EVOLVE PET ELITE

CORDLESS VACUUM

USER GUIDE

F18OPUV22Y

IMPORTANT SAFETY INFORMATION

This machine is intended for household use only and NOT for commercial or

industrial use. This machine is intended for dry vacuuming only. Do not use this

machine for any other purpose. PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND

USE ONLY AS INSTRUCTED IN THIS GUIDE.

• Don’t leave the charger plugged in when unattended.

• Don’t use the machine if it is faulty or has been dropped, damaged or left

outdoors.

• Don’t use the machine to pick up any flammable or combustible materials

(lighter fluid, petrol, kerosene etc.) or use the machine in an area with explosive

vapours or liquid.

• Don’t use the machine to pick up hot coals, cigarette butts, matches or smoking

hot burning items or use in an area where there may be harmful fluids (chlorine,

bleach and ammonia drain cleaner).

• Don’t handle the charger, battery or use the machine with wet hands.

• Don’t unplug the charger by pulling on the power cord.

• Don’t use the charger if the power cord or plug is damaged.

• Don’t attempt to remove blockages with sharp objects as this may cause damage

to the machine.

• Don’t use the machine with the incorrect battery or charger as this may result in

damage or injury to the user. The correct battery charger information is listed on

the battery pack ratings label.

• Don’t charge the battery outdoors, or leave the charger connected to the mains

when not in use.

• Don’t use the machine with a damaged battery. If the battery is damaged return

the machine, battery and charger to the point of purchase.

• Don’t over fill the dirt container to avoid blocking the air flow through the

machine.

• The brushbar in the powered head constantly rotates when switched on. Never

use the powered head on one spot for an extended period of time as the

brushbar may damage the floor surface.

• Only Hoover ONEPWR batteries and chargers should be used with this machine.

• Only Hoover ONEPWR recommended tools and accessories should be used with

this machine.

• Always remove the battery from the machine before carrying out any

maintenance or if storing unused for a long period of time.

• Keep all openings clear and free from debris as this may affect the

airflow/suction.

• Turn off all controls on the machine before disconnecting or connecting the

battery.

• Always protect the charger power cord from heated surfaces or near open

flames.

• Only use the machine indoors on dry surfaces and keep the area you’re cleaning

well lit.

• The power cord cannot be replaced. If the cord is damaged the charger should

be scrapped.

• Do not use this charger to charge non-rechargeable batteries.

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• Keep fingers, hair and loose clothing away from moving parts and openings

whilst using the machine.

• Store the machine in a cool, dry area. Keep the machine away from rain and

moisture.

• Take extra care when using the machine on the stairs.

• Use only Australian/New Zealand approved 10amp extension cords, non-approved

extension cords may overheat. Care should be taken to arrange the extension

cord as it can be a trip hazard.

• To prevent any damage being sustained, test on an inconspicuous area of the

flooring first.

• Always make sure the separator and filter are fitted correctly before using your

machine and only use the machine with the filter and separator in place.

• Always check the powered head and accessories are free from damage, dirt and

debris before using.

• This machine does not stay upright without constant support. Between uses, lie

flat on the floor in a suitable location so that it does not become a trip hazard or

can be stepped on.

IMPORTANT SAFETY INFORMATION

BATTERY SAFETY PRECAUTIONS

• Replace the battery with a Hoover ONEPWR battery only. Use of another battery

may present a risk of fire or explosion.

• Do not attempt to disassemble the battery, remove any component projecting

from the battery terminals and do not dispose of in a fire.

• The battery and charger have no user serviceable parts. Fire or injury may result.

• Prior to disposal, protect exposed terminals with heavy insulating tape to prevent

shorting. The battery is to be disposed of safely at your local battery recycling

centre.

• When the battery pack is not in use, keep it away from other metal objects that

can make a connection from one terminal to another. Shorting the battery

terminals together may cause burns or a fire.

• In case of battery leakages avoid any contact with the skin. If liquid comes into

contact with the skin, wash immediately with soap and water, then neutralise

with lemon juice or vinegar. If liquid gets into the eyes, ush with clean water

for at least 10 minutes, then seek immediate medical attention.

• To reduce the risk of re, personal injury, and product damage due to short

circuit, never immerse the tool, battery pack, or charger in uid or allow uid

to ow inside them. Corrosive or conductive uids, such as seawater, certain

industrial chemicals, and bleach or bleach-containing products, etc., can cause a

short circuit.

GENERAL INFORMATION

Technical Specications F18OPUV22Y

Product Description Hoover ONEPWR Evolve Pet

Elite Cordless Vacuum

Console Model Number BH53800ANZV

Product Weight

(without battery pack) 3.45kg

Dirt Container Capacity 1.2L

Runtime* Up to 35 mins

Charge Time (per battery) 3 hours

Charger Model Number BH05000ANZ

Battery Included 1x 4.0Ah (BH29040ANZV)

Battery Voltage 18V Li-Ion

Compatible Battery Packs

Subject to technical change without notice.

* Runtime is based on internal testing. Actual runtime will vary under specific

conditions or when using different accessories.

Description of Symbols

DISTRIBUTED BY:

Techtronic Industries Australia Pty Ltd

31 Gilby Road, Mount Waverley, VIC, 3149, Melbourne, Australia

Web Address: www.hoover.com.au

Customer Careline: 1300 698 130

Techtronic Industries N.Z. Limited

Unit C, 70 Business Parade South, East Tamaki, Auckland, 2013, New Zealand

Web Address: www.hoover.co.nz

Customer Careline: 0800 126 688

Regulatory

Compliance

Mark

For Indoor

Use Only

Read User

Manual

MODEL TYPE RATED VOLTAGE RATED CAPACITY CELL NUMBER

F18BTOP21J4 Li-Ion 18V 4.0Ah 5

BH29040ANZ Li-Ion 18V 4.0Ah 5

BH29040ANZV Li-Ion 18V 4.0Ah 5

15 16

1HANDLE

2POWER ON/OFF

3MODE SELECTOR BUTTONS

4BATTERY LED

5MAIN UNIT

6BRUSHBAR

7BATTERY DOCK

8DIRT CONTAINER RELEASE BUTTON

9FILTER (HIDDEN)

10 DIRT CONTAINER LID RELEASE BUTTON

11 SEPARATOR

12 DIRT CONTAINER

13 DIRT RELEASE BUTTON

14 BRUSHBAR COVER

15 ONEPWR 4.0AH BATTERY

ONEPWR CHARGER

MACHINE OVERVIEW

EVOLVE PET ELITE

CORDLESS VACUUM

MODEL: F18OPUV22Y

Subject to technical change without notice. Images are illustrative only.

1HANDLE

2POWER ON/OFF

3MODE SELECTOR BUTTONS

4BATTERY LED

5MAIN UNIT

6BRUSHBAR

7BATTERY DOCK

8DIRT CONTAINER RELEASE BUTTON

9FILTER (HIDDEN)

10 DIRT CONTAINER LID RELEASE BUTTON

11 SEPARATOR

12 DIRT CONTAINER

13 DIRT RELEASE BUTTON

14 BRUSHBAR COVER

15 ONEPWR 4.0AH BATTERY

ONEPWR CHARGER

GETTING STARTED

Push the handle into the main body

until it clicks into place.

THIS MACHINE IS ONLY TO BE USED WITH HOOVER ONEPWR BATTERIES AND CHARGER.

PLEASE READ THE BATTERY AND CHARGER USER GUIDES BEFORE USE.

NOTE: Before first use, ensure the battery is fully charged. Failure to fully charge the battery before first use

may result in poor battery performance. The life expectancy of the battery will vary depending on the usage of the

machine.

Once fully charged, slide the battery off

the charger to remove.

To check the battery charge

level press the battery symbol.

Plug in the charger. Attach the battery

pack to the charger by aligning the ribs

on the battery pack to the grooves in

the charger.

The charger light will flash white to

show when the battery is charging. The

light on the charger will stop flashing

and go off when the battery is fully

charged.

CHARGING THE BATTERY

ASSEMBLING THE VACUUM

NOTE: The handle contains electrical connections. To ensure that the handle

has been correctly installed, please ensure a “click” sound is audible during

the installation of the handle.

Slide the battery onto the machine until

it clicks into place.

Place your foot on the floorhead. Pull the handle backwards to

recline.

GETTING STARTED

WARNING: The brushbar in the floorhead constantly rotates when activated. Never use the floorhead on one spot

for an extended period of time as the brushbar may damage the surface. To prevent any damage being sustained,

test on an inconspicuous area of the flooring/surface first.

CAUTION: Always take extra care when using the vacuum on the stairs.

OPERATION

Cycle Down

To increase runtime

for hard floors and

everyday messes.

Cycle Up

To increase suction for

embedded messes.

Battery LED

Illuminates WHITE

when on and RED when

battery is low.

Power On/Off To remove the battery press both the

buttons to release.

CAUTION: Store the vacuum safely after use to prevent tripping accidents.

NOTE: When less than 20% charge is remaining the low battery indicator will flash red indicating the battery is

running low and charging is required.

CAUTION: If the brushbar in the floorhead has been obstructed, the brushbar motor protection sensor may activate.

The brushbar will stop and the machine may switch off. To reset, switch the machine off and remove the battery.

Remove the floorhead from the reach wand/handheld and clear any obstruction. Wait 1 minute before refitting the

floorhead. Install the battery and switch the machine on.

Press down the dirt container release

button and pull the container to remove.

Hold the dirt container over a bin and

press the dirt release button to allow

dirt and debris to fall out. To close, push

the dirt release door until it clicks into

place.

To re-fit, tilt the dirt container and

line the front of the container up onto

machine. Push back until it clicks into

place.

CLEANING & MAINTENANCE

WARNING: To reduce the risk of personal injury, always turn power switch off and remove battery before cleaning

or servicing.

IMPORTANT: Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from

various types of commercial solvents and may be damaged by their use. Use a clean cloth to remove dirt, dust, oil,

grease, etc.

EMPTYING THE DIRT CONTAINER

NOTE: For best cleaning results, empty the dirt container after each use.

24hr

40°C

MAX

Tap the filter and separator against a bin

to remove dirt and debris.

Wipe over the separator metal shroud

with a dry cloth.

Wash the filter under running water

(40°C max). Leave for at least 24hrs or

until fully dry before replacing.

Press the button on the lid of the dirt

container and lift the lid to access

the filter. Pull the tab on the filter to

remove.

Lift the separator from the dirt

container.

Press down the dirt container release

button and pull the container to remove.

CLEANING AND MAINTENANCE

CLEANING THE FILTER AND SEPARATOR

IMPORTANT: The lter should be tapped over a bin every 4-6 uses, to remove dirt and debris, and replaced every

6-9 months, depending upon use. The lter should be washed every 3 months, or when required. Allow the lter to

completely dry before reinstalling.

CAUTION: Ensure both the lter and separator are retted before use.

IMPORTANT: Don’t over ll the dirt container to avoid blocking the air ow through the vacuum cleaner. Do not

exceed the MAX line indicated on the side of the dirt container.

Otros manuales para ONEPWR EVOLVE PET ELITE

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Aspiradora de Hoover

Hoover

Hoover H-Free HF122UH Manual de usuario

Hoover

Hoover WindTunnel 2 Manual de usuario

Hoover

Hoover U5780900 - WindTunnel Cyclonic Bagless Upright Vacuum... Manual de usuario

Hoover

Hoover Hydropower Manual de usuario

Hoover

Hoover air Manual de usuario

Hoover

Hoover TELIOS CYCLONIC Manual de usuario

Hoover

Hoover CH82 Manual de usuario

Hoover

Hoover Slider Slider Vacuum Cleaner Manual de usuario

Hoover

Hoover DUST MANAGER Manual de usuario

Hoover

Hoover 094HF122GH Manual de usuario

Hoover

Hoover ONE PWR EVOLVE MAX Manual de usuario

Hoover

Hoover Performance Floors & All HU86-FAL-S Manual de usuario

Hoover

Hoover TC5213 Dust Manager Cyclonic Manual de usuario

Hoover

Hoover TE70-TE75011 Guía rápida

Hoover

Hoover Power Capsule Manual de usuario

Hoover

Hoover SpinScrub Manual de usuario

Hoover

Hoover Vacuum cleaner Manual de usuario

Hoover

Hoover Portapower S1029-075 Manual de usuario

Hoover

Hoover fh50800 Manual de usuario

Hoover

Hoover SRC144LB Manual de usuario

Hoover

Hoover H-Energy 700 IM ML Manual de usuario

Hoover

Hoover FH50035 - SteamVac Carpet Cleaner Manual de usuario

Hoover

Hoover PUREPOWER PU71EN01 Manual de usuario

Hoover

Hoover FloorMate SpinScrub 800 Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
