Hored IS108GPS-4F Manual de usuario

User Manual

IS108GPS-4F

12-port Gigabit managed PoE switch

Installation ManualIntroduction

<User Manual> mainly introduces the hardware features,

installation methods, and precautions during the installation of

IS108GPS-4F.

This manual includes the following sections:

Chapter 1: Product introduction. Briefly describe the basic functions

and features of the switch, detailed hardware and software

specificationsand appearance information.

Chapter 2: Hardware Connections. Guide the connection of switch

with other devicesand precautions.

Chapter 3: Product Installation. Guide the hardware installation

method and precautions.

Chapter 4: Product Packaging and Use Recommendations.

Chapter 1 Product Introduction

1.1 Product introduction

The IS108GPS-4F is a Gigabit-managed industrial PoE switch

that provides 8 Gigabit PoE ports and 4 Gigabit SFP ports. Each PoE

port can provide up to 46W for IEEE802.3af /at compatible

powered devices (PDs). It is especially suitable for applications

where AC power is not easily available or high wiring costs. With

EMC industrial grade 4 protection; corrugated high-strength

aluminum profile housing, IP40 grade, low power design, seismic

rail mounting, -40°C-75° C operating temperature, it can work in

harsh environments; IS108GPS-4F also supports Apollo cloud

one-stop management platform for status checking and

management monitoring,to make it become a reliable solution for

Intelligent transportation, video surveillance and other harsh

industrial environments.

1.2 Features

Full Gigabit Ethernet port

8 full Gigabit RJ45 PoE network port, and 4 Gigabit SFP ports,

breaking the traditional 100M limitation, data transmission will not

stuck

Broadcom high performance industrial grade chip for more

stable performance

Broadcom high-performance industrial-grade chips that

dramatically increase network data processing rates

Powerful working environment

EMC industrial grade 4 protection; corrugated high-strength

aluminum profile housing, IP40 grade, low power design, seismic

rail mounting, -40 ° C-75 ° C operating temperature, can work in

harsh environments

Support Apollo cloud platform one-stop management

Support cloud platform to visualize management of switches and

attached power devices, making operation and maintenance

management easier

1.3 Software and hardware specifications

Hardware specification

Chip

Broadcom high performance chip

Flash

16MB

RAM

64MB DDR

Port

8 10/100/1000M RJ45 port

4 1000M SFP port

PoE Power

supply

810/100/1000Mbps RJ45 port support

802.3af/atPoE power supply

The maximum power supply of the whole

machine is240W

The maximum power per port is 46W

Indicator

12Link/Act indicator

8POEindicator

ALMAlarm indicator

P1、P2Power Indicator 1SYSindicator

Performance

Forward mode: store and forward

Backplane bandwidth: 24Gbps

Packet forwarding rate: 17.8Mpps

Support 8K MAC address table depth

Standard

protocol

IEEE 802.3: Ethernet Media Access Control (MAC)

Protocol

IEEE 802.3i: 10BASE-T Ethernet

IEEE 802.3u: 100BASE-TX Fast Ethernet

IEEE 802.3ab: 1000BASE-T Gigabit Ethernet

IEEE 802.3z: 1000BASE-X Gigabit Ethernet

(optical fiber)

IEEE 802.3ad: Standard method for performing

link aggregation

IEEE 802.3x: Flow Control

IEEE 802.1p: LAN Layer 2 Qos/Cos protocol for

traffic prioritization (multicast filtering)

IEEE 802.1q: VLAN Bridge Operation

IEEE 802.1d: STP spanning tree

IEEE 802.1s: MSTP Spanning Tree

IEEE 802.1w: RSTP Spanning Tree

IEEE 802.3af

IEEE 802.3at

Industry

Standard

EMI:FCC CFR47 Part 15, EN55022/CISPR22, Class

EMS:

IEC61000-4-2 (ESD): ±8kV (contact), ±15kV (air)

IEC61000-4-3 (RS): 10V/m (80MHz-2GHz)

IEC61000-4-4 (EFT): Power Port: ±4kV; Data Port:

±2kV

IEC61000-4-5 (Surge): Power Port: ±2kV/DM,

±4kV/CM; Data Port: ±6kV

IEC61000-4-6 (CS): 3V (10kHz-150kHz); 10V

(150kHz-80MHz)

IEC60068-2-6 (Vibration)

IEC60068-2-27 (Shock)

IEC60068-2-32 (Free Fall)

Operation

environment

Working temperature: -40 ~ 75 ° C

Storage temperature: -40 to 75 ° C

Relative humidity: 5% to 95% (no condensation)

Certification

CE, FCC, RoHS

Mean time

between

failures(MTBF)

100,000 hrs

Warranty

3 years

Lightning

protection

Network port: ±6KV power port: ±4KV

ESD

Contact: ±8KV Air: ±15KV

Physical

specification

Input:48-56VDC

Housing: IP40 grade protection, corrugated high

strength metal housing

Installation: DIN rail mounting

Size: 163mm × 46.5mm × 110mm, weight: 1kg

Software specification

Global

control

button

AI PoE

AI Loop Protect

AI VLAN

AI Extend

Hardware

watchdog

Support

Traffic

Statistics

Support

Port energy

saving

Support

DHCP

Support DHCP Snooping

VLAN

Support 4KVLANs

Support 802.1Q VLAN、MAC VLAN ,IP VLAN

Voice VLAN

MACaddress

Follow the IEEE 802.1d standard

Support MAC address automatic learning and

aging

Support static, dynamic, filtering address table

Safety

features

Password protection

Support restrict user access based on port

number, IP address, and MAC address

Support HTTPS、SSL V3、TLS V1、SSH V1/V2

SupportIP-MAC-PORT ternary binding

Support ARP protection, IP source protection,

DoS protection

Support DHCP Snooping and DHCP attack

protection

Support 802.1X authentication, AAA

Support port security, port isolation

Support CPU protection

POE

management

Support PoE power limit

Support viewing of PoE chip status

Support to set PoE port priority

Support to set PoE power supply time period

QoS

Support 8 port queues

Support port priority, 802.1P priority, DSCP

priority

Supports SP, WRR, and RR priority scheduling

algorithms

Supports automatic identification,

managementand retrieval of information about

attached devices

Spanning tree

Supports STP (IEEE 802.1d), RSTP (IEEE 802.1w)

and MSTP (IEEE 802.1s) protocols

Support loop protection, root bridge

protection, TC protection, BPDU protection,

BPDU filtering

Multicast

Suppor IGMP v1/v2 Snooping

Support fast leave mechanism

Support multicast VLAN

Supports multicast filtering, packet statistics,

and unknown multicast discards.

Storm

suppression

Support multicast suppression

Support broadcast suppression

Support unknown unicast suppression

Link

aggregation

Support static aggregation

Support dynamic aggregation

Support IP, MAC, hybrid load balancing mode

Supports up to 32 aggregation groups

IPv6

SupportIPv6 Ping、IPv6 Tracert、IPv6 Telnet

SupportIPv6 SSH 、IPv6 SSL

Management

and

maintenance

Support WEB network management (HTTP,

HTTPS, SSL V3)

Support CLI (Telnet, SSH V1/V2, local serial port)

SupportSNMP V1/V2/V3，

SupportLLDP、RMON

Support ARP protection, IP source protection,

DoS protection

Support SNMP protocol
