hotcontrol Temperature Controller C 148
User‘s Manual
2User‘s Manual C 148 Temperature Controller
The Symbol calls attention to an operating procedure, practice, or the like,
which, if not correctly performed or adhered to, could result in personal injury or da-
mage to or destruction of part or all of the product and system. Do not proceed bey-
ond a warning symbol until the indicated conditions are fully understood and met.
Use the Manual
Installers Read Chapter 1, 2
System Designer Read All Chapters
Expert User Read Page 10
Note: It is strongly recommended that a process should incorporate a LIMIT CON-
TROL which will shut down the equipment at a preset process condition in order to
preclude possible damage to products or system.
Information in this user‘s manual is subject to change without notice.
This manual is applicable for the products with software version 23 and later version.
WARNING SYMBOL
Die deutsche Bedienungsanleitung finden Sie auf unserer homepage
You will find the German user manual on our homepage
https://www.hotset.com/de/downloads/downloads/
3User‘s Manual C 148 Temperature Controller
Chapter 1 Overview
1-1 General 5
1-2 Keys and Displays 8
1-3 Menu Overview 10
1-4 Parameter Descriptions 11
Chapter 2 Installation
2-1 Unpacking 18
2-2 Mounting 18
2-3 Wiring precautions 19
2-4 Power Wiring 21
2-5 Sensor Installation Guidlines 21
2-6 Sensor Input Wiring 22
2-7 Control Output Wiring 22
2-8 Alarm Wiring 23
Chapter 3 Programming
3-1 Lockout 24
3-2 Signal Input 24
3-3 Control Outputs 25
3-4 Alarm 29
3-5 Configure User Menu 30
3-6 Ramp 31
3-7 Dwell Timer 32
3-8 PV Shift 33
3-9 Digital Filter 34
3-10 Failure Transfer 35
3-11 Auto-tuning 36
3-12 Manual tuning 38
3-13 Manual Control 39
Chapter 4 Specifications
Specifications 40
Appendix
A-1 Error Codes 45
4User‘s Manual C 148 Temperature Controller
FIGURES & TABLES PAGE NO
Figure 1.1 Fuzzy Control Advantage 6
Figure 1.3 Front Panel Description 9
Figure 1.4 Display of Initial Stage 9
Figure 2.1 Mounting Dimensions 19
Figure 2.3 Lead Termination 20
Figure 2.6 Rear Terminal Connection 20
Figure 2.7 Power Supply Connections 21
Figure 2.8 Sensor Input Wiring 22
Figure 2.11 Output 1 Pulsed Voltage to Drive SSR 22
Figure 2.19 Alarm Output to Drive Load 23
Figure 2.20 Alarm Output to Drive Contactor 23
Figure 3.2 Heat Only ON-OFF Control 25
Figure 3.3 Deviation High Alarm 28
Figure 3.4 Process Low Alarm 28
Figure 3.5 RAMP Function 31
Figure 3.6 Dwell Timer Function 32
Figure 3.7 PV Shift Application 33
Figure 3.8 Filter Characteristics 34
Figure 3.9 Effects of PID Adjustment 39
Table 1.1 Display Form of Characters 9
Table 3.2 PID Adjustment Guide 38
Table A.1 Error Codes and Corrective Actions 45
Contents
5User‘s Manual C 148 Temperature Controller
The Fuzzy Logic plus PID micropro-
cessor-based controller series, incor-
porate two bright, easy to read 4-digit
LED displays, indicating process va-
lue and set point value. The Fuzzy Lo-
gic technology enables a process to
reach a predetermined set point in the
shortest time, with the minimum of
overshoot during power-up or exter-
nal load disturbance.
C148 is a 1/16 DIN size panel mount
controller. The unit is powered by 90-
250 VAC or 11-26 VDC / VAC supply,
incorporating a 14V / 40mA output
for SSR as standard. There are six
types of alarm plus a dwell timer can
be configured for the alarm output.
The units are fully programmable
for PT100 and thermocouple types
„J, K, T, E, B, R, S, N, L“ with no need
to modify the unit. The input signal is
digitized by using a 18-bit A to D con-
verter. Its fast sampling rate allows the
unit to control fast processes.
By using proprietary Fuzzy modi-
fied PID technology, the control loop
will minimize the overshoot and un-
dershoot in a shortest time. The fol-
lowing diagram is a comparison of
results with and without Fuzzy tech-
nology.
CHAPTER 1 OVERVIEW 1-1 General
6User‘s Manual C 148 Temperature Controller
High Accuracy
The series are manufactured with
custom designed ASIC(Application
Specific Integrated Circuit) tech-
nology which contains a 18-bit A
to D converter for high resolution
measurement (true 0.1°F resolution
for thermocouple and PT100) The
ASIC technology provides improved
operating performance, low cost, en-
hanced reliability and higher density.
Fast Sampling Rate
The sampling rate of the input A to D
converter reaches 5 times / second.
The fast sampling rate allows this
series to control fast processes.
Fuzzy Control
The function of Fuzzy control is to
adjust PID parameters from time to
time in order to make manipulation
output value more flexible and adap-
tive to various processes. The results
is to enable a process to reach a pre-
determined set point in the shortest
time, with the minimum of overshoot
and undershoot during power-up or
external load disturbance.
CHAPTER 1 OVERVIEW1-1 General
Figure 1.1 Fuzzy Control Advantage
7User‘s Manual C 148 Temperature Controller
CHAPTER 1 OVERVIEW 1-1 General
Auto-tune
The auto-tune function allows the user
to simplify initial setup for a new sys-
tem. A clever algorithm is provided to
obtain an optimal set of control para-
meters for the process, and it can be
applied either as the process is war-
ming up (cold start) or as the process
has been in steady state (warm start ).
Lockout Protection
According to actual security require-
ment, one of four lockout levels can
be selected to prevent the unit from
being changed abnormally.
Bumpless Transfer
Bumpless transfer allows the control-
ler to continue to control by using its
previous value as the sensor breaks.
Hence, the process can be well con-
trolled temporarily as if the sensor is
normal.
Soft-start Ramp
The ramping function is performed
during power up as well as any time
the set point is changed. It can be
ramping up or ramping down. The
process value will reach the set point
with a predetermined constant rate.
Digital Filter
A first order low pass filter with a pro-
grammable time constant is used to
improve the stability of process value.
This is particularly useful in certain
application where the process value is
too unstable to be read.
SEL Function
The units have the flexibility for user
to select those parameters which are
most significant to him and put these
parameters in the front of display se-
quence. There are at most 8 parame-
ters can be selected to allow the user
to build his own display sequence.
8User‘s Manual C 148 Temperature Controller
CHAPTER 1 OVERVIEW1-2 Keys and Displays
KEYPAD OPERATION
SCROLL KEY
This key is used to select a parameter
to be viewed or adjusted.
UP KEY
This key is used to increase the value
of selected parameter.
DOWN KEY
This key is used to decrease the value
of selected parameter.
RESET KEY
This key is used to:
1. Revert the display to display the
process value.
2. Reset the latching alarm, once the
alarm condition is removed.
3. Stop the manual control mode,
auto-tuning mode and calibration
mode.
4. Clear the message of communica-
tion error and auto-tuning error.
5. Restart the dwell timer when the
dwell timer has been time out.
6. Enter the manual control menu du-
ring failure mode occurs.
ENTER KEY
Press for 5 seconds or longer.
Press for 5 seconds to:
1. Enter setup menu. The display
shows
2. Enter manual control mode during
manual control mode is se-
lected.
3. Enter auto-tuning mode during
auto-tuning mode is selected.
4. Perform calibration to a selected
parameter during the calibration
procedure.
Press for 6.2 seconds to select
manual control mode.
Press for 7.4 seconds to select
auto-tuning mode.
Press for 8.6 seconds to select
calibration mode.
9User‘s Manual C 148 Temperature Controller
Figure 1.4 Display of Initial Stage
Table 1.1 Display Form of Characters
Figure 1.3 Front Panel Description
10 User‘s Manual C 148 Temperature Controller
Parameter sometimes not available
or are not changeable!
CHAPTER 1 OVERVIEW1-3 Menu Overview
