Blu-Ray) Player*****

Roxio MyDVD Business 2010*****

Roxio MyDVD Business 2010 HD*****

HP Marketplace

HP Wallpaper

Desktop

Applications

HP Wireless Hotspot

HP Support Assistant

PDF Complete, corporate edition

PDF Complete Corporate Edition

WinZip Basic

Adobe Flash Player

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 9

HP Documentation

(eDOCS)

HP eHelp Documentation

HP Hardware Reference Guide

HP Quick Setup & Getting Started Guide

HP Regulatory and Safety Information

HP Safety and Comfort Guide

HP Warranty Documentation

HP eHelp Documentation

HP Hardware Reference Guide

HP Quick Setup & Getting Started Guide

HP Regulatory and Safety Information

HP Safety and Comfort Guide

HP Warranty Documentation

HP Support

Applications

HP EUDI Support Environment

HP Help and Support

HP Setup v9.0

HP Support Assistant

HP EUDI Support Environment

HP Help and Support

HP Recovery Manager

HP Setup v9.0

HP Support Assistant

*Available via download

** Computrace agent is shipped turned off, and must be activated by customers when they purchase a subscription. Subscriptions

can be purchased for terms ranging from one to five years. Service is limited, check with Absolute for availability outside the U.S.

*** Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers,

supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter).Requires optional

broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and

availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary.

****Preinstalled on models with webcam

*****Optional

ENVIRONMENTAL & REGULATORY

Energy Star® qualified models available

EPEAT® registered where applicable/supported. See

www.epeat.net

for registration status by country.

TAA compliant

For accessibility information on HP products, please visit:

http://www.hp.com/accessibility

ENVIRONMENTAL

Weight

System weight

16.72 lb

7.6 kg

Shipping weight

17.86 lb

8.1 kg

Maximum supported weight

77 lb

35 kg

Volume

790.26 cu in (12.95 L)

Dimensions

(W x D x H)

Without stand

13.3 x 14.9 x 3.95 in

33.8 x 37.85 x 10 cm

Tower stand

7.01 x 7.87 x 1.12in

178 x 20 x 2.85 cm

Shipping carton

19.68 x 23.38 x 9 in

QuickSpecs

HP Compaq Pro 4300 Small Form Factor Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14288 North America — Version 22 — December 16, 2013

Page 10

Otros manuales para Compaq Pro 4300

Tabla de contenidos

Otros manuales de De oficina de HP

HP Pavilion a345 Instrucciones de instalación

HP EliteDesk 800 Manual de usuario

HP Pavilion t370 Manual de usuario

HP Compaq Evo D310 Manual de instalación y operación

HP TouchSmart Elite 7320 Manual de usuario

HP Pavilion v400 - Desktop PC Manual de usuario

HP Pavilion xl900 - Desktop PC Manual de usuario

HP A6700f - Pavilion - 4 GB RAM Manual de instrucciones

HP dx7200 - Microtower PC Manual de usuario

HP Brio 8300 Manual de usuario

HP Compaq 6000 Pro SFF Manual de usuario

HP ProOne 490 G3 Instrucciones de instalación

HP OMEN Obelisk 873 Instrucciones de instalación

HP Compaq Presario Manual de usuario

HP dx2450 - Microtower PC Manual de operación y mantenimiento

HP Media Center m7100 - Desktop PC Hoja de especificaciones

HP ZBook x2 Manual

HP A6319fh - Pavilion - 2 GB RAM Manual de instrucciones

HP Pavilion a200 - Desktop PC Manual de usuario

HP -380467-003 - COMPAQ PRESARIO C300 C500 C700 F500 F700 LAPTOP... Manual de funcionamiento

HP Pavilion w5500 - Desktop PC Manual de usuario

HP Compaq Pro 6300 All-in-One Manual de operación y mantenimiento

HP ProDesk 480 G6 MT Manual

HP Neoware c50 - Thin Client Instrucciones de montaje

Manuales populares de De oficina de otras marcas

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Dell

Dell Alienware Area-51 R4 Manual de usuario
