HP Brio 8300 Manual de usuario

Getting Started

HP PC

http://www.hp.com/go/brio

Choosing a Comfortable Work Space

Choose a work space for your computer near a grounded electrical wall outlet.

SAFETY WARNINGS:

If you are in any doubt about whether you can lift the equipment safely, do not try to move it without help.

Please read carefully the relevant sections in your HP Brio PC’s documentation for safety instructions relating to:

●unpacking and setting up your display

●electrical connections

●telephone connections

REGULATORY, WARRANTY AND SOFTWARE LICENSE INFORMATION

Please read carefully the relevant sections in your HP Brio PC’s documentation.

Unpacking the Computer and the Display

COMMUNICATIONS OPTION ONLY

DISPLAY CABLE

TELEPHONE CABLE

COMPUTER

MOUSE

POWER CORD

DOCUMENTATION

DISPLAY

Remove the computer and the display from their ship-

ping boxes. When you have completely unpacked the

boxes, you will find the items shown here.

KEYBOARD

Tarako

fm5

Page

Tuesday

December

1997

9:00

Insert the display connector into the back of the

computer, as shown. If your HP Brio PC does not

have the enhanced video display option, connect

the display as shown in the alternate display

position.

Please note that all connectors are shaped to go

in one way only.

Insert the mouse and keyboard connectors into

the back of the computer, as shown in the illus-

tration.

KEYBOARD MOUSE

DISPLAY

(enhanced video option)

(alternate display position)

Positioning the Computer and the Display

If you have a tilt-swivel, attach it to the display as described in the display manual. Refer to your display documentation to

make sure it is firmly attached.

Position the display on your desk.

Place the computer under your desk. Position the computer to allow proper ventilation and access to the cables.

Connecting the Mouse, Display, and Keyboard to the Computer

Tarako

fm5

Page

Tuesday

December

1997

9:00

Connecting Your Printer to the Computer (optional)

Connecting your Sound Card (if applicable)

PARALLEL

SERIAL

LINE IN (BLUE)

MIC (RED)

SPEAKER (GREEN)

MIDI/GAME PORT

LINE OUT (BLACK)

Insert the printer connector into the back of the

computer, as shown in the illustration.

If you have a serial printer, connect it to the socket

labeled SERIAL.

If you have a parallel printer, connect it to the

socket labeled PARALLEL.

If you have amplified computer speakers, plug

one end of the cable into the LINE OUT socket of

your sound card, and the other end into the

Input socket of your speakers.

If your speakers are not amplified or if you

want to use a headset, use the SPEAKER socket

of your sound card.

Tarako

fm5

Page

Tuesday

December

1997

9:00

Connecting the Telephone Cable (if applicable)

Connecting the Computer and Display Power Cords

VOLTAGE SWITCH

Check that the voltage of your computer

is set to the correct value for the coun-

try that you are in.

The voltage is displayed on the back of the

computer, above the computer power

socket.

Connect the power cords to the computer

and display as shown in the illustration.

Plug both cords into grounded electrical out-

lets.

Connect the telephone cable to the modem on the back of your computer, using the most appropriate configuration.

Tarako

fm5

Page

Tuesday

December

1997

9:00

Starting Up Your Computer for the First Time

Welcome to Your Computer

(only models pre-installed with HP Brio Center)

Turn on the display first, and then

the computer. This is to ensure that

the computer can detect the display

and adjust itself to the best settings.

Manual Part Number 5966-8292-EN

1997 Hewlett-Packard Company

2. TURN ON

THE COMPUTER

1. TURN ON

THE DISPLAY

Once you have started up your computer, double-click on the shortcut on the

desktop to launch the HP Brio Center.

The HP Brio Center lets you get the most out of your PC, quickly and efficiently, while

at the same time being your first point of reference to all questions or problems you

might encounter. Here’s just some of the possibilities with the HP Brio Center:

●register your HP Brio PC

●take a guided tour of your HP Brio PC

●view on-line help

●perform tasks with help

●communicate & share resources

●back-up data

●perform troubleshooting

Tarako

fm5

Page

Tuesday

December

1997

9:00
