Model

F-330BAH(-C)

Self-Contained Flaker

Hoshizaki America, Inc.

Issued: 5-4-2007

Revised: 9-5-2007

INSTRUCTION MANUAL

IMPORTANT

Only qualied service technicians should attempt to install, service, or maintain

this icemaker. No installation, service, or maintenance should be undertaken

until the technician has thoroughly read this Instruction Manual. Likewise, the

owner/manager should not proceed to operate the icemaker until the installer

has instructed them on its proper operation. Failure to install, operate, and

maintain the equipment in accordance with this manual may adversely affect

safety, performance, and warranty coverage.

HOSHIZAKI provides this manual primarily to assist qualied service technicians in the

installation, maintenance, and service of the icemaker.

Should the reader have any questions or concerns which have not been satisfactorily

addressed, please call, write, or send an e-mail message to the HOSHIZAKI Technical

Support Department for assistance.

HOSHIZAKI AMERICA, INC.

618 Highway 74 South

Peachtree City, GA 30269

Attn: HOSHIZAKI Technical Support Department

Phone: 1-800-233-1940 Technical Service

(770) 487-2331

Fax: 1-800-843-1056

(770) 487-3360

E-mail: [email protected]

Web Site: www.hoshizaki.com

NOTE: To expedite assistance, all correspondence/communication MUST include the

following information:

  •ModelNumber

  •SerialNumber

  •Completeanddetailedexplanationoftheproblem

CONTENTS

I. Specications...................................................................................................................... 4

A. Nameplate Rating ......................................................................................................... 4

B. Dimensions/Connections .............................................................................................. 5

II. Installation and Operating Instructions .............................................................................. 6

A. Checks Before Installation............................................................................................. 6

B. How to Remove Panels ................................................................................................ 6

C. Location ........................................................................................................................ 7

D. Setup............................................................................................................................. 7

E. Electrical Connection .................................................................................................... 7

F. Water Supply and Drain Connections ............................................................................ 7

G. Final Checklist ............................................................................................................. 9

H. Startup ........................................................................................................................ 10

III. Cleaning and Maintenance ..............................................................................................11

A. Cleaning and Sanitizing Instructions ............................................................................11

1. Cleaning Solution....................................................................................................11

2. Cleaning Procedure ................................................................................................11

3. Sanitizing Solution ................................................................................................. 13

4. Sanitizing Procedure - Initial .................................................................................. 13

5. Sanitizing Procedure - Final................................................................................... 13

B. Maintenance ............................................................................................................... 15

C. Preparing the Icemaker for Long Storage .................................................................. 16

•Pleasereviewthismanual.Itshouldbereadcarefullybeforethe icemaker is installed

and operated. Only qualied service technicians should install, service, and maintain the

icemaker. This manual should be made available to the technician prior to installation,

maintenance, or service.

•Keepthismanualwiththeicemakerforlaterreference.

I. Specications

A. Nameplate Rating

1. F-330BAH, F-330BAH-C

See the nameplate for electrical and refrigeration specications. This nameplate is located

on the rear panel.

We reserve the right to make changes in specications and design without prior notice.

HOSHIZAKI ICE MAKER

MOTOR-COMPRESSOR THERMALLY PROTECTED,

NOT INTENDED FOR OUTDOOR USE!

Hoshizaki America, Inc.

Peachtree City, GA

www.hoshizaki.com

LISTED

ICE MAKER

946Z

MODEL NUMBER F-330BAH

SERIAL NUMBER

AC SUPPLY VOLTAGE 115/60/1

AMPERES 6.7 AMPS

DESIGN PRESSURE HI-470PSI LO-230PSI

REFRIGERANT 404A 7.1 OZ.

Note: Only the "MODEL NUMBER" is replaced for F-330BAH-C.

B. Dimensions/Connections

1. F-330BAH, F-330BAH-C

Unit = inches (mm)

II. Installation and Operating Instructions

A. Checks Before Installation

IMPORTANT

1. Install in accordance with all applicable national, state, and local regulations.

2. Remove shipping carton, tape, and packing. If any are left in the icemaker, it

will not work properly.

3. Ensure all components, fasteners, and thumbscrews are securely in place

after installation.

•

Remove the top panel and front panel to prevent damage when installing the

icemaker.

•

Remove the package containing the accessories.

•

Remove the protective plastic lm from the panels. If the icemaker is exposed

to the sun or to heat, remove the lm after the icemaker cools.

•

Check that the refrigerant lines do not rub or touch lines or other surfaces, and

that the fan blade turns freely.

•

Check that the compressor is snug on all mounting pads.

•

See the nameplate on the rear panel, and check that your voltage supplied

corresponds with the voltage specied on the nameplate.

B. How to Remove Panels

See Fig. 1

•Front Panel: Remove the screw. Lift up

and towards you.

•Top Panel: Open the door. Remove the

screws. Lift up at the front slightly, push

rearward, and lift off.

Fig. 1

Top Panel

Screw

Front Panel

Screw

Door

C. Location

CAUTION

This icemaker is not intended for outdoor use. Normal operating ambient

temperature should be within +45°F to +100°F (+7°C to +38°C); Normal

operating water temperature should be within +45°F to +90°F (+7°C to +32°C).

Operation of the icemaker, for extended periods, outside of these normal

temperature ranges may affect icemaker performance.

For best operating results:

•Icemakershouldnotbelocatednexttoovens,grillsorotherhighheatproducing

equipment.

•Locationshould

provide a rm and level foundation for the equipment.

•Allow24"(61cm)clearanceattoptoallowforremovaloftheaugerandforeaseof

maintenance and/or service should they be required.

D. Setup

1) Attach the four adjustable legs provided to the bottom of the icemaker.

2) Position the icemaker in the selected permanent location.

3) Level the icemaker from side-to-side and front-to-rear by adjusting the legs.

E. Electrical Connection

WARNING

The GREEN ground wire in the factory-installed power cord is connected

to a screw on the bracket where the cord enters the machine. If it becomes

necessary to remove or replace the power cord, be sure to connect the power

cord's ground wire to this screw upon reattachment.

•Electricalconnectionsmustbeinstalledinaccordancewithapplicablenational,state

and local regulations.

•Theunitrequiresanindependentpowersupply.Seethenameplateforpropervoltage

and breaker/fuse size.

•Usuallyanelectricalpermitandservicesofalicensedelectricianarerequired.

F. Water Supply and Drain Connections

•Watersupplyinletis1/2"femalepipethread(FPT).

•Awatersupplylineshut-offvalveanddrainvalvemustbeinstalled.Aminimumof

3/8" OD copper tubing is recommended for the water supply lines.

•Watersupplypressureshouldbeaminimumof10PSIGandamaximumof113PSIG.

If the pressure exceeds 113 PSIG, the use of a pressure reducing valve is required.

•Drainoutletis3/4"FPT.

•Drainlinemusthave1/4"fallperfoot(2cmper1m)onhorizontalrunstogetgood

ow. A vented tee connection is also required for proper ow.

•Drainlineshouldnotbepipeddirectlytothesewersystem.Anairgapofaminimumof

2 vertical inches (5 cm) should be between the end of the drain pipe from the unit and

the oor drain.

•Thisicemakermustbeinstalledinaccordancewithapplicablenational,state,andlocal

regulations.

•Aplumbingpermitandservicesofalicensedplumbermayberequiredinsomeareas.

Floor

Drain

Fig. 2

Shut-Off

Valve

Drain Valve

Drain Outlet

3/4" FPT

Piping to

approved

drain.

Two-inch

(5 cm) air gap

Water Supply Inlet

1/2" FPT

G. Final Checklist

1) Is the icemaker level?

2) Is the icemaker in a site where the ambient temperature is within +45°F to +100°F

(+7°C to +38°C) and the water temperature within +45°F to +90°F (+7°C to +32°C) all

year around?

3) Is there at least 24" (61 cm) clearance at top for maintenance or service?

4) Have the shipping carton and all tape and packing been removed from the icemaker?

5) Are all components, fasteners, and thumbscrews securely in place?

6) Have all electrical and piping connections been made?

7) Has the power supply voltage been checked or tested against the nameplate rating?

And has a proper ground been installed to the icemaker?

8) Are the water supply line shut-off valve and drain valve installed? Has the water

supply pressure been checked to ensure a minimum of 10 PSIG and a maximum of

113 PSIG?

Note: The icemaker may stop running when the water supply is OFF, or if the pressure

is below 10 PSIG. When the proper water pressure is reached, the icemaker will

automatically start running again.

9) Are the compressor hold-down bolts snug? Have the refrigerant lines been checked to

make sure they do not rub or touch other lines or surfaces?

10) Has the bin control switch been checked for correct operation? Move the actuator

located on the inside of the bin top panel. The compressor should stop within

90 seconds, and the gear motor within 150 seconds.

11) Has the end user been given the instruction manual, and instructed on how to operate

the icemaker and the importance of the recommended periodic maintenance?

12) Has the end user been given the name and telephone number of an authorized service

agent?

13) Has the warranty tag been lled out and

forwarded to the factory for warranty

registration?

14) Have the safety switch brackets moved

out of location during shipping? Make sure

they are in position as illustrated in Fig. 3.

15) Has the safety switch been checked for

correct operation? Activate the safety

switch. The ice machine should shut down

immediately. Turn the ice machine off, then

back on, to reset.

Safety Bracket (A)

Safety Bracket (B)

Safety Switch

Spout

Fig. 3

H. Startup

CAUTION

1. All parts are factory-adjusted. Improper adjustments may result in failure.

2. If the unit is turned off, wait for at least 3 minutes before restarting the

icemaker to

prevent damage to the compressor.

1) Clean the storage bin.

2) Open the water supply line shut-off valve.

3) Make sure the power switch on the control box is in the "OFF" position. Plug the unit

into the electrical outlet.

4) Move the ush switch

to the "ICE" position and move

the

power switch to the

"ON" position to start the

automatic icemaking process

5) Replace the panels in their correct positions.

Otros manuales para F-330BAH-C

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Máquina de hielo de Hoshizaki

Hoshizaki

Hoshizaki DCM-450BAB Manual de usuario

Hoshizaki

Hoshizaki DCM-450BAE Manual de usuario

Hoshizaki

Hoshizaki KM-600MAH Manual de usuario

Hoshizaki

Hoshizaki F-300BAF Manual de usuario

Hoshizaki

Hoshizaki IM-220AA Manual de usuario

Hoshizaki

Hoshizaki DB-130H Manual de usuario

Hoshizaki

Hoshizaki KM-1200SAB Manual de usuario

Hoshizaki

Hoshizaki KML-451MWH Manual de usuario

Hoshizaki

Hoshizaki F-2000MRF Manual de usuario

Hoshizaki

Hoshizaki KM-2400SRB3 Manual de usuario

Hoshizaki

Hoshizaki KM-1800SAH Manual de usuario

Hoshizaki

Hoshizaki KM-1301SAJ/3 Manual de usuario

Hoshizaki

Hoshizaki IM-130ANE-HC Manual de usuario

Hoshizaki

Hoshizaki KM1601SRH350 Manual de usuario

Hoshizaki

Hoshizaki DCM-500BAH Manual de usuario

Hoshizaki

Hoshizaki KM-500MAF Manual de usuario

Hoshizaki

Hoshizaki KML-350MAH Manual de usuario

Hoshizaki

Hoshizaki KML-451MAH Manual de usuario

Hoshizaki

Hoshizaki KM-320MAH Manual de usuario

Hoshizaki

Hoshizaki FM-120KE-HC Manual de usuario

Hoshizaki

Hoshizaki C-100BAE-AD Manual de usuario

Hoshizaki

Hoshizaki FM-150KE(-N) Manual de usuario

Hoshizaki

Hoshizaki F-1000MAF-C Manual de usuario

Hoshizaki

Hoshizaki Serenity Series KMS-822MLH Manual de usuario

Manuales populares de Máquina de hielo de otras marcas

Sub-Zero

Sub-Zero 315I Instrucciones de uso

Unold

Unold 48945 Manual de usuario

Kenmore

Kenmore 2217402A Manual de usuario

Cornelius

Cornelius WM600 Instrucciones de funcionamiento

GE XPIO43SCSS Manual de usuario

Whynter

Whynter FIM-450HA Manual de usuario

U-Line

U-Line UMCR014-SC01A Manual de instalación

Andrew James

Andrew James AJ000522 Manual de usuario

Scotsman

Scotsman CME1356 Manual de usuario

Scotsman

Scotsman ACM 25 Manual de usuario

Kärcher

Kärcher IP 120 Manual de usuario

U-Line

U-Line SS1095 Manual de usuario

Maytag

Maytag MIM1554WRS - Ice Maker Manual de usuario

Princess

Princess Yonanas Manual de usuario

Unold

Unold 48946 Manual de usuario

Electrolux

Electrolux E15IM60GP Manual de usuario

Cornelius

Cornelius UC150 ICE ONLY Manual de usuario

Bunn

Bunn BUNN-O-MATIC ULTRA-1 Manual del propietario
