HP Server Static Mount Kit AB295A

for HP 10000 Rack

Installation Instructions

Manufacturing Part Number: AB295-96001

April 2004

U.S.A.

Legal Notices

The information contained herein is subject to change without notice. The only warranties for HP products

and services are set forth in the express warranty statements accompanying such products and services.

Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for

technical or editorial errors or omissions contained herein.

Printed in the U.S.A.

Reproduction, adaptation, or translation of this document without prior written permission is prohibited,

except as allowed under the copyright laws.

Related Documents. The latest versions of server documents, and any updates to these documents are

posted under the appropriate server at http://docs.hp.com. For online access to technical support information,

self-solve tools, online assistance, community forums of IT experts, broad multi vendor knowledge base, and

monitoring and diagnostic tools, go to http://www.hp.com/support.

Chapter 1 3

1HP Server Static Mount Kit for HP 10000

Rack – Installation Instructions

Introduction

This manual provides instructions for static mounting the hp Integrity cx2600 server chassis in a HP 10000

rack.

Cabinet Safety Precautions

WARNING Ensure that the rack is level and stable before working on the rack. Be sure the

leveling jacks (feet) extend to the floor and that the full weight of the rack rests

firmly on the floor.

WARNING Ensure that the rack has anti-tip measures in place. Such measures may include

floor-bolting, anti-tip feet, ballast, or a combination of these measures as specified by

the rack manufacturer and applicable codes.

WARNING Be sure that adequate personnel are on hand to support the product(s) during the

installation process. Use of the appropriate lifting device is recommended as an

installation aid.

WARNING Always load the rack from the bottom up. Load the heaviest items in the rack first.

This makes the rack bottom-heavy and helps prevent the rack from becoming

unstable.

WARNING Do not overload the branch circuit that provides power to the rack. The total rack

load should not exceed 80% of the branch circuit rating.

Mounting Kit Contents

This manual provides installation instructions for server mount kit AB295A. This kit is intended for use with

the hp Integrity cx2600 server, and includes the following:

• Two Mounting Rails (left and right)

• Two Rear Rack Ears

• Two Rear Cable Routing Brackets

• One Cable Management Strain Relief Bar

• Mounting Hardware (screws and nuts)

HP Server Static Mount Kit for HP 10000 Rack – Installation Instructions

Installation Procedure

Chapter 1

Installation Procedure

Figure 1-1 HP Integrity cx2600 Servers Mounted in a HP 10000 Rack

Mounting Kit

Before mounting your server in the HP 10000 rack, inspect the mounting kit hardware. Check that all

required mounting hardware is available. A mounting kit parts list is provided at the rear of this manual.

Mount the Server

Mount a server in the HP 10000 rack as follows:

Step 1. Attach the rear cable routing brackets to the server chassis using T15 flathead screws.

2600inrack2

HP Server Static Mount Kit for HP 10000 Rack – Installation Instructions

Installation Procedure

Chapter 1 5

Figure 1-2Attach the Brackets and Rack Ears to the Server Chassis

Step 2. Attach the rear rack ears to the server chassis using T15 flathead screws.

Step 3. Install left and right HP 10000 rack rails at desired position in rack as shown in Figure 1-3. Insert

M5 cagenuts into the rack columns and secure rails to the rack columns using T25 M5 screws.

Tighten the front screws before tightening the rear screws.

Figure 1-3Attach the Rails to the Rack Columns

Step 4. Install four M5 cagenuts in front rack columns, above the rails. Then slide the server into position

on the rails and secure it to the front columns with T25 M5 screws threaded into the cagenuts, as

shown in Figure 1-4.

chasbrkt2

Rear Cable

Routing Bracket

T15 Flathead

Screws

Rear Rack Ear

rckrail3

T25 M5 Screws

HP Server Static Mount Kit for HP 10000 Rack – Installation Instructions

Installation Procedure

Chapter 1

Figure 1-4Insert the Server into the Rack

Step 5. From the rear of the rack, secure the server rack ears to the rails using four T25 M5 screws as

shown in Figure 1-5.

Figure 1-5Secure the Server Chassis at the Rear of the Rack

Step 6. Hold the cable management strain relief bar to the cable routing brackets and secure it in place

with four T25 10X32 screws.

chasmnt2

Cage Nuts

T25 Screws

cmbar4

Cable

Management

Bar

T25

10x32

Screws T25 M5

Screws T2510x32

Screws

HP Server Static Mount Kit for HP 10000 Rack – Installation Instructions

AB295A Rack Mount Kit

Chapter 1 7

AB295A Rack Mount Kit

The HP Server Mounting Kit, part number AB295A includes the items listed below.

Table 1-1 Mounting Kit Parts List

Item Quantity HP Part Number

Left HP 10000 rack rail 1 AB295-00001

Right HP 10000 rack rail 1 AB295-00002

Cable management

strain relief bar

1 AB292-00011

Rear rack ear 2 AB295-00003

Rear cable routing

bracket

2 AB293-00001

Screw, T25, M5 x 16 mm,

w/ crestcup washer,

15 mm O.D.

16 0515-2990

Screw, T15, M4 x 0.7 mm

6 mm, flathead,

w/ patchlock

14 0515-2042

Screw, T25, 10-32 x 0.625,

panhead, w/ CC washer

4 2680-0323

Cagenut, M5 12 0535-1032

HP Server Static Mount

Kit for HP 10000 rack –

installation instructions

1 AB295-96001
